1 Introduction
1.1 Validity of documentation
This operating manual explains the function and operation, describes the installation and
provides guidelines on how to connect the product.
This documentation is valid for the product PSS u2 ES 16DOD 0.5A hardware version 01 or
higher. It is valid until new documentation is published.
1.2 Using the documentation
This document is intended for instruction. Only install and commission the product if you
have read and understood this document. The document should be retained for future ref-
erence.
Please refer to the PSS u2 Installation Manual.
1.3 Definition of symbols
Information that is particularly important is identified as follows:
DANGER!
This warning must be heeded! It warns of a hazardous situation that poses
an immediate threat of serious injury and death and indicates preventive
measures that can be taken.
WARNING!
This warning must be heeded! It warns of a hazardous situation that could
lead to serious injury and death and indicates preventive measures that can
be taken.
CAUTION!
This refers to a hazard that can lead to a less serious or minor injury plus
material damage, and also provides information on preventive measures
that can be taken.
NOTICE
This describes a situation in which the product or devices could be dam-
aged and also provides information on preventive measures that can be
taken. It also highlights areas within the text that are of particular import-
ance.

Introduction
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 5
INFORMATION
This gives advice on applications and provides information on special fea-
tures.

Overview
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 6
2 Overview
Module structure:
A module consists of
}an electronic module,
}a terminal block with cage clamp terminals and
}a module carrier
The electronic modules are plugged into the backplane and determine the function. The
backplane is used for communication between the head module and the electronic modules
and forms the carrier unit for the electronic modules. The terminal block is plugged into the
electronic modules and is used to connect the field wiring.
Details of the terminal blocks that can be used are available under "Intended Use".
2.1 Module features
Application of the product PSS u2 ES 16DOD 0.5A:
Electronic module with digital outputs and expanded diagnostics for standard applications
The product has the following features:
}16 Digital outputs
– Semiconductor technology
– Single-pole
– Positive-switching
– Current load capacity per output: 0,5 A
– Short circuit-proof
– Overload-proof
}Energy-saving functions
}The module provides advanced diagnostic data:
– Overload
– Short circuit
– Undervoltage
}LEDs for:
– Switch status per output
– Module error
– Operating status

Safety
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 7
3 Safety
3.1 Intended use
The module provides digital standard outputs and may be used for standard applications in
the PSS u2 system.
Intended use includes making the electrical installation EMC-compliant. The module is de-
signed for use in an industrial environment. Interference may occur if used in other areas.
The following is deemed improper use in particular
}Any component, technical or electrical modification to the module,
}Use of the module outside the areas described in this manual,
}Any use of the module that is not in accordance with the technical details.
The module PSS u2 ES 16DOD 0.5A may be used in conjunction with the following ter-
minal block:
}16-pin terminal block
3.2 System requirements
INFORMATION
The module is supported by
}PASconfig from version 1.0.0
– We recommend that you always use the latest version (download
from www.pilz.com).

Safety
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 8
3.3 Safety regulations
3.3.1 Use of qualified personnel
The products may only be assembled, installed, programmed, commissioned, operated,
maintained and decommissioned by persons who are competent to do so.
A competent person is a qualified and knowledgeable person who, because of their train-
ing, experience and current professional activity, has the specialist knowledge required. To
be able to inspect, assess and operate devices, systems and machines, the person has to
be informed of the state of the art and the applicable national, European and international
laws, directives and standards.
It is the company’s responsibility only to employ personnel who
}Are familiar with the basic regulations concerning health and safety / accident prevention,
}Have read and understood the information provided in the section entitled Safety
}Have a good knowledge of the generic and specialist standards applicable to the specific
application.
3.3.2 Warranty and liability
All claims to warranty and liability will be rendered invalid if
}The product was used contrary to the purpose for which it is intended,
}Damage can be attributed to not having followed the guidelines in the manual,
}Operating personnel are not suitably qualified,
}Any type of modification has been made (e.g. exchanging components on the PCB
boards, soldering work etc.).
3.3.3 Disposal
}When decommissioning, please comply with local regulations regarding the disposal of
electronic devices (e.g. Electrical and Electronic Equipment Act).

Function description
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 9
4 Function description
4.1 Block diagram
Module
Supply
Data
(ST)
Periphery
Supply
+24 V DC
Module Bus
1
O0
2
O1
15
O14
16
O15
Fig.: Block diagram PSS u2 ES 16DOD
4.2 Supply
}The module is supplied with voltage via the head module.
4.3 Outputs
Signals at the output
}"0" signal (0V) at the output:
– Output is high impedance
– No current to the load
}"1" signal (+24V) at the output:
– Output is low impedance
– Current is supplied to the load
Outputs
}The head module sets the output status via the module bus.
If the module does not receive a process image of outputs from the head module, then sub-
stitute values are used for the process data. The value that is to be used as the substitute
value can be configured.
Substitute values may be:
}Output switched off (default value)
}Output switched on
}Last valid value

Function description
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 10
4.4 Reaction times
Detailed information on the reaction times is available in the operating manual of the head
modules.
4.5 Energy-saving functions
The energy-saving levels are controlled by the head module and are not configurable. The
module supports the following energy-saving levels:
}Switching off the LEDs
The LEDs have two energy-saving levels:
– Switching off the LEDs to display the terminal status
– Switching off the LEDs to display the module and terminal status
}Switching off the terminals
– The module switches off the voltage at the digital outputs.
}Standby mode
– All module functions are inactive.
– The LEDs for displaying the module and terminal status are switched off.

Address assignment
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 11
5 Address assignment
The module occupies 2 Bytes in the process image of outputs.
PIO Meaning State
Byte 0
Bit 0 Output data O0 0: "0" signal (0 V) at the output
1: "1" signal (+ 24 V) at the output
Bit 1 Output data O1
Bit 2 Output data O2
Bit 3 Output data O3
Bit 4 Output data O4
Bit 5 Output data O5
Bit 6 Output data O6
Bit 7 Output data O7
Byte 1
Bit 0 Output data O8 0: "0" signal (0 V) at the output
1: "1" signal (+ 24 V) at the output
Bit 1 Output data O9
Bit 2 Output data O10
Bit 3 Output data O11
Bit 4 Output data O12
Bit 5 Output data O13
Bit 6 Output data O14
Bit 7 Output data O15
The module occupies 2 Bytes in the process image of inputs:
PII Meaning State
Byte 0
Bit 0 Valid bit of output O0 0: Output error
1: The signal in the PIO corresponds to the
output signal
Bit 1 Valid bit of output O1
Bit 2 Valid bit of output O2
Bit 3 Valid bit of output O3
Bit 4 Valid bit of output O4
Bit 5 Valid bit of output O5
Bit 6 Valid bit of output O6
Bit 7 Valid bit of output O7
Byte 1

Address assignment
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 12
PII Meaning State
Bit 0 Valid bit of output O8 0: Output error
1: The signal in the PIO corresponds to the
output signal
Bit 1 Valid bit of output O9
Bit 2 Valid bit of output O10
Bit 3 Valid bit of output O11
Bit 4 Valid bit of output O12
Bit 5 Valid bit of output O13
Bit 6 Valid bit of output O14
Bit 7 Valid bit of output O15

Installation
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 13
6 Installation
6.1 General installation guidelines
NOTICE
Damage due to electrostatic discharge!
Electrostatic discharge can damage components. Ensure against discharge
before touching the product, e.g. by touching an earthed, conductive sur-
face or by wearing an earthed armband.
6.1.1 Dimensions
The dimensions include the backplane, electronic module and terminal block.
12,5
50,1
54.4
88,37
6
51,1 60
111,1
(95.3)
51,7
Fig.: Dimensions in mm, including backplane, electronic module and terminal block

Installation
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 14
6.2 Inserting and removing an electronic module
Please note:
}Backplane must be installed first.
}Electronic modules may only be plugged or unplugged if the terminal block has been re-
moved first.
}The mechanics of the electronic modules are designed for 20 plug in/out cycles.
}On electronic modules with outputs, the terminal block may only be inserted and removed
when the load is switched off. Unforeseeable error reactions may be triggered if modules
are inserted and removed under load.
6.2.1 Inserting an electronic module
1. Insert the electronic
module into the suspen-
sion lug on the back-
plane.

Installation
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 15
2. Swivel the electronic
module downwards until
you hear it click into
place.
3. Insert the terminal
block into the suspen-
sion lug on the module.
4. Swivel the terminal
block upwards until you
hear it click into place.

Installation
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 16
6.2.2 Removing an electronic module
1. Press the unlocking
mechanism on the ter-
minal block that is
shown by the arrow and
pull off the terminal
block forward.
2. Press the unlocking
mechanism that is
shown by the arrow and
pull off the electronic
module upwards.

Installation
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 17
6.2.3 Changing an electronic module during operation
An electronic module can be hot swapped.
Effects:
}Module bus communication between the other modules is not interrupted.
}The configuration data is retained.
}The module is detected automatically as soon as the module is re-inserted.
Procedure:
1. Removing an electronic module [ 16]
2. Inserting an electronic module [ 14]
A new electronic module can be inserted during operation.
Procedure:
}Inserting an electronic module [ 14]
Effects:
}Module bus communication between the other modules is not interrupted.
}To detect the new module the following steps can be necessary:
– Creating a new configuration or changing an existing configuration
– Download of the configuration to the head module
– Restart of the head module. After a restart, the system behaves as after a warm reset
using a reset pushbutton (see operating manual of the head module, chapter “Reset
pusbutton", section "Carrying out a warm reset (restart)").

Wiring
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 18
7 Wiring
7.1 General wiring guidelines
Please note:
}The actuators may be connected using unshielded cables.
}The outputs do not need suppression for inductive loads.
}Use copper wiring.
7.1.1 Connection mechanism for terminal blocks
Procedure:
}Use a flat head screwdriver.
}Strip the wire back 9 mm.
}Feed the stripped cable as far as it will go into the opening for the spring-loaded terminal.
}Check that the cable is firmly seated.
Please note:
}The minimum cable cross section for field connection terminals on the terminal blocks is
0.15mm2 (AWG26).
}The maximum cable cross section for field connection terminals on the terminal blocks is
1.5mm2 with ferrules (AWG14)
}Use copper wiring.

Wiring
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 19
7.2 Terminal configuration
Terminal configuration Connection example
PSS u2 ES 16DOD 0.5A
1: Output O0
2: Output O1
3: Output O2
4: Output O3
5: Output O4
6: Output O5
7: Output O6
8: Output O7
9: Output O8
10: Output O9
11: Output O10
12: Output O11
13: Output O12
14: Output O13
15: Output O14
16: Output O15
PSS u2 ES 16PT 0V
1: 0 V
2: 0 V
3: 0 V
4: 0 V
5: 0 V
6: 0 V
7: 0 V
8: 0 V
9: 0 V
10: 0 V
11: 0 V
12: 0 V
13: 0 V
14 0 V
15: 0 V
16: 0 V
1-channel actuator
Actuators supplied via the 0 V periphery
supply from the module PSS u ES 16PTD
0V
ES 16DOD ES 16PT 0V
O0
0V
16 16

Operation
Operating Manual PSS u2 ES 16DOD 0.5A
1003616-EN-03 | 20
8 Operation
The status of the module is displayed via a red and a green LED. The status of the termin-
als is displayed via a green LED. If there is a module error, the module status display will
light up red. The error will be signalled to the head module and will be entered in the head
module's diagnostic log.
8.1 Display elements and messages
[1]
[1]
Legend
[1] Module status display
[2] Terminal status display
The module can detect the following errors:
[1] Colour [1] [2] Colour [2] Meaning Further information
-- -- Module not ready for opera-
tion
Green -- Module ready for operation
Green Green Module in operation and there
is a "1"-signal at the output
Green -- Module in operation and there
is a "0"-signal at the output
Red ---- Configuration error
Module was inserted in the
wrong slot.
Red -- Internal errors See module's dia-
gnostic log
Red Green The module status display
and the terminal status display
on the relevant output flash
synchronously
Short circuit/overload/under-
voltage
See module's dia-
gnostic log
Red -- Temperature warning: Too
warm (1)
See module's dia-
gnostic log
