Pilz PSSu E F 2DOR 8 User manual

PSSu E F 2DOR 8(-T)(-R)
Operating Manual-21334-EN-13
}Decentralised system PSSuniversal I/O

Preface
This document is the original document.
All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made
for the user's internal purposes. Suggestions and comments for improving this documenta-
tion will be gratefully received.
Source code from third-party manufacturers or open source software has been used for
some components. The relevant licence information is available on the Internet on the Pilz
homepage.
Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS p®,
SafetyEYE®, SafetyNET p®, the spirit of safety® are registered and protected trademarks
of Pilz GmbH & Co. KG in some countries.
SD means Secure Digital

Contents
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 3
1 Introduction ............................................................................................................................5
1.1 Validity of documentation.......................................................................................................... 5
1.1.1 Retaining the documentation .................................................................................................... 5
1.1.2 Terminology: System environment A and B ............................................................................. 5
1.2 Definition of symbols................................................................................................................. 6
2 Overview .................................................................................................................................7
2.1 Module structure ....................................................................................................................... 7
2.2 Module features ........................................................................................................................ 7
2.3 Front view ................................................................................................................................. 8
3 Safety ...................................................................................................................................... 10
3.1 Intended use ............................................................................................................................. 10
3.2 Safety regulations ..................................................................................................................... 11
3.2.1 Use of qualified personnel ........................................................................................................ 11
3.2.2 Warranty and liability ................................................................................................................ 12
3.2.3 Disposal .................................................................................................................................... 12
4 Function description ............................................................................................................. 13
4.1 Block diagram ........................................................................................................................... 13
4.2 Module features ........................................................................................................................ 13
4.2.1 Functions .................................................................................................................................. 13
4.2.2 Integrated protection mechanisms............................................................................................ 15
4.2.3 Reaction times .......................................................................................................................... 15
4.3 Configuration ............................................................................................................................ 15
4.3.1 PSSu assignment in system environment A............................................................................. 15
4.3.1.1 Addresses in the process image............................................................................................... 16
4.3.2 PSSu assignment in system environment B............................................................................. 16
5 Installation ..............................................................................................................................17
5.1 General installation guidelines.................................................................................................. 17
5.1.1 Dimensions ............................................................................................................................... 17
5.2 Installing the base module ........................................................................................................ 18
5.3 Inserting and removing an electronic module ........................................................................... 19
5.3.1 Inserting an electronic module.................................................................................................. 20
5.3.2 Removing an electronic module ............................................................................................... 21
5.3.3 Changing an electronic module during operation ..................................................................... 21
6 Wiring ......................................................................................................................................22
6.1 General wiring guidelines ......................................................................................................... 22
6.1.1 Mechanical connection of the base modules............................................................................ 22
6.2 Terminal configuration .............................................................................................................. 24
6.3 Connecting the module............................................................................................................. 26
6.4 Function test during commissioning ......................................................................................... 27
7 Operation ................................................................................................................................28
7.1 Messages ................................................................................................................................. 28
7.2 Display elements ...................................................................................................................... 29

Contents
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 4
7.2.1 Display elements for module diagnostics ................................................................................. 29
7.2.2 Display elements for an output's FS enable ............................................................................. 29
7.2.3 Display elements for output status............................................................................................ 30
8 Technical details ....................................................................................................................31
8.1 Safety characteristic data ......................................................................................................... 35
8.2 Service life graphs .................................................................................................................... 36
9 Order reference ......................................................................................................................38
9.1 Product ..................................................................................................................................... 38
9.2 Accessories .............................................................................................................................. 38

Introduction
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 5
1 Introduction
1.1 Validity of documentation
This documentation is valid for the product types PSSu E F 2DOR 8, PSSu E F 2DOR 8-T
and PSSu E F 2DOR 8-R. It is valid until new documentation is published.
This operating manual explains the function and operation, describes the installation and
provides guidelines on how to connect the product.
1.1.1 Retaining the documentation
This documentation is intended for instruction and should be retained for future reference.
1.1.2 Terminology: System environment A and B
The PSSu system can be used in two different system environments. The module's applic-
ation area is described in the chapter "Intended Use" of the manual.
The distinction is made between
}PSSu in system environment A
}PSSu in system environment B
The distinction is based on the application area of the PSSu system.
PSSu in system environment A may be used in the
}Decentralised system PSSu I/O
}Not in the automation system PSS 4000
PSSu in system environment B may be used in the
}Automation system PSS 4000, e.g. with
– Decentralised system PSSu I/O with SafetyNET p
– Control system PSSu PLC
– Control system PSSu multi

Introduction
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 6
1.2 Definition of symbols
Information that is particularly important is identified as follows:
DANGER!
This warning must be heeded! It warns of a hazardous situation that poses
an immediate threat of serious injury and death and indicates preventive
measures that can be taken.
WARNING!
This warning must be heeded! It warns of a hazardous situation that could
lead to serious injury and death and indicates preventive measures that can
be taken.
CAUTION!
This refers to a hazard that can lead to a less serious or minor injury plus
material damage, and also provides information on preventive measures
that can be taken.
NOTICE
This describes a situation in which the product or devices could be dam-
aged and also provides information on preventive measures that can be
taken. It also highlights areas within the text that are of particular import-
ance.
INFORMATION
This gives advice on applications and provides information on special fea-
tures.

Overview
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 7
2 Overview
2.1 Module structure
A module consists of
}Electronic module and
}Base module with
– Screw terminals or
– Cage clamp terminals
The base modules are the carrier units for the electronic modules and are used to connect
the field wiring. The electronic modules are inserted on to the base modules and determine
the module's function.
Details of the base modules that can be used are available in the chapter entitled “Intended
Use”.
2.2 Module features
The product has the following features:
}Relay contacts
– N/O contact
– Volt-free
– Current load capacity per output: 8 A
}LEDs for:
– Switch status of each output
– Module error

Overview
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 8
}For failsafe applications in system environment A and B
}T-type:
PSSu E F 2DOR 8-T: for increased environmental requirements
}R-type:
PSSu E F 2DOR 8-R: for railway applications
2.3 Front view
2111
2212
2414
4131
4232
4434
Err
11
O0
21
12
O0
22
O0
13
C
23
C
14 24
PSSu E F
2DOR 8
31
O1
41
32
O1
42
O1
33
C
43
C
34 44
11
31
FS0
FS1
2313 4333
PSSu E F
2DOR 8
312225
000000
001
10
1
3
4
9
8
5
6
7
11
2
12
A
B
Legend:
}A: Electronic module
}B: Base module
}1: LEDs for
– Module diagnostics
– Displaying an output's FS enable (enable principle)
}2: Labelling strip with:
– Name of electronic module
– Order number
– Serial number

Overview
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 9
– Hardware version number
– 2D code
}3: Labelling strip for the terminal configuration on the base module
}4: Status LEDs
}5: Name of electronic module
}6: Connection level 1
}7: Connection level 2
}8: Connection level 3
}9: Connection level 4
}10: Square mounting holes (connection levels 1, 2, 3 and 4)
– With screw to loosen/tighten the screw terminal on base modules with screw termin-
als
– With mechanism to operate the cage clamp on base modules with cage clamp termin-
als
}11: Round connection holes (connection levels 1, 2, 3 and 4) for connecting the signal
lines
}12: Mounting slot for colour marker to label the connection level (connection levels 1, 2, 3
and 4)

Safety
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 10
3 Safety
3.1 Intended use
The module may be used for failsafe applications in system environment A and B (automa-
tion system PSS 4000).
The modules PSSu E F 2DOR 8 and PSSu E F 2DOR 8-T may be used as a safety com-
ponents in accordance with the Lifts Directive 95/16/EC in accordance with the require-
ments of EN81-1/2:1998+A3:2009, EN81-20:2015, EN81-50:2015, EN81-22:2014 and
EN115-1:2008+A1:2010.
The programmable safety system should be installed in a protected environment that meets
at least the requirements of pollution degree 2. Example: Protected inside space or control
cabinet with protection class IP54 and corresponding air conditioning.
The module meets the requirements of ENIEC61508 up to SIL 3.
It provides failsafe outputs in accordance with IEC 61131-2. The module may be used to
switch:
}Resistive loads
}Inductive loads
The module can be used in furnaces. If the module's relay outputs shut down the entire fuel
supply and the furnace is used in continuous operation, appropriate external measures
must be used to establish diversity of the shutdown elements (requirement of EN 50156-1).
For example, an appropriate measure may be an additional, monitored switching element
(contactor or relay), which is controlled by a safe semiconductor output and is switched in
series with both relay outputs.
The module PSSu E F 2DOR 8-T is suitable for use where there are increased environ-
mental requirements (see Technical Details).
The module PSSu E F 2DOR 8-R is suitable for use where there are increased environ-
mental requirements demanded by railway applications (see Technical details).
Intended use includes making the electrical installation EMC-compliant. Please refer to the
guidelines stated in the "PSSuniversal Installation Manual". The module is designed for use
in an industrial environment. It is not suitable for use in a domestic environment, as this can
lead to interference.
The following is deemed improper use in particular:
}Any component, technical or electrical modification to the module
}Use of the module outside the areas described in this manual
}Any use of the module that is not in accordance with the technical details.

Safety
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 11
INFORMATION
The module is supported by
}PSSuniversal Configurator and PSSuniversal Assistant from Version 1.4.0
}PAS4000 from Version 1.0.0
– We recommend that you always use the latest version (download
from www.pilz.com).
The PSSu E F 2DOR 8 module may be used in conjunction with the following base mod-
ules:
}PSSu BP 2/16 S
}PSSu BP 2/16 C
}PSSu BP-C 2/16 S
}PSSu BP-C 2/16 C
The PSSu E F 2DOR 8-T and PSSu E F 2DOR 8-R modules may be used in conjunction
with the following base modules:
}PSSu BP 2/16 S-T
}PSSu BP 2/16 C-T
}PSSu BP-C 2/16 S-T
}PSSu BP-C 2/16 C-T
3.2 Safety regulations
3.2.1 Use of qualified personnel
The products may only be assembled, installed, programmed, commissioned, operated,
maintained and decommissioned by competent persons.
A competent person is a qualified and knowledgeable person who, because of their train-
ing, experience and current professional activity, has the specialist knowledge required. To
be able to inspect, assess and operate devices, systems and machines, the person has to
be informed of the state of the art and the applicable national, European and international
laws, directives and standards.
It is the company’s responsibility only to employ personnel who
}Are familiar with the basic regulations concerning health and safety / accident prevention,
}Have read and understood the information provided in the section entitled Safety
}Have a good knowledge of the generic and specialist standards applicable to the specific
application.

Safety
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 12
3.2.2 Warranty and liability
All claims to warranty and liability will be rendered invalid if
}The product was used contrary to the purpose for which it is intended,
}Damage can be attributed to not having followed the guidelines in the manual,
}Operating personnel are not suitably qualified,
}Any type of modification has been made (e.g. exchanging components on the PCB
boards, soldering work etc.).
3.2.3 Disposal
}In safety-related applications, please comply with the mission time TM in the safety-related
characteristic data.
}When decommissioning, please comply with local regulations regarding the disposal of
electronic devices (e.g. Electrical and Electronic Equipment Act).

Function description
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 13
4 Function description
4.1 Block diagram
K0
K1
14 24
(C-Rail)
Module Bus
Periphery
Supply
+ 24 V DC
Module
Supply
+ 5 V DC
Data
(FS)
34 44 21 41
12 3222 42
11 31
13 23 33 43
4.2 Module features
4.2.1 Functions
Module supply
}The module supply provides the module with voltage.
Outputs

Function description
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 14
}The head module sets the output status via the module bus.
}The relationship between the load current and the operating temperature is illustrated in
the following derating diagram. The operating point should be below the characteristic
curve.
PSSu E F 2DOR 8: Derating diagram for the permitted ambient temperature T dependent
on load current I
20
40
60
80
100
0
1 2 3 4 5 6 7 8 9 10 I [A]
T[°C]
PSSu E F 2DOR 8(-T)(-R): Derating diagram for the permitted ambient temperature T de-
pendent on load current I
20
40
60
80
100
0
1 2 3 4 5 6 7 8 9 10 I [A]
T [°C]

Function description
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 15
4.2.2 Integrated protection mechanisms
When the PSSuEFPS1(-T) or PSSu E F PS2(-T)(-R) is used to supply the system, the
module supply is buffered for 20ms if the supply voltage is interrupted.
The module has the following protection mechanisms:
}1monitored relay contact per output
}Protective separation between both relay contacts (see Technical details)
}Protective separation between both relay contacts and the periphery supply as well as
the module supply, in accordance with DINVDE0110 overvoltage category 2 in a protec-
ted industrial network
}Temperature monitoring
The module provides the following diagnostic data:
}Start-up error
}Configuration error
}FS communication error
}Bus termination error
}Temperature error: Too warm
}Temperature error: Too hot
}Relay control error
}Relay error
4.2.3 Reaction times
Information on the reaction times of the outputs can be found in the PSSuniversal System
Description.
4.3 Configuration
4.3.1 PSSu assignment in system environment A
Functions for the FS outputs of a PSSu are defined in the PSSuniversal Configurator on the
PSSWIN-PRO system software:
}Read access through the standard bus system
(configured per module):
“R” configuration
}Read/write access through the standard bus system
(configured per FS output):
"&" configuration (local enable principle)
}Optimisation of ST process image by combining adjacent bits of the same type.
“*” configuration

Function description
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 16
INFORMATION
The PSSuniversal Configurator on the PSSWIN-PRO system software
must be used to define the I/O-Groups to which FS inputs and outputs be-
long (SafetyBUSp). The PSSu can be divided into sections A and B for this
purpose. All the FS outputs on a PSSu always belong to section A.
Section A and section B on a PSSu may belong to different I/O-Groups.
Further information on configuration is available in the PSSuniversal Configurator's online
help.
4.3.1.1 Addresses in the process image
The module occupies 2 consecutive bit addresses in the process image. The process im-
age in which the outputs are shown depends on the configuration.
With write access ("&"), the Bits in the ST-PIO are used to switch the FS outputs with the
local enable principle.
Configuration SafetyBUS p Standard bus system
FS-PIO ST-PII ST-PIO
None 2 Bit
(e. g.: 32.00 … 32.01)
- - - - - -
Read ST (“R”) 2 Bit - - -
ST read and write (“&”) 2 Bit 2 Bit
4.3.2 PSSu assignment in system environment B
Data access is via pre-defined I/O data types:
I/O data name I/O data type I/O data element Meaning
O0(11,21) FS_O_DO Data: SAFEBOOL Output data O0
O1(31,32) FS_O_DO Data: SAFEBOOL Output data O1

Installation
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 17
5 Installation
5.1 General installation guidelines
Please refer also to the PSSuniversal Installation Manual.
NOTICE
Damage due to electrostatic discharge!
Electrostatic discharge can damage components. Ensure against discharge
before touching the product, e.g. by touching an earthed, conductive sur-
face or by wearing an earthed armband.
5.1.1 Dimensions
25,2 mm
76 mm
52,1 mm8,1 mm
67,7 mm
25,2 mm
56,1 mm 71,8 mm 0,8 mm
128,9 mm
72,7 mm
(2.862")
(2.992")
(2.209") (2.827") (0.031")
5.075")
(0.992") (2.051")(0.319")
(0.992")
(2.665")

Installation
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 18
5.2 Installing the base module
Prerequisite:
}The head module must be installed.
}If the head module does not have an integrated power supply, a supply voltage module
must be installed to the right of the head module.
Please note:
}For mechanical reasons it is not possible to mix base modules with screw terminals and
base modules with cage clamp terminals.
}All contacts should be protected from contamination.
}The mechanics of the base modules are designed for 50 plug in/out cycles.
Procedure:
}We recommend that you wire up the base modules before inserting the electronic mod-
ules.
}Slot the groove on the base module on to the mounting rail from below [1].
}Push the base module back [2] until you hear it lock into position.
}On the mounting rail, slide the base module to the left until you hear the two lateral
mounting hooks on the adjacent module lock into position [3].
Schematic representation:
[2]
[1]
[3]

Installation
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 19
5.3 Inserting and removing an electronic module
Please note:
}Only insert on to base modules that are already installed.
}Preferably these base modules should be ready wired.
}Electronic modules with outputs may only be inserted and removed when the load is
switched off. Unforeseeable error reactions may be triggered if modules are inserted and
removed under load.
}When an electronic module is plugged into a base module for the first time, one part of
the coding element remains on the electronic module, while its counterpart is fixed on to
the base module. This is how the base module is coded.
}The mechanics of the electronic modules are designed for 50 plug in/out cycles.

Installation
Operating Manual PSSu E F 2DOR 8(-T)(-R)
21334-EN-13 | 20
5.3.1 Inserting an electronic module
Procedure:
}The electronic module must audibly lock into position [1].
}Mark the electronic module using the labelling strips [2].
Schematic representation:
[2]
[1]
[1]
