Pinnacle GOS196 User manual

ITEM NO: GOS196
Very Important: Unpack the unit and confirm that you have all the parts listed. Assemble the unit on
a solid, level surface. Avoid carpet. You will need the assistance of a second person during assembly.
Safety tip: For added safety and support we recommend you fix unit to a wall.
You will need the following: 2x Adjustable Spanner and rubber mallet.
Please note: When moving shelving unit lift using the uprights.
Benchtop
Capacity:
800kg
Shelf
Capacity:
800kg
HD PREMIUM WORKBENCH
915H x 1955W x 610Dmm
SAFETY TIP:
Parts List Step 1
Step 3Step 2
15mm Laminate Shelf x 1
9mm Laminate Shelf x 1
Uprights ‘A’
x 2
Beams ‘B’ x 4
Brackets ‘C’
x 4
Braces ‘D’
x 8
Bolts ‘E’
x 8
Bolts ‘F’
x 6
Rivets ‘G’
x 8
NOT TO SCALE
Separate legs of first Upright ‘A’, unfold the attached braces (as per the above diagram)
and fix the legs together using the provided Bolts ‘F’. Please note: washers should be
positioned on either side of each brace. Repeat above steps for second upright.
Attach Beams ‘B’ to each Upright ‘A’ using the bottom keyholes
and tap into place using a rubber mallet.
Repeat this step using two Beams ‘B’ for the top keyholes, tapping
them into place with a rubber mallet.
When assembling or installing this product
wear protective gloves and eyewear.
800 kg
BENCHTOP CAPACITY

Step 5
Step 6 Step 7
WARRANTY CONDITIONS: Any claim under this warranty must be made within 1 year of the date of purchase of the product. To make a claim under this warranty, take the product (with proof
of purchase) to any Bunnings store (for AUS customers see www.bunnings.com.au and for NZ customers see www.bunnings.co.nz for store locations). Pinnacle Hardware bears reasonable,
direct expenses of claiming under the warranty. You may submit details and proof of purchase to our support centre for consideration. The warranty covers manufacturer defects in materials,
workmanship and finish under normal use. This warranty is provided in addition to other rights and remedies you may have under law: Our goods come with guarantees that cannot be excluded
under the Australian consumer law or Consumer Guarantees Act 1993 (NZ). You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. This warranty excludes
damage resulting from product misuse or product neglect, any modifications, additions or alterations to the product including the addition of extra shelves. Additions or modifications can
compromise the structure and safety of the product. The warranty covers domestic use only and does not apply to commercial applications. This warranty is given by Pinnacle Hardware, ABN
87 614 496 196, 45-49 Whitfield Boulevard, Cranbourne West Vic 3977, 1800 349 776, Email: [email protected]. Products sold in New Zealand are imported by Bunnings New Zealand.
‘Pinnacle’ is a trademark © Pinnacle Hardware. Suitable for model number GOS196.
Step 4
Fasten Brackets ‘C’ to each Beam ‘B’ using the provided Bolts and
nuts ‘E’ as per the diagram.
Install the 15mm laminate shelf on the top and the 9mm laminate
shelf on the bottom.
Insert Rivets ‘G’ into holes at the ends of each Beam ‘B’ to secure
them to the Upright ‘A’.
Attach Braces ‘D’ to the top side of each Beam ‘B’ as shown above.
