Pioneer dvr-3100-s User manual
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2003
DVR-3100-S
RRV2843
DVD RECORDER
DVR-3100-S
THIS MANUAL IS APPLICABLETOTHE FOLLOWING MODEL(S) ANDTYPE(S).
Model Type Power Requirement Region No. Serial No.
Please confirm 3rd & 4th
alphabetical letters.
DVR-3100-S WY AC220-240V 2 &&TT######$$
DVR-3100-S WYXU AC220-240V 2 &&PG######$$
DVR-3100-S WVXU AC220-240V 2 &&PG######$$
÷When servicing this model, some service procedures may reset the settings that customer
set (*) to the factory default settings. Make sure to explain this to the customer.
(*) : Initial Setup (Clock Setting, Remote Control Set, Channel settings, Video Out settings,
Audio In settings, Audio Out settings, Language settings)
Refer to the chapter 12 of the Operating Instructions for more details.
For details, refer to "Important symbols for good services" .
T-ZZV OCT. 2003 printed in Japan
