PL Systems EXOCUTER EX6 User manual

Mounting Options
Wall
Desk
Suspended
(Chain not supplied)
Please read these instructions carefully and store in a safe
place for future reference.
EXOCUTOR™
As part of the P+L brand of insect control products, Exocutor™
is an effective and flexible commercial flykiller which utilises
highly effective UV tubes. Available in a white or stainless
steel finish, four sizes of unit are available which can be wall
mounted, ceiling suspended or desk mounted.
Contents of package
- 1 x Exocutor™flykiller
- 2 x Screws, wall plugs and suspension keyrings
- 1 x Mains cable
- 2 x High powered UV tubes
or
- 1 x High powered UV tube (Exocutor 6 Only)
WARNING - THIS APPLIANCE MUST BE EARTHED
INSECT CONTROL PRODUCTS
Exocutor™utilises high powered ultra violet tubes to attract
flying insects and zaps them on a triangular killing grid, before
collecting them in a deep removable catch tray.
WARNING
EXOCUTOR ™MUST ONLY BE USED IN AREAS WHICH ARE FREE
OF DUST AND ANY POSSIBLE EXPLOSIVE VAPOUR MIXTURE.
SHOULD YOU HAVE ANY QUERIES CONTACT YOUR LOCAL FIRE
AUTHORITY FOR ADVICE BEFORE INSTALLATION.
EXOCUTOR ™IS SUITABLE FOR INDOOR USE ONLY AND IS NOT
SUITABLE FOR USE IN BARNS, STABLES AND SIMILAR
LOCATIONS.
POSITIONING
Exocutor™should ideally be fixed around two meters above
the ground, preferably in the darkest place within the area to
be protected and is supplied with a two meter mains lead.
Do not position the unit close to windows, skylights or other
sources of light, or where it may be obscured by furniture,
doors or other obstacles. Ideally, Exocutor™units should be
visible from every part of the area to be protected.
INSTALLATION
PRIOR TO INSTALLATION, ENSURE THE POWER SUPPLY OF YOUR
MAINS OUTLET CORRESPONDS TO THAT MARKED ON THE
SPECIFICATION LABEL FOUND ON THE FLYKILLER.
Exocutor™should be mounted as shown in the mounting
options section of this document. Use the removable mains
lead and plug to connect the Exocutor™to a power supply of
appropriate rating, as specified on the specification label
found on the catch tray.
WARNING - THIS APPLIANCE MUST BE EARTHED
USING EXOCUTOR ™
Exocutor™should ideally be in operation for 24 hours a day,
ensuring your premises are kept free of flying insects. Insects
are most attracted to Exocutor™units at night when there is
no competition from daylight or other light sources.
CLEANING
ENSURE THAT THE FLYING INSECT KILLER IS DISCONNECTED
FROM THE MAINS BEFORE CLEANING
It is recommended that cleaning is carried out regularly every
month. During cleaning the unit should be thoroughly wiped
down with a damp cloth, removing any build up of dirt.
Ensure the unit is completely dry before reconnecting it to the
power supply.
GUARANTEE
Exocutor™has a two year guarantee and if maintained as
recommended in these instructions should continue to work
for many years.* Use of non-approved consumables may
invalidate the guarantee.
*Excludes tubes and starters. Does not cover breakdown due to misuse, incorrect operation
or use in an incorrect application.
MOUNTING FIXING CENTRES
METHOD EX6 EX16 EX30 EX40
Wall 210mm 288mm 438mm 603mm
Desk - - - -
Suspended 261mm 356mm 506mm 668mm
EX6, 16, 30 & 40
Commercial Zapper Insect Control

SPECIFICATION / REPLACEMENT PARTS
Unit EX6
Voltage 230V ~ 50Hz
Dimensions(mm) 270 x 140 x 260
Coverage 20 Sq. Meters
Weight 3.5 Kg
Light Output 6W
Tubes 1 x I617
Starter 1 x I154
Tray T001
Unit EX16
Voltage 230V ~ 50Hz
Dimensions(mm) 360 x 140 x 260
Coverage 40 Sq. Meters
Weight 4 Kg
Light Output 16W
Tubes 2 x I621
Starter 2 x I154
Tray (W / S/S) T003 / T004
Unit EX30
Voltage 230V ~ 50Hz
Dimensions(mm) 510 x 140 x 260
Coverage 80 Sq. Meters
Weight 6.5 Kg
Light Output 30W
Tubes 2 x I616
Starter 2 x I154
Tray (W / S/S) T005 / T006
Unit EX40
Voltage 230V ~ 50Hz
Dimensions(mm) 660 x 140 x 260
Coverage 120 Sq. Meters
Weight 8.5 Kg
Light Output 40W
Tubes 2 x I618
Starter 2 x I154
Tray (W / S/S) T007 / T008
C2009
P+L Systems Ltd
Information provided on these instructions is modified and
updated from time to time. This is due to the constant
redevelopment of our products. As such, it is not intended that
you should rely on it or that it should form part of any contract.
P+L Systems Ltd
Ten St James Business Park
Grimbald Crag Court
Knaresborough
HG5 8QB UK
T [phone]
F [phone]
W www.pandlsystems.com
E [email protected]
R2 02/09
TUBE REPLACEMENT
BEFORE REPLACING THE TUBES, ALWAYS ENSURE THAT THE UNIT IS DISCONNECTED
FROM THE MAINS SUPPLY.
To ensure the efficiency of Exocutor™in catching flying insects, the UV tubes should
be replaced annually. After twelve months the phosphor coating that emits the
correct wavelength of UV light has burnt away and the UV output is diminished
substantially.
To replace the UV tubes…
1. Rotate the tube through 90°, freeing it from the tube holders.
2. Pull the tube away from the chassis.
3. Dispose of the used UV tube in conjunction with local WEEE regulations.
STARTER REPLACEMENT
BEFORE REPLACING THE STARTERS, ALWAYS ENSURE THAT THE UNIT IS DISCONNECTED
FROM THE MAINS SUPPLY.
The starters provide an extra spark to initially light the UV tube. Starters wear out and
should be replaced at the same intervals as the UV tubes.
To replace the starters…
1. Rotate the starter anti-clockwise.
2. Pull the starter free from the unit.
TRAY REMOVAL
The tray is connected to the power supply of the unit via a hidden switch. By
removing the tray, the connection is broken and power is cut to the unit. This
ensures safe access to the unit for servicing and cleaning.
When replacing the tray ensure it is pushed fully into position and that the
connection is made to power the unit.
Tube ReplacementStarter Replacement
WEEE Compliance No. 01576542
