PL Systems Satalite 18 User manual

Please read these instructions carefully and store in a safe place
for future reference.
SATALITETM
As part of the Insect-O-Cutor®brand of insect control products,
SataliteTM a contemporary and highly effective decorative insect
control unit for use within front of house applications. SataliteTM
utilises highly effective UV tubes and is designed for use with a
high specification glupac®glueboard. Two sizes of unit are
available, SataliteTM 18 and SataliteTM 30, both of which can be
mounted either horizontally or vertically.
CONTENTS OF PACKAGE
- 1 x Satalite flykiller
- 1 x Glupac®pheromone impregnated glueboard
- 2 x Screws and wall plugs
- 1 x Mains cable (Type X)
- 1 x Compact 18W tube (fitted)
or
- 2 x 15W High powered insect attractive UV tubes (fitted)
WARNING - THIS APPLIANCE MUST BE EARTHED (CLASS 1)
INSECT CONTROL PRODUCTS
SataliteTM utilises high powered ultra violet tubes to attract flying
insects and retains the caught insects on a pheromone
impregnated glueboard for inspection or hygienic disposal.
WARNING
SataliteTM is not to be used by children or persons with reduced
physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or
instruction.
Children should be supervised to ensure they do not play with
the appliance.
If the mains cable is damaged it must be replaced by a
specialist mains cable available from P+L Systems Ltd or your
supplier.
Not suitable for applications where potentially explosive environ-
ments may exist.
POSITIONING AND GUIDANCE FOR USE
THIS UNIT IS FOR INDOOR USE ONLY.
SataliteTM should ideally be fixed around two meters above the
ground, preferably in the darkest place within the area to be
protected. Do not position the unit close to windows, skylights or
other sources of light, or where it may be obscured by furniture,
doors or other obstacles. Ideally, SataliteTM should be visible from
every part of the area to be protected.
SataliteTM should ideally be in operation for 24 hours a day,
ensuring your premises are kept free of flying insects. Insects are
most attracted to SataliteTM units at night when there is no
competition from daylight or other light sources.
GUARANTEE
SataliteTM has a two year guarantee and if maintained as
recommended in these instructions should continue to work for
many years.* Use of non-approved consumables may invalidate
the guarantee. Ensure genuine glupac®glueboards are used in
conjunction with this product.
*Excludes tube(s), glueboard and starter(s). Does not cover breakdown due to misuse,
incorrect operation or use in an incorrect application.
Satalite 18 & 30
Front Guard Removal
Decorative Glueboard Insect Control
INSTALLATION
INSTALLATION SHOULD BE CARRIED OUT BY SERVICE PERSONNEL
ONLY.
To ensure SataliteTM reaches you in perfect condition, a protective
film covers the aluminium backplate. Remove this film before
use.
SataliteTM should be mounted as shown in the mounting options
section of this document. Once installed in position, fit the
glupac®glueboard in position as described in the glueboard
replacement section of this document. Use the removable mains
lead and plug to connect the SataliteTM to an appropriate power
supply.
CLEANING
CLEANING SHOULD BE CARRIED OUT BY SERVICE PERSONNEL
ONLY, AFTER ENSURING THAT THE UNIT IS DISCONNECTED FROM
THE MAINS SUPPLY.
It is recommended that cleaning is carried out regularly when
the glueboard is replaced. Once the glueboard is removed, the
unit should be thoroughly wiped down with a damp cloth,
removing any build up of dirt. Ensure the unit is completely dry
before reconnecting it to the power supply.
MOUNTING FIXING CENTRES
METHOD 18 30
Wall 180mm 426mm
WALL MOUNTING OPTIONS
Horizontal Vertical
2.
1.

30W Tube Replacement
SPECIFICATION / REPLACEMENT PARTS
Unit Satalite 18 Unit Satalite 30
Voltage 230V ~ 50Hz Voltage 230V ~ 50Hz
Dimensions(mm) 312 x 300 x 134 Dimensions(mm) 312 x 540 x 170
Coverage 30 Sq. Meters Coverage 60 Sq. Meters
Weight 1.3 Kg Weight 2.0 Kg
Light Output 18W Light Output 30W
Tube 1 x TPX18 Tubes 2 x TPX15-18
Starter 1 x I154 Starters 2 x I154
Glueboards (x6) INL147 (White) Glueboards (x6) INL161 (White)
GLUEBOARD REPLACEMENT
GLUEBOARD REPLACEMENT SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY, AFTER
ENSURING THAT THE UNIT IS DISCONNECTED FROM THE MAINS SUPPLY.
The glueboard should be replaced every month with a genuine glupac®glueboard. Use of
non-approved glueboards may invalidate your guarantee.
To replace the glueboard…
1. Remove the used glupac®glueboard by simply sliding it out of the top of
the front reflector and either retain for insect evaluation or dispose of it hygienically.
2. Remove the protective release paper from the new glupac®glueboard.
3. Slowly slide the new glueboard into position along the two runners with
the adhesive side facing the tube(s).
Always ensure the selected genuine glupac®glueboards are compatible with your unit, available
from your pest control operator or P+L Systems Ltd.
TUBE REPLACEMENT
TUBE REPLACEMENT SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY, AFTER ENSURING THAT
THE UNIT IS DISCONNECTED FROM THE MAINS SUPPLY.
To ensure the efficiency of SataliteTM in catching flying insects, the UV tube(s) should be replaced
annually. After twelve months the phosphor coating that emits the correct wavelength of UV light
has burnt away and the UV output is diminished substantially.
To replace the UV tube(s) first remove the front guard as shown in the diagrams on the previous
page. Then remove the tube(s) by...
SataliteTM 18 1. Pull the tube gently from the tube holder until it un-clips.
2. Gently rotate the tube until it becomes free from the tube support.
3. Dispose of the used UV tube in conjunction with local WEEE regulations.
SataliteTM 30 1. Rotate the tube through 90 degrees.
2. Gently pull the tube away from the unit.
3. Dispose of the used UV tubes in conjunction with local WEEE regulations.
STARTER REPLACEMENT
STARTER REPLACEMENT SHOULD BE CARRIED OUT BY SERVICE PERSONNEL ONLY, AFTER ENSURING
THAT THE UNIT IS DISCONNECTED FROM THE MAINS SUPPLY.
The starter(s) provide(s) an extra spark to initially light the UV tube(s). Starters wear out and should
be replaced at the same intervals as the UV tube(s).
To replace the starter(s)…
1. Rotate the starter anti-clockwise.
2. Pull the starter free from the unit.
18W Tube Replacement Glueboard Replacement
Starter Replacement
R4 04/14
C2014
P+L Systems Ltd
Information provided on these instructions is modified and
updated from time to time. This is due to the constant
redevelopment of our products. As such, it is not intended that
you should rely on it or that it should form part of any contract.
Sterling House
Grimbald Crag Close
Knaresborough
North Yorkshire
HG5 8PJ UK
T [phone]
F [phone]
W www.pandlsystems.com
E [email protected]
WEEE Compliance No. WEE/GF0661QR
