Planet VIP-110 User manual

InternetTelephony Gateway
User s manual
VIP-110/VIP-210
release1.0
February 10, 2004

PLANET VIP-110/VIP-210 Web Configuration Guide
-2 -
Copyright
Copyright (C) 2004 PLANET TechnologyCorp. All rights reserved.
The products and programs described in this User sManual are licensed products of PLANET Technology,
This User s Manual contains proprietary information protected by copyright, and this User s Manualand all
accompanying hardware, software, and documentation arecopyrighted.
No part of this User s Manual maybe copied, photocopied, reproduced, translated, or reduced to any elec-
tronic medium or machine-readable form byanymeans byelectronic or mechanical. Including photocopying,
recording, or information storage and retrievalsystems, for anypurpose other than the purchaser's personal
use, and without the prior express written permission of PLANETTechnology.
Disclaimer
PLANET Technologydoes not warrant that the hardware willwork properlyin allenvironments and applica-
tions, and makes no warrantyand representation, either implied or expressed, with respect to the quality,
performance, merchantability, or fitness for a particular purpose.
PLANET has made everyeffort to ensure that this User s Manualis accurate; PLANET disclaims liabilityfor
any inaccuracies or omissions that mayhave occurred.
Information in this User sManual is subject to change without notice and does not represent a commitment
on the part of PLANET.PLANET assumes no responsibility for anyinaccuracies that maybecontainedin this
User sManual. PLANET makes no commitment to update or keep current the information in this User s
Manual,and reserves the right to make improvementsto this User sManual and/or to the products described
in this User s Manual, at anytime without notice.
Ifyou find information in this manual that is incorrect, misleading, or incomplete, we would appreciateyour
comments and suggestions.
CEmark Warning
The is a class B device, In a domestic environment, this product maycause radio interference, in which case
the user maybe required to take adequate measures.
Trademarks
The PLANETlogo is a trademark of PLANET Technology.This documentation mayreferto numerous hard-
ware and software products bytheir trade names. In most, ifnot all cases, these designations areclaimed as
trademarks or registered trademarks bytheir respective companies.
Revision
User sManual for PLANET InternetTelephonyGateway
Model: VIP-110/VIP-210
Rev: 1.0 (FEB. 2004)
Part No. EM-VIP210V1

PLANET VIP-110/VIP-210 Web Configuration Guide
-3 -
Table of Contents
VIP-110/VIP-210 Features................................................................................5
Package Content.............................................................................................6
Physical Details...............................................................................................6
LED Display &Button................................................................................7
PhysicalInterfaces....................................................................................7
Reset Button............................................................................................8
PhysicalInstallation Requirement................................................................9
Procedure................................................................................................9
LAN/WANInterface quick configurations.....................................................12
LAN IP configuration via command line interface (CLI)..................................12
Preparation before beginningweb administrationon VIP-110/VIP-210..................14
CheckingTCP/IP settings on Windows 95/98...............................................14
CheckingTCP/IP settings on Windows NT....................................................16
CheckingTCP/IP Settings - Windows 2000:.................................................20
CheckingTCP/IP Settings - Windows XP......................................................22
LAN IP addressconfiguration via web configurationinterface.........................24
WAN IP address configurationvia web configurationinterface........................25
Internet Access Setup..............................................................................26
Overview on theweb interface of VIP-110/VIP-210.............................................28
Manipulationof VIP-110/VIP-210via web browser.......................................29
Internet Access Setup..............................................................................30
DialPlan Management.....................................................................................36
Dialplan Concept.....................................................................................36
H.323 Configurations......................................................................................43
Tools Menu..............................................................................................48
Advanced Configuration menu...................................................................49
HelpMenu..............................................................................................50
ConfigurationSamples..............................................................................51
VIP to VIP...............................................................................................51

PLANET VIP-110/VIP-210 Web Configuration Guide
-4 -
Overview
In the past, real-time voice communication can only be performedon the
PSTN. With the growth of Internet technology, Internet telephony service
plays and turns into acost-effective and highly reliable substitution
system of the old-time traditional PBX system. PLANET VoIP (Voice over
IP) system VIP-110/VIP-210 offers toll quality voice and real-time
fax data over IP networks. With optimized H323 architecture, PLANET VIP
series are ideal solution for various VoIP applications such as
Headquarter and Branch Office communication, and IDD cost-effective
solution. With its intuitive user-friendly interface, PLANET VIP series
may be installed easily conveniently, and dramatically down cost the
huge amount of IDD fee.
With embedded, efficient Real-Time Operating System, VIP-110/VIP-210
provides efficiency and feature enhancement capabilities; being
programmed with updated firmware users may have the most flexibility
and functionality to meet different kind of application requirement.
It comes equipped with remote management capabilities, configurable
signaling to work with PBX, KTS, and/or telephone. Building on
state-of-the-art advanced VoIP related technology. PLANET
VIP-110/VIP-210 offers various features: echo cancellation, Voice
Activity Detection (VAD), Comfort Noise Generation (CNG), lost packet
recovery algorithms and optimized voice and FAX coders to bring users
superior voice quality, and best compatibility with major Internet
telephony service providers.
More than these, PLANET VIP-110/VIP-210, not only provides quality voice
communications and real-time fax over IP networks, but also offers
Internet sharing capabilities with otherLAN users. Withan optimized
H.323 and routing architecture, the PLANETVIP-110/VIP-210 is the ideal
choice for Voice over IP communications and providing integrated Internet
sharing features, such as Virtual server, policy based firewall
protection, QoS and DMZ support; with thesefeatures, users may now enjoy
high quality voice calls and secure Internet access without interfering
with routine activities.
Introduction

PLANET VIP-110/VIP-210 Web Configuration Guide
-5 -
VIP-110/VIP-210Features
o Standards compliant&excellent voice quality
The PLANETVIP-110/VIP-210is H.323standard version3 compliant (includingH.323
fast-start mode). The VIP-110/VIP-210 is interoperablewith3rdpartyvoice gatewaysaswell
as otherPLANET VoIPproducts. Retainingthetradition of excellencein PLANET VoIP
products, the VIP-110/VIP-210canprioritize voicepackets using IPprecedence, andcom-
bines state-of-the-art technologyof voice packet handling, including echo, noise reduction,
voice reconstruction andredundancyto provide customers tollqualityVoIPcommunication.
o VoIP,FoIPandNetwork conversion
Viaconfigurablevoice codec: G.723, G.729ab, G.711mu andFAX:T.30, T.38, the
VIP-110/VIP-210 provides supportfor multiplealgorithms to meet different VoIPapplication
demands.The VIP-110/VIP-210 supports conversion of telephonyprotocols(SS7, Analog
(FXS/FXO))intoa packet switching network betweencallingand called voice gateways or a
PBX system,inaheterogeneous signal-switching environment.
o Domainname call &DDNSsupports
EitherIPor URLaddressing, theVIP-110/VIP-210is ableto locate and communicate with
destination H.323 gateways and terminals. The DDNSserviceis supported for those VoIP
gateways deployedin a dynamicIPenvironment. The combination ofconnection agents
(PPPoE,or DHCPclients)anda built-inDDNS clientcan help those who do not have static
IPaddresses bymappingdynamic IPaddresses toaneasy-to-rememberURL, allowing
other 3rdpartyvoice gateways and terminalsto locatethepositionof the VIPina simple
manner.(Toestablishvoice communication viadomain name,please make sure the other
partygateway/terminalsupports domain name calling.)
o Internet sharing, easysetup andnetwork administration
ViainternalPPPoE/DHCP/fixedIPallocation agents, the VIP-110/VIP-210 establishes
Internetaccess viaa singleuser account and shares Internet resource witheveryoneon your
office network. Viaanintuitive userinterface,network administrationorITpersonnel can
completean Internet connection injust minutes! System administrators canlogon to the
machine locallyfrom theLANor remotelycheck machineornetwork status andperform
administration ortrouble-shootingfrom anywhere in the world.
o NAT Optimization, Firewall policypacket filtering andQoSmechanism
The VIP-110/VIP-210providesuser definable policy-based firewallprotection, and a packet
filteringmechanism to preventbusiness or residential network from malicious attacks orin-

PLANET VIP-110/VIP-210 Web Configuration Guide
-6 -
trusion. The firewallpolicyoffers VoIPadministrators access controlprivilege choices to ap-
plyto LAN users torestrict Internet access or prevent improperuse.
o Virtual Server,DMZ & Internet application capability
WithVirtualserver, specialapplications, and DMZfeatures, theVIP-110/VIP-210shares the
LAN resources for Internet users, andprovidesvarious Internet application compatibilityin a
moreconvenient way.
Package Content
Thecontents of your product should contain the following items:
VIP-110orVIP-210 unit
Power adapter
Quick InstallationGuide
User s Manual CD
Physical Details
The front panel of VIP-110/VIP-210contains apushbutton and 5/6LED indicators. The following
figure illustrates thefront/rear panel of VIP-110/VIP-210.
VIP-110 Front Panel
VIP-110 Rear Panel

PLANET VIP-110/VIP-210 Web Configuration Guide
-7 -
VIP-210 Front Panel
VIP-210 Rear Panel
LEDDisplay &Button
Indicator Color Activity Indication
PWR GreenOn Power is supplied to the gateway.
CPU GreenBlinking The system is running. (Heartbeat LED)
LAN
Ÿ ACT
Ÿ LNK
Green
Green
On
On
Data is presented on LAN.
The gatewayis connected to LAN.
WAN
Ÿ ACT
Ÿ LNK
Green
Green
On
On
Data is presented on WAN.
The gatewayis connected to WAN.
PHONE/LINE
Voice Channels
GreenOff
On
Blinking
The line isidle.
The line isbeingused.
The line isringing.
Physical Interfaces
VIP-110/VIP-210 isequippedwith aWAN interface with 10/100Mbps auto-negotiation capability,1
LAN Ethernet ports with10/100 Mbps auto-negotiationcapability. Inaddition to the LAN/WAN
Ethernet interface ports, One (VIP-110) / two (VIP-210) RJ-11telephony interfaceports on the rear
panel.Their functions are describedbelow:

PLANET VIP-110/VIP-210 Web Configuration Guide
-8 -
Reset Button
There is apushbuttonlocated behind asmall holenext tothe PWRLED. Thisbuttonallows you
to reset VIPor force VIPtoenterfirmware upgrade mode.
Reset
Push a small,stiff object into theholeuntil the SYSTEM LED stopsblinking,then release the
button.
Port Label Function
RJ-45LAN
ConnectingVIPtoa10/100Mbps Ethernet
network
RJ-45WAN
ConnectingVIPtoa10/100Mbps Ethernet
network /xDSL/CablemodemforInternet
access
RJ-11Telephony
ConnectPBX Extension line/TelephonetoVIP
forvoice communication

PLANET VIP-110/VIP-210 Web Configuration Guide
-9 -
Physical Installation and IP Configuration
This chapter illustrates basic installation of VIP-110/VIP-210
Physical Installation Requirement
• Network cables. Usestandard 10/100BaseT network (UTP)cables with RJ45 connectors.
• TCP/IP protocol must be installed on all PCs.
For Internet Access, an InternetAccess account with an ISP,and either of aDSLor Cable modem
(forWAN portusage)
Procedure
1. ChooseanInstallationSite
Selectasuitable place on the networktoinstall VIP–110/VIP-210.
Ensure VIP–110/VIP-210 and the DSL/Cable modem are powered OFF.
2. Connect LANCables
• Use standard LAN cables to connectPCs to the Switching Hub ports onVIP–110/VIP-210.
Both 10BaseT and 100BaseT connections can beused simultaneously.
• If required, you can connect anyLAN portto anotherHub.AnyLAN port on
VIP–110/VIP-210will automaticallyfunction as an "Uplink" port when required. Just
connectanyLANport toa normalporton the other hub, usinga standardLANcable.
3. Connect WAN Cable
Connect theDSLorCablemodemto theWANport on VIP–110/VIP-210. Use thecable
suppliedwithyourDSL/Cablemodem.If no cable was supplied,usea standardcable.
4.Power Up
• Power onthe CableorDSLmodem.
• Connect the supplied poweradapter toVIP–110/VIP-210 andpower up.
Use onlythe power adapter provided. Using a different one maycause hardware damage

PLANET VIP-110/VIP-210 Web Configuration Guide
-10 -
5. Checkthe LEDs
• The PWR LED should be ON.
• The CPU LED should flash.
• For each LAN (PC)connection, theLAN LNK/ACT LED shouldbe ON(providedthe PC is
alsoON.)
• The WAN LED should be ON.
6. Connecting to the telephonydevices
VIP-110/VIP-210 supports one types telephonytheFXS(ForeigneXchange Station).FXS
interface is used to connect to regular analog telephone sets or FAX machine
Administration Interface
PLANET VIP-110/VIP-210 provides CLI(CommandLineInterface), andGUI (Web based,
GraphicalUser Interface)formachine management and administration.
Web configuration access:
TostartVIP-110/VIP-210 webconfiguration, you must have oneof these webbrowsersinstalled
oncomputer formanagement
• Netscape Communicator4.03 or higher
• Microsoft Internet Explorer 4.01 or higherwith Java support
DefaultLAN interface IPaddress of VIP-110/VIP-210 is 192.168.0.1. Youmaynow openyour web
browser,and insert 192.168.0.1 in theaddress bar of your web browserto logon VIP-110/VIP-210
web configurationpage.
VIP-110/VIP-210will prompt forlogon username/password, pleaseenter: admin / 123 to continue
machineadministration.
Connection of incorrect telephony devices to the ports on
the TIM can cause permanent damage to the TIM and/or VIP.
ë
Note

PLANET VIP-110/VIP-210 Web Configuration Guide
-11 -
CLIconfiguration access:
• Youcan connect theVIP-110/VIP-210 viatelnet terminal program
• Start upyour terminal program, here, weuse HyperTerminal as theexample.
• Setup the parameters as below forTelnet connection
HostAddress: 192.168.0.1
Port Number:23
ConnectUsing: TCP/IP(WinSock)
• When connected, you llbeasked toinsert theusername/password formachine admini-
stration, pleaseenter “admin/123”for authentication. Afterloggingin, the terminalwill
prompt “ITG>”toindicate yourmachine is now readyfor operation.
ë
Note
Please locate your PC in the same network segment
(192.168.0.x) of VIP-110/VIP-
210. If you’re not familiar
with TCP/IP, please refer to related chapter on user’s
manual CD or consult your network administrator for proper
network configurations.

PLANET VIP-110/VIP-210 Web Configuration Guide
-12 -
If you
cannot get anyresponse from the terminal program
after strike “Enter
”key several times. Please check the
TCP/IP configurations of your computer, i.e. the des-
tination VIP should be reachable
by your PC. Then check the
parameters above again. If all the n
etwork parameters are
correctly configured, it is recommended to check if the
network cabling is secure.
ITG>net set lan
net set lan ip <addr>
net set lan mask <mask>
ITG>
LAN/WAN Interface quick configurations
Nature of PLANETVIP-110/VIP-210is an IPSharing (NAT)device, itcomes withtwodefault IP
addresses,and default LAN side IPaddressis “192.168.0.1”, default WAN side IPaddress is
“172.16.0.1”. You mayuse anyPC toconnect to the LAN portof VIP-110/VIP-210 tostartmachine
administration.,
LAN IP configuration via command lineinterface (CLI)
Here we d like toconfigure the IPaddress of VIP-110/VIP-210 LAN interface, LAN IPaddress
related commands are:
• The command “net setlan ip”isused toset the IPaddress ofVIP. If you wouldliketoset
up the IPaddress to “192.168.0.1”, for example. You can havethe commandas belowand
press the<Enter>key:
ë
Note
ITG>net set lan ip192.168.0.1<enter>
In general cases, the LAN IP address is the default gateway
of LAN side workstations for Internet access, and the WAN
IP of VIP-110/VIP-210is
the IP address forremote calling
party to connect with.
i
Hint

PLANET VIP-110/VIP-210 Web Configuration Guide
-13 -
• The command “netsetlan mask”is used toset thenetwork mask of VIP. If you would like
toset up the network mask to “255.255.255.0”,forexample. Youcan have the command
as below andpress the<Enter> key:
Youll need tosave theconfiguredLAN IPaddress, network mask valueinto machinevia
command: net store , then insert command: net reset to rebootmachine and makethechanges
effective.
ITG>net set lan mask 255.255.255.0

PLANET VIP-110/VIP-210 Web Configuration Guide
-14 -
Preparation before beginning web administration on
VIP-110/VIP-210
In this section,we ll introduce steps of how to setupaPC to communicatewith VIP-110/VIP-210
and Internet access related parameters through TCP/IPprotocol configuration.
Before startingwebbrowsertoconnect to VIP-110/VIP-210, please check TCP/IPconfigurations
on PC: thePCmust be configuredeither as a DHCPclient and or fixed IPallocationon the intranet
orInternet. Afterensuring TCP/IPconfigurationonthemanagingworkstation,youmayconnect to
web administrationpage of VIP-110/VIP-210 either from intranet,or Internet
Followingare guidelines of settingup TCP/IPconfigurations on different OSplatform
Checking TCP/IPsettings on Windows 95/98
If there is noTCP/IPinstalled on your Windows 95orWindows 98, you mustaddthe protocoland
changethe settings onyourPC.
Step1Open the ControlPanel, and double-click the Network icon. The Network windowappears
Step 2 If TCP/IPprotocol shown inthe network window,please continue to thenextstep. If it
is not shown,please addTCP/IPprotocolsupport as follows:
a. Click Add.
b. Double-click Protocol in the Select Network ComponentType window, then
the SelectNetwork Protocol window appears.
c. Choose Microsoft for the manufacturer.
d. Choose TCP/IP for the network protocol.

PLANET VIP-110/VIP-210 Web Configuration Guide
-15 -
e. Click OK,and the Network window appears.
Step 3.1
Change the TCP/IPsettings to useDHCPas follows (DHCP environment):
a.Double-click thefirst TCP/IPcable icon. The TCP/IP Propertieswindowappears.
b.Verifythat the IPAddress tabhas Obtain an IPaddress automaticallyselected
and that theIP Address andSubnetMask fields are grayed out.
Step 3.2 ChangetheTCP/IPsettings to useDHCPas follows (Fixed IPallocation):
If there is noDHCPserverin your network, please consultyour network administrator
the TCP/IPparameters ofyour PC, and insert the obtained data inIPaddress tab.To
access different IPsegment(forexample, from LAN toInternet), you will needtoas-
sign the gatewayand DNS(forInternet access)in yourPC.
Step 5 Addthe DNSservergiven to you byyour ISP or network administrator:
a.Click the DNSConfiguration tab.
b.Click Enable DNS.
c. Enter your host name inthe Host field.

PLANET VIP-110/VIP-210 Web Configuration Guide
-16 -
d.Enter yourdomain name inthe Domain field.
e.Enter the IPaddress of theDNSserverin the DNS Server Search Order field.
f. Click Add. TheIP address displaysin thewindowbelow the field.
Step 5 Click OK, andreboot machineto make themodifications effective inyourPC.
Checking TCP/IPsettings on Windows NT
ObtainanIPaddress from aDHCPServer
Select ControlPanel - Network, and, on the Protocols tab, select the TCP/IPprotocol, asshown
below.

PLANET VIP-110/VIP-210 Web Configuration Guide
-17 -
Windows NT4.0 - TCP/IP
a) Click the Properties button to see a screen like the one below.
Windows NT4.0 - IP Address

PLANET VIP-110/VIP-210 Web Configuration Guide
-18 -
b) Select the network card for your LAN.
c) Select the appropriate radio button - Obtain an IP address froma DHCP Server or Specify an IP
Address, as explained.
Specifyan IP Address
If yourPC is alreadyconfigured with an IPaddress, check with your network administratorbefore
making the following changes.
a)The Default Gateway must beset tomatchyournetworkenvironment.Toset this:
• Click the Advanced button on the screen above.
• On the following screen, click the Add buttonin the Gateways panel, and entergatewayIP
address, asshownbelow.
• If necessary, use the Up button to make the inserted on the first entryin the Gateways list.
Windows NT4.0 - Add Gateway
b)The DNSshouldbe set totheaddress provided byyourISP, as follows:
• Click the DNS tab.
• On theDNS screen,shown below, click the Add button (under DNSServiceSearch Order),
and enter the DNSprovided byyour ISP.

PLANET VIP-110/VIP-210 Web Configuration Guide
-19 -
Windows NT4.0 - DNS

PLANET VIP-110/VIP-210 Web Configuration Guide
-20 -
Checking TCP/IPSettings - Windows 2000:
Select ControlPanel -Network and Dial-up Connection.
a) Right-click the Local Area Connection iconand select Properties.You should see a
screen like thefollowing:
Network Configuration (Win 2000)
b)Select the TCP/IP protocolforyour network card.
c) Click on the Properties button. You should then see a screenlikethe following.
