Planet ICA-100 User manual

Internet Camera
ICA-100/ICA-100W
User s Manual

ii
Copyright
Copyright (C) 2003 PLANET Technology Corp. All rights reserved.
The products and programs described in this User s Manual are licensed products of PLANET
Technology, This User s Manual contains proprietary information protected by copyright, and
this User s Manual and all accompanying hardware, software, and documentation are copy-
righted.
No part of this User s Manual may be copied, photocopied, reproduced, translated, or reduced
to any electronic medium or machine-readable form by any means by electronic or mechanical.
Including photocopying, recording, or information storage and retrieval systems, for any pur-
pose other than the purchaser's personal use, and without the prior express written permission
of PLANET Technology.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments
and applications, and makes no warranty and representation, either implied or expressed, with
respect to the quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User s Manual is accurate; PLANET dis-
claims liability for any inaccuracies or omissions that may have occurred.
Information in this User s Manual is subject to change without notice and does not represent a
commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies
that may be contained in this User s Manual. PLANET makes no commitment to update or keep
current the information in this User s Manual, and reserves the right to make improvements to
this User s Manual and/or to the products described in this User s Manual, at any time without
notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would
appreciate your comments and suggestions.
CE mark Warning
The is a class B device, In a domestic environment, this product may cause radio interference,
in which case the user may be required to take adequate measures.
Trademarks
The PLANET logo is a trademark of PLANET Technology. This documentation may refer to
numerous hardware and software products by their trade names. In most, if not all cases, these
designations are claimed as trademarks or registered trademarks by their respective compa-
nies.
Revision
User s Manual for PLANET Internet Camera:
Model: ICA-100/ICA-100W
Rev: 2.0 (July 2003)
Part No. EM-ICA100v2

i
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION......................................................................................1
ICA-100/ICA-100W Features.................................................................................1
Package Contents.................................................................................................2
Physical Details.....................................................................................................2
CHAPTER 2 INSTALLATION........................................................................................6
Requirements........................................................................................................6
Connecting ICA-100 series to the Camera Stand...............................................6
Hardware Install Procedure..................................................................................7
CHAPTER 3 CONFIGURATION....................................................................................8
Login.......................................................................................................................8
Home Page.............................................................................................................8
System Administration.........................................................................................9
ViewImage- ActiveX Mode.................................................................................24
ViewImage- Java Mode......................................................................................25
CHAPTER 4 IPVIEW INSTALLATION........................................................................26
Install Procedure.................................................................................................26
Launch IPView.....................................................................................................30
CHAPTER 5 USE OF IPVIEW.....................................................................................33
Overview..............................................................................................................33
Security................................................................................................................33
Menu Bar..............................................................................................................34
Add Camera.........................................................................................................36
Delete Camera.....................................................................................................39
ViewImages.........................................................................................................39
Snap Shot.............................................................................................................40
Record Images.....................................................................................................40
Property................................................................................................................40
IPViewIcon Description.....................................................................................56
Context Sensitive Meun......................................................................................57
APPENDIX AFREQUENTLY ASKED QUESTIONS...................................................59
APPENDIX B TROUBLE SHOOTING.........................................................................61
APPENDIX C I/O CONNECTORS...............................................................................63
APPENDIX D ADJUSTFOCUS/ REPLACE LENS.....................................................65
Adjust Internet Camera Focus...........................................................................65
Replace the Lens.................................................................................................66
APPENDIX E INSTALL XPLUG CONTROL UTILITY.................................................67
Install on Web Server..........................................................................................67
Install to Local PC...............................................................................................67
APPENDIX F SPECIFICATION...................................................................................71
APPENDIX G GLOSSARY OF TERMS.......................................................................73

1
Chapter 1
Introduction
This Chapter provides an overview of Internet Camera 's features and
capabilities.
Internet Camera provides a lowcost solution for enterprise and SOHO users to en-
hance the abilityofnetworkenvironment. Byconnecting directlyto an Ethernet or Fast
Ethernet, the high qualityvideo image can be monitored everywhere. The main differ-
ence fromthe conventional PC Camera is that Internet Camera is a standalone system.
There is no need to attach another computer with Internet Camera like usual PC
cameras do. Via a web browser, Internet Camera can be managed, accessed and
controlled remotelyover the Intranet or Internet. Management can be more efficient
and relative cost will be reduced bythis way.
ICA-100/ICA-100W Features
Internet Camera includes manyadvanced features, which are designed to provide
powerful functions while being easyto use.
Vivid Your Website.
Live-images on web site is a newtrend ofInternet nowadays. Must websites always
be immutable and frozen with onlytext and static pictures? Add ICA-100 series to
make websites more vigorous.
User-friendlyInterface.
Internet Camera supports both ActiveX mode for Internet Explorer and Java mode
for Internet Explorer and Netscape Navigator. The onlyrequirement for configuration
and image viewing is a web browser software such as Internet Explorer 5.0 or above
or Netscape 6.0 or above. Via user-friendlyweb interface, even a beginner with less
knowledge about networkcan manage easily.
Remote Monitoring and Management.
ICA-100 series can fullyintegrate with your network. Bythe conveniences ofworld
wide Internet, you can do the monitoring anywhere. Via add-on utility, networkadminis-
trators can decide whether individuals or the whole teammayaccess ICA100 series.
Multi-user password protection support offers more flexibilitywhile managing ICA100
series.
Alarm Trigger Function.
Adding external sensors to the auxiliaryI/O connecter ofICA-100 series can let you
programevent-based notification to fit various securitydemands. Internet Camera can
connect up to two input and two output external devices.
DDNS Support
Internet users can access the live images with a DDNS registered hostname instead of
knowing camera s real IP address.
1

Broadband Router User Guide
2
Motion Detection
Monitor anysuspicious movement in a specific area.
Wired and Wireless Network Support.(ICA-100W only)
ICA-100Wprovides both wired and wireless function. You can use ICA-100Win differ-
ent LAN environment bysimple mode switching.
Package Contents
The following items should be included:
•Internet Camera unit
•Camera Stand Accessory
•Power Adapter
•CD-ROM
•QuickInstallation Guide
•Wireless Antenna*2 (ICA-100Wonly)
Ifanyofthe above items are damaged or missing, please contact your dealer immedi-
ately.
Physical Details
Front Panel
Power LED
LAN LED
Figure 1-1: Front Panel
Power LED
The Power LED is positioned on the right side ofICA-100 seriess lens while facing
ICA-100 series. Steadyblue confirms ICA-100 series is powered on.
LAN ( /WLAN ) LED
The LAN ( /WLAN ) LED is positioned on the far right side ofICA-100 seriess lens
while facing ICA-100 series. It is located right ofthe Power LED. Steadyorange con-
firms good connection to LAN or WLAN connectivity. Dependent on the data traffic the
LED will begin to flash to indicate ICA-100 series is receiving/ transferring from/to the
LAN or WLAN network.
Note:

Introduction
3
There are three settings for the Power and LAN ( /WLAN ) LED to control the light
illumination for monitoring purpose fromNormal / Off / Dummy. Please refer to the
Web Configuration section for detailed information and usage.
Rear Panel
Figure 1-2: Rear panel of ICA-100
Figure 1-3: Rear panel of ICA-100W
Network Cable Connector
Internet Camera provides an RJ-45 connector for connections to 10Base-TEthernet
cabling or 100Base-TX Fast Ethernet cabling (which should be Category5 twisted-pair
cable). The port supports the NWayprotocol, allowing ICA-100 series to automatically
detect or negotiate the transmission speed ofthe network.
DC Power Connector
The DC power input connector is located on ICA-100 seriess rear panel and is labeled
DC 5V with a single jacksocket to supplypower to ICA-100 series. Power will be
generated when the power supplyis connected to a wall outlet.
Reset Button
Reset will be initiated when the reset button is pressed once and Power LED begins to
flash.
FactoryReset ofICA-100: Press the reset button for three seconds or until Power LED

Broadband Router User Guide
4
begins to light up, then release the reset button and the Power LED will begin to flash
indicating ICA-100 is changing to factoryreset. When factoryreset is completed the IP
address will return to the default setting as 192.168.0.20.
FactoryReset ofICA-100W: Press the reset button for three seconds or until Power
LED begins to light up, then release the reset button and the Power LED will begin to
flash indicating ICA-100Wis changing to factoryreset. When factoryreset is com-
pleted ICA-100Wwill be set to default on channel 11 and EES-ID is set as“NULL
String”(This default setting will let ICA-100Wable to connect ANYaccess point on the
infrastructure network). The IP address will also return to the default setting as
192.168.0.20.
I/O Connector
There are four I/O connectors, two for input and two for output situated on the rear
panel. The I/O connectors provide the physical interface to send and receive digital
signals to a varietyofexternal alarmdevices. Please refer to the Users Guide appen-
dix for detailed information.
Slide Switch( ICA-100W only)
The slide switch permits user to determine the type ofnetworkcommunication media
for ICA-100Wand is positioned on the rear panel. The three settings are as follows:
·LAN (Local Area Network)
·LAN/WLAN (Local Area Network/Wireless Local Area
Network)
·WLAN (Wireless Local Area Network)
Antenna Connector( ICA-100W only)
There are two Reverse PolaritySMA type antenna connectors located at the rear panel
ofICA-100Wproviding connection for two high sensitivityantenna included with the
device. You can also install the antenna with higher dB gain to get longer distance
connection. However, onlyantenna connector above the DC power connector is used
to transmit wireless signal. Thus, onlyconnect the high dB gain antenna to this con-
nector. The other one should still connect with bundled antenna.
Top Panel
Figure 1-4:Top Panel of ICA-100

Introduction
5
Figure 1-5:Top Panel of ICA-100W
Screw Hole
Located on the top panel ofICA-100 series, the screwhole is used to connect the
camera stand onto ICA-100 series byattaching the screwhead on the camera stand
into the screwhole ofICA-100 series.
Bottom Panel
Figure 1-6 Bottom Panel
Screw Hole
Located on the bottompanel ofICA-100 series the screwhole is used to connect the
camera stand onto ICA-100 series byattaching the screwhead on the camera stand
into the screwhole ofICA-100 series.
.

6
Chapter 2
Installation
This Chapter covers the physical installation of ICA-100 Series.
Requirements
ICA-100 ICA-100W
Network Environment
LAN 10/ 100M Ethernet 10/ 100M Ethernet
IEEE 802.11b Wireless LAN
Monitoring System Recommended to Access ICA-100 series
System Hardware •CPU: PentiumII, 266 MHzor above
•MemorySize: 32 MB (64 MB recommended)
•VGA card resolution: 800x600 or above
Web Browser •Internet Explorer 5.0 or above (ActiveX & JAVA Mode –
Image Viewfor Windows OS and JAVA Mode –Image
Viewfor other OS)
•Netscape 6.0 or above (JAVA Mode –Image View)
System Requirement for IPView Application
Support OS Win 98, Win 98 SE, Win 2000, Win Me, Win XP
System Hardware •CPU: PentiumIII, 450 MHzor above
•MemorySize: 128 MB (256 MB recommended)
•VGA card resolution: 800x600 or above
Connecting ICA-100 series to the Camera Stand
ICA-100 series comes with a camera stand accessorywith a swivel ball screwhead
that can be attached to ICA-100 series 's top or bottomscrewhole. Attach the camera
stand to ICA-100 series and station it for your application. There are three holes lo-
cated in the base ofthe camera stand allowing ICA-100 series to be mounted on the
ceiling or anywall securely.
2

Installation
7
Figure 2-1: Camera Stand
Hardware Install Procedure
ICA-100
1.Connect an Ethernet cable
Connect one end ofan Ethernet cable to the LAN port located on the ICA-100 rear
panel and attach the other end to the networkdevice (hub or switch).
2.Attach the external power supply
Connect the provided power adapter to the ICA-100s connector labeled "5VDC" on
rare panel.
3.Check the LEDs
The PWR and ACTLEDs should be on.
ICA-100W
1.Attach Wireless Antenna (LAN+WLAN or WLAN mode)
Screwthe 2 external Antenna provided into the antenna connector located on ICA-
100W s rear panel.
2.Connect an Ethernet cable (LAN or LAN+WLAN mode)
Connect one end ofan Ethernet cable to the LAN port located on the ICA-100Ws rear
panel and attach the other end to the networkdevice (hub or switch).
3.Switch to appropriate network type
Select the desired Networkcommunication type for ICA-100Wfromthe Slide Switch.
Position the Slide Switch to the setting required.
4.Attach the external power supply
Connect the provided power adapter to the ICA-100W s connector labeled "5VDC" on
rare panel.
5.Check the LEDs
The PWR and ACTLEDs should be on.

8
Chapter 3
Configuration
This Chapter provides details of the software configuration process.
Login
ICA-100 series must be configured through its built-in Web-based Configuration.
Extensive knowledge ofLAN will be helpful in setting up. Fromthe web browser, type
http ://192.168.0.20 in the address box to access Home page ofICA-100 series.
If you can't connect
IfICA-100 series do not respond, checkthe following:
• Machine is properlyinstalled, LAN or WLAN connection is OK, and it is
powered ON. You can test the connection byusing the "Ping" com-
mand:
• Open the MS-DOS windowor command prompt window.
• Enter the command:
ping 192.168.0.20
Ifno response is received, either the connection is not working, or
your PC's IP address is not compatible with ICA-100 series IP Ad-
dresses. (See next item.)
• Ensure that your PC is using an IP Address within the range
192.168.0.1 to 192.168.0.254 (excluding 192.168.0.20).
Also, the NetworkMaskshould be set to 255.255.255.0 to match ICA-
100 series.
In Windows, you can checkthese settings byusing Control Panel-
Network to checkthe Properties for the TCP/IP protocol.
Home Page
After the default IP address is entered fromthe browser, the Home page will appear
with a still image. There will be three options to choose fromto set-up and viewyour
Internet Camera and theyare as follows:
•ViewImage –ActiveX Mode
•ViewImage –Java Mode
•SystemAdministration
3

PC Configuration
9
Figure 3-1:Home Page
System Administration
Clickon System Administration”fromthe Home page to access the settings re-
quired for ICA-100 series. There will be several options in the menu bar to choose
fromto set your Internet Camera and theyare as follows:
•System
•Image
•Users
•DateTime
•Trigger
•Upload
•Information
•Tools
System
The Systemmenu contains commands for settings that are required for inputting key
details to set-up ICA-100 series for operation.
Clickon "System" in the systemadministration menu bar and the Systemscreen will
appear. The screen belowis fromICA-100W; the screen ofICA-100 is the same but
has no “Wireless Interface”parameters.

Broadband Router User Guide
10

PC Configuration
11
Figure 3-2: System Screen of ICA-100W
Camera Name:
This field is used for entering a descriptive name for the device. The default setting for
the Camera Name is CS-xxxxxx, where xxxxxx is the last six digit ofthe MAC Address.
The maximumlength is 32 (Printable ASCII).
Location:
This field is used for entering a descriptive name for the location used byICA-100
series.
Admin:
This field is used for entering the Administrator ID along with the password to access
the SystemAdministration settings. Be sure to enter the password twice to confirmthe
details once in the Admin Password field and again in the ConfirmPassword field. The
default setting for Admin is blankspace (Null String) you need to keyin the Admin ID
with a maximumlength of12 (Printable ASCII) characters and enter the Admin Pass-
word with a maximumlength of8 (Printable ASCII) characters. Please note that Admin
ID and Admin Password must be set before using IPViewutilityto connect Internet
Camera; otherwise the Internet Camera can not be added to IPView.
IP Assignment:
There are two options to select fromthe IP Assignment.
Note: Access to ICA-100 series is done through assigning a proper IP address. Please
make sure to use a vacant IP address when you assign the IP address for ICA-100
series. This will prevent errors fromoccurring ifthe IP address is overlapped.
ManuallyAssign
You can click ManuallyAssign”and directlyenter the IP address.
The default settings are as follows:
·Default IP –192.168.0.20
·Subnet Mask –255.255.255.0
·Default Gateway –0.0.0.0
Assign AutomaticallyUsing
Ifyour networkis using RARP, BOOTP or DHCP server you can click Assign
AutomaticallyUsing”and clickon RARP”, BOOTP”or DHCP”. Under this
setting ICA-100 series will automaticallyassign an IP address fromRARP, BOOTP
or DHCP server. Each time ICA-100 series starts up be sure the RARP, BOOTP or
DHCP server is setup as assign a static IP to your Internet Camera. Ifyour applica-
tion requires direct connection froman ADSL modemthrough ICA-100 seriess RJ-
45 LAN port and you also have an ISP PPPoE account. Clickon PPPoE”option
and enter the Service Name, User ID and Password into the respective fields. ICA-
100 series will get an IP address fromthe ISP each time ICA-100 series starts up.
DNS IP Address:
DNS (Domain Name System) server is an Internet service that translates domain
names into IP addresses. Enter at least one DNS IP Address.
Dynamic DNS:
ClickYes/No to enable/disable DDNS function. Before you use this function, you must
register a hostname froma DDNS service provider first.
Service Provider

Broadband Router User Guide
12
Enter the URL ofthe DDNS service provider whomyou registered to.
Host Name
Enter the hostname you registered.
User Name
Enter the user name that used to login the DDNS web site.
Password
Enter the password ofyour account.
Wireless Interface: (ICA-100W only)
Connection Mode:
Use the Connection Mode to determine the type ofwireless communication for ICA-
100W. There are three choices of Infrastructure mode, 802.11 Adhoc mode and
Adhoc mode. The default setting for the Connection Mode is Infrastructure.
Note: Keep in mind after setting the Wireless Interface, making sure that the Slide
Switch on the rear panel is positioned to either LAN/WLAN or WLAN setting for the
wireless communication to take effect.
Network Name:
This field is used to setup which wireless network (ESS-ID Extended Service Set ID)
ICA-100Wis to be connected for communication. The ESS-ID is a unique identifier
shared among all points in a wireless networkenvironment. The default Network
Name is blankspace (NULL String), this default setting will let ICA-100Wconnect
to ANYaccess point under the infrastructure networkmode. To connect ICA-100W
to a specific access point on the networkmake sure to set the ESS-ID ofICA-100W
to correspond with the access point s ESS-ID for communication. Type anystring
up to 32 characters long (spaces, symbols, and punctuation are not allowed) in the
NetworkName box.
To connect ICA-100Wto an Ad-hoc wireless workgroup make sure to set the same
wireless channel and ESSID to match with the PC/Notebookwireless channel and
ESS-ID for direct wireless communication under the Ad-hoc wireless workgroup
(ad-hoc and 802.11 ad-hoc modes).
Note : ICA-100Wad-hoc mode supports two modes (802.11 ad-hoc mode and
proprietaryad-hoc mode). Which option should be chosen depends on which ad-
hoc mode is supported byyour wireless card driver on the PC/ Notebook. Some
driver supports both modes, however, some driver support onlyone ofthe modes.
The names ofeach ad-hoc mode maynot be consistent between each wireless
card vendor therefore you mayneed to tryeach ofthe ad-hoc mode (802.11 mode
and proprietarymode) and select the mode that can communicate with each other.
Wireless Channel:
The pull down menu provides the wireless channel for communication. A "channel"
is a range offrequencies to be used in communication between ICA-100Wand Ac-
cess Point in infrastructure mode or ICA-100Wand PC/Notebookin Ad-hoc mode.
Select the appropriate channel fromthe list provided depending on the regulatory
region that the unit is sold. The default setting is at channel 11.
Encryption WEP Key:
Wireless networkcommunications are easilyintercepted. WEP (Wired Equivalent
Privacy) is an encryption method specified bythe IEEE 802.11b standard to make
anyintercepted communications extremelydifficult to interpret byunauthorized par-
ties. To enable WEP Encryption, first decide which WEP keyformat will be applied.

PC Configuration
13
Clickon ASCII or HEX checkbox to select input format as ASCII format or HEX
format, and then input WEP key. To Confirmthe WEP keyyou must enter the data
once again in the ConfirmWEP Keyfield.
ASCII input format:
ASCII format causes each character to be interpreted as an eight-bit value. All
unaccented upper- and lower-case Western European characters that can be
input through your keyboard's typing zone are valid. To setup 64-bit WEP key,
input 5 ASCII characters, for example, ‘12345. To setup 128-bit WEP key, input
13 ASCII characters, for example, ‘1234567890123. These character counts
result in bit counts of40 and 104, respectively; ICA-100Wwill automaticallypad
your input to a bit count of64 or 128.
HEX input format:
Hex format causes each pair ofcharacters you type to be interpreted as an
eight-bit value in hexadecimal (base 16) notation. Onlythe digits 0 through 9 and
the letters A through F (in upper or lower case) are valid. To setup 64-bit WEP
key, input 10 HEX format, for example, ‘3132333435, this is the same with
ASCII input ‘12345 . To setup 128-bit WEP key, input 26 HEX format, for exam-
ple, ‘31323334353637383930313233, this is the same with ASCII input
‘1234567890123. These character counts result in bit counts of40 and 104, re-
spectively; ICA-100Wwill automaticallypad your input to abit count of 64 or 128.
On the ConfirmWEP Keyfield, input the same characters as the Encryption
Code field. Make sure the Encryption Code is the same with the access points
encryption code that ICA-100Wis to be connected under Infrastructure mode.
Your PC/Notebook s encryption code also needs to be setup the same with ICA-
100W's encryption code under either Infrastructure mode or Ad-hoc mode.
The default setting for the Encryption Keyis Disable therefore, to secure the
wireless transmission be sure to Enable the Encryption Keybyentering the rele-
vant data.
Note: Carefullyinput Encryption Code, anyerror setting will cause communica-
tion linkto fail.
LED Control:
The LED control allows user to setup the LED illumination as desired. This feature
provides the flexibilitywhen surveillance activityis ON.
There are three options as follows:
Normal
Power - SteadyOn ofthe LED indicator.
LAN - SteadyOn ofthe LED indicator. When LAN activityis present the LED indica-
tor will flash steadily.
OFF
Power - LED indicator is off
LAN - LED indicator is off
Dummy
Power - SteadyOn ofthe LED indicator.
LAN - SteadyOn ofthe LED indicator with randomflashing.
The default setting for the LED control is at Normal. When you have configured the
LED control the correct illumination will set in after 1 minute.

Broadband Router User Guide
14
Note: This function is built-in to the LED indicators to add extra capabilities. The three
options allowthe Administrator to configure and camouflage the illumination for the
LED indicator to falsifythe monitoring status. In Normal Mode the LED indicator func-
tions as normally. Under Off Mode the LED indicators are both off however, it is still
monitoring the activity. In DummyMode the LED indicators operate in monitoring
condition but monitoring activityis off or on.
Loading ActiveX From:
This field is used to specifythe location ofXplug Control (ActiveX) plug-in program.
Enter the information as required in .ocx format, for example: http://www.<your com-
pany>.com/xplug.ocx where <your company> must be replaced with your companys
DNS name.
Open Second Port:
The Web Server field allows settings to open a second port for ICA-100 series. This
will permit users IP Sharing Gateways to support multiple Internet Cameras. Bydefault
Port 80 is always opened for ICA-100 series Web Server access. Select
Yes”and input the second port value. For example: Ifyou have 5 Internet Cameras
to be installed, each with an IP address from
192.168.0.101
192.168.0.102
192.168.0.103
192.168.0.104
192.168.0.105
You can open the second port for each Internet Camera fromport 81 to Port 85 as
illustrated below:
Internet Camera 1 –IP 192.168.0.101, second web port 81
Internet Camera 2 –IP 192.168.0.102, second web port 82
Internet Camera 3 –IP 192.168.0.103, second web port 83
Internet Camera 4 –IP 192.168.0.104, second web port 84
Internet Camera 5 –IP 192.168.0.105, second web port 85
You also need to setup your DSL gatewayfor Port Mapping.
Port 81 map to 192.168.0.101
Port 82 map to 192.168.0.102
Port 83 map to 192.168.0.103
Port 84 map to 192.168.0.104
Port 85 map to 192.168.0.105
The Transfer Image field allows settings to open a second port for ICA-100 series to
transfer images. The default Port 8481 is open image transfer and you can define a
second port similar to the above.
Save/Cancel:
After making sure all settings in the Systemare correct, clickon the Save”icon to
store the settings for ICA-100 series. You can alternativelyclickon the Cancel”icon
to restore all settings to the values last saved to or retrieved fromICA-100 series.

PC Configuration
15
Image menu in the systemadministration contains commands to provide the settings
for the images captured byICA-100 series. Clickon Image”in the systemadministra-
tion menu bar and the Image screen will appear as illustrated below:
Figure 3-3: Image Screen
Video Resolution:
Select the desired video resolution format ranging from320x240 (default) or 640x480.
Compression Rate:
Select the desired compression rate with five levels fromverylowto veryhigh. Higher
video compression rate will generate more compact file size with less video qualityand
vise-versa. The default setting is at Medium.
Frame Rate:
Select the frame rate desired with default setting at Auto for optimal frame rate.
Brightness Control:
Adjust the brightness level with default setting at 64.
Contrast Control:
Adjust the contrast level with default setting at 64.
Hue Control:
Adjust the hue level with default setting at 64.
Light Frequency:
Adjust the light frequencyto suit your area ofoperation fromthe options either 50 Hz
or 60 Hz(default).
Note: 50 Hzand 60 Hzvariants are available to accommodate the different light
frequencyfound in USA (60 Hz) and Europe (50 Hz) for ICA-100 series to ensure
better image quality.
Save/Cancel:

Broadband Router User Guide
16
After making sure all settings in the Image are correct, clickon the Save”icon to
store the settings for ICA-100 series. You can alternativelyclickon the Cancel”icon
to restore all settings to the values last saved to or retrieved fromICA-100 series.
Users
The User options menu contains commands to allowsystemadministrator to assign
legal users who are permitted to monitor ICA-100 series fromthe remote site.
Clickon Users”in the systemadministration menu bar and the Users screen will
appear as illustrated below:
Figure 3-4: Users Screen
Add User:
User Name:
Enter the user name in this field. A maximumof64 users names are allowed, how-
ever each users name must be different. Each user name can be used as a group
given the password for example, ifthe User Name is “Guest”and the User Pass-
word is “Guest”anyone can access ICA-100 series with these details used as a
group ofusers under the User Name Guest. The maximumlength for the User
Name is 12 (Printable ASCII).
User Password:
Enter the user s password assigned bythe administrator. The maximumpassword
length is 8 (Printable ASCII).
I/O Output Control:
Administrator has the authorityto give permission for the privilege to control the I/O
Output Control to users byselecting Yes”or No”to activate the I/O Output con-
trol.
To add a newusers name input the necessaryinformation first and clickon the Add”
icon.
Delete User:
Select the user you wish to delete fromthe pull down menu and clickon the delete”
icon.
Note: Once administrator has configured ICA-100 series Users, anyuser will be
required to enter a login password to access the video image ofICA-100 series.
The password dialog box is illustrated below.

PC Configuration
17
Figure 3-5: User Login Screen
DateTime
The DateTime menu contains commands for setting ICA-100 series' time and date
requirements to provide correct information to users who might be thousands ofmiles
awayin the remote site. There are two options to select fromthe DateTime menu bar
either Synchronized with Time Server or Set Manually. Clickon DateTime”in the
systemadministration menu bar and the DateTime screen will appear as illustrated
below:
Figure 3-6: DateTime Screen
DateTime:
Select Synchronized with Time Server”and the time will be based on GMTsetting.
The time will be synchronized every10 minutes. This is also the default setting for ICA-
100 series.
IP Address:
Enter the IP Address ofthe Time Server in this field.
