Planet ICA-4200V User manual

Full HD 20M IR Vari-Focal Dome IP
Camera
ICA-4200V
1
Full HD 20M IR Vari-Focal
Dome IP Camera
ICA-4200V

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
2
Copyright
Copyright ©2013 by PLANET Technology Corp. All rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language or computer language, in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to
the contents hereof and specifically disclaims any warranties, merchantability or fitness for any
particular purpose. Any software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not PLANET, its distributor, or
its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or
consequential damages resulting from any defect in the software. Further, PLANET reserves the
right to revise this publication and to make changes from time to time in the contents hereof
without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance. (example-use only shielded interface cables when connecting
to computer or peripheral devices). Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two
conditions: ( 1 ) This device may not cause harmful interference, and ( 2 ) this Device must
accept any interference received, including interference that may cause undesired operation.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment.
In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human
proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation.

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
Safety
This equipment is designed with the utmost care for the safety of those who install and use it.
However, special attention must be paid to the dangers of electric shock and static electricity
when working with electrical equipment. All guidelines of this and of the computer manufacture
must therefore be allowed at all times to ensure the safe use of the equipment.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference,
in which case the user may be required to take adequate measures.
WEEE Regulation
3
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users
of electrical and electronic equipment should understand the meaning of the
crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal
waste and have to collect such WEEE separately.
Revision
User’s Manual for PLANET Full HD 20M IR Vari-Focal Dome IP Camera
Model: ICA-4200V
Rev: 1.00 (February.2013)
Part No. EM-ICA4200V

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
4
Table of Content
Chapter 1. Product Introduction..................................................................................... 6
1.1. Package Contents............................................................................................ 6
1.2. Overview............................................................................................................ 6
1.3. Features............................................................................................................. 9
1.4. Product Specification..................................................................................... 10
Chapter 2. Hardware Interface..................................................................................... 12
2.1 Physical Description........................................................................................ 12
2.1.1 Identification of ICA-4200V physical detail....................................... 12
2.1.2 I/O Control Instruction.......................................................................... 13
2.1.3 Connector board................................................................................... 15
2.2 Hardware Installation...................................................................................... 17
2.3 Initial Utility Installation ................................................................................... 20
2.4 Preparation....................................................................................................... 22
2.4.1 Search and View by PLANET IP Wizard II....................................... 22
2.4.2 Configure Network by PLANET IP Wizard II.................................... 24
2.5 Using UPnP of Windows XP or 7.................................................................. 25
2.5.1 Windows XP.......................................................................................... 25
2.5.2 Windows 7............................................................................................. 30
2.6 Setup ActiveX to use the Internet Camera.................................................. 31
2.6.1 Internet Explorer 6 for Windows XP.................................................. 32
2.6.2 Internet Explorer 7 for Windows XP.................................................. 32
2.6.3 Internet Explorer 7 for Windows Vista............................................... 33
Chapter 3. Web-based Management.......................................................................... 35
3.1. Introduction...................................................................................................... 35
3.2. Connecting to Internet Camera.................................................................... 35
3.3 Live View........................................................................................................... 36
3.4 ActiveX Control ................................................................................................ 38
3.4.1 Digital Zoom.......................................................................................... 40
3.4.2 Snapshot................................................................................................ 40
3.4.3 Record.................................................................................................... 40
3.4.4 Volume................................................................................................... 41
3.4.5 About...................................................................................................... 41
3.5 Network Configuration.................................................................................... 42
3.5.1 Network.................................................................................................. 42
3.5.2 IPv6 ........................................................................................................ 44
3.5.3 HTTPS ................................................................................................... 44
3.5.4 DDNS server......................................................................................... 45
3.5.5 PPPoE.................................................................................................... 46
3.5.6 Streaming .............................................................................................. 47
3.5.7 UPnP...................................................................................................... 48
3.5.8 Bonjour................................................................................................... 49
3.5.9 IP Filter................................................................................................... 50
3.5.10 IP Notification...................................................................................... 50
3.6 Camera Configuration..................................................................................... 52

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
5
3.6.1 Picture.................................................................................................... 52
3.6.2 Privacy Mask......................................................................................... 55
3.6.3 PTZ Setting ........................................................................................... 55
3.6.4 Preset Setting ....................................................................................... 56
3.6.5 Tour Setting........................................................................................... 57
3.7 System............................................................................................................ 58
3.7.1 System................................................................................................... 58
3.7.2 Date & Time........................................................................................... 59
3.7.3 Maintenance.......................................................................................... 60
3.8Video ................................................................................................................. 62
3.8.1 Common................................................................................................ 62
3.8.2 Overlay Image ...................................................................................... 62
3.8.3 Video Profile.......................................................................................... 63
3.8.4 ROI ......................................................................................................... 65
3.8.5 AOI.......................................................................................................... 65
3.9Audio Configuration......................................................................................... 66
3.10 User Privilege Access Configuration.......................................................... 67
3.11 Protocol........................................................................................................... 68
3.11.1 ONVIF .................................................................................................. 68
3.11.2 SNMP................................................................................................... 69
3.12 Mail Configuration ......................................................................................... 70
3.13 Event Detection ............................................................................................. 71
3.13.1 Motion Detection................................................................................ 71
3.13.2 Camera Tampering ............................................................................ 72
3.13.3 Audio Detection.................................................................................. 73
3.14 Storage Configuration................................................................................... 74
3.14.1 SD Card............................................................................................... 74
3.14.2 SAMBA Server.................................................................................... 75
3.15 Continuous Recording.................................................................................. 75
3.16 Recording List................................................................................................ 76
3.17Event Server Configuration.......................................................................... 77
3.17.1 FTP Server.......................................................................................... 77
3.17.2 TCP Server.......................................................................................... 78
3.17.3 HTTP Server....................................................................................... 79
3.17.4 SAMBA Server.................................................................................... 79
3.18 Event Schedule Configuration.................................................................... 81
3.18.1 Setting.................................................................................................. 81
3.18.2 Record Configuration ........................................................................ 84
3.18.3 Port Status........................................................................................... 85
Appendix A: PING IPAddress...................................................................................... 86
Appendix B: 3GPPAccess ........................................................................................... 87
Appendix C: Bandwidth and Video Size Estimation................................................. 88
Appendix D: DDNS Application.................................................................................... 89
Appendix E: Configure Port Forwarding Manually.................................................... 90
Appendix F: Power Line Frequency............................................................................ 91
Appendix G:Troubleshooting & Frequently Asked Questions................................. 92

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
Chapter 1. Product Introduction
1.1. Package Contents
The package should contain the followings:
zIP Camera Unit x 1
zPower Adapter x 1
zScrew package x 1
zUser’s Manual CD-ROM x 1
zQuick Installation Guide x 1
NOTE: 1. If any of the above items are missing, please contact your dealer immediately.
2. Using the power supply that is not the one included in Internet Camera packet
will cause damage and void the warranty for this product.
1.2. Overview
High Resolution Surveillance in Day and Night
PLANET ICA-4200V Network Camera with IR Illuminator is a high resolution camera for
round-the-clock surveillance over IP networks. It supports H.264, MPEG-4, and JPEG
compression formats and delivers excellent picture quality in Full HD resolutions at 30 frames per
second (fps). Incorporating the new Exmor™ CMOS image sensor, which is specially designed for
surveillance applications, the ICA-4200V provides high quality images under all lighting conditions.
It is perfect for remote and discreet monitoring of indoor areas such as stores, banks, hotels, office
lobbies, and warehouses.
Day & Night Functionality
To adapt to constantly changing lighting conditions, the ICA-4200V comes with a removable
IR-Cut filter and built-in IR illuminators, which enables the camera to provide color video when
there is sufficient light, and black/white video in dark conditions. The ICA-4200V is able to maintain
clear images 24 hours a day.
6

FullHD20MIRVari-FocalDomeIPCamera
4200VICA-
Exceptional Image quality
Together with powerful image processing attributes like Wide Dynamic Range and 3D Digital
Noise Reduction (3DNR) technology, the camera is able to filter the intense backlight surrounding
a subject and remove noises from video signal. The result is that an extremely clear and exquisite
picture quality can be produced even under any challenging lighting conditions.
7

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
Passive InfraRed (PIR) Sensor
When people pass by or in an emergency situation, the built-in PIR motion detection sensor in the
ICA-4200V will “detect” and start recording automatically. It is able to detect movement far from 6
meters away. When motion is detected in the specified areas, the additional function of alarm
notification can send an e-mail alert or send captured images via FTP upload to a designated
storage server.
Camera tampering and audio detection
Provided with three individually configurable motion detection zones, the camera can record video
or trigger alarms or alerts when motion is detected in user-specified areas of the camera image.
Also, the camera's built-in microphone enables it to hear what the video cannot see and to trigger
the audio detection alarm when sounds like screams, glass breaking, etc., are detected.
8

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
9
Advanced Event Management
To enhance surveillance flexibility and event management capabilities, the ICA-4200V supports a
number of advanced features including Auto-Iris to avoid over exposure, AV out to perform the
two-way audio function, RS485 to connect to an optional pan/tilt enclosure which effectively
supports pan/tilt functionality, and inputs/outputs to connect with external devices such as door
sensors and relays to activate light or close doors.
Flexible Installation and Power Functionality
The ICA-4200V incorporates IEEE 802.3af Power over Ethernet standard and able to be powered
via the network cable from a PoE power sourcing equipment such as PoE Switch and PoE injector.
It thus eliminates the need for of extra power cables and reduces installation costs while increases
the deployment flexibility. In addition, the ICA-4200V provides advanced features such as the
Gigabit Ethernet Transmission, giving users the utmost in bandwidth flexibility and storage
efficiency. The ICA-4200V is ONVIF compliant and therefore interoperable with other
manufacturer’s products. It also includes 64-CH central management software for ease of
maintenance and remote monitoring. The ICA-4200V is indisputably the top choice for reliable and
high performance surveillance.
1.3. Features
¾Camera
Sony's 1/2.9 type "Exmor" 2MP CMOS sensor
3.3~12.0 mm Vari-Focal, DCAuto-Iris Lens
0.5 lux Minimum Illumination at F1.2
Maximum resolution 1920 x 1080
Removable IR-Cut Filter for Day & Night Function
Built-in PIR sensor (6m/120 degree coverage) for thermal / motion detection
¾Video / Audio
H.264 / MPEG-4 and M-JPEG video compression simultaneously
Simultaneous multi-stream support
H.264 high profile, main profile and baseline
Max. Resolution 1080P at 30fps
3DNR to improve picture quality at low Lux
WDR Enhancement for enhance visibility under extremely bright or dark environments
Two-Way audio support with enhanced audio quality
Tamper and audio detection for unauthorized changes
¾Network and Configuration
Compliant with IEEE 802.3af PoE interface for flexible deployment
Equipped with Gigabit Ethernet port
Auto MDI/MDI-X supported
Supports for IPv6 in addition to the standard IP protocol version 4
RTSP / UPnP / 3GPP / HTTPS protocols selectable
¾Easy Installation & Management
ONVIF compliant for interoperability
Built-in 12 IR Illuminators, effective up to 20 meters
Intelligent Motion / Tampering / Audio detection alarm triggers
Built-in Samba client for NAS

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
10
3GPP for 3G mobile remote applications
Micro SD card local video recording supported
RS485 interface for P/T scanner control
Digital Input/Output for integration with sensors and alarms
Cam Viewer 3 Central management software supported
1.4. Product Specification
Model ICA-4200V
Full HD 20M IR Vari-Focal Dome IP Camera
Camera
Image device 1/2.9 type Sony Exmor progressive scan CMOS sensor
Lens Vari-Focal 3.3~12.0mm, DCAuto-Iris
Mechanical IR Cut Filter
Angle of view : horizontal: 27 ~ 82 Degree / vertical: 19 ~ 64 Degree
Min Illumination 0.5 Lux (Color) @ F1.2
0.1 Lux (B/W)
IR Illuminations IR LED x 12, 850nm
Built-in IR illuminators, effective up to 20 meters
Effective Pixels 1920 x 1080 pixels
Video Compression H.264 / MPEG-4 / M-JPEG
Video Resolution
1080P mode
H.264: 1080P / 640 x 360 / 320 x 180 / 160 x 90
M-JPEG: 1080P / 640 x 360 / 320 x 180 / 160 x 90
MPEG4: 1080P / 640 x 360 / 320 x 180 / 160 x 90
720P mode
H.264: 1280 x 720 / 640 x 360 / 160 x 90
M-JPEG: 1280 x 720 / 640 x 360 / 160 x 90
MPEG-4: 1280 x 720 / 640 x 360 / 160 x 90
Frame Rate Up to 30fps for all resolutions
Image Setting
AE, AWB
3D Noise reduction
WDR
Color, brightness, sharpness, contrast
Mirror/Flip
10 Privacy Masks
Text, time and date overlay
Overlay image on video
Streaming
Simultaneously multi-profile streaming
Streaming over UDP, TCP, HTTP, or HTTPS
M-JPEG streaming over HTTP (server push)
Supports 3GPP mobile surveillance (MPEG4)
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4/H.264)
ROI
Audio
Audio Streaming Two-Way Audio

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
11
Audio Compression RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR
Microphone External microphone input
Audio Output Adjustable audio output gain
Network and Configuration
Standard IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T
Protocol IPv4, IPv6, TCP/IP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP,
ICMP, Samba
Security Password protection, IP address filtering, HTTPS encrypted data
transmission, user access log
Users 20 clients on-line monitoring at the same time
System Integration
Application Programming
Interface Open API for software integration
ONVIF Compliant
Alarm Triggers Intelligent Motion / Tampering / Audio detection and external input
Alarm Events
File upload via FTP, Samba to NAS, SD card or email
Notification via email, HTTP, and TCP
External output activation
Audio alerting output
Go to PTZ preset position
Video Buffer Pre- and post-alarm buffering
General
Power Requirement 12V DC, 1A
IEEE 802.3af Class 3
Power Consumption 8W max.
Operating Temperature 0 ~ 50 Degree C
Operating Humidity 20 ~ 80% (non-condensing)
Weight 635g
Dimension (Φx L) 152 x 109 mm
Emission CE, FCC
Connectors
10/100/1000 Mbps Gigabit Ethernet, RJ-45
DC power jack
Terminal block for 1 alarm input and 1 output
RS-485 interface for scanners, pan/tilts
External MIC input
Audio out
Composited video out (Max. resolution: D1 720 x 480 pixel))
Micro SD/SDHC card (Max 32GB, Class 6)
Factory default reset

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
12
Chapter 2. Hardware Interface
2.1 Physical Description
2.1.1 Identification of ICA-4200V physical detail
Item Description
Lens Lens set. Keep this area clean to keep excellent video quality.
IR LED Emits infrared light to provide light source in dark places
Light sensor
Detects the illumination level or the place where this IP camera is
installed, and switches IR LEDs on when it’s required.
NOTE:
When IR LEDs are switched on, this IP camera will switch
to black and white video mode to enhance video quality.
Do not cover light sensor or this IP camera will work in
black and white mode only.
PIR PIR sensor is used to sense motion or detect whether a human has
moved in or out of the sensors range.

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
13
2.1.2 I/O Control Instruction
Descriptions for I/O cable set:
Interface Description
DC Power
The input power is DC 12V, 1A.
Note：ONLY use package power adapter supplied with the internet.
Otherwise, the product may be damaged.
RJ-45
(LAN socket, PoE )
Connect to PC or Hub/Switch.
For connect to 10Base-T Ethernet or 100Base-TX or 1000Base-TX
Fast Ethernet cabling. This Ethernet port built auto-negotiation
protocol can detect or negotiate the transmission speed of the
network automatically. Please use CAT-5 cable to connect the
Network Camera to a 1000Mbps Fast Ethernet network switch or hub.
Note：ONLY use one power source, either from DC or from 802.3af
Power over Ethernet.
Audio Output
(Green, Line Out) Connect a loud speaker to the IP Camera. This is for voice alerting
and two-way audio.
Microphone Input
(Pink, Audio In) Connect a microphone to the IP Camera.
Video Output
(BNC)
The Network Camera also provides composite video output. The
video output function is only for easy installation to check view angle
and focus. The output is not a Mega-pixel resolution. Furthermore, the
video output is off by default. Please turn on video.
Reset
(Factory Default) This button is used to restore the all factory default settings.
DI/DO, RS-485
The 6 pin terminal block includes 1 input ports and 1 output ports, and
RS-485 D+ and D-.
Name Cable Color Function

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
14
12VDC Brown/White DC 12V (50mA maximum)
GND Blue/White GND
D+ Purple/White RS485 data +
D- Gray RS485 data -
DI Green/White Digital signal input
DO Orange/White Digital signal output

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
15
2.1.3 Connector board
Interface Description
Terminal block
Pin Name Function
1 12VDC in DC 12V power input
2 MIC in- External MIC input-
3 MIC in+ External MIC input+
4 Audio out+
5 Audio out-
6 Video out Composited video output
7 12VDC out DC 12V output (50mA maximum)
8 DI Digital signal input
9 GND Digital ground
10 DO Digital signal output
11 RS485+ RS485 data +
12 RS485- RS485 data -
RJ45
5
Micro SD
Card Slot
12VDC
in
(
red
)
Video out
Audio
in/out
(
red
)
6
LAN
DIDO+
RS485
Reset &
LAN LED
1
Pin12
3
4
2
Factory
Default
Reset
Pin1
Terminal
Block

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
16
RJ-45
(LAN socket, PoE )
Connect to PC or Hub/Switch.
For connect to 10Base-T Ethernet or 100Base-TX or 1000Base-TX Fast
Ethernet cabling. This Ethernet port built auto-negotiation protocol can
detect or negotiate the transmission speed of the network automatically.
Please use CAT-5 cable to connect the Network Camera to a 1000Mbps
Fast Ethernet network switch or hub.
Note：ONLY use one power source, either from DC or from 802.3af
Power over Ethernet.
12VDC in & Power
NDG
The input power is DC 12V, 1A.
Note：ONLY use package power adapter supplied with the internet.
Otherwise, the product may be damaged.
MIC in
(audio in) Connect an external microphone to the camera.
Audio out +/- Connect a loud speaker to the camera. This function is for voice alerting
and two-way audio.
Video out Connect a TV monitor to the camera. User can check the focus/zoom
and view angle of the camera.
DI/GND/DO/RS485 The 6 pin terminal block includes 1 input ports and 1 output ports, and
RS-485 D+ and D-.
Factory Default
Reset
This button is used to restore the all factory default settings.
Restore the device:
a. Press the button down continuously.
b. Hold the button at least 5 seconds and release it. Then the device has
been restored to default settings and reboot again.
Micro SD Card Slot User can insert a micro SD card into this slot for recording.
NOTE: That to cabling this camera by type of connector board, firstly, user must
remove the attached “connector cable” from wafer 1~ 6 shown as below:

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
17
2.2 Hardware Installation
2.2.1 Connector board
1. Please select the most suitable position on ceiling to install the camera.
2. Remove two screws to release the top cover of the dome and open it.
3. Set the mounting base onto ceiling and center it through the mounting hole, using the two
retaining screws for the main body, supplied by the appurtenance bag.
4. To adjust lens, move the camera body by pan and/or tilt manually and set the
zoom/focus by turning the lens to the left or right direction.
5. Connect the LAN cable to Ethernet’s switch or hub and the DC-Jack to the power
source.

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
18
NOTE: Use the power adapter, 12VDC, included in the package and connect it to
wall outlet for AC power. And connect the other cables and connectors if
necessary.
6. When the camera cabling is completed, close the top cover dome housing and
secure it by two screws. And then adjust PIR sensor to proper position. Once the PIR
sensor is well [position, then secure it by another two screws.
6. Done
2.2.2. Network Installation
1. Connect an Ethernet cable
Connect the LAN cable on the camera to the network device (hub or switch).
NOTE: If there has an IEEE802.3af PoE switch in your network, you can connect the
camera LAN cable to this PoE switch to obtain power. The power adapter is
unnecessary when Internet camera is connected to a PoE switch.
2. Attach the power supply
Plug in power adapter and connect to power source. After power on, the camera will start to
operate.
NOTE: 1. Only use the power adapter supplied with Internet camera Otherwise, the
product may be damaged.
2. The power adapter is unnecessary when Internet camera is connected to a
PoE switch. Otherwise, the product may be damaged when Internet camera is
connected to a PoE switch and power adapter simultaneously.
3. Attach BNC connector
Connect the video BNC connector to a monitor set if necessary check camera viewing angle
and focus.

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
19
4. Attach Speaker to camera (option)
If user needs not only video stream but also audio stream, then the speaker should be
attached to camera.
5. PoE (Power Over Ethernet)
Power over Ethernet (PoE) is a technology that integrates power into a standard LAN
infrastructure. It enables power to be provided to the network device, such as an IP phone or
a network camera, using the same cable as that used for network connection. It eliminates
the need for power outlets at the camera locations and enables easier application of
uninterruptible power supplies (UPS) to ensure 24 hours a day, 7 days a week operation.

FullHD20MIRVari-FocalDomeIPCamera
ICA-4200V
20
2.3 Initial Utility Installation
This chapter shows how to quick set up your H.264 camera. The camera is with the default
settings. However to help you find the networked camera quickly the windows utility PLANET IP
Wizard II can search the cameras in the network that shall help you to configure some basic
setting before you started advanced management and monitoring.
1. Insert the bundled CD into the CD-ROM drive to launch the auto-run program. Once
completed, a welcome menu screen will appear.
2. Click the “IP Wizard II” hyperlink; you will see the dialog box as below.
NOTE: If the welcome screen does not appear, click “Start” at the taskbar. Then, select
“Run” and type “D:\Utility\IPWizard II\setup.exe”, assume D is your CD-ROM drive.
3. The “Welcome to the Install Shield Wizard for PLANET IP Wizard II” prompt will display on the
screen and click “Next” to continue.
4. Please click “Next” to install with original settings, or you may click “Change…” button to
modify the install folder then press “Next” to continue.
