For easy home networking Switch solution, PLANET releases the new
FSD-805 series wall mountable 10/100Mbps Fast Ethernet Switch which
offers palm size and desktop installation with internal power supply.
∎FSD-805SC: 8 + 1 Multi-mode 100FX Desktop Switch, up to 2km
∎FSD-805S15: 8 + 1 Single mode 100FX Desktop Switch, up to 15km
With 8 independent ports and auto-negotiation capability, all the RJ-45
ports in the FSD-805SC and FSD-805S15 can be configured to data rate
of 10/20Mbps or 100/200Mbps automatically. To meet the increasing
bandwidth requirements for local area networks, the Switch provides non-
blocking wire-speed performance and 1.6Gbps internal switching fabric.
The PLANET FSD-805SC and FSD-805S15 are the ideal option to alleviate
the bottleneck in client / server and peer-to-peer environments in a cost-
effective way.
The PLANET FSD-805SC and FSD-805S15 provide one shared 100Base-FX
optic-fiber SC interface with port 1, TP / Fiber port selection through the
DIP Switch. They provide choice of multi-mode / single mode 100Base-FX
SC interface and the fiber transmit distance can be 2km and 15km away
for link to remote backbone.
All RJ-45 copper interfaces built in the FSD-805SC and FSD-805S15
support 10/100Mbps Auto-Negotiation for optimal speed detection
through RJ-45 Category 5, 5e or 6 cables. With Auto-MDI/MDI-X feature
support, they can detect the type of connection to any Ethernet device
without the need of special straight or crossover cables.
The Flow Control function allows FSD-805 series Fast Ethernet Switch
support routers and servers to directly connect to this Switch for fast and
reliable data transfer.
Data Sheet
1
Key Features
Complies with the IEEE 802.3 Ethernet and IEEE 802.3u Fast•Ethernet standard
Features Store-and-Forward mode with wire-speed filtering and•forwarding rates
Support 2K MAC address table•
Support to handle up to 1522 bytes packet size•
LED indicators for simple diagnostics and management•
Hardware based 10/100Mbps auto-negotiation•
Full / Half-Duplex capability on every TX ports, total bandwidth•is up to 200Mbps per port
IEEE 802.3x PAUSE frame flow control for full duplex operation•
Backpressure flow control for half duplex operation•
One shared 100Base-FX interface for up to 2km (multi-mode•fiber 50μm/125μm) on FSD-805SC
One shared 100Base-FX interface for up to 15km (single-mode•fiber 9μm/125μm) on FSD-805S15
Automatic source address learning and aging•
Compact size, wall-mountable design•
Internal power adapter 100-240V AC, 50/60Hz, 0.2A•
FCC, CE class A compliant•
8-Port 10/100Mbps Desktop Fast Ethernet Switch
( Internal Power)
Applications
Ideal Switch for Home / SOHO and Space-limited locations
With 8 10/100Mbps Fast Ethernet ports, the FSD-805SC and FSD-
805S15 provide a cost-effective and high-performance solution for
Home / SOHO applications. In multiple applications, the advanced
functionality of the FSD-805SC and FSD-805S15 eliminate traditional
issues associated with current Ethernet environment. With multi-mode /
single mode 100Base-FX SC interface, the FSD-805SC and FSD-805S15
fiber transmit distance can be 2km and 15km away for uplink to core
Switch or backbone in a small office, factory or warehouse Ethernet
connection.
Factory
Office
FSD-805
Workgroup
PDA
15km/100Base-FX
Fiber
2km/100Base-FX
Fiber
RJ-45
FSD-805S15
FSD-805SC
Core Switch
File Server
Warehouse
10/100Base-TX
100Base-FX

C-FSD_805SC_S15
Data Sheet
2
Specification
Product 8-Port 10/100Mbps Desktop Fast Ethernet Switch ( Internal Power)
Model FSD-805SC FSD-805S15
Hardware Specification
10/100Base-TX Ports 8 8
100Base-FX SC Port 1 (Shared with Port-1) 1 (Shared with Port-1)
Fiber Port Type SC / Multi-mode SC / Singel mode
Cable Distance 2km 15km
Optical Frequence 1300nm 1310nm
Launch Power (dBm) Max:-14
Min: -19.0
Max:-7
Min: -20
Receive Senstivity -34.5 -28
Maximum Input Power -14 -8
Dimensions ( W x D x H) 191 mm x 85 mm x 26 mm
Weight 325g
Power Requirement Internal power 100-240V AC, 0.2A
Power Consumption /
Dissipation 4.3 watts / 14.6 BTU
Switch Specification
Switch Processing Scheme Store-and-Forward
Address Table 2K entries
Share data Buffer 1Mbit on-chip frame buffer
Flow Control Back pressure for half duplex
IEEE 802.3x Pause Frame for full duplex
Switch fabric 1.6Gbps
Throughput (packet per
second) 11.9Mpps
Network cables
10/100Base-TX:
• 2-Pair UTP Cat. 3,4, 5 (100meters, max.) EIA/TIA-568 100-ohm STP (100meters, max.)
100Base-FX:
• Multi-mode optic ber 62.5/125μm, 50/125μm(2km, max.).
• Single-mode optic ber 9/125μm (15km, max.)
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet: 100Base-TX and 100Base-FX
IEEE 802.3x Full-duplex flow control
Temperature Operating: 0~50 Degree C
Storage: -40~70 Degree C
Humidity Operating Operating: 5% to 90%, Storage: 5% to 90% (Non-condensing)
Regulation Compliance FCC Part 15 Class A, CE
Ordering Information
FSD-805SC 8-Port 10/100Mbps Desktop Fast Ethernet Switch with 1-Port shared 100Base-FX (SC, Multi-mode~2km)
FSD-805S15 8-Port 10/100Mbps Desktop Fast Ethernet Switch with 1-Port shared 100Base-FX (SC, Single-mode~15km)
Related Products
FSD-805 8-Port 10/100Mbps Desktop Fast Ethernet Switch ( 8 RJ-45, 100m)
