Planet FSD-Series User manual

Trademarks
Copyright  PLANET Technology Corp. 2004
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners. Contents in this docu-
ment are subject to revision without prior notice.
FCC Class A Appliance
This equipment generates and uses radio frequency energy. If it is not installed
and used properly in strict accordance with the manufacturer‘s instructions,
it may cause interference to radio and television reception. It has been type-
tested and found to comply the specications in sub-part J of Part 15 of FCC
Rules, which are designed to provide reasonable protection against such inter-
ference in a residential installation. There is no guarantee that interference will
not occur in a particular installation. If this equipment does cause interference
to radio or television reception which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Re-orient the receiving antenna
Relocate the computing device with respect to the receiver
Move the computer away from the deceiver
Plug the computer into a different outlet so that compute and receiver are on
different electrical circuits.
If necessary the user should consult the dealer or an experienced radio or
television technician for additional suggestions.
CE Mark Warning
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
WEEE Warning
To avoid the potential effects on the environment and human health as
a result of the presence of hazardous substances in electrical and elec-
tronic equipment, end users of electrical and electronic equipment should
understand the meaning of the crossed-out wheeled bin symbol. Do not
dispose of WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Revision
The information in this manual is subject to change without notice.
User's manual for PLANET 8/16-port 10/100Mbps Fast Ethernet Switch
Model: FSD-800/1600/801/1601SC & ST
Rev: 4.0 (July. 2004)
Part No. 2010-000004-003

1
Table of Contents
Chapter 1 General Introduction 1
1.1 Checklist 1
1.2 Introduction 1
1.3 Features 2
Chapter 2 Hardware Description 3
2.1 Front Panel 3
2.1.1 FSD-800/FSD-801 3
2.1.2 FSD-1600/FSD-1601 4
2.2 Rear Panel 5
2.3 Hardware Installation 7
Chapter 3 Configuration and Application 8
3.1 The Switch Operation 8
3.2 The Smart Function (16-port model) 9
3.2.1 TP or Fiber-optic selection (for FSD-1601 only) 9
3.2.2 Port-based VLAN 10
3.2.3 Port-Trunking 10
3.2.4 IP ToS/DS (DiffServ), VLAN Tag Based QoS 10
3.2.5 Port-based priority 11
3.3 Application 11
3.3.1 Basic 100Mbps Server, PCs to 10/100Mbps Switch 11
3.3.2 Connect to 100Base-FX Switch/Device (Model: FSD-801/1601)
12
3.3.3 Set up the workgroup and uplink to the backbone (Model: FSD-
1600/1601) 13
Chapter 4 Troubleshooting 14
Appendix A Specifications 15
Appendix B RJ-45 Pin Specification 17

1
Chapter 1
General Introduction
1.1 Checklist
Check the contents of your package for following parts:
• The Fast Ethernet Switch
• User’s Manual
• Power Cord
If any of these pieces are missing or damaged, please contact your dealer immediately, if
possible, retain the carton including the original packing material, and use them against
to repack the product in case there is a need to return it to us for repair.
1.2 Introduction
The 8/16-port 10/100Mbps Ethernet Switch is designed to allow simultaneous
transmission of multiple packets via an internal high-speed data channel. This means that
it can partition a network more efciently than bridges or routers in most environments.
This Switch is a highly reliable network switch and is the ideal device for bridging Ethernet
to Fast Ethernet workgroups or networks. Simple and cost-effective, the Switch complies
to IEEE802.3u, IEEE802.3, 100Base-TX, and 10Base-T. Therefore, the Switch will be the
fast being recognized as one of the most important building blocks for today networking
technology. Choice of 100Base-FX optic-ber ST/SC interface,
The FSD-801/1601ST&SC are also ideal to extend the network distance up to 2 kilometers
away as a link to your remote backbone.
The Switch also provide rack-mounting kits option for being installed On 10-inch or 19-
inch rack to ease the placement and management effort.
Compact in size and designed for Plug and Play installation, the Switch allows the network
administrator to simply connect the network and power cables and the switching/bridging
functions begin automatically. No hardware or software congurations are required.
The front panel of the Switch provides LED indicators for easy recognition of the switch
operation status and for troubleshooting. These LED indicators display the power status
for the system and link/activity, speed, and full-duplex status for each port.
With 8/16-port Fast Ethernet Switching designed specically for connecting workgroup
devices and desktops, companies no longer have to invest in expensive and inexible
switches engineered primarily for backbone implementations. Instead, companies can
deploy scaleable, affordable switches that increase the aggregate bandwidth of the
network by boosting throughput to the workgroups that need it most.

2
3
1.3 Features
• 8/16-port 10/100base-TX Auto-Negotiation Ethernet Switches
• One optional 100Base-FX fiber port for extending up to 2km
• Complies with the IEEE802.3 Ethernet and IEEE802.3u Fast Ethernet stan-
dard
• Features Store-and-Forward architectures with wire-speed filtering and for-
warding rates
• Provide rack-mounting kit option for 10-inch and 19-inch Rack
• Full/Half-Duplex capability on every TX ports, total bandwidth is up to
200Mbps/port
• Support up to 1K/8K Uni-cast address, Layer 2 address resolution-Self Learn-
ing
• IEEE802.3x compliant full-duplex flow control
• Back pressure half-duplex flow control
• Runt and CRC Filtering eliminates erroneous packets to optimize the network
bandwidth
• Provide internal power supply
• LED indicators for simple diagnostics and management
• Auto- MDI and MDI-X detect for easily connecting to PC or hub/Switch uplink
• DIP Switch for smart function (16-port model only)

2
3
Chapter 2
Hardware Description
This section describes the hardware features of the Switch. For easier management and
control of the Switch, familiarize yourself with its display indicators, and ports. Front panel
illustrations in this chapter display the unit LED indicators. Before connecting any network
device to the hub, read this chapter carefully.
2.1 Front Panel
The unit front panel provides a simple interface monitoring the Switch. It includes a power
indicator for each port.
2.1.1 FSD-800/FSD-801
Figure 2-1 Front Panel of FSD-800 / FSD-801
LED indicators
Printing Color Description
Power
(PWR) Green This indicator lights green when the Switch is receiving power, otherwise it is off.
LNK/
ACT Green
This indicator green when the port is connected to a either
10Mbps Ethernet or 100Mbs Fast Ethernet station, If the
station to which the Switch connected is powered off, or if
there is a problem with the link, the LED will remain off.
And the indicator blinking green when the data will be re-
ceived to all other connected ports.
100 Green
This indicator green when the port is connected to a
100Mbps Fast Ethernet station. If the station to which the
Switch is connected is powered off, a 10Mbps Ethernet
station, or if there is a problem with the link, the LED will
remain off.

4
5
FDX/
COL Amber
Lit: Full duplex operation
Unlit: Half duplex operation
Blink: indicates data collisions on the respective Ethernet
segment of this port. Whenever a collision is detected, the
respective COL indicator will briefly blink.
This is normal when the network is busy.
 NOTE:
Port # 8 of FSD-801 is a shared port. Either Twisted Pair port
or Fiber-optic port can operate in one time. Please power off
FSD-801 before switching the share port to different con-
nection type.
DIP Switch (FSD-801)
Printing Description
FDX (default) The 100Base-FX fiber port of the switch is operating in full-
duplex mode.
HDX The port is operating in half-duplex mode.
 NOTE:
check the opposite end is using the same transmit mode
before make the connection. If you want to adjust the DIP
switch, please power off FSD-801 first.
2.1.2 FSD-1600/FSD-1601
Figure 2-2 Front Panel of FSD-1600/ FSD-1601

4
5
LED indicators
Printing Color Description
Power
(PWR) Green This indicator lights green when the Switch is receiving power; otherwise, it is off.
LNK/
ACT Green
This indicator green when the port is connected to a either
10Mbps Ethernet or 100Mbs Fast Ethernet station , If the
station to which the Switch is connected is powered off, or if
there is a problem with the link, the LED will remain off.
And the indicator blinking green when the data will be re-
ceived to all other connected ports.
100 Green
This indicator green when the port is connected to a
100Mbps Fast Ethernet station. If the station to which the
Switch is connected is powered off, a 10Mbps Ethernet
station, or if there is a problem with the link, the LED will
remain off.
FDX/
COL Amber
Lit: Full duplex operation
Unlit: Half duplex operation
Blink: indicates data collisions on the respective Ethernet
segment of this port. Whenever a collision is detected, the
respective COL indicator will briefly blink
This is normal when the network is busy.
 NOTE:
Port # 16 of FSD-1601 is a shared port. Either Twisted Pair
port or Fiber-optic port can operate in one time.
2.2 Rear Panel
There is one power socket on the back of the switch, 100~240VAC, 50/60Hz. And one
more DIP-switch for FSD-1600 and FSD-1601 for smart function.
Figure 2-3 Rear Panel of the FSD-800/801
Figure 2-4 Rear Panel of the FSD-1600/1601

6
7
DIP Switch (Smart function for FSD-1600/1601)
DIP Function Description
1 TP / FX Selection ON: Enable FX
OFF: Enable TP
2Fiber Full/Half
duplex Switch
ON: Enable Fiber Full Duplex
OFF: Enable Fiber Half Duplex
3VLAN topology
type selection
ON: 15VLANs (port#1-15) with 1 overlapping
port (port#16) topology
OFF: 14VLANs (port#1-14) with 2 overlapping
port (port#15,16) topology
4 Port Based VLAN ON: Enable VLAN
OFF: NO VLAN
5Port Trunk 0
(port 1,2,3,4)
ON: Enable Trunk group 0
OFF: Disable group 0
6Port Trunk 1
(port 5,6,7,8)
ON: Enable Trunk group 1
OFF: Disable group 1
7Port Trunk 2
(port 9,10,11,12)
ON: Enable Trunk group 2
OFF: Disable group 1
8Port Trunk 3
(port 13,14,15,16)
ON: Enable Trunk group 3
OFF: Disable group 3
9
TCP/IP TOS / DS
(Diffserv)
Based QoS
ON: Enable QoS
OFF: Turn off the QoS
10 802.1Q VLAN Tag
Priority Based Qos
ON: Enable
OFF: Disable
11&12 Port Based Prior-
ity QoS
12 11 Description
Off Off Disable
Off On Port 1-2 high priority ports (2 ports)
On Off Port 1-4 high priority ports (4 ports)
On On Port 1-8 high priority ports (8 ports)

6
7
 NOTE:
1. For fiber-optic connection, please check the opposite end is us-
ing the same transmit mode before make the connection.
2. Port#16 of the switch is shared with 100Base-FX port. Make
sure either Fiber-optic or twisted pair port is being connected.
3. For more information about the Smart function, please refer to
Chapter 3.
4. All the DIP is in OFF position by default!
2.3 Hardware Installation
1. Place the Switch on a smooth surface
2. Connect the output cord of power supply to the AC inlet.
3. Connect hub or PC to one port of the Switch using Category 3/4/5 UTP/STP
cabling.
4. Connect another hub or PC to the other port of Switch by following the same
process as described in Step 3.
Notice:
Cable distance for the Switch
The cable distance between the Switch and hub / PC should not exceed 100
meter.
The fiber-optic should not exceed 412 meters in Half-duplex mode and 2 kilome-
ters for Full-duplex mode
Make sure the wiring is correct
It can be used Category 3/4/5 cable in 10Mbps operation. To reliably operate your
network at 100Mbps, you must use an Unshielded Twisted-Pair (UTP) Category 5
cable, or better Data Grade cabling. While a Category 3 or 4 cable may initially
seem to work, it will soon cause data loss.
The fiber-optic cable should be a multi-mode fiber cable with 62.5/125μm or
50/125μm in specification.
You can find the information from the printing of the cable. If you are not familiar
with it, please consult your local dealers for the information.
Power System
The Switch accepts AC input with 100~240V AC, 50/60Hz. To prevent from data
loss or network downtime, consider install an UPS (Un-interrupt Power Supply) for
the Switch. And in some area, a surge suppression device also can help to prevent
from the Switch being damaged by un-regulated surge or current to it.
All kinds of hub / PC can connect to switch by using straight-through wires. The Switch
also supports auto MDI detection. This means you can direct connect any port of the
Switch to another MDI-X devices with a straight wire.

8
9
Chapter 3
Configuration and Application
This chapter shows you how the Switch works, and how to install the Switch and also to
congure the smart functions provided in the 16-port model.
3.1 The Switch Operation
Address Table
The Switch is implemented with an address table. This address table composed of many
entries. Each entry is used to store the address information of some node in network,
including MAC address, port no, etc. The information comes from the learning process
of Ethernet Switch.
Learning
When one packet comes in from any port. The Ethernet Switch will record the source
address, port no. and the other related information in address table. These information
will be used to decide either forwarding or ltering for future packets.
Forwarding & Filtering
When one packet comes from some port of the Ethernet Switch, it will also check the
destination address besides the source address learning. The Ethernet Switch will lookup
the address table for the destination address. If not found, this packet will be forwarded
to all the other ports except the port which this packet comes in. And these ports will
transmit this packet to the network it connected. If found, and the destination address is
located at different port from this packet comes in, the Ethernet Switch will forward this
packet to the port where this destination address is located according to the information
from address table. But, if the destination address is located at the same port with
this packet comes in, when this packet will be ltered. Thereby increasing the network
throughput and availability
Store-and-Forward
Store-and-Forward is one type of packet-forwarding techniques. A Store-and-Forward
Ethernet Switch stores the incoming frame in an internal buffer, do the complete error
checking before transmission. Therefore, no error packets occurrence, it is the best
choice when a network needs efciency and stability.
The Switch scans the destination address from the packet header, searches the routing
table provided for the incoming port and forwards the packet, only if required. The fast
forwarding makes the switch attractive for connecting servers directly to the network,
thereby increasing throughput and availability. However, the switch is most commonly
used to segment existing hubs, which nearly always improves overall performance.
A Ethernet Switch can be easily congured in any Ethernet network environment to
signicantly boost bandwidth using conventional cabling and adapters.
Due to the learning function of the Ethernet switch, the source address and corresponding
port number of each incoming and outgoing packet are stored in a routing table. This
information is subsequently used to lter packets whose destination address is on the
same segment as the source address. This connes network trafc to its respective

8
9
domain, reducing the overall load on the network.
The Switch performs “Store-and-forward” therefore, no error packets occur. More
reliably, it reduces the re-transmission rate. No packet loss will occur.
Auto-Negotiation
The STP ports on the Switch have built-in "Auto-Negotiation." This technology
automatically sets the best possible bandwidth when a connection is established with
another network device (usually at Power On or Reset). This is done by detect the modes
and speeds at the second of both device is connected and capable of. Both 10Base-T and
100Base-TX devices can connect with the 100Base-TX port in either Half- or Full-Duplex
mode.
If attached device is: 100Base-TX port will set to:
*10Mbps, no auto-negotiation 10Mbps
*10Mbps, with auto-negotiation 10/20Mbps (10Base-T/Full-Duplex)
*100Mbps, no auto-negotiation 100Mbps
*100Mbps, with auto-negotiation 100/200Mbps (100Base-TX/Full-Duplex)
3.2 The Smart Function (16-port model)
The FSD-1600 and FSD-1601 is with one DIP switch on the rear of the switch, these ON/
OFF switches provides the functions as below:
• Twisted Pair or Fiber-optic selection
• Port based VLAN
• Port Trunking
• ToS/ QoS selection
• Priority Setup
They are all in OFF position by default!
3.2.1 TP or Fiber-optic selection (for FSD-1601 only)
Related DIP: 1, 2
Default meaning: Port#16 runs in Twisted pair, Auto-Negotiation.
DIP 1: Turns on will force the ber-optic port enabled.
 NOTE: Please do not turn on if you are using FSD-1600.
DIP 2: Turns on will force the 100Base-FX ber-optic port runs in Full-duplex mode.

10
11
3.2.2 Port-based VLAN
Related DIP: 3, 4
Default meaning: No VLAN setting.
VLAN can be used to separate ports into different groups in the same switch. This will
secure port from being accessed by other ports on the switch.
DIP 4: Turns on will enable the port-based VLAN capability
DIP 3: The two positions represent two different VLAN choices:
OFF:There are 14 VLANs. Port 1 to Port 14 can communicate with Port 15,
and Port 16 where 1 to 14 cannot see each other.
ON: There are 15 VLANs. Port 1 to Port 15 cannot see each other but they
all can retrieve data from port 16. i.e. members of VLAN 1 are 1 & 16,
VLAN 2 are 2 & 16, VLAN 3 are 3 & 16, etc.
3.2.3 Port-Trunking
Related DIP: 5, 6, 7, 8
Default meaning: No port-trunking.
Port trunks will four times the bandwidth (800Mbps) while connecting with another
switches that also with port trunk capability. Up to four groups where each group with 4
ports is allowed.
DIP 5: Turns on to enable trunk 0, from port 1 to port 4.
DIP 6: Turns on to enable trunk 1, from port 5 to port 8.
DIP 7: Turns on to enable trunk 2, from port 9 to port 12.
DIP 8: Turns on to enable trunk 3, from port 13 to port 16.
 NOTE: Turn on the Trunk will also disable VLAN capability.
3.2.4 IP ToS/DS (DiffServ), VLAN Tag Based QoS
Related DIP: 9, 10
Default meaning: No priority-packet detection.
The Switch will store each incoming packets and check the tag eld to determine the
priority, high or low. Then follow the priority to forward to the destination.
The Switch supports two types of detection.
• VLAN Tag-based detection (Layer 2)
• ToS/DS (DiffServ) detection (IP Layer 3)
DIP 9: Turns on for IP ToS/DS QoS.

10
11
DIP 10: Turns on for VLAN tag priority QoS.
 NOTE:
The connected end-nodes (PCs, Routers) should also support
VLAN priority or ToS priority. Normally, these functions could
turn off by default. Check the user’s guide of your networked
device for this capability.
3.2.5 Port-based priority
Related DIP: 11, 12
Default meaning: No hardware port priority.
If your end-nodes do not support priority, and you would like to preserve more bandwidth
for those network users, port-based priority will direct set the related port to high
priority.
DIP 11 DIP 12 Description
ON OFF Port 1 and Port 2 are high priority ports
OFF ON Port 1~ 4 are high priority ports
ON ON Port 1 ~8 are high priority ports
 NOTE:
FSD-1600/1601 only support dual priority, this means the
priority only will be HIGH or LOW no matter which port you
connected to.
 NOTE: Priority support can co-work with VLAN.
3.3 Application
3.3.1 Basic 100Mbps Server, PCs to 10/100Mbps Switch
Plug one end of the Category 5 UTP Cable into any one port of the Switch, and the other
end of this cable into the RJ-45 of Fast Ethernet Adapter in the server or PC. The cable
length between these 2 connecting points should not exceed 100 meters.

12
13
Figure 3-1 10/100Mbps File server to Switch Connection
3.3.2 Connect to 100Base-FX Switch/Device (Model: FSD-801/1601)
Plug the pair the ber-cable to the Switch’s ber-optic port, secure the ber-optic
connector. Connect to other end to the ber-optic port of the device like repeater hub,
switch or workstations.
Be noted for the duplex mode. For Hub, only Half-Duplex mode can be selected, at the
mean time, the cable distance cannot exceed 412 meters. For Switch or end-node that
works on full-duplex mode, the maximum distance cannot exceed 2 kilometers.
The pair of the connectors must be crossed, ie. TX/RX port of the Switch should connect
to RX/TX Port of the device in other end.
Consult your local dealer for more information about ber-optic wires, connector type or
network distances.
Figure 3-2 Fiber-cable Switch to Switch Connection

12
13
3.3.3 Set up the workgroup and uplink to the backbone (Model: FSD-
1600/1601)
Figure 3-3 Connection with VLAN enable
Turn on the DIP 4, the FSD-1600 soon separate the fourteen ports (Port 1 to Port 14) into
different group, then you can install two le servers to port 15, port 16, those fourteen
users shall not see each other where they can freely access the information from the
two le server. Or, port 15 is connect to your local server and port 16 up connect to your
networks backbone, either 100 meters (FSD-1600) or 2 kilometers away (FSD-1601, both
DIP 1 & 2 in ON position)
3.3.4 Set up Video/Voice Networks (Model: FSD-1600/1601)
Some networks could have a devices like Video or Voice device like Internet Telephony
Gateway, the support of priority may help you to make your voice or video in higher
position to get the precious networks bandwidth, for example to the Intermet.
If your Voice Gateway support ToS, you may direct turn on the DIP 9 to get the higher
priority, or if your device or network nodes do not support you can turn on DIP 11 or DIP
12 to have the hardware priority,
Figure 3-4 3 Voice Gateway to Switch Connection

14
15
Chapter 4
Troubleshooting
This chapter contains information to help you solve problems. If the Switch is not
functioning properly, make sure the Switch was set up according to instructions in this
manual.
The Link LED is not Lit
Solution:
Make sure the switch conguration is consistent with the connecting device
Check the cable connections.
Performance is bad
Solution:
Check the full duplex status of the Ethernet Switch. If the Ethernet Switch is set to full
duplex and the partner is set to half duplex, then the performance will be poor.
Some stations can not talk to other stations located on the other port
Solution:
The address table may contain older information than of the address table of that node.
Please power down to refresh the address information.

14
15
Appendix A
Specifications
General (Ethernet)
Standards: IEEE 802.3 10Base-T EthernetIEEE 802.3u 100 Base-TX and
100Base-FX Fast EthernetIEEE 802.3x Flow control
Protocol: CSMA/CD
Data Transfer
Rate:
Ethernet:
10Mbps(half duplex) / 20Mbps (full duplex) Fast Ethernet:
100Mbps (half duplex) / 200Mbps (full duplex)
Topology: Star
General (Cabling)
Network Cables:
• 10Base-T:2-pair UTP Cat. 3,4, 5 (100 m, max.)EIA/TIA-
568 100-ohm STP (100 m, max.)
• 100Base-TX:2-pair UTP Cat. 5 (100 m, max.)EIA/TIA-568
100-ohm STP (100 m, max.)
• 100Base-FX: (Models: FSD-4/8/1601)
1-pair Multi-mode optic fiber 62.5/125μm, 50/125μm(2
km, max.)
Number of
Ports:
8/16-STP ports
Models:FSD-8/1601
1-ST/SC fiber-optic port (1300nm wavelength)
Hardware Physical /Environmental Specification
AC inputs 100~240VAC, 50/60Hz
Power Con-
sumption 15~25 watts
LED Indication System : PowerPort: 3 LED Indicators per port
(LINK/ACT, 100, FDX/ COL)
Operating Tem-
perature 0 ~ 50 degree C
Storage Tem-
perature -20 ~ 70 degree C
Humidity 10% ~ 90% non-condensing
Dimensions 220 x 135 x 44 mm (W x D x H)

16
17
EMI FCC Class A, CE Mark Class A
Performance
Transmission
Method Store-and-forward
Filtering Address
Table 1/8K entries
Packet Filtering/
Forwarding Rate
14,880pps per port (for 10Mbps)
148,800pps per port (for 100Mbps)
MAC Address
Learning Automatic update / Max age: fixed

16
17
Appendix B
RJ-45 Pin Specification
When connecting your FSD-series 10/100Mbps Ethernet Switch to another switch, a
bridge or a hub, a modied crossover cable is not necessary. Each port of the Switch
is auto-MDI detection. That means you can direct connect the Switch to any Ethernet
devices with a Category 5, UTP straight wire.
However, the following diagram and tables also show the standard RJ-45 receptacle/
connector and their pin assignments for the switch-to-network adapter card connection,
and the straight / crossover cable for the Switch-to-switch/hub/bridge connection.
RJ-45 Connector pin assignment
Contact Media Direct Interface Signal Media Direct Interface -Cross
1 TX + (transmit) Rx + (receive)
2 TX - (transmit) Rx - (receive)
3 Rx + (receive) TX + (transmit)
4, 5 Not used
6 Rx - (receive) TX - (transmit)
7, 8 Not used
The standard cable, RJ-45 pin assignment
The standard RJ-45 receptacle/connector

18
This page is intentionally left blank
