Planet FGSD-1008HPS User manual

8/16/24-Port 10/100TX 802.3at PoE +
2-Port Gigabit TP/SFP Combo
Managed Ethernet Switch
FGSD-1008HPS/FGSW-1816HPS/FGSW-2624HPS/
FGSW-2624HPS4
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. Requirements ............................................................................................. 4
3. Starting Web Management .......................................................................... 5
3.1 Logging in to the Managed PoE Switch .................................................. 5
 3.2 SavingCongurationviaWeb ............................................................... 7
4. Terminal Setup (FGSW-2624HPS Only) .......................................................... 8
4.1 Logging on to Console ......................................................................... 9
 4.2 ConguringIPAddress......................................................................... 9
 4.3 StoringCurrentSwitchConguration....................................................10
5. RecoveringBacktoDefaultConguration.....................................................11
6. Customer Support .....................................................................................12

3
1. Package Contents
Thank you for purchasing PLANET 8/16/24-Port 10/100TX 802.3at PoE + 2-Port
Gigabit TP/SFP Combo Managed Ethernet Switch, FGSD-1008HPS, FGSW-1816HPS,
FGSW-2624HPS and FGSW-2624HPS4.
“Managed PoE Switch” mentioned in this quick installation guide refers to the
above switch products.
Open the box of the Managed PoE Switch and carefully unpack it. The box should
contain the following items:
zThe Managed PoE Switch x 1
zQuickInstallationGuidex1
zRS232 to RJ45 Cable x 1 (FGSW-2624HPS only)
zRubber Feet x 4
zTwoRack-mountingBracketswithAttachmentScrewsx1
zPower Cord x 1
zSFP Dust-proof Caps x 2
If any item is found missing or damaged, please contact your local reseller for
replacement.

4
2. Requirements
zWorkstations running Windows 10/XP/2003/Vista/7/8/2008, MAC OS X or later,
Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerial Port Connection (Terminal) (FGSW-2624HPS only)
 The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
The above Workstations have been installed with terminal emulator,suchas
HyperTerminalincludedinWindowsXP/2003.
 Serial cable -- one end is attached to the RS232 serial port, while the other
end to the console port of the FGSW-2624HPS.
zEthernet Port Connection
 Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.
The above PC is installed with Web browser and JAVA runtime environment
plug-in.
Note
It is recommended to use Internet Explorer 8.0 or above to access
the Managed PoE Switch. If the Web interface of the Managed PoE
Switch is not accessible, please turn off the anti-virus software or
firewall and then try it again.

5
3. Starting Web Management
The following shows how to start up the Web Management of the Managed
PoE Switch. Note the Managed PoE Switch is congured through an Ethernet
connection. Please make sure the manager PC must be set to the same IP subnet
address.
Forexample,thedefaultIP addressoftheManagedPoESwitchis192.168.0.100,
then the manager PC should be set to 192.168.0.x (where x is a number
between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with Telnet Client
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address:
192.168.0.100
Figure 3-1: IP Management Diagram
Note
The following web screen is based on the FGSW-2624HPS4; the
display of the FGSW-2624HPS4 is the same as that of the FGSD-
1008HPS,FGSW-1816HPSandFGSW-2624HPS.
3.1 Logging in to the Managed PoE Switch
1. Use Internet Explorer 8.0 or above Web browser and enter IP address
http://192.168.0.100(thefactorydefaultIPaddressortheonethatyouhave
just changed in console) to access the Web interface.
2.When the following dialog box appears, please enter the default user name and
password “admin” (or the password you have changed via console). The login
screen in Figure 3-2 appears.

6
DefaultIPAddress:192.168.0.100
DefaultUsername:admin
Default Password: admin
Figure 3-2: Login Screen
3.Afterenteringthepassword,themainscreenappearsasFigure3-3shows.
Figure 3-3: Web Main Screen of Managed PoE Switch

7
The Switch Menu on the top and left of the Web page lets you access all the
commands and statistics the Managed PoE Switch provides.
Figure 3-4: Switch Menu
Now, you can use the Web management interface to continue the Switch
management or manage the Switch by console interface.
Please refer to the user’s manual for more.
3.2 SavingCongurationviaWeb
To save all applied changes and set the current conguration as a startup
conguration, the startup-conguration le will be loaded automatically across a
system reboot.
1. Click the Save icon on the top Switch Menu bar.
Figure 3-5: Save Cong -- Hot key

8
4. Terminal Setup (FGSW-2624HPS Only)
Tocongure thesystem,connectaserialcabletoaCOMporton aPCornotebook
computer and to RJ45 type of serial port of the FGSW-2624HPS.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port
RS232 to RJ45 Cable
Console Port
RJ45
Figure 4-1: FGSW-2624HPS Console Connectivity
A terminal program is required to make the software connection to the FGSW-
2624HPS.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
Baud: 115200
Data bits: 8
Parity:None
Stop bits: 1
Flow control:
Figure 4-2: COM Port Conguration

9
4.1 Logging on to Console
Once the terminal is connected to the device, power on the FGSW-2624HPS and
the terminal will display “running testing procedures”. Then, the following message
asks to log in user name and password. The factory default user name and
password are shown as follows and the login screen in Figure 4-3 appears.
Username:admin
Password: admin
Welcome to FGSW-2624HPS it is Thu Jan 00:01:47 UTC 1970
Figure 4-3: FGSW-2624HPS Console Login Screen
The user can now enter commands to manage the FGSW-2624HPS. For a detailed
descriptionofthecommands,pleaserefertothefollowingchapters.
Note
1. For security reason, please change and memorize the new pass-
word after this first setup.
2. Only accept command in lowercase letter under console inter-
face.
4.2 ConguringIPAddress
TheFGSW-2624HPSisshippedwithdefaultIPaddressshownbelow.
IPAddress:192.168.0.100
Subnet Mask: 255.255.255.0
To check the current IP address or modify a new IP address for the Switch, please
use the procedures as follows:
ShowthecurrentIPAddress
1.Atthe“>”prompt,enter“show ip”.

10
2.ThescreendisplaysthecurrentIPaddressasshowninFigure4-4.
> show ip
IPAddress:192.168.0.100
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.0.254
DNSServer:
DHCP Client: Disabled
Figure 4-4: IP Information Screen
ConguringIPAddress
3.At the “>” prompt, enter the following command and press <Enter> as shown
in Figure 4-5.
>congipaddress192.168.1.100
>congipsubmask255.255.255.0
Figure 4-5: Conguring IP Address Screen
The previous command would apply the following settings for the FGSW-2624HPS.
IPAddress:192.168.1.100
Subnet Mask: 255.255.255.0
4.Repeatstep1tocheckiftheIPaddresshaschanged.
4.3 StoringCurrentSwitchConguration
Atthe“>”prompt,enterthefollowingcommandandpress<Enter>.
> save
Figure 4-6: Saving Current Conguration Command Screen
If the IP is successfully congured, the FGSW-2624HPS will apply the new IP
address setting immediately. You can access the Web interface of the FGSW-
2624HPSthroughthenewIPaddress.
Note
If you are not familiar with the console command or the related
parameter, enter “?” anytime in console to get the help descrip-
tion.

11
5.RecoveringBacktoDefaultConguration
IPaddresshasbeenchangedoradminpasswordhasbeenforgotten–
To reset the IP address to the default IP address “192.168.0.100” or reset the
login password to default value, press the hardware-based reset button on the
front panel for about 5 seconds. After the device is rebooted, you can log in to
the management Web interface within the same subnet of 192.168.0.xx.
FGSD-1008HPS
1357
2468
PWR
Gigabit
Reset
10
9
ACTLNK
ACT1000 LNK
PoE-in-Use
PoE
8-Port 10/100TX 802.3at PoE +
2-Port Gigabit Managed Switch PoE Power Usage (W)
120
90
60
30
Figure 5-1: FGSD-1008HPS Reset Button
2
1
PWRReset
2 4 6 8 10 12 14 16
1 3 5 7 9 11 13 15
FGSW-1816HPS
PoE
PoE
ACTLNKPoE-in-Use
PoE Power Usage
190W
150W
100W
50W
Figure 5-2: FGSW-1816HPS Reset Button
Figure 5-3: FGSW-2624HPS Reset Button
42
1 3
PWR
Reset
2 6 10 14 18 22
4 8 12 16 20 24
1 5 9 13 17 21
3 7 11 15 19 23
PoE
FGSW-2624HPS4
24-Port 10/100TX 802.3at PoE + 2 Gigabit Managed Switch
400W
PoE Power Usage
300W
200W
100W
ACTLNKPoE-in-Use
Figure 5-4: FGSW-2624HPS4 Reset Button

12
6. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resourceand User’sManual onPLANETWebsiterst tocheckif itcouldsolveyour
issue.If youneedmore supportinformation,pleasecontactPLANET switchsupport
team.
PLANETonlineFAQs:
http://www.planet.com.tw/en/support/faq
Switch support team mail address:
[email protected]
FGSD-1008HPS(v2),FGSW-1816HPS(v2),FGSW-2624HPS(v3)andFGSW-2624HPS4(v2)
User’sManual:
http://www.planet.com.tw/en/support/downloads?method=category&c1=lan-
switches&p=&type=3
(Please select your switch model name from the drop-down menu of Product
Model.)
