Planet WGSW-14020 User manual

10/100/1000Mbps
Managed Gigabit Ethernet Switch
WGSW-14020
User s Manual

Trademarks
Copyright PLANET Technology Corp. 2003.
Contents subject to revision without prior notice.
PLANET is aregistered trademark ofPLANET Technology Corp. All other trademarks belong
to their respective owners.
Disclaimer
PLANET Technology does notwarrant that the hardware will work properly in all environments
and applications,and makes no warranty and representation, either implied orexpressed,with
respect to the quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensurethat this User sManual is accurate; PLANET
disclaims liability for any inaccuracies or omissions thatmay have occurred.
Information in this User sManual is subject to change without notice and does not represent a
commitment on the part of PLANET. PLANETassumes no responsibility for any inaccuracies
thatmaybe contained in this User s Manual.PLANET makes no commitmentto update or keep
current the information in this User sManual,and reserves the rightto make improvementsto
this User sManual and/or to the productsdescribed in this User sManual, at any time without
notice.
If you find information in this manual that is incorrect, misleading, or incomplete, wewould
appreciate your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuantto Part15 ofthe FCC Rules. These limitsare designed to provide reasonable
protection against harmful interference when the equipment is operated in acommercial
environment.This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the Instruction manual,may cause harmful
interference to radio communications. Operation of this equipment in aresidential area is likely
to cause harmful interference in which case the user will be required tocorrect the interference
at his own expense.
CE Mark Warning
This is aClass Aproduct. In adomestic environment, this product may cause radio interference,
in which case the user may be required to take adequate measures.
Revision
PLANETManaged Gigabit Ethernet Switch User's Manual
FOR MODELS: WGSW-14020
Part No.: EM-WG14

TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION..................................................................................................1
1.1 CHECKLIST.........................................................................................................................1
1.2 ABOUT THE SWITCH............................................................................................................1
1.3 FEATURES..........................................................................................................................1
1.4 SPECIFICATIONS.................................................................................................................2
CHAPTER 2 HARDWAREINSTALLATION.............................................................................3
2.1 FRONT PANEL.....................................................................................................................3
2.2 REAR PANEL ......................................................................................................................5
2.3 HARDWARE INSTALLATION...................................................................................................6
2.4 STACK INSTALLATION..........................................................................................................8
CHAPTER 3 CONSOLEAND TELNETMANAGEMENT.........................................................9
3.1 CONNECT TO PC BY RS-232 SERIAL CABLE........................................................................9
3.2 TELNET ............................................................................................................................10
3.3 MAIN MENU......................................................................................................................10
CHAPTER 4.WEB MANAGEMENT.......................................................................................11
4.1 START AWEB BROWSER SESSION....................................................................................11
4.2 STACK MAIN PAGE............................................................................................................12
4.3 SWITCH MAIN PAGE..........................................................................................................13
4.4 DEVICE CONFIGURATION...................................................................................................16
4.5 TOPOLOGY INFO...............................................................................................................17
4.6 PORTS .............................................................................................................................17
4.7 SECURITY.........................................................................................................................21
4.8 SNMP.............................................................................................................................21
4.9 VLAN..............................................................................................................................23
4.10 PORT AGGREGATION ......................................................................................................25
4.11 STA...............................................................................................................................26
4.12 ADDRESS TABLE.............................................................................................................29
4.13 MIRROR .........................................................................................................................30
CHAPTER 5.TROUBESHOOTING........................................................................................31
APPENDIXA...........................................................................................................................32
A.1 SWITCH‘S RJ-45 PIN ASSIGNMENTS..................................................................................32
A.2 10/100MBPS, 10/100BASE-TX........................................................................................32
A.3 RJ-45 CABLE PIN ASSIGNMENT..........................................................................................33

- 1 -
CHAPTER 1. INTRODUCTION
1.1 Checklist
Check the contents of your package for following parts:
lWGSW-14020.
lCD-ROM.
lQuickInstallation Guide
lPower cord.
l19”rack-mount brackets.
lRS-232 cable.
If anyof these pieces are missing or damaged, pleasecontact your dealer immediately,if
possible, retain the carton includingtheoriginal packing material,andusethemagainst to
repackthe product in case there is a needto return it to us for repair.
1.2 About the Switch
WGSW-14020 is apowerful, high-performance 14G+2slot 10/100/1000Mbps Fast
Ethernet and Gigabit managed switch with fourteen10/100/1000Mbps ports and two
slide-in slot. The available modules including 10/100/1000Base-T,1000Base-SX and
1000Base-LX. It is ideal for backbone connection toother workgroup products.
WGSW-14020 provideswitch stacking functiontomanageupto8switches bysingleIP
address. Throughits proprietarymanagement bus usingstandardRJ-45 cable,the
distancebetween stacked switches canbeupto800m.The management bus traffic is
separatedfromthe network ports, ensuring heavy networkloadingnot affect management
tasks. You can manage upto 128 Gigabit Ethernet ports byjust an IP address.
With much powerful software capability,the device could be managed byconsole, telnet
and the web. SNMP MIBII, Bridge MIBandenterprise privateMIBarealso supported to
get themaximummanagement functionality.This is much useful for systemmanager to
monitor thesystemefficiently.Moreover,therichdiagnosticLEDs also provide agood
wayfor troubleshooting.The standardIEEE 802.1Q withVLANtaggingfeaturemakes
logicallyseparatingnodes easier with up to 255VLAN groups allowed. Port trunking is
also supported with up to 8trunkgroups on single switch. Toease network
troubleshootingbysniffer software,WGSW-14020 also supports port mirror toduplicate
up to2 ports transmitting and receivingpackets to specified sniffer port.
1.3 Features
w 14 port 10/100/1000Base-Tand 2 slot for 1000Base-Tor 1000Base-SX/LX module
w 32Gbps switch fabric
w Provide 4K MAC address entries
w The whole switchingclustercouldstackup to 8 sets and management bysingle IP
w Proprietarymanagement bus extendup to 800mfor management stacking
w Complies withIEEE 802.3x, full-duplex flowcontrol,IEEE 802.1DSpanningTree
Protocol, IEEE 802.3z1000Base-SX/LX, IEEE 802.3ab1000Base-T,IEEE
802.3/802.3u (10/100Base-TX), IEEE 802.1Q VLAN

- 2 -
w Configurable throughconsole,Telnet, Web and SNMP
w Support SNMP MIB II (RFC1213), Bridge MIB (RFC 1493) andenterprise private MIB
w Port Trunking Support
w Port Mirroring for dedicated ports monitoring
w MDI/MDI-X auto-detection
1.4 Specifications
Model WGSW-14020
NetworkPorts 14 x RJ-45, 10/100/1000Base-T
StackPorts 2 x RJ-45
Module slot 2, 1000Base-T, 1000Base-SX, 1000Base-LX
Console 1 x RS-232 DB-9
StackID selection Knobwith 8settings (0~7)
MAC address table size 4k
SwitchFabric 32Gbps
Transmission method Store-and-forward
Packet Buffer Memory 272K Bytes
LEDs System: PWR, Master, Status
Per port:ACT, 10, 100, 1000
Port Module: LNK, ACT
Stack: LNK
Cables 10Base-T: 2-pair UTP Cat. 3,4,5 up to 100m
100Base-TX: 2-pair UTP Cat.5, up to 100m
1000Base-T: 4-pair UTP Cat 5, up to 100m
1000Base-SX: 50/125 and 62.5/125 fiber-optic cable, up to 550m
1000Base-LX: 9/125 fiber optic cable, up to 10km
50/125 and 62.5/125 fiber-optic cable, up to 550m
RackMount 19”rackmount, 1U height
Dimension 440 x 285 x 44 mm
Operating Environment Temperature: 0~50 degreeC(operating), -20~70 degreeC
(storage)
Humidity:0~90%,non-condensing
Power Supply 100~240VAC, 50~60Hz, auto-sensing
EMC/EMI FCC, CE
Management Interface Web, Console, TelnetandSNMP
Protocols and Standards IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3z/802.3ab (Gigabit Ethernet)
IEEE 802.3x (flow control)
IEEE 802.1D Spanning Tree
IEEE 802.1Q VLAN tag
RFC 768UDP
RFC 783 TFTP
RFC 791IP
RFC 792ICMP
RFC 826ARP
RFC 854 Telnet
RFC 2068 HTTP
NetworkManagement RFC 1157 SNMPv1/v2
RFC 1123 MIB-2
RFC 1493Bridge MIB

- 3 -
CHAPTER 2. HARDWARE INSTALLATION
This product series providethree different operating speeds –10Mbps, 100Mbps, and
1000Mbps in the sameswitch andautomaticallydistinguish thespeed ofincoming
connection.
This section describes thehardwarefeatures andinstallation ofthese Switches. For
easier management and control ofthe switch, familiarize yourselfwith itsdisplay
indicators, andports. Front panelillustrations in this chapterdisplaytheunitLED
indicators. Before connecting anynetworkdevice tothe switch, readthis chapter
carefully.
There are threechoices ofdifferent modules for expansion:
l WGSW-D1GT:10/100/1000Base-Tmodule
l WGSW-D1SX:1000Base-SX module
l WGSW-D1LX:1000Base-LX module
2.1 Front Panel
The unit front panel provides a simple interface monitoring the switch.
GSW-1402S
STATUS LNK
MASTER
PWRACT 12345678910111213141516
Intelligent 10/100/1000Mbps Ethernet Switch
WGSW-14020
STACK
INOUT
SWITCH ID
LNK
RESET
1234567891011121314
LNK
10
100
1000
WGSW-14020 Switch front panel
LED indicators
PWR Green On: Power on
MASTER Green When this LED steady green, it means the device acts
competent leading role(Master), an indispensable essential for
system administrator to control and monitor whole system.
At the time one member ofthe cluster disconnected or new
member joined, the LED blinks. Soon, one and only one master
will be raised.You can refer to “SWITCH ID”forrelative
information.
STATUS Green Blink: Run Time Error occurs
ACT Green Blink: There is traffic transverses the port
10
100
LNK 1000
Green On: I
ndicate link status and traffic speed (10 for 10Mbps, 100 for
100Mbps, 1000 for 1000Mbps)
LNK –15/16 Green On: Indicate the link status of network port on module
LNK STACK Green On: The switch is stacked to others
Off: The switch is standalone or the stack link have problem

- 4 -
Stack ports
There are twostackports on thefront panel. One is IN andtheother is OUT.When
stacked, the IN port should connect to the other switch sOUTport and the OUTport
should connect toother switch sIN out. You can just use normal Cat 5or better cable with
RJ-45 connector to stack. Onlystraight-through UTP/STPcable can be used.There is no
Duplex Mode issue and themaximumdistance between first and last switchis 800m.
SWITCH ID
Each switch onastack must have auniqueswitch ID.There are eightdegrees (0~7) in
the rotaryswitch. The switch with least switch ID will becomemaster switch and the
others becomeslave. Ifmaster switch is fail or disconnected tothe switch bystack port,
the switch with least switch ID will becomemaster.
Reset button
At the middle offront panel,the reset button is designed for reboot the switch without turn
off and on the power.
Networkports
There are 1410/100/1000Mbps RJ-45(copper) ports on thefront panel.The
auto-negotiationfeatureof the switch allowseach port of the device running at oneof the
following operation modes:
Speed Duplex Mode
Full Duplex10Mbps HalfDuplex
Full Duplex100Mbps HalfDuplex
1000Mbps Full Duplex
All ports supports MDI/MDI-X auto crossover capabilitythat is the port canconnect either
the PC or hub withoutcrossover cableadjustment. Followingarethesummaries of
cabling required:
Media Speed Wiring
10Mbps Category3,4,5 UTP/STP
100Mbps Category5 UTP/STP
10/100/1000
Mbps copper
1000Mbps Category5 UTP/STP

- 5 -
2.2 Rear Panel
The rear panelofthe switch indicates anAC inlet power socket, which acceptsinput
power from100 to240VAC,50-60Hz, oneRS-232consoleportfor setting up theswitch
via a connectiontoa terminal or PC using aterminal emulation program,and two slide-in
slots for installing additional modules.
1516 CONSOLE
9600, 8, N, 1
100-240VAC
50-60Hz
WGSW-14020 Switch front panel
Slide-in slots
The twoslide-in slots onthe rear panel are reserved for following optionalgigabit
modules. Theycan provide fat pipes for up linking to backbone or connecting to servers.
1000Base-SX
WGSW-D1SX TXRX
1000BASE-SX : WGSW-D1SX
1000Base-LX
WGSW-D1LX TXRX
1000BASE-LX : WGSW-D1LX
1000Base-T
WGSW-D1GT
1000BASE-T: WGSW-D1GT
The following is thegigabit module operation and cabling required:
Media Speed Duplex Mode Wiring Distance
10Mbps Full / HalfCategory3,4,5 UTP/STP 100m
100Mbps Full / HalfCategory5 UTP/STP100m
1000BASE-T
1000Mbps Full Category5 UTP/STP100m
62.5/125 µmMMF 220m1000BASE-SX 1000Mbps Full 50/125 µmMMF 500m
62.5/125 µmMMF 550m
50/125 µmMMF 550m
1000BASE-LX 1000Mbps Full
9/125 µmSMF 10km
Console Port
The RS-232 console is aninterface for connectingaterminal directly.Through the
console port, it provides richdiagnostic information includes network statistics, linkstatus
and systemsetting. The operating mode ofthe console port is:
♦ DCE
♦ 9600(Fix baud rate)
♦ n (No paritychecking)
♦ 8 (8 Data bits)
♦ 1 (1 stop bit)
♦ None (No flowcontrol)

- 6 -
You can use anormal RS-232 cable and connect to the console port onthe device. After
the connection, you can runanyterminal emulation program(Hyper Terminal, Winterm,
Telix, and soon) to enter the startup screen ofthe device.
Power Receptacle
For compatibility with electric service in most areas ofthe world, the switchspowersupply
automaticallyadjusts to linepower in the range100-240 VAC and 50-60Hz.
Plugthefemale endofthepower cordfirmlyinto thereceptacle on therear panelofthe
switch. Plugthe other endof the power cord into an electric service outletthen thepower
will be ready.
Power Notice:
1.The deviceisapower-requireddevice, itmeans, it will not worktill itispowered.If your
networksshould active all the time, pleaseconsider usingUPS (UninterruptedPower
Supply) for your device. It will prevent you fromnetworkdata loss or networkdowntime.
2.In somearea, installingasurge suppression device may also help to protect your switch
frombeing damaged byunregulatedsurge or current tothe Switch orthepower
adapter.
2.3 Hardware Installation
This switchcanbeplaced directlyon your desktop, ormounted in a rack. If youinstall the
device in a normal-standalone standard, the switch is an Intelligent Switch, and users can
immediatelyuse most ofthe features simplybyattaching the cables andturning the
power on. In this case, anymanagerial proceedings areeffective onlyin the rangeofthe
switch. After management stacking, you can enjoythepowerful management functions
and control the whole system.
Desktop Installation
For desktop installation,theswitchneedstoputonaclean,flat deskor tableclose toa
power outlet. Plug in all networkcables and the power cord, then the systemis ready.
Before installing the switch, you must ensure:
1. It is accessible and cables can be connected easily.
2. Cabling is awayfrom:
w Sources ofelectrical noise such as radios, transmitters and broadband amplifiers
w Power lines and fluorescent lightingfixtures.
3. Keepwater or moisture off.
4. Airflow aroundtheunit andthroughthevents in the sideofthe case is great for heat
radiation (companyrecommend that youprovide a minimumof25 mmclearance).
To prolongtheoperationallife of your units:
1. Never stackunit more than eight sets highiffreestanding.
2. Do not place objects on topofanyunit or stack.
3. Do not obstruct anyvents at the sides ofthe case.

- 7 -
Rack-mount Installation
The switch maystandalone, or maybemounted in astandard 19-inch equipment rack.
Rackmountingproduces an orderlyinstallation whenyou haveanumber ofrelated
networkdevices. The switchis suppliedwithrack mounting brackets and screws. These
are used for rackmounting the unit.
RackMounting the Switchin the19-inch rack:
1. Disconnect all cables fromthe switchbefore continuing.
2. Placetheunit the right way up on a hard, flat surface with the front facing toward
you.
3. Locate a mounting bracket over the mounting holes onone side ofthe unit.
4. Insert thescrews and fullytighten witha suitable screwdriver.
5. Repeat the two previous steps for the other side ofthe unit.
6. Insert theunit intothe19" rackand secure with suitable screws (not provided).
7. Reconnect all cables.
Installing Network Cables
StationConnections -
Refer to the wiring statement oftheprevioussection; connect each station to theswitch
with correct type ofcables.
Switch-to-Switch Connections –
In making aswitch-to-switch connection, use Gigabit ports to connect another switch or
backbone isstrongly recommended. The Gigabit ports providethefat pipetotheserver or
backbone connectivityfor boosting thetotal systemperformance. Refer to thewiring
statement ofthe previous section;connect each stationto the switch withcorrect type of
cables.
Furthermore, as the switch supports Port Aggregation (Port Trunk) capabilityandup to 8
groups, itis alsogreattobuildupswitch-to-switch connectivity.For detail information,
please refer to the console and web management section.
ModuleInstallation
The two slide-in slots on the rear panel are purposed for installing optional modules. They
can beusedas a networkbackbone or connect toaserver. Follow the steps as described
to install a module:
1. Power off the switch.
2. Removing the two screws on theface plate ofslide-in slot witha flat-head
screwdriver.
3. Push the modulegentlyinto theslot along the slide tracks.
4. Ensuring that it firmlyengages with the connector then tighten the screws to secure
the module.
NOTE: The slide-in slots are not hot swappable, power off the switch before installing
modules.

- 8 -
2.4 Stack Installation
There are two RJ-45 ports on the front panel for proprietarymanagement stack.Only
straight-through UTP/STPcable can be used.
Plugone end ofthe cablein the “IN”port andtheother endto the ”OUT”port ofnext
device. Repeat the step for everydevice in the stackcluster, then ending at last switch.
NOTE:Before management stacking, be sureofeverydevice uses aunique “SWITCH
ID”,or the management stackwill not work.The switch withleast SWITCH ID
will becomeMaster.OnlyMasterswitch smanagement interface (console,
telnet, web and SNMP) is accessible.
Please find thefollowingpicture for sample connection. Please notethe stack port is for
management only.For data packets to be transmitted between switches, youwill still
needto connect their networkports.

- 9 -
CHAPTER 3. CONSOLE AND TELNETMANAGEMENT
3.1 Connect To PC by RS-232 serial Cable
NOTE: Ifyou have stackedseveralswitches together, makesure you are working on
Master switch (switchwithleast SwitchID). Other slave switches management
interface allows onlyviewing theconfiguration by “guest”account.
Toconfigure the system,connect the provided serial cable toaCOM port on aPC or
notebookcomputer and toserial (console) port ofthe device. The console port ofthe
device is DCEalready,sothatyoucanconnect theconsole port directlythrough PC
without the need ofNull Modem.
Aterminal programis required to makethe softwareconnectionto thedevice.Windows'
Hyper Terminal programmaybeagood choice. It canbe accessed from the Startmenu.
ClickSTART, then Programs, Accessories and then Hyper Terminal.
MS-DOS basedterminal programsuch as PC-PLUS,PROCOMM,canalso makethe
connection withthedevice built-in software. The COM port should be configured as:
♦Baud : 9600
♦Parity: None
♦Data bits: 8
♦Stop bits: 1
♦FlowControl : None
Ifyouare usingWindows95/NT/98/2000/XP,launch “HyperTerminal”,createanew
connection, andadjust settings as below:
Please then power on theswitch; launch thenewterminal program you just set up.Press
“Enter”key,thenlogin screen appears. Please check chapter 3.3 for detail on console
management.

- 10 -
3.2 Telnet
To access the switchthrough a Telnet session:
1. Be Sure ofthe switch is configured with an IPaddressand theswitch is reachable
froma PC.
2. Start the Telnet programon a PCand connect to theswitch.
The management interface is exactlythe same with RS-232 console management except
the “root”priviledge is not supported.
3.3 MainMenu
After you enter the switch sconsole interface byRS-232 cable or telnet, thefollowing
pageis shown. Please enter username and password to access WGSW-14020.
There are threesystemdefaultaccounts for different privilege levels:
“root”:root candoanyconfiguration includes changingpassword and enable/disable
management capabilityvia console port. The default password ofroot is
“superuser”.Notethat this account is notworkable ontelnetandweb
management interface.
“admin”admin candoanyconfigurationexceptchangingpassword. Thedefault
password ofadmin is “admin”.
“guest”:guest can viewthe whole switchinformation only,moreover, access to Web
management interface is not allowed.The default password is “guest”.
Main menu appears aftersuccessfullyloginWGSW-14020. Toenteranyofthe
submenus, simplytypethenumber after thecommand prompt. When select further
options, youmaybeasked for the device ID which youwant to configure. Please just
input the SWITCH ID which you haveconfigured on the switch front panel.
The management functionsofconsole interface are exactlythesamewithweb-based
management interface butintextmode. For further operation, please refer to “4. Web
Management”.

- 11 -
CHAPTER 4. WEBMANAGEMENT
4.1 Start AWeb Browser Session
The Web Interface ofWGSW-14020 is coded byJava Applet and running on the JavaTM
Virtual Machine(JVM) version 1.3.1 platform. You should configure the management
stationwith an IP address and subnetmaskcompatible withWGSW-14020 for accessing
it. Also, the management station shouldbe well configured and connected toInternet for
automaticallydownloading(upgrading) the suitable JVM through Internet from
http://java.sun.com. Or you can download from
http://java.sun.com/j2se/1.3/download.html and manuallyinstall it.
Note: Usuallythenewer JavaTM Virtual Machineis notbackward compatible.JVM version
1.3.1is stronglyrecommended to ensure properlyoperation.
The default networkconfigurations are as follows:
IP: 192.168.0.1
Subnet Mask:255.255.255.0
Default Gateway:192.168.0.254
1. Activatea web browser and enter theIP address youhave configured in the address
field. A screen pops up andasksfor username/password. Use systemdefault users
name “admin”and password “admin”( If you have configured a newpassword, input
the newpassword) to access WGSW-14020.
2. After Login, the web management will start todownload thejavafile for the switch.
3. After the file download is completed, the following message is shown. Pleaseclick
“Continue”to enter the stack main page.

- 12 -
4.2 Stack Main Page
The stackmain page contains two options:
Topology
This screen displays one or more switches ofthemanagement stack. Basic properties
can be read bythescreen, including Hardwarecharacteristic, Device Name, Up time,
Master and Slave relationship.Also, bymouse clicking listed items can enter for further
operation.
System Configuration
IfyouaremanagingaMaster or aStandalone device, the systemconfiguration
parameters are equal to parameters ofNet Configurationand Device Informationin
Device tab. For further information, please refer to Device statement.

- 13 -
4.3 Switch MainPage
SwitchMain Page appears after you clickone oftheswitch(es) on the topologypage.
There are 8 function button listed on top: Home, Save, Default,Reboot,Ping, Telnet,
Contact,and Upgrade.
<Home>
Shortcutto backto stackhome page
<Save>
Save the currentsettingto Non-volatile Memory.The difference between <Save> and
<Apply> is that Apply applies settings right awaybutsaves the values in thesystem
memory.Everytimewhenswitch reboots, systemobtains systemparameters from
Non-volatile Memory you <Saved> before butnotsystemmemory.
Select the one(s) you wantto save parameters, then click “Save”button tosave it to
Non-volatile Memory.
<Default>
Makethe switch(es) returning tofactory default value.Select theswitch andclick “Default”
button, theselected-switch(es) will returntoinitial value. Ifyou wanttoclear the previous
value in the System Memory, please <Save> it.

- 14 -
<Reboot>
You can specifyswitch(es) and reboot it.
Warm Boot Reboot the switch in a shorttime.
Cold Boot Boot the switch and with fully Power On Self Test (POST). The system is
completely checked but spends much time.
<Ping>
The Ping is acommonlyused tooltodetect the remote host or IPaddress existsor not.
Moreover, networkstatus also can be known bythe ratio ofpackets Replyand Loss.
<Telnet>
Bysimplyclicking the <Telnet> button, the Telnet programimplements and displays login
screen.
<Contact>
Contact PLANETtechnicians for technical support byE-Mail
<Upgrade>
Youcan select the device IDandclickthe upgrade method. Pleasenote the twoor more
device canbe upgraded at the same time.

- 15 -
WEB Upload
w Select Device ID and “WEB Upload”radiobutton thenclick OK
w Specifythe file pathbyclicking Browse button and click Start
TFTP Download
1. Select Device ID and “TFTP Download”radio buttonthen click OK
2. Enter theTFTP server s IP address in Server IP field
3. Enter file namein File Name field
ClickStart button to download the code and systemupdate with itautomatically
Local FileTransfer
1. Select Device ID and “Local File Transfer”radio buttonthenclick OK.
2. Click “Application”or ”Java Applet”radiobutton(Application - Systemfirmware, Java
Applet -- Web User Interface).
The systemstarting softwaresynchronization fromMaster Device (That thesynchronized
hardwareshould be identical to Master Device)

- 16 -
Device
The shortcut to go toanother member switch in the management stack
4.4 Device Configuration
Panel Display
Port Status
Port Link Down (Black): Port is not connected or attached device shuts down
Port Link Up(Green): Port links up andworking correctly
Port Link Up(Amber): Port links up but in blockingmode
Port Disabled (Red): Port has been disabled
NetworkConfiguration
IP Address: IP address ofthis device
Subnet Mask: Subnet Maskof your network
GatewayIP: IP address ofGateway
SWITCHID
MASTERLED
STATUS LED
Slide-in Modules
RJ-45 ports

- 17 -
Device Information
Name:Naming the system(optional)
Contact : Who the Systemadministrator is (optional)
Location: Where the management stacklocates (optional)
NOTE: The NetworkConfiguration and Device Information ofMaster Devicein the
management stackwill become systemparameters automatically.
4.5 TopologyInfo
This page displaysinformationabout the switch(es), such as Device ID, Hardware
version, Boot-Up version,POSTversion, Runtimeversion(Firmware version), JAVA
Applet version (Web User Interface version), Device Nameand DeviceLocation. When
management stackpersist, bythe Device ID, all the members are transparentlylisted.
4.6 Ports
Information
It is a ports configurations summarytable. Viathesummarytable, you can knowstatus of
each port clear at aglance,like Link Up/Link Down, Enable/Disable, Link Speed, Duplex
mode and Flow Control.
NOTE: Also bysimplyclicking the port onthe ‘Panel Display,theport information
screen pops up
