Planet FSD-808P User manual

8-Port 10/100Mbps PoE Fast Ethernet Switch
FSD-808P
User’s Manual

Trademarks
Copyright © PLANET Technology Corp. 2015.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks
belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all
environments and applications, and makes no warranty and representation, either
implied or expressed, with respect to the quality, performance, merchantability, or
tness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate;
PLANET disclaims liability for any inaccuracies or omissions that may have
occurred.
Information in this User’s Manual is subject to change without notice and does not
represent a commitment on the part of PLANET. PLANET assumes no responsibility
for any inaccuracies that may be contained in this User’s Manual. PLANET makes
no commitment to update or keep current the information in this User’s Manual,
and reserves the right to make improvements to this User’s Manual and/or to the
products described in this User’s Manual, at any time without notice.
If you nd information in this manual that is incorrect, misleading, or incomplete,
we would appreciate your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the Instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.

CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
Energy Saving Note of the Device
This power required device does not support Standby mode operation.
For energy saving, please remove the power cable to disconnect the device from
the power circuit.
Without removing power cable, the device will still consume power from the
power source. In view of Saving the Energy and reduce the unnecessary power
consumption, it is strongly suggested to remove the power connection for the
device if this device is not intended to be active.
WEEE Warning
To avoid the potential effects on the environment and human health
as a result of the presence of hazardous substances in electrical and
electronic equipment, end users of electrical and electronic equipment
should understand the meaning of the crossed-out wheeled bin
symbol. Do not dispose of WEEE as unsorted municipal waste and
have to collect such WEEE separately.
Revision
PLANET 8-Port 10/100Mbps PoE Fast Ethernet Switch User’s Manual
For Model: FSD-808P
REVISION: 2.1 (JANUARY, 2015)
Part No.: 2351-A31190-005

Table of Contents
1. Introduction ............................................................................................... 5
1.1 Checklist............................................................................................. 5
1.2 Product Description.............................................................................. 5
1.3 Features ............................................................................................. 6
1.4 Specications ...................................................................................... 7
2. Hardware Description .................................................................................. 8
2.1 Front Panel ......................................................................................... 8
2.2 Rear Panel .......................................................................................... 9
3. Hardware Installation .................................................................................10
3.1 Desktop Installation ............................................................................10
3.2 Rack Mounting ...................................................................................11
3.3 Product Applications............................................................................13
3.3.1 Connecting end node or Switch ..................................................13
3.3.2 Department/ Workgroup PoE Switch: ..........................................14
3.4 Power over Ethernet Powered Device ...................................................15
4. Power over Ethernet Overview ....................................................................16
5. Troubleshooting .........................................................................................19
Appendix A Networking Connection ..................................................................20
A.1 DATA OUT PoE Switch RJ45 Port Pin Assignments (Port 1 to Port 8) .......20
A.2 10/100Mbps, 10/100Base-TX ...............................................................20

5
1. Introduction
1.1 Checklist
Check the contents of your package for the following parts:
zFSD-808P x 1
zUser’s Manual x 1
zPower Cord x 1
zTwo Rack-mounting Brackets with Attachment Screws x 8
If any of these pieces are missing or damaged, please contact your dealer
immediately; if possible, retain the carton including the original packing material,
and use them again to repack the product in case there is a need to return it to us
for repair.
1.2 Product Description
To fulll the demand of sufcient PoE power for network applications with Fast
Ethernet transmission performance, the FSD-808P, a new member of the 802.3af
PoE Fast Ethernet Switch family, is an 8-port 10/100Mbps Power over Ethernet
Switch, which features high performance Fast Ethernet IEEE 802.3af PoE (up to
15.4 watts) with a total of 125-watt PoE budget. Its eight 802.3af PoE ports,
with PoE power injector function, are able to drive eight IEEE 802.3af compliant
powered devices. The FSD-808P also provides a simple, cost-effective, and non-
blocking wire-speed performance in a compact 12-inch metal housing for desktop
deployment for SOHO ofce or department network application.
All RJ45 copper interfaces in the FSD-808P support 10/100Mbps auto-negotiation
for optimal speed detection over RJ45 Category 5 or 5e cabling. It also supports
standard auto-MDI/MDI-X that can detect the type of connection to any Ethernet
device without requiring special straight-through or crossover cable.

6
1.3 Features
RJ45 Interface
Eight 10/100Mbps Fast Ethernet ports
8 ports support 48V DC power to PoE powered device
Power over Ethernet
Complies with IEEE 802.3af Power over Ethernet End-Span PSE
Up to 8 IEEE 802.3af devices powered
Supports PoE Power up to 15.4 watts for each PoE port
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m
Switching
Hardware based 10/100Mbps auto-negotiation and auto MDI/MDI-X
Flow control for full duplex operation and back pressure for half duplex opera-
tion
Integrates address look-up engine, supporting 2K absolute MAC addresses
Automatic address learning and address aging
Hardware
12-inch desktop size, 1U height
LED indicators for PoE ready and PoE activity
Fanless design

7
1.4 Specications
Model FSD-808P
8-Port 10/100Mbps PoE Fast Ethernet Switch
Hardware Specications
Hardware Version 2
Network Connector 8-Port RJ45 for 10/100BASE-TX
PoE Inject Port 8-Port with 802.3af PoE injector function
LED Display
System: Power (Green)
Per port : PoE (Orange)
LNK/ACT (Green)
Switch Architecture Store and Forward switch architecture
MAC Address 2K MAC address table with auto learning function
Switch Fabric 1.6Gbps
Switch Throughput 1.19Mpps@64Bytes
Power Requirements AC 100~240V, 50/60Hz, 1.2A max.
Power Consumption Max.135 watts / 460 BTU
Dimensions (W x D x H) 280 x 180 x 43 mm
Weight 1.65kg
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PSE
PoE Power Supply Type End-Span
PoE Power Output Per port 48V DC, 350mA. max. 15.4 watts
Power Pin Assignment 1/2(+), 3/6(-)
PoE Power Budget 125 watts
Standard Conformances
Regulation Compliance FCC Class A, CE
Standard Compliance
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3af
Ethernet
Fast Ethernet
Flow Control
Power over Ethernet
Environment
Operating Temperature 0 ~ 50 degrees C
Storage Temperature -40 ~ 70 degrees C
Operating Humidity 5 ~ 95%, relative humidity, non-condensing
Storage Humidity 5 ~ 95%, relative humidity, non-condensing

8
2. Hardware Description
The FSD-808P provides two different running speeds -- 10Mbps and 100Mbps --
and can automatically distinguish the speed of the incoming connection.
This section describes the hardware features of the FSD-808P. For easier
management and control of the Switch, familiarize yourself with its display
indicators and ports. Front panel illustrations in this chapter display the unit LED
indicators. Before connecting any network device to the FSD-808P, please read this
chapter carefully.
2.1 Front Panel
The Front Panel of the FSD-808P PoE Ethernet Switch consists of 8x auto-sensing
10/100Mbps Ethernet RJ45 ports. The LED Indicators are also located on the front
panel of the FSD-808P.
Figure 2-1: FSD-808P Switch Front Panel
2.1.1 LED Indicators
System
LED Color Function
PWR Green Light: Indicates the Switch has power.
Per 10/100Mbps Port
LED Color Function
PoE Orange Light: Indicates the port is providing 48V DC in-line
power.
LNK/ACT Green
Light: Indicates the link through that port is successfully
established.
Blinking: Indicates that the Switch is actively sending or
receiving data over that port.

9
2.2 Rear Panel
The rear panel of the FSD-808P indicates an AC inlet power socket, which accepts
input power from 100 to 240V AC, 50-60Hz.
100~240V AC
50 / 60Hz, 3A max.
Figure 2-2: FSD-808P Switch Rear Panel
Power
Notice
1. The device is a power-required device, meaning it will not work
till it is powered. If your networks should be active all the time,
please consider using UPS (Uninterrupted Power Supply) for your
device. It will prevent you from network data loss or network
downtime.
2. In some areas, installing a surge suppression device may also
help to protect your FSD-808P from being damaged by unregu-
lated surge or current to the FSD-808P or the power adapter.

10
3. Hardware Installation
Start up
Please refer to the following for your cabling:
10/100BASE-TX
All 10/100BASE-TX ports come with auto-negotiation capability. They automatically
support 10/100BASE-TX and 10BASE-T networks. Users only need to plug a
working network device into one of the 10/100BASE-TX ports, and then turn on
the FSD-808P. The port will automatically run at 10Mbps, 20Mbps, 100Mbps or
200Mbps after negotiating with the connected device.
Cabling
Each 10/100BASE-TX port uses RJ45 sockets -- similar to phone jacks -- for
connection to unshielded twisted-pair cable (UTP). The IEEE 802.3 / 802.3u Fast
Ethernet standard requires Category 5, 5e UTP for 100Mbps 100Base-TX. 10Base-T
networks can use Cat. 3, 4 and 5 (see table below). Maximum distance is 100
meters (328 feet).
Port Type Cable Type Connector
10BASE-T Cat. 3, 4, 5, 2-pair RJ45
100BASE-TX Cat. 5, 5e UTP, 2-pair RJ45
Any Ethernet devices like hubs/PCs can connect to the FSD-808P by using straight-
through wires. The eight 10/100Mbps ports are auto-MDI/MDI-X, which can be
used on straight-through or crossover cable.
3.1 Desktop Installation
To install the Switch on desktop, simply follow the following steps:
Step 1 Attach the rubber feet to the recessed areas on the bottom of the Switch
as shown in Figure 3-1.
Figure 3-1: Attaching the Rubber Feet to the PoE Fast Ethernet Switch
