Planet MGSD-10080F User manual

8-Port 100/1000X SFP + 2-Port 10/100/1000T Managed
Metro Ethernet Switch
MGSD-10080F
Quick Installation Guide

Table of Contents
1. Package Content......................................................................................... 3
2. Requirements ............................................................................................. 4
3. Wiring DC Power Inputs .............................................................................. 5
4. Terminal Setup ........................................................................................... 6
5. Logon to the Console .................................................................................. 8
6. CongureIPAddress .................................................................................. 9
7. Start Web Management..............................................................................11
8. Customer Support .....................................................................................15

3
1. Package Content
Thank you for purchasing PLANET Layer 2 Managed Metro Ethernet Switch, MGSD-
10080F. “Managed Switch” will also be mentioned as an alternative to the
MGSD-10080FinthisQuickInstallationGuide.
Open the box of the Managed Switch and carefully unpack it. The box should
contain the following items:
TheMGSD-10080FSwitchx1l
User’s Manual CD x 1l
QuickInstallationGuidex1l
DB9toRJ-45ConsoleCablex1l
Dust Cap x 11l
Rubber Feet x 4l
RackMountAccessoryKitx1l
ACPowerCordx1l
If any item is found missing or damaged, please contact your local reseller for
replacement.

4
2. Requirements
Workstations of subscribers running Windows XP/2003/Vista/7/2008, MAC OS9l
orlater,Linux,UNIXorotherplatformcompatiblewithTCP/IPprotocols.
WorkstationinstalledwithEthernetNIC(NetworkInterfaceCard)l
Serial Port connectl(Terminal)
TheabovePCwithCOMPort(DB9)
Ethernet Port connectl
Networkcables-Usestandardnetwork(UTP)cableswithRJ-45connectors.
TheabovePCinstalledwithWEBBrowserandJAVAruntimeenvironmentPlug-
in.
Note
It is recommended to use Internet Explore 7.0 or above to access
theManagedSwitch.

5
3. Wiring DC Power Inputs
The6-contactterminalblockconnector ontherearpanel ofMGSD-10080Fisused
for two DC redundant powers input. Please follow the steps below to insert the
power wire.
1.Insert positive / negative DC power wires into the contacts 1 and 2 for DC
POWER1,or5and6forDCPOWER2.
100~240V AC
50/60 Hz
ON
AC POWER
OFF
DC POWER
ON
DC Input Range 36V~72V
OFF
Fault
GNDGNDDO 1DO 0DI 1DI 0
DC 2DC 1
V1+ V2+
123456
123456
2.Tightenthewire-clampscrewsforpreventingthewiresfromloosing.
1 2 3 4 5 6
DC 1 FaultAlarm DC 2
+-+-
Note
Thewiregaugefortheterminalblockshouldbeintherangeof12
~24AWG.

6
4. Terminal Setup
Tocongurethesystem,connectaserialcabletoaCOM port on a PC or notebook
computer and to serial (console) port of the Managed Switch. The console port of
the Managed Switch is DCE already. So, you can connect the console port directly
tothePCwithouttheneedofNullModem.
PC / Workstation
with
Terminal emulation software
Serial Port
PLANET Metro Managed Switch
RJ-45 to DB9 RS-232 Cable
A terminal program is required to make the software connection to the Managed
Switch. Windows' Hyper Terminal program may be a good choice. The Hyper
TerminalcanbeaccessedfromtheStart menu.
1. Click START,thenPrograms,AccessoriesandthenHyper Terminal.

7
2.When the following screen appears, make sure that the COM port should be
conguredas:
Baud :115200
Data bits : 8
Parity :None
Stop bits : 1
FlowContro:None

8
5. Logon to the Console
Once the terminal is connected to the device, power on the Managed Switch and
theterminalwillstartrunningtestingprocedures.
Then, the following message of the login username and password appears. Both
the factory default username and password are "admin" as the login screen in
Figure5-1appears.
Username: admin
Password:admin
Figure 5-1: MGSD-10080F Managed Switch Console Login Screen
Note
1. For security reason, please change and memorize the new pass-
wordafterthisfirstsetup.
2.Only accept command in lowercase letter under console inter-
face.

9
6.CongureIPAddress
TheManagedSwitchisshippedwithdefaultIPaddressasshownbelow.
IPAddress:192.168.0.100
Subnet Mask: 255.255.255.0
To check the current IP address or create a new IP address for the Switch, please
usetheproceduresasfollows:
Show the current IP address
1. On “Switch/>” prompt,enter“show ip”.
2.ThescreendisplaysthecurrentIPaddress,SubnetMaskandGateway,asshown
inFigure6-1.
Figure 6-1: Display of IP Information

10
Congure IP address
3. On “Switch/>” prompt, enter the following command and press <Enter> as
showninFigure6-2.
Switch/>ipsetup192.168.1.100255.255.255.0192.168.1.1
ThepreviouscommandwouldapplythefollowingsettingsfortheSwitch.
IP Address: 192.168.1.100
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.1
Figure 6-2: Setting IP Address
4.RepeatStep1tocheckiftheIPaddressischanged.
If the IP is successfully congured, the Managed Switch will apply the new IP
address setting immediately. You can access the Web interface of the Managed
SwitchthroughthenewIPaddress.
Note
Ifyouarenotfamiliarwithconsolecommandortherelatedparam-
eter,enter“help”anytimeinconsoletogetthehelpdescription.

11
7. Start Web Management
The following shows how to start up the Web Management of the Managed
Switch. Note the Managed Switch is congured through an Ethernet connection.
Please make sure the manager PC must be set on the same IP subnet address.
For example, the default IP address of the Managed Switch is 192.168.0.100,
thenthemanagerPCshouldbesetat192.168.0.x(wherexisanumberbetween
1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with
Terminal emulation software
IP Address :
192.168.0.x
PLANET Metro Managed Switch
RJ-45 / UTP Cable
Figure 7-1: IP Management Diagram
Login the Managed Switch
1.Use Internet Explorer 7.0 or above Web browser. Enter IP address
http://192.168.0.100 (the factory-default IP address or that you have just
changedinconsole)toaccesstheWebinterface.

12
2.When the following dialog box appears, please enter the default username and
password “admin” (or the password you have changed via console). The login
screeninFigure7-2appears.
Default Username: admin
DefaultPassword:admin
Figure 7-2: Login Screen
3.Afterenteringthepassword,themainscreenappearsasFigure7-3shows.
Figure 7-3: Web Main Screen of the Managed Switch

13
4.The Switch Menu on the left of the Web page let you access all the commands
andstatisticstheSwitchprovides.
Figure 7-4: S witch Menu
Note
If you are not familiar with Switch functions or the related param-
eter, press “Help” button anytime at left of the Web page to get
thehelpdescription.
Now, you can use the Web management interface to continue the Switch
management or manage the Switch by console interface.
Please refer to the user manual for more.

14
Changing IP Address or forgetting admin password –
To reset the IP address to the default IP Address “192.168.0.100” or reset
the login password to default value. Press the hardware reset button at the
front panel over 5 seconds. After the device is rebooted, you can login to the
management Web interface within the same subnet of 192.168.0.xx.
1 3 5 7
2 4 6 8
RingPWR
DC 1 Owner
DC 2
Fault
ACTLNK
ACTLNK
1000
100
RESET
10
9
100~240V AC
50/60 Hz
ON
AC POWER
OFF
DC POWER
ON
DC Input Range 36V~72V
OFF
Fault
GNDGNDDO 1DO 0DI 1DI 0
DC 2DC 1
V1+ V2+
1 2 3 4 5 6
1 2 3 4 5 6
Reset Button

15
8. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resource at the PLANET website rst to check if it could solve your issue. If you
needmoresupportinformation,pleasecontactPLANETswitchsupportteam.
PLANETonlineFAQ:
http://www.planet.com.tw/en/support/faq.php?mt=menu_support_1
Switchsupportteammailaddress:
[email protected]w
Copyright © PLANET Technology Corp. 2013.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
