Planet GSD-Series User manual

5/8-Port 10/100/1000Mbps
Gigabit Ethernet Switch
GSD-Series
User's Manual

Trademarks
Copyright © PLANET Technology Corp. 2007.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks
belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all
environments and applications, and makes no warranty and representation, either
implied or expressed, with respect to the quality, performance, merchantability, or
tness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate;
PLANET disclaims liability for any inaccuracies or omissions that may have
occurred.
Information in this User’s Manual is subject to change without notice and does not
represent a commitment on the part of PLANET. PLANET assumes no responsibility
for any inaccuracies that may be contained in this User’s Manual. PLANET makes
no commitment to update or keep current the information in this User’s Manual,
and reserves the right to make improvements to this User’s Manual and/or to the
products described in this User’s Manual, at any time without notice.
If you nd information in this manual that is incorrect, misleading, or incomplete,
we would appreciate your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the Instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.

CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human
health as a result of the presence of hazardous substances in
electrical and electronic equipment, end users of electrical and
electronic equipment should understand the meaning of the
crossed-out wheeled bin symbol. Do not dispose of WEEE as
unsorted municipal waste and have to collect such WEEE
separately.
Revision
PLANET 5/8-Port 10/100/1000Mbps Gigabit Ethernet Switch User's Manual
For Models: GSD-503 / GSD-504 / GSD-803 / GSD-804
Revision: 3.0(AUGUST.2007)
Part No: EM_GSD58v3 (2010-A33130-001)

TABLE OF CONTENTS
1. INTRODUCTION.......................................................................................... 5
1.1 Package Contents ................................................................................. 5
1.2 How to Use This Manual ....................................................................... 5
1.3 Product Features................................................................................... 5
1.4 Product Specications............................................................................ 7
2. INSTALLATION............................................................................................ 8
2.1 Product Description ............................................................................... 8
2.1.1 Product Overview............................................................................... 8
2.1.2 Switch Front Panel ............................................................................. 9
2.1.3 LED Indicators ..................................................................................10
2.1.4 Switch Rear Panel .............................................................................10
2.2 Installing the Switch ............................................................................11
2.2.1 Desktop Installation ..........................................................................11
3. SWITCH OPERATION..................................................................................13
3.1 Address Table......................................................................................13
3.2 Learning .............................................................................................13
3.3 Forwarding & Filtering ..........................................................................13
3.4 Store-and-Forward ...............................................................................13
3.5 Auto-Negotiation..................................................................................14
4. TROUBLESHOOTING...................................................................................15
APPENDIX A: NETWORKING CONNECTION...................................................16
A.1 Switch‘s RJ-45 Pin Assignments ............................................................16
A.2 RJ-45 cable Pin Assignments ................................................................17

5
1. INTRODUCTION
1.1 Package Contents
Check the contents of your package for following parts:
● Gigabit Ethernet Switch x 1
● User's manual x 1
● Power adapter x 1
● Rubber feet x 4
If any of these are missing or damaged, please contact your dealer immediately,
if possible, retain the carton including the original packing material, and use them
against to repack the product in case there is a need to return it to us for repair.
1.2 How to Use This Manual
This Gigabit Ethernet Switch User Manual is structured as follows:
Chapter 2 Installation
The chapter explains the feature, functionality and the physical installation of the
Switch.
Chapter 3 Switch operation
The chapter explains the Gigabit Ethernet Switch transmit operation.
Chapter 4 Troubleshooting
The chapter explains the troubleshooting of the Gigabit Ethernet Switch.
Appendix A
This chapter contains cable information of the Gigabit Ethernet Switch.
1.3 Product Features
● Comply with IEEE 802.3, 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab
1000Base-T
● 5/8-Port 10/100/1000Mbps Gigabit Ethernet ports

6
● Features Store-and-Forward mode with wire-speed ltering and forwarding rates
● Hardware based 10/100Mbps, half / full duplex and 1000Mbps full duplex mode,
ow control and auto-negotiation
● IEEE 802.3x ow control for full duplex operation and Backpressure for half du-
plex operation
● Integrated address look-up engine, support 8K absolute MAC addresses
● 9K Jumbo packet support
● Automatic address learning and address aging
● Supports Auto MDI/MDI-X function
● Support CSMA/CD protocol
● External power adapter 12V 1A
● FCC, CE class A compliant

7
1.4 Product Specications
Product GSD-503 GSD-504 GSD-803 GSD-804
Hardware Specication
10/100/1000Base-T
Ports 5 Auto MDI/MDIX ports 8 Auto MDI/MDIX ports
Dimensions (mm)
(W x D x H) 155x86x26 176x106x30 155x86x26 176x106x30
Weight (kg) 0.36 0.16 0.45 0.18
Power Requirement External power adapter 12V 1A
Power Consumption
/ Dissipation 5.4 watts / 18 BTU 9.2 watts / 31 BTU
Switch Specication
Switch Processing
Scheme Store-and-Forward
Address Table 8K entries
Flow Control Back pressure for half duplex, IEEE 802.3x Pause Frame
for full duplex
Switch fabric 10Gbps 16Gbps
Throughput
(packet per second) 7.44Mpps 11.9Mpps
Jumbo packet size 9K
Standards Conformance
Standards
Compliance
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3x (Full-duplex ow control)
Temperature Operating: 0~50 degree C
Storage: -40~70 degree C
Humidity Operating: 5% to 90%,
Storage: 5% to 90% (Non-condensing)
Regulation
Compliance FCC Part 15 Class A, CE

8
2. INSTALLATION
This section describes the functionalities of the Gigabit Ethernet Switch’s
components and guides how to install it on the desktop. Basic knowledge of
networking is assumed. Please read this chapter completely before continuing.
2.1 Product Description
The PLANET GSD-503/GSD-504 and GSD-803/GSD-804 are 10/100/1000Mbps
Gigabit Ethernet Switches in a compact housing for easily desktop placement.
With 5/8 ports respectively, non-blocking wire-speed performance and 10/16Gbps
internal switching fabric, the Switches can handle extremely large amounts of data
in a secure topology linking to a backbone or high capacity servers. The Switches
has 8K MAC Address table. The Switches offers wire-speed packets transfer
performance without risk of packet loss. The high data throughput of Switches
makes it ideal for most Gigabit environments, especially while network upgrades to
a Gigabit environment.
All RJ-45 copper interfaces support 10/100/1000Mbps Auto-Negotiation for optimal
speed detection through RJ-45 Category 6, 5 or 5e cables. Support is standard
for Auto-MDI/MDI-X that can detect the type of connection to any Ethernet device
without requiring special straight or crossover cables.
The Flow Control function allows your Gigabit Switch supported routers and servers
to directly connect to this Switch for fast, reliable data transfer.
2.1.1 Product Overview
The PLANET GSD-503/GSD-504 and GSD-803/GSD-804 are Gigabit Ethernet
Switches with 5/8 RJ-45 10/100/1000Mbps ports for high-speed network
connectivity. The Switches can also automatically identify and determine the correct
transmission speed and half / full duplex mode of the attached devices with its 5/8
ports. The Gigabit ports with jumbo frame feature supported, can handle extremely
large amounts of data transmission in a secure topology linking to a backbone or
high-power servers.
The GSD-503/GSD-504 and GSD-803/GSD-804 also supports Store-and-Forward
forwarding scheme to ensure low latency and high data integrity, eliminates
unnecessary trafc and relieves congestion on critical network paths. With an
intelligent address recognition algorithm, the Switches could recognize up to 8K

9
different MAC address and enables ltering and forwarding at full wire speed.
2.1.2 Switch Front Panel
Figure 2-1 & 2-2 & 2-3 & 2-4 shows a front panel of GSD-503 / GSD-504 / GSD-
803 / GSD-804.
Figure 2-1 GSD-503 front panel
Figure 2-2 GSD-504 front panel
Figure 2-3 GSD-803 front panel
Figure 2-4 GSD-804 front panel

10
2.1.3 LED Indicators
LED Color Function
PWR Green Lights to indicate that the Switch is powered on.
1000 Green
Lit: indicate that the port is operating at
1000Mbps.
Off: indicate that the port is operating at 10Mbps
or 100Mbps.
LNK/ACT Green
Lit: indicate the link through that port is
successfully established.
Blinks to indicate that the Switch is actively
sending or receiving data over that port.
2.1.4 Switch Rear Panel
Figure 2-5 & 2-6 & 2-7 & 2-8 shows a rear panel of GSD-503 / GSD-504 / GSD-
803 / GSD-804.
Figure 2-5 GSD-503 rear panel
Figure 2-6 GSD-504 rear panel

11
Figure 2-7 GSD-803 rear panel
Figure 2-8 GSD-804 rear panel
Power Notice:
1. The device is a power-required device, it means, it will not work till it is pow-
ered. If your networks should active all the time, please consider using UPS (Un-
interrupted Power Supply) for your device. It will prevent you from network data
loss or network downtime.
2. In some area, installing a surge suppression device may also help to protect
your Switch from being damaged by unregulated surge or current to the Switch
or the power adapter.
2.2 Installing the Switch
This part describes how to install your Gigabit Ethernet Switch and make
connections to it. Please read the following topics and perform the procedures in
the order being presented.
Note: This Switch does not need software configuration.

12
2.2.1 Desktop Installation
To install the Switch on desktop, simply follow the next steps:
Step 1: Attach the rubber feet to the recessed areas on the bottom of the Switch.
Step 2: Place the Switch on desktop near an AC power source.
Step 3: Keep enough ventilation space between the Switch and the surrounding
objects.
Note: When choosing a location, please keep in mind the environmental
restrictions discussed in Chapter 1, Section 1.4 Product Specifications.
Step 4: Connect your Switch to network devices.
A. Connect one end of a standard network cable to the 10/100/1000 RJ-45 ports
on the Back of the Switch.
B. Connect the other end of the cable to the network devices such as printer serv-
ers, workstations or routers…etc.
Note: Connection to the Switch requires UTP Category 5 network cabling with
RJ-45 tips. For more information, please see the Cabling Specification in
Appendix A.
Step 5: Supply power to the Switch.
A. Connect one end of the power cable to the Switch.
B. Connect the 12V DC power adapter to a standard wall outlet.
When the Switch receives power, the Power LED should remain solid Green.

13
3. SWITCH OPERATION
3.1 Address Table
The Switch is implemented with an address table. This address table composed of
many entries. Each entry is used to store the address information of some node
in network, including MAC address, port no, etc. This information comes from the
learning process of Ethernet Switch.
3.2 Learning
When one packet comes in from any port. The Switch will record the source
address, port no. And the other related information in address table. This
information will be used to decide either forwarding or ltering for future packets.
3.3 Forwarding & Filtering
When one packet comes from some port of the Ethernet Switching, it will also
check the destination address besides the source address learning. The Ethernet
Switching will lookup the address-table for the destination address. If not found,
this packet will be forwarded to all the other ports except the port which this
packet comes in. And these ports will transmit this packet to the network it
connected. If found, and the destination address is located at different port
from this packet comes in, the Ethernet Switching will forward this packet to the
port where this destination address is located according to the information from
address table. But, if the destination address is located at the same port with this
packet comes in, then this packet will be ltered. Thereby increasing the network
throughput and availability.
3.4 Store-and-Forward
Store-and-Forward is one type of packet-forwarding techniques. A Store-and
Forward Ethernet Switching stores the incoming frame in an internal buffer, do
the complete error checking before transmission. Therefore, no error packets
occurrence, it is the best choice when a network needs efciency and stability.
The Ethernet Switch scans the destination address from the packet-header,
searches the routing table provided for the incoming port and forwards the packet,
only if required. The fast forwarding makes the Switch attractive for connecting

14
servers directly to the network, thereby increasing throughput and availability.
However, the Switch is most commonly used to segment existing hubs, which
nearly always improves overall performance. An Ethernet Switching can be easily
congured in any Ethernet network environment to signicantly boost bandwidth
using conventional cabling and adapters.
Due to the learning function of the Ethernet Switching, the source address and
corresponding port number of each incoming and outgoing packet are stored in
a routing table. This information is subsequently used to lter packets whose
destination address is on the same segment as the source address. This connes
network trafc to its respective domain, reducing the overall load on the network.
The Switch performs “Store and Forward" therefore, no error packets occur. More
reliably, it reduces the re-transmission rate. No packet loss will occur.
3.5 Auto-Negotiation
The STP ports on the Switch have built-in “Auto-negotiation”. This technology
automatically sets the best possible bandwidth when a connection is established
with another network device (usually at Power On or Reset). This is done by detect
the modes and speeds at the second of both device is connected and capable of,
both 10Base-T and 100Base-TX devices can connect with the port in either Half- or
Full-Duplex mode. 1000Base-T can be only connected in Full-duplex mode.

15
4. TROUBLESHOOTING
This chapter contains information to help you solve problems. If the Switch is not
functioning properly, make sure the Gigabit Ethernet Switch was set up according
to instructions in this manual.
The per port LED is not lit
Solution:
Check the cable connection of the GSD-503/GSD-504 and GSD-803/GSD-804.
Performance is bad
Solution:
Check the speed duplex mode of the partner device. The GSD-503/GSD-504 and
GSD-803/GSD-804 is run at Auto-negotiation mode and if the partner is set to half
duplex, then the performance will be poor.
Per port LED is lit, but the trafc is irregular
Solution:
Check that the attached device is not set to dedicate full duplex. Some devices use
a physical or software switch to change duplex modes. Auto-negotiation may not
recognize this type of full-duplex setting.
Why the Switch doesn’t connect to the network
Solution:
Check per port LED on the Switch. Try another port on the Switch Make sure the
cable is installed properly Make sure the cable is the right type Turn off the power.
After a while, turn on power again.

16
APPENDIX A: NETWORKING CONNECTION
A.1 Switch‘s RJ-45 Pin Assignments
1000Mbps, 1000Base-T
Contact MDI MDI-X
1 BI_DA+ BI_DB+
2 BI_DA- BI_DB-
3 BI_DB+ BI_DA+
4 BI_DC+ BI_DD+
5 BI_DC- BI_DD-
6 BI_DB- BI_DA-
7 BI_DD+ BI_DC+
8 BI_DD- BI_DC-
10/100Mbps, 10/100Base-TXnt
RJ-45 Connector pin assignment
Contact MDI
Media Dependant Interface
MDI-X
Media Dependant Interface -Cross
1 Tx + (transmit) Rx + (receive)
2 Tx - (transmit) Rx - (receive)
3 Rx + (receive) Tx + (transmit)
4, 5 Not used
6 Rx - (receive) Tx - (transmit)
7, 8 Not used

17
A.2 RJ-45 cable Pin Assignments
The standard RJ-45 receptacle/connector
There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The
following shows the pin allocation and color of straight cable and crossover cable
connection:
Figure A-1 Straight-Through and Crossover Cable
Please make sure your connected cables are with same pin assignment and color
as above picture before deploying the cables into your network.

This page is intentionally left blank

This page is intentionally left blank

This page is intentionally left blank
