Planet SGS-5220-24T2X User manual

L2+ 24-Port Gigabit + 2-Port 10G SFP+
Stackable Managed Switch
SGS-5220-24T2X / SGS-5220-24P2X / SGS-5220-24S2X
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. Requirements ............................................................................................. 4
3. Terminal Setup ........................................................................................... 5
4. Logon to Console........................................................................................ 6
5. ConguringIPAddress................................................................................ 7
6. Starting Web Management .......................................................................... 9
7. SavingConguration..................................................................................12
8. RecoveringBacktoDefaultConguration.....................................................13
9. Customer Support .....................................................................................14

3
1. Package Contents
Thank you for purchasing PLANET L2+ 24-Port Gigabit + 2-Port 10G SFP+
StackableManagedSwitch.Thedescriptionofthismodelisshownbelow:
SGS-5220-24T2X L2+24-Port10/100/1000T+4-PortSharedSFP+2-Port
10GSFP+StackableManagedSwitch
SGS-5220-24P2X L2+24-Port10/100/1000T802.3atPoE+2-Port10GSFP+
StackableManagedSwitch/440W
SGS-5220-24S2X L2+24-Port100/1000XSFP+8-PortSharedTP+2-Port
10GSFP+StackableManagedSwitch
“Stackable Managed Switch” is used as an alternative name in this Quick
InstallationGuide.
Open the box of the Managed Switch and carefully unpack it. The box should
containthefollowingitems:
zTheStackableManagedSwitchx1
zQuickInstallationGuidex1
zRJ45 to RS232 Cable x 1
zRubberFeetx4
zTwoRack-mountingBracketswithAttachmentScrewsx1
zPowerCordx1
zSFPDust-proofCapx8(Model:24Tand24P)
zSFPDust-proofCapx28(Model:24S)
If any item is found missing or damaged, please contact your local reseller for
replacement.

4
2. Requirements
zWorkstations running Windows XP/2003/Vista/7/8/2008, MAC OS X or later,
Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerialPortConnection(Terminal)
 The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
 The above Workstations have been installed with terminal emulator, such as
HyperTerminalincludedinWindowsXP/2003.
 Serial cable -- one end is attached to the RS232 serial port, while the other
endtotheconsoleportoftheManagedSwitch.
zEthernetPortConnection
 Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.
 The above PC is installed with Web Browser and JAVA runtime environment
plug-in.
Note
It is recommended to use Internet Explore 8.0 or above to access
the Managed Switch. If the Web interface of the Managed Switch
is not accessible, please turn off the anti-virus software or firewall
andthentryitagain.

5
3. Terminal Setup
Tocongurethesystem,connectaserialcabletoaCOM port on a PC or notebook
computerandtoRJ45typeofserialportoftheStackableManagedSwitch.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port Serial Port
115200,8,n,1
RS232 to RJ45 Cable
Figure 3-1 Stackable Managed Switch Console Connectivity
A terminal program is required to make the software connection to the Managed
Switch.
1. Run terminal program on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
Baud :115200
Databits :8
Parity :None
Stopbits :1
Flowcontrol :None
Figure 3-2COMPortConguration

6
4. Logon to Console
Once the terminal is connected to the device, power on the Stackable Managed
Switch, and the terminal will display “running testing procedures”. Then, the
following message asks to log-in user name and password. The factory default
user name and password are shown as follows and the login screen in Figure 4-1
appears.(exampleonModel:24T)
Username:admin
Password:admin
Figure 4-1: Stackable Managed Switch Console Login Screen
The user can now enter commands to manage the Managed Switch. For a detailed
descriptionofthecommands,pleaserefertothefollowingchapters.
Note
1.For security reason, please change and memorize the new pass-
wordafterthisfirstsetup.
2.Onlyacceptcommandinlowercaseletterunderconsoleinterface.

7
5.ConguringIPAddress
TheManagedSwitchisshippedwithdefaultIPaddressshownbelow.
IPAddress:192.168.0.100
SubnetMask:255.255.255.0
To check the current IP address or modify a new IP address for the Switch, please
usetheproceduresasfollows:
Show the current IP Address
1.Atthe“#”prompt,enter“show ip interface brief”.
2.ThescreendisplaysthecurrentIPaddressasshowninFigure5-1.
Figure 5-1: IP Information Screen
 Conguring IP Address
3.At the “#” prompt, enter the following command and press <Enter> as shown
inFigure5-2.
SGS-5220-24T2X# congure terminal
SGS-5220-24T2X(cong)# interface vlan 1
SGS-5220-24T2X(cong-if-vlan)# ip address 192.168.1.100 255.255.255.0

8
The previous command would apply the following settings for the Stackable
ManagedSwitch.
IPAddress:192.168.1.100
SubnetMask:255.255.255.0
Figure 5-2: Conguring IP Address Screen
4.Repeatstep1tocheckiftheIPaddressischanged.
 Store current switch conguration
5.Atthe“#”prompt,enterthefollowingcommandandpress<Enter>.
# copy running-cong startup-cong
Figure 5-3: Saving Current Conguration Command Screen
If the IP is successfully congured, the Stackable Managed Switch will apply the
new IP address setting immediately. You can access the Web interface of the
ManagedSwitchthroughthenewIPaddress.
Note
If you are not familiar with the console command or the related
parameter, enter “help” anytime in console to get the help
description.

9
6. Starting Web Management
The following shows how to start up the Web Management of the Managed
Switch. Note the Managed Switch is congured through an Ethernet connection.
Please make sure the manager PC must be set on the same IP subnet address.
For example, the default IP address of the Managed Switch is 192.168.0.100,
then the manager PC should be set at 192.168.0.x (where x is a number
between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address:
192.168.0.100
Figure 6-1: IP Management Diagram
Logging in the Managed Switch
1.Use Internet Explorer 8.0 or above Web browser and enter IP address
http://192.168.0.100(thefactorydefaultIPaddressortheonethatyouhave
justchangedinconsole)toaccesstheWebinterface.

10
2.When the following dialog box appears, please enter the default user name and
password “admin” (or the password you have changed via console). The login
screeninFigure6-2appears.
DefaultUsername:admin
DefaultPassword:admin
Figure 6-2: Login Screen
3.Afterenteringthepassword,themainscreenappearsasFigure6-3shows.
Figure 6-3: Web Main Screen of Managed Switch
