Planet GS-6320-8P2X User manual

L3 8-Port 10/100/1000T 802.3at PoE +
+ 2-Port 10G SFP+ Managed Switch
GS-6320-8P2X
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. Requirements ............................................................................................. 4
3. Terminal Setup ........................................................................................... 5
3.1 Logging on to Console ......................................................................... 6
 3.2 ConguringIPAddress......................................................................... 7
 3.3 StoringCurrentSwitchConguration..................................................... 9
4. Starting Web Management .........................................................................10
 4.1 LoggingintotheManagedPoESwitch .................................................10
 4.2. SavingConguration...........................................................................13
5. RecoveringBacktoDefaultConguration.....................................................14
6. Customer Support .....................................................................................15

3
1. Package Contents
ThankyouforpurchasingPLANETManagedPoESwitch,GS-6320-8P2X.
“Managed PoE Switch” is used as an alternative name in this Quick Installation
Guide.
Open the box of the Managed PoE Switch and carefully unpack it. The box should
contain the following items:
zTheManagedPoESwitchx1
zQuickInstallationGuidex1
zRJ45 to RS232 Cable x 1
zRubber Feet x 4
zTwoRack-mountingBracketswithAttachmentScrewsx1
zPowerCordx1
zSFPDust-proofCapsx2
If any item is found missing or damaged, please contact your local reseller for
replacement.

4
2. Requirements
zWorkstations running Windows XP/2003/2008/2012/Vista/7/8/10, MAC OS X or
later,Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerial Port Connection(Terminal)
The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
 TheaboveWorkstationshavebeeninstalledwith terminal emulator, suchas
TeraTerm,PuTTYorHyperTerminalincludedinWindowsXP/2003.
Serial cable -- One end is attached to the RS232 serial port, while the other
endtotheconsoleportoftheManagedPoESwitch.
zEthernet Port Connection
 Networkcables--Usestandardnetwork(UTP)cableswithRJ45connectors.
 TheabovePCisinstalledwithWebbrowser.
Note
It is recommended to use Internet Explorer 8.0 or above to access
the Managed PoE Switch. If the Web interface of the Managed PoE
Switch is not accessible, please turn off the anti-virus software or
firewallandthentryitagain.

5
3. Terminal Setup
To congure the system, connect a serial cable to a COM port on a PC or
notebookcomputerandtoRJ45typeofserialportoftheManagedPoESwitch.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port
RS232 to RJ45 Cable
Console Port
RJ45
Figure 3-1: Managed PoE Switch Console Connectivity
A terminal program is required to make the software connection to the Managed
PoESwitch.PuttyorTeraTermmaybeagoodchoice.
1. Run terminal program Tera Term on the OS.
2.When the following screen appears, make sure that the COM port should be
conguredas:
Speed:115200
Data:8bits
Parity:None
Stop bits: 1
Flowcontrol:None
Figure 3-2: COM Port Conguration

6
3.1 Logging on to Console
Once the terminal is connected to the device, power on the Managed PoE Switch,
and the terminal will display “running testing procedures”. Then, the following
message asks to log in username and password. The factory default user name
andpasswordareshownasfollowsandtheloginscreeninFigure3-3appears
Username:admin
Password:admin
Figure 3-3: Managed PoE Switch Console Login Screen
The user can now enter commands to manage the Managed PoE Switch. For a
detaileddescriptionofthecommands,pleaserefertothefollowingchapters.
Note
1.For security reason, please change and memorize the new pass-
wordafterthisfirstsetup.
2.Onlyacceptcommandinlowercaseletterunderconsoleinterface.

7
3.2 ConguringIPAddress
TheManagedPoESwitchisshippedwithdefaultIPaddressshownbelow.
IPAddress:192.168.0.100
Subnet Mask: 255.255.255.0
To check the current IP address or modify a new IP address for the Switch, please
usetheprocedureasfollows:
Show the current IP Address
1.Atth“#”prompt,enter“show ip interface brief”.
2.ThescreendisplaysthecurrentIPaddressasshowninFigure3-4.
Figure 3-4: IP Information Screen

8
 ConguringIPAddress
3.At the “#” prompt, enter the following command and press <Enter> as shown
inFigure3-5.
GS-6320-8P2X#congureterminal
GS-6320-8P2X(cong)#interface vlan 1
GS-6320-8P2X(cong-if-vlan)#ip address 192.168.1.100 255.255.255.0
The previous command would apply the following settings for the Managed PoE
Switch.
IPAddress:192.168.1.100
Subnet Mask: 255.255.255.0
Figure 3-5: Conguring IP Address Screen
4.Repeatstep1tocheckiftheIPaddresshaschanged
If the IP is successfully congured, the Managed PoE Switch will apply the new IP
addresssetting immediately. Youcanaccessthe Webinterfaceof theManaged PoE
SwitchthroughthenewIPaddress.

9
3.3 StoringCurrentSwitchConguration
In the Managed PoE Switch, the running conguration sequence running-cong
can be saved from the RAM to FLASH by “copy” command, so that the running
conguration sequence becomes the start-up conguration le, which is called
congurationsave.
Atthe“#”prompt,enterthefollowingcommandandpress<Enter>.
#copyrunning-congstartup-cong
Figure 3-6: Saving Current Conguration Command Screen
Note
If you are not familiar with the console command or the related
parameter, enter “help” anytime in console to get the help
description.

10
4. Starting Web Management
The following shows how to start up the Web Management of the Managed
PoE Switch. Note the Managed PoE Switch is congured through an Ethernet
connection. Please make sure the manager PC must be set to the same IP subnet
address.
Forexample,thedefault IPaddressoftheManagedPoESwitchis192.168.0.100,
then the manager PC should be set to 192.168.0.x (where x is a number
between1and254,except100),andthedefaultsubnetmaskis255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address: 192.168.0.100
Figure 4-1: IP Management Diagram
4.1 Logging in to the Managed PoE Switch
1.Use Internet Explorer 8.0 or above Web browser and enter IP address
https://192.168.0.100 (the factory default IP address or the one that you
havejustchangedinconsole)toaccesstheWebinterface.
2.When the following dialog box appears, please enter the default user name and
password “admin” (or the password you have changed via console). The login
screeninFigure4-2appears.
DefaultIPAddress:192.168.0.100
DefaultUsername:admin
DefaultPassword:admin
Figure 4-2: Login Screen
