User’s Manual of SGSW-24040 / 24240 Series
1
User’s Manual
SGSW-24040 / SGSW-24040R
24-Port 10/100/1000Mbps
Layer 2 Managed Stackable Switch
SGSW-24040P / SGSW-24040P4
24G PoE Layer2 Managed Stackable Switch
SGSW-24240 / SGSW-24240R
24-Port 100/1000 SFP Fiber
Layer2 Managed Stackable Switch
SGSW-24040HP
24G High PoE Layer2 Managed Stackable Switch

User’s Manual of SGSW-24040 / 24240 Series
2
Trademarks
Copyright © PLANET Technology Corp. 2011.
Contents subject to which revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no
warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for
a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability
for any inaccuracies or omissions that may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of
PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANETmakes
no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to
this User's Manual and/or to the products described in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and
suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at whose own expense.
CE Mark Warning
This is a ClassA product. In a domestic environment, this product may cause radio interference, in which case the user may be
required to take adequate measures.
Energy Saving Note of the Device
This power required device does not support Standby mode operation.
For energy saving, please remove the power cable to disconnect the device from the power circuit.
Without removing power cable, the device will still consuming power from the power source. In the view of Saving the Energy
and reduce the unnecessary power consuming, it is strongly suggested to remove the power connection for the device if this
device is not intended to be active.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
Revision
PLANET 24-Port 10/100/1000Mbps with 4 Shared SFP / 24 100/1000 SFP Slots with 8 Shared TP Managed Stackable Switch
User's Manual
FOR MODELS: SGSW-24040 / SGSW-24240 Series
REVISION: 1.6 (February.2011)
Part No: EM-SGSW-24040_24240 Series (2080-A93070-004)

User’s Manual of SGSW-24040 / 24240 Series
3
TABLE OF CONETNTS
1. INTRODUTION ....................................................................................................................19
1.1 Packet Contents .........................................................................................................................................19
1.2 Product Description...................................................................................................................................19
1.3 How to Use This Manual............................................................................................................................22
1.4 Product Features........................................................................................................................................23
1.5 Product Specification ................................................................................................................................26
2. INSTALLATION ...................................................................................................................34
2.1 Hardware Description................................................................................................................................34
2.1.1 Switch Front Panel ..............................................................................................................................................34
2.1.2 LED Indications ...................................................................................................................................................36
2.1.3 Switch Rear Panel...............................................................................................................................................40
2.2 Install the Switch........................................................................................................................................43
2.2.1 Desktop Installation .............................................................................................................................................43
2.2.2 Rack Mounting.....................................................................................................................................................44
2.2.3 Installing the SFP transceiver..............................................................................................................................45
2.2.4 Connecting DC Power Supply.............................................................................................................................47
2.3 Stack Installation ........................................................................................................................................49
2.3.1 Connecting Stacking cable..................................................................................................................................50
2.3.2 Management Stacking.........................................................................................................................................50
3. SWITCH MANAGEMENT....................................................................................................53
3.1 Requirements..............................................................................................................................................53
3.2 Management Access Overview.................................................................................................................54
3.3 Administration Console.............................................................................................................................54
3.4 Web Management.......................................................................................................................................56
3.5 SNMP-Based Network Management.........................................................................................................57
4. WEB CONFIGURATION......................................................................................................58
4.1 Main Web Page ...........................................................................................................................................61
4.2 System.........................................................................................................................................................63

User’s Manual of SGSW-24040 / 24240 Series
4
4.2.1 System Information..............................................................................................................................................64
4.2.2 IP Configuration...................................................................................................................................................65
4.2.3 IPv6 Configuration...............................................................................................................................................66
4.2.4 Users Configuration.............................................................................................................................................67
4.2.5 Users Privilege Levels.........................................................................................................................................70
4.2.6 NTP Configuration...............................................................................................................................................72
4.2.7 UPnP Configuration.............................................................................................................................................73
4.2.8 DHCP Relay........................................................................................................................................................74
4.2.9 DHCP Relay Statistics.........................................................................................................................................76
4.2.10 CPU Load..........................................................................................................................................................78
4.2.11 System Log........................................................................................................................................................79
4.2.12 Detailed Log ......................................................................................................................................................80
4.2.13 Remote Syslog..................................................................................................................................................81
4.2.14 SMTP Configure................................................................................................................................................81
4.2.15 Web Firmware Upgrade.....................................................................................................................................83
4.2.16 TFTP Firmware Upgrade...................................................................................................................................84
4.2.17 Configuration Backup........................................................................................................................................85
4.2.18 Configuration Upload.........................................................................................................................................87
4.2.19 Factory Default..................................................................................................................................................88
4.2.20 System Reboot..................................................................................................................................................89
4.3 Simple Network Management Protocol....................................................................................................90
4.3.1 SNMP Overview ..................................................................................................................................................90
4.3.2 SNMP System Configuration...............................................................................................................................91
4.3.3 SNMP System Information Configuration............................................................................................................92
4.3.4 SNMP Trap Configuration....................................................................................................................................93
4.3.5 SNMPv3 Configuration........................................................................................................................................95
4.3.5.1 SNMPv3 Communities Configuration........................................................................................................95
4.3.5.2 SNMPv3 Users Configuration....................................................................................................................95
4.3.5.3 SNMPv3 Groups Configuration.................................................................................................................98
4.3.5.4 SNMPv3 Views Configuration....................................................................................................................99
4.3.5.5 SNMPv3 Accesses Configuration............................................................................................................100
4.4 Port Management .....................................................................................................................................102
4.4.1 Port Configuration..............................................................................................................................................102
4.4.2 Port Statistics Overview.....................................................................................................................................104
4.4.3 Port Statistics Detail...........................................................................................................................................105
4.4.4 SFP Module Information....................................................................................................................................107
4.4.5 Port Mirroring Configuration...............................................................................................................................108
4.5 Link Aggregation......................................................................................................................................112
4.5.1 Static Aggregation Configuration .......................................................................................................................114

User’s Manual of SGSW-24040 / 24240 Series
5
4.5.2 LACP Configuration...........................................................................................................................................116
4.5.3 LACP System Status .........................................................................................................................................117
4.5.4 LACP Port Status...............................................................................................................................................118
4.5.5 LACP Port Statistics...........................................................................................................................................119
4.6 VLAN..........................................................................................................................................................121
4.6.1 VLAN Overview.................................................................................................................................................121
4.6.2 IEEE 802.1Q VLAN...........................................................................................................................................121
4.6.3 VLAN Basic Information.....................................................................................................................................125
4.6.4 VLAN Port Configuration ...................................................................................................................................126
4.6.5 VLAN Membership Configuration......................................................................................................................130
4.6.6 VLAN Membership Status for User Static..........................................................................................................131
4.6.7 VLAN Port Status for User Static.......................................................................................................................132
4.6.8 Port Isolation Configuration...............................................................................................................................134
4.6.9 Private VLAN Membership Configuration..........................................................................................................137
4.6.10 VLAN setting example:....................................................................................................................................139
4.6.10.1 Two separate 802.1Q VLAN..................................................................................................................139
4.6.10.2 VLAN Trunking between two 802.1Q aware switch...............................................................................143
4.6.10.4 Port Isolate............................................................................................................................................144
4.7 Spanning Tree Protocol...........................................................................................................................147
4.7.1 Theory ...............................................................................................................................................................147
4.7.2 STP Bridge Configuration..................................................................................................................................153
4.7.3 Bridge Status.....................................................................................................................................................155
4.7.4 CIST Port Configuration.....................................................................................................................................156
4.7.5 MSTI Priorities...................................................................................................................................................159
4.7.6 MSTI Configuration............................................................................................................................................160
4.7.7 MSTI Ports Configuration ..................................................................................................................................161
4.7.8 Port Status.........................................................................................................................................................164
4.7.9 Port Statistics.....................................................................................................................................................165
4.8 Multicast....................................................................................................................................................167
4.8.1 IGMP Snooping .................................................................................................................................................167
4.8.2 IGMP Snooping Configuration...........................................................................................................................171
4.8.3 IGMP Port Related Configuration......................................................................................................................172
4.8.4 VLAN Configuration...........................................................................................................................................173
4.8.5 Port Group Filtering...........................................................................................................................................174
4.8.6 IGMP Snooping Status ......................................................................................................................................175
4.8.7 MVR Configuration............................................................................................................................................176
4.8.8 MVR Status........................................................................................................................................................178
4.9 Quality of Service.....................................................................................................................................180

User’s Manual of SGSW-24040 / 24240 Series
6
4.9.1 Understand QOS...............................................................................................................................................180
4.9.2 QCL Configuration Wizard.................................................................................................................................181
4.9.2.1 Set up Policy Rules.................................................................................................................................182
4.9.2.2 Set up Typical Network Application Rules ...............................................................................................183
4.9.2.3 Set up ToS Precedence Mapping............................................................................................................185
4.9.2.4 Set up VLAN Tag Priority Mapping..........................................................................................................187
4.9.3 QoS Control List Configuration..........................................................................................................................188
4.9.3.1 QoS Control Entry Configuration.............................................................................................................189
4.9.4 Port QoS Configuration......................................................................................................................................190
4.9.5 Bandwidth Control.............................................................................................................................................192
4.9.6 Storm Control Configuration ..............................................................................................................................194
4.9.7 QoS Statistics....................................................................................................................................................195
4.9.8 DSCP Remarking ..............................................................................................................................................196
4.9.9 Voice VLAN Configuration.................................................................................................................................198
4.9.10 Voice VLAN OUI Table.....................................................................................................................................201
4.10 Access Control Lists..............................................................................................................................202
4.10.1 Access Control List Status...............................................................................................................................202
4.10.2 Access Control List Configuration....................................................................................................................203
4.10.3 ACE Configuration...........................................................................................................................................205
4.10.4 ACL Ports Configuration ..................................................................................................................................213
4.10.5 ACL Rate Limiter Configuration .......................................................................................................................215
4.11 Authentication.........................................................................................................................................217
4.11.1 Understanding IEEE 802.1X Port-Based Authentication..................................................................................218
4.11.2 Authentication Configuration............................................................................................................................221
4.11.3 Network Access Server Configuration..............................................................................................................222
4.11.4 Network Access Overview ...............................................................................................................................233
4.11.5 Network Access Statistics ................................................................................................................................234
4.11.6 Authentication Server Configuration.................................................................................................................240
4.11.7 RADIUS Overview ...........................................................................................................................................244
4.11.8 RADIUS Details ...............................................................................................................................................245
4.11.9 Windows Platform RADIUS Server Configuration............................................................................................251
4.11.10 802.1X Client Configuration...........................................................................................................................256
4.12 Security ...................................................................................................................................................259
4.12.1 Port Limit Control.............................................................................................................................................259
4.12.2 Access Management .......................................................................................................................................263
4.12.3 Access Management Statistics........................................................................................................................264
4.12.4 HTTPs .............................................................................................................................................................265
4.12.5 SSH.................................................................................................................................................................265
4.12.6 Port Security Status.........................................................................................................................................266

User’s Manual of SGSW-24040 / 24240 Series
7
4.12.7 Port Security Detail..........................................................................................................................................269
4.12.8 DHCP Snooping ..............................................................................................................................................270
4.12.9 DHCP Snooping Statistics...............................................................................................................................271
4.12.10 IP Source Guard Configuration......................................................................................................................272
4.12.11 IP Source Guard Static Table.........................................................................................................................274
4.12.12 ARP Inspection..............................................................................................................................................275
4.12.13 ARP Inspection Static Table...........................................................................................................................277
4.13 Address Table.........................................................................................................................................279
4.13.1 MAC Address Table Configuration...................................................................................................................279
4.13.2 Static MAC Table Configuration.......................................................................................................................280
4.13.3 MAC Address Table Status ..............................................................................................................................280
4.13.4 MAC Table Learning........................................................................................................................................282
4.13.5 Dynamic ARP Inspection Table........................................................................................................................283
4.13.6 Dynamic IP Source Guard Table......................................................................................................................285
4.14 LLDP........................................................................................................................................................287
4.14.1 Link Layer Discovery Protocol.........................................................................................................................287
4.14.2 LLDP Configuration .........................................................................................................................................287
4.14.3 LLDPMED Configuration .................................................................................................................................291
4.14.4 LLDP-MED Neighbor.......................................................................................................................................297
4.14.5 Neighbor..........................................................................................................................................................300
4.14.6 Port Statistics...................................................................................................................................................301
4.15 Network Diagnostics..............................................................................................................................304
4.15.1 Ping .................................................................................................................................................................304
4.15.2 IPv6 Ping.........................................................................................................................................................305
4.15.3 Remote IP Ping Test........................................................................................................................................306
4.15.4 Cable Diagnostics............................................................................................................................................308
4.16 Power over Ethernet (SGSW-24040P / SGSW-24040P4 / SGSW-24040HP) ......................................310
4.16.1 Power over Ethernet Powered Device.............................................................................................................310
4.16.2 Power Configuration........................................................................................................................................311
4.16.3 Port Configuration............................................................................................................................................314
4.16.4 PoE Status.......................................................................................................................................................316
4.16.5 PoE Schedule..................................................................................................................................................318
4.16.6 LLDP Neighbor Power Over Ethernet..............................................................................................................319
4.17 Stack ........................................................................................................................................................321
4.17.1 Stack................................................................................................................................................................322
4.17.1.1 Switch IDs...........................................................................................................................................322
4.17.1.2 Master Election...................................................................................................................................323
4.17.1.3 Stack Redundancy..............................................................................................................................324

User’s Manual of SGSW-24040 / 24240 Series
8
4.17.1.4 Shortest Path Forwarding...................................................................................................................324
4.17.2 Stack Configuration..........................................................................................................................................325
4.17.3 Stack Information.............................................................................................................................................328
4.17.4 Stack Port State Ovewview..............................................................................................................................329
4.17.5 Stack Example.................................................................................................................................................330
5. COMMAND LINE INTERFACE..........................................................................................334
5.1 Accessing the CLI ....................................................................................................................................334
Logon to the Console..........................................................................................................................................334
Configure IP address...........................................................................................................................................334
5.2 Telnet Login ..............................................................................................................................................337
6. Command Line Mode.......................................................................................................338
6.1 System Command....................................................................................................................................338
System Configuration..........................................................................................................................................338
System Name......................................................................................................................................................339
System Contact...................................................................................................................................................340
System Location..................................................................................................................................................340
System Timezone................................................................................................................................................341
System Prompt....................................................................................................................................................341
System Reboot....................................................................................................................................................342
System Restore Default.......................................................................................................................................342
System Load .......................................................................................................................................................343
System Log .........................................................................................................................................................343
6.2 Stack..........................................................................................................................................................345
Stack List.............................................................................................................................................................345
Stack Master Priority............................................................................................................................................345
Stack Master Reelect...........................................................................................................................................346
Stack Select.........................................................................................................................................................346
Stack SID Swap...................................................................................................................................................346
Stack SID Delete .................................................................................................................................................347
Stack SID Assign.................................................................................................................................................347
6.3 IP Command..............................................................................................................................................349
IP Configuration...................................................................................................................................................349
IP DHCP..............................................................................................................................................................349
IP Setup...............................................................................................................................................................350
IP Ping.................................................................................................................................................................351
IP DNS ................................................................................................................................................................351

User’s Manual of SGSW-24040 / 24240 Series
9
IP DNS Proxy ......................................................................................................................................................352
IPv6 AUTOCINFIG ..............................................................................................................................................352
IPv6 Setup...........................................................................................................................................................353
IPv6 Ping.............................................................................................................................................................354
IP NTP Configuration...........................................................................................................................................354
IP NTP Mode.......................................................................................................................................................355
IP NTP Server Add..............................................................................................................................................355
IP NTP Server IPv6 Add......................................................................................................................................356
IP NTP Server Delete..........................................................................................................................................356
6.4 Port Management Command...................................................................................................................358
Port Configuration ...............................................................................................................................................358
Port Mode............................................................................................................................................................358
Port Flow Control.................................................................................................................................................359
Port State.............................................................................................................................................................360
Port Maximum Frame..........................................................................................................................................360
Port Power...........................................................................................................................................................361
Port SFP..............................................................................................................................................................361
Port Excessive.....................................................................................................................................................362
Port Statistics.......................................................................................................................................................362
Port VeriPHY.......................................................................................................................................................363
6.5 MAC Address Table Command...............................................................................................................364
MAC Configuration..............................................................................................................................................364
MAC Add.............................................................................................................................................................365
MAC Delete.........................................................................................................................................................365
MAC Lookup........................................................................................................................................................366
MAC Age Time ....................................................................................................................................................366
MAC Learning .....................................................................................................................................................367
MAC Dump..........................................................................................................................................................367
MAC Statistics.....................................................................................................................................................368
MAC Flush...........................................................................................................................................................369
6.6 VLAN Configuration Command ..............................................................................................................370
VLAN Configuration.............................................................................................................................................370
VLAV PVID..........................................................................................................................................................370
VLAN Frame Type...............................................................................................................................................371
VLAN Ingress Filter .............................................................................................................................................371
VLAN Mode.........................................................................................................................................................372
VLAN Link Type...................................................................................................................................................373
VLAN Q-in-Q Mode .............................................................................................................................................373
VLAN Ethernet Type............................................................................................................................................374

User’s Manual of SGSW-24040 / 24240 Series
10
VLAN Add............................................................................................................................................................374
VLAN Delete........................................................................................................................................................375
VLAN Lookup......................................................................................................................................................375
VLAN Status........................................................................................................................................................376
6.7 Private VLAN Configuration Command .................................................................................................378
PVLAN Configuration..........................................................................................................................................378
PVLAN Add .........................................................................................................................................................379
PVLAN Delete.....................................................................................................................................................379
PVLAN Lookup....................................................................................................................................................380
PVLAN Isolate.....................................................................................................................................................380
6.8 Security Command...................................................................................................................................382
Security Switch User Configuration.....................................................................................................................382
Security Switch User Add....................................................................................................................................382
Security Switch User Delete................................................................................................................................383
Security Switch Privilege Level Configuration .....................................................................................................383
Security Switch Privilege Level Group.................................................................................................................384
Security Switch Privilege Level Current...............................................................................................................385
Security Switch Auth Configuration .....................................................................................................................385
Security Switch Auth Method...............................................................................................................................386
Security Switch SSH Configuration.....................................................................................................................387
Security Switch SSH Mode..................................................................................................................................387
Security Switch HTTPs Configuration .................................................................................................................388
Security Switch HTTPs Mode..............................................................................................................................388
Security Switch HTTPs Redirect .........................................................................................................................389
Security Switch Access Configuration .................................................................................................................389
Security Switch Access Mode..............................................................................................................................390
Security Switch Access Add ................................................................................................................................390
Security Switch Access IPv6 Add ........................................................................................................................391
Security Switch Access Delete............................................................................................................................392
Security Switch Access Lookup...........................................................................................................................392
Security Switch Access Clear..............................................................................................................................392
Security Switch Access Statistics ........................................................................................................................393
Security Switch SNMP Configuration ..................................................................................................................393
Security Switch SNMP Mode...............................................................................................................................395
Security Switch SNMP Version............................................................................................................................396
Security Switch SNMP Read Community............................................................................................................396
Security Switch SNMPWrite Community............................................................................................................397
Security Switch SNMP Trap Mode.......................................................................................................................397
Security Switch SNMP Trap Version....................................................................................................................398

User’s Manual of SGSW-24040 / 24240 Series
11
Security Switch SNMP Trap Community.............................................................................................................398
Security Switch SNMP Trap Destination..............................................................................................................399
Security Switch SNMP Trap IPv6 Destination .....................................................................................................399
Security Switch SNMP Trap Authentication Failure.............................................................................................400
Security Switch SNMP Trap Link-up....................................................................................................................400
Security Switch SNMP Trap Inform Mode ...........................................................................................................401
Security Switch SNMP Trap Inform Timeout........................................................................................................402
Security Switch SNMP Trap Inform Retry Times .................................................................................................402
Security Switch SNMP Trap Probe Security Engine ID.......................................................................................403
Security Switch SNMP Trap Security Engine ID..................................................................................................403
Security Switch SNMP Trap Security Name........................................................................................................404
Security Switch SNMP Engine ID........................................................................................................................404
Security Switch SNMP Community Add ..............................................................................................................404
Security Switch SNMP Community Delete..........................................................................................................405
Security Switch SNMP Community Lookup.........................................................................................................405
Security Switch SNMP User Add.........................................................................................................................406
Security Switch SNMP User Delete.....................................................................................................................407
Security Switch SNMP User Changekey.............................................................................................................407
Security Switch SNMP User Lookup ...................................................................................................................407
Security Switch SNMP Group Add.......................................................................................................................408
Security Switch SNMP Group Delete ..................................................................................................................409
Security Switch SNMP Group Lookup.................................................................................................................409
Security Switch SNMP ViewAdd.........................................................................................................................410
Security Switch SNMP View Delete.....................................................................................................................410
Security Switch SNMP View Lookup...................................................................................................................410
Security Switch SNMP Access Add.....................................................................................................................411
Security Switch SNMPAccess Delete.................................................................................................................412
Security Switch SNMPAccess Lookup................................................................................................................412
Security Network Psec Switch.............................................................................................................................413
Security Network Psec Port.................................................................................................................................414
Security Network Limit Configuration ..................................................................................................................415
Security Network Limit Mode...............................................................................................................................416
Security Network Limit Aging...............................................................................................................................416
Security Network Limit Agetime...........................................................................................................................417
Security Network Limit Port.................................................................................................................................417
Security Network Limit Limit................................................................................................................................418
Security Network Limit Action..............................................................................................................................419
Security Network Limit Reopen...........................................................................................................................419
Security Network NAS Configuration...................................................................................................................420
Security Network NAS Mode...............................................................................................................................420

User’s Manual of SGSW-24040 / 24240 Series
12
Security Network NAS State................................................................................................................................421
Security Network NAS Reauthentication.............................................................................................................422
Security Network NAS ReauthPeriod..................................................................................................................422
Security Network NAS EapolTimeout..................................................................................................................423
Security Network NAS Agetime...........................................................................................................................423
Security Network NAS Holdtime..........................................................................................................................424
Security Network NAS RADIUS_QoS .................................................................................................................424
Security Network NAS RADIUS_VLAN...............................................................................................................425
Security Network NAS Guest_VLAN...................................................................................................................425
Security Network NAS Authenticate....................................................................................................................426
Security Network NAS Statistics..........................................................................................................................427
Security Network ACL Configuration ...................................................................................................................428
Security Network ACLAction...............................................................................................................................429
Security Network ACL Policy...............................................................................................................................430
Security Network ACL Rate.................................................................................................................................431
Security Network ACLAdd ..................................................................................................................................431
Security Network ACL Delete ..............................................................................................................................433
Security Network ACL Lookup.............................................................................................................................433
Security Network ACL Clear................................................................................................................................433
Security Network ACL Status...............................................................................................................................434
Security Network DHCP Relay Configuration......................................................................................................434
Security Network DHCP Relay Mode..................................................................................................................435
Security Network DHCP Relay Server.................................................................................................................435
Security Network DHCP Relay Information Mode ...............................................................................................436
Security Network DHCP Relay Information Policy...............................................................................................437
Security Network DHCP Relay Statistics.............................................................................................................437
Security Network DHCP Snooping Configuration................................................................................................438
Security Network DHCP Snooping Mode............................................................................................................439
Security Network DHCP Snooping Port Mode.....................................................................................................439
Security Network DHCP Snooping Statistics.......................................................................................................440
Security Network IP Source Guard Configuration ...............................................................................................441
Security Network IP Source Guard Mode............................................................................................................442
Security Network IP Source Guard Port Mode....................................................................................................442
Security Network IP Source Guard Limit.............................................................................................................443
Security Network IP Source Guard Entry............................................................................................................444
Security Network IP Source Guard Status...........................................................................................................444
Security Network ARP Inspection Configuration..................................................................................................445
Security Network ARP Inspection Mode..............................................................................................................445
Security Network ARP Inspection Port Mode ......................................................................................................445
Security Network ARP Inspection Entry...............................................................................................................446

User’s Manual of SGSW-24040 / 24240 Series
13
Security Network ARP Inspection Status.............................................................................................................447
Security AAA Configuration .................................................................................................................................447
Security AAA Timeout..........................................................................................................................................448
Security AAA Deadtime .......................................................................................................................................449
Security AAA RADIUS.........................................................................................................................................449
Security AAAACCT_RADIUS..............................................................................................................................450
Security AAA TACACS+ ......................................................................................................................................451
Security AAA Statistics.........................................................................................................................................451
6.9 Spanning Tree Protocol Command ........................................................................................................453
STP Configuration...............................................................................................................................................453
STP Version ........................................................................................................................................................453
STP Tx Hold........................................................................................................................................................454
STP MaxHops .....................................................................................................................................................454
STP MaxAge .......................................................................................................................................................455
STP FwdDelay ....................................................................................................................................................455
STP CName ........................................................................................................................................................456
STP BPDU Filter..................................................................................................................................................456
STP BPDU Guard................................................................................................................................................457
STP Recovery.....................................................................................................................................................457
STP Status ..........................................................................................................................................................458
STP MSTI Priority................................................................................................................................................459
STP MSTI Map....................................................................................................................................................459
STP MSTI Add.....................................................................................................................................................460
STP Port Configuration........................................................................................................................................460
STP Port Mode....................................................................................................................................................461
STP Port Edge ....................................................................................................................................................461
STP Port AutoEdge .............................................................................................................................................462
STP Port P2P......................................................................................................................................................462
STP Port RestrictedRole .....................................................................................................................................463
STP Port RestrictedTcn.......................................................................................................................................463
STP Port bpduGuard...........................................................................................................................................464
STP Port Statistic.................................................................................................................................................464
STP Port Mcheck.................................................................................................................................................465
STP MSTI Port Configuration..............................................................................................................................465
STP MSTI Port Cost............................................................................................................................................466
STP MSTI Port Priority........................................................................................................................................467
6.10 Multicast Configuration Command ......................................................................................................468
IGMP Configuration.............................................................................................................................................468
IGMP Mode .........................................................................................................................................................468

User’s Manual of SGSW-24040 / 24240 Series
14
IGMP Leave Proxy ..............................................................................................................................................469
IGMP State..........................................................................................................................................................469
IGMP Querier......................................................................................................................................................470
IGMP Fastleave...................................................................................................................................................470
IGMP Throttling ...................................................................................................................................................471
IGMP Filtering .....................................................................................................................................................471
IGMP Router .......................................................................................................................................................472
IGMP Flooding ....................................................................................................................................................473
IGMP Groups.......................................................................................................................................................473
IGMP Status ........................................................................................................................................................473
6.11 Link Aggregation Command .................................................................................................................475
Aggregation Configuration...................................................................................................................................475
Aggregation Add..................................................................................................................................................475
Aggregation Delete..............................................................................................................................................476
Aggregation Lookup ............................................................................................................................................476
Aggregation Mode...............................................................................................................................................477
6.12 Link Aggregation Control Protocol Command....................................................................................478
LACP Configuration.............................................................................................................................................478
LACP Mode.........................................................................................................................................................479
LACP Key............................................................................................................................................................479
LACP Role...........................................................................................................................................................480
LACP Status........................................................................................................................................................480
LACP Statistics....................................................................................................................................................481
6.13 LLDP Command......................................................................................................................................482
LLDP Configuration.............................................................................................................................................482
LLDP Mode .........................................................................................................................................................482
LLDP Optional TLV..............................................................................................................................................483
LLDP Interval.......................................................................................................................................................484
LLDP Hold...........................................................................................................................................................484
LLDP Delay.........................................................................................................................................................485
LLDP Reinit.........................................................................................................................................................485
LLDP Statistics....................................................................................................................................................486
LLDP Info ............................................................................................................................................................487
LLDP CDP Aware ................................................................................................................................................487
6.14 LLDPMED Command .............................................................................................................................488
LLDPMED Configuration.....................................................................................................................................488
LLDPMED Civic...................................................................................................................................................488
LLDPMED ECS...................................................................................................................................................489

User’s Manual of SGSW-24040 / 24240 Series
15
LLDPMED Policy Delete......................................................................................................................................490
LLDPMED Policy Add..........................................................................................................................................490
LLDPMED Port Policy .........................................................................................................................................491
LLDPMED Coordinates.......................................................................................................................................492
LLDPMED Datum................................................................................................................................................492
LLDPMED Fast ...................................................................................................................................................493
LLDPMED Info ....................................................................................................................................................493
LLDPMED Debuge_med_transmit_var ...............................................................................................................493
6.15 Power over Ethernet Command............................................................................................................494
PoE Configuration...............................................................................................................................................494
PoE Mode............................................................................................................................................................495
PoE Priority .........................................................................................................................................................495
PoE Mamagement Mode.....................................................................................................................................496
PoE Maximum Power..........................................................................................................................................497
PoE Allocated Power...........................................................................................................................................497
PoE Power Supply ..............................................................................................................................................498
PoE Status...........................................................................................................................................................498
6.16 Quality of Service Command ................................................................................................................499
QoS Configuration...............................................................................................................................................499
QoS Classes .......................................................................................................................................................499
QoS Default.........................................................................................................................................................500
QoS Tag Priority..................................................................................................................................................500
QoS QCL Port .....................................................................................................................................................501
QoS QCLAdd......................................................................................................................................................501
QoS QCL Delete..................................................................................................................................................502
QoS QCL Lookup................................................................................................................................................503
QoS Mode ...........................................................................................................................................................503
QoS Weight.........................................................................................................................................................503
QoS Rate Limiter.................................................................................................................................................504
QoS Shaper.........................................................................................................................................................504
QoS Storm Unicast..............................................................................................................................................505
QoS Strom Multicast............................................................................................................................................505
QoS Strom Broadcast..........................................................................................................................................506
QoS DSCP Remarking........................................................................................................................................507
QoS DSCP Queue Mapping................................................................................................................................507
6.17 Mirror Command ....................................................................................................................................508
Mirror Configuration.............................................................................................................................................508
Mirror Port ...........................................................................................................................................................508
Mirror SID............................................................................................................................................................509

User’s Manual of SGSW-24040 / 24240 Series
16
Mirror Mode.........................................................................................................................................................509
6.18 Configuration Command.......................................................................................................................511
Configuration Save..............................................................................................................................................511
Configuration Load..............................................................................................................................................511
6.19 Firmware Command...............................................................................................................................512
Firmware Load ....................................................................................................................................................512
Firmware IPv6 Load............................................................................................................................................512
6.20 UPnP Command .....................................................................................................................................513
UPnP Configuration.............................................................................................................................................513
UPnP Mode.........................................................................................................................................................513
UPnP TTL............................................................................................................................................................514
UPnPAdvertising Duration..................................................................................................................................514
6.21 MVR Command.......................................................................................................................................515
MVR Configuration..............................................................................................................................................515
MVR Group .........................................................................................................................................................516
MVR Status .........................................................................................................................................................516
MVR Mode ..........................................................................................................................................................516
MVR Port Mode...................................................................................................................................................517
MVR Multicast VLAN...........................................................................................................................................517
MVR Port Type....................................................................................................................................................518
MVR Immediate Leave........................................................................................................................................518
6.22 Voice VLAN Command...........................................................................................................................520
Voice VLAN Configuration...................................................................................................................................520
Voice VLAN Mode ...............................................................................................................................................521
Voice VLAN ID.....................................................................................................................................................522
Voice VLAN Agetime...........................................................................................................................................522
Voice VLAN Traffic Class.....................................................................................................................................523
Voice VLAN OUI Add...........................................................................................................................................523
Voice VLAN OUI Delete.......................................................................................................................................524
Voice VLAN OUI Clear........................................................................................................................................524
Voice VLAN OUI Lookup.....................................................................................................................................525
Voice VLAN Port Mode........................................................................................................................................525
Voice VLAN Security ...........................................................................................................................................526
6.23 SMTP Command.....................................................................................................................................527
SMTP Configuration............................................................................................................................................527
SMTP Mode ........................................................................................................................................................527
SMTP Server.......................................................................................................................................................527

User’s Manual of SGSW-24040 / 24240 Series
17
SMTP Auth ..........................................................................................................................................................528
SMTPAuth_user.................................................................................................................................................528
SMTPAuth_pass.................................................................................................................................................529
SMTP Mailfrom....................................................................................................................................................529
SMTP Mailsubject................................................................................................................................................529
SMTP Mailto1......................................................................................................................................................530
SMTP Mailto2......................................................................................................................................................530
6.24 Show Command .....................................................................................................................................531
ShowACL Configuration .....................................................................................................................................531
Show Link Aggregation Configuration .................................................................................................................531
Show IGMP Configuration...................................................................................................................................531
Show IP Configuration.........................................................................................................................................531
Show LACP Configuration...................................................................................................................................532
Show LLDP Configuration...................................................................................................................................532
Show MAC Configuration....................................................................................................................................532
Show Mirror Configuration...................................................................................................................................532
Show PoE Configuration.....................................................................................................................................532
Show Port Configuration......................................................................................................................................533
Show Private VLAN Configuration.......................................................................................................................533
Show QoS Configuration.....................................................................................................................................533
Show SNMP Configuration..................................................................................................................................533
Show Stack Configuration ...................................................................................................................................534
Show System Configuration................................................................................................................................534
Show VLAN Configuration...................................................................................................................................534
Show STP Configuration.....................................................................................................................................534
7. SWITCH OPERATION.......................................................................................................535
7.1 Address Table...........................................................................................................................................535
7.2 Learning ....................................................................................................................................................535
7.3 Forwarding & Filtering.............................................................................................................................535
7.4 Store-and-Forward ...................................................................................................................................535
7.5 Auto-Negotiation ......................................................................................................................................536
8. POWER OVER ETHERNET OVERVIEW..........................................................................537
What is PoE?...................................................................................................................................................537
The PoE Provision Process...........................................................................................................................539

User’s Manual of SGSW-24040 / 24240 Series
18
Stages of powering up a PoE link...............................................................................................................................539
Line Detection.............................................................................................................................................................539
Classification ..............................................................................................................................................................540
Start-up.......................................................................................................................................................................540
Operation....................................................................................................................................................................540
Power Disconnection Scenarios.................................................................................................................................540
9. TROUBLE SHOOTING......................................................................................................542
APPENDEX A........................................................................................................................544
A.1 Switch's RJ-45 Pin Assignments ...........................................................................................................544
A.2 10/100Mbps, 10/100Base-TX...................................................................................................................544
APPENDEX B : GLOSSARY.................................................................................................546

User’s Manual of SGSW-24040 / 24240 Series
19
1. INTRODUTION
The PLANET Layer 2 Managed Gigabit Switch series –SGSW Stackable, SGSW PoE and SGSW Fiber switch are all multiple
ports Gigabit Ethernet Switched with SFP fiber optical connective ability and robust layer 2 features; the description of these
models as below:
SGSW-24040 : 24-Port 10/100/1000Base-T with 4 Shared SFP Managed Stackable Switch
SGSW-24040R : 24-Port 10/100/1000Base-T with 4 Shared SFP Managed Stackable Switch / Redundant Power
SGSW-24040P 24-Port 10/100/1000Base-T PoE Managed Stackable Switch / 220W / IEEE 802.3af
SGSW-24040P4 24-Port 10/100/1000Base-T PoE Managed Stackable Switch / 380W / IEEE 802.3af
SGSW-24240 24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch
SGSW-24240R 24-Port 100/1000Base-X with 8 Shared TP Managed Stackable Switch / Redundant Power
SGSW-24040HP 24-Port 10/100/1000 Base-T PoE Managed Stackable Switch / 360W / IEEE 802.3af/at
Terms of “Managed Switch” means the Switches mentioned titled in the cover page of this User’s manual, i.e. SGSW- series
Managed Switch.
1.1 Packet Contents
Open the box of the Managed Switch and carefully unpack it. The box should contain the following items:
Check the contents of your package for following parts:
The Managed Switch x1
User’s manual CD x1
Quick installation guide x1
19” Rack mount accessory kit x1
Power cord x1
Rubber feet X4
RS-232 DB9 male Console cable x1
CB-STX50 – 50cm stack cable x1
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton including the
original packing material, and use them against to repack the product in case there is a need to return it to us for repair.
1.2 Product Description
Cost-effective IPv6 Managed Gigabit Switch solution for SMB
Nowadays, lots of electronic products or mobile devices can browse the Internet, which means the need of IP Address

User’s Manual of SGSW-24040 / 24240 Series
20
increases. However, the current IPv4 network infrastructure is not capable enough to provide IPAddress to each single
users/Clients. The situation forces the ISP to build up the IPv6 (Internet Protocol version 6) network infrastructure speedily.
To fulfill the demand, PLANET releases the IPv6 management Gigabit Ethernet Switch, SGSW- series Managed Switch. It
supports both IPv4 and IPv6 management functions. It can work with original network structure (IPv4) and also support the
new network structure (IPv6) in the future. With easy and friendly management interfaces and plenty of management
functions included, the SGSW- series Managed Switch is the best choice for ISP to build the IPv6 FTTx edge service and for
SMB to connect with IPv6 network.
High-Performance / Cost-effective / Telecom class Gigabit solution for Enterprise backbone and Data Center
Networking
The PLANET Managed Switch is a L2/L4 Managed Gigabit Switch. Since Gigabit network interface had become the basic
equipment and requirement of Enterprise and Network Servers, with 48Gbps switching fabric, the Managed Switch can
handle extremely large amounts of data in a secure topology linking to a backbone or high capacity servers. The powerful
QoS and Network Security features make it to meets the needs of effective data traffic control for both Campus and Enterprise,
such VoIP, video streaming and multicast application.
High Performance
The Managed Switch provides 24 10/100/1000Mbps Gigabit Ethernet ports with 4 shared Gigabit SFP slots. It boasts a high
performance switch architecture that is capable of providing non-blocking switch fabric and wire-speed throughput as high as
48Gbps, which greatly simplifies the tasks of upgrading the LAN for catering to increase bandwidth demands.
Robust Layer 2 Features
The Managed Switch can be programmed for basic switch management functions such as port speed configuration, Port
aggregation, VLAN, Spanning Tree protocol, QoS, bandwidth control and IGMP Snooping. The Managed Switch provides
802.1Q Tagged VLAN, Q-in-Q VLAN trunning and private VLAN, the VLAN groups allowed on the Managed Switch will be
maximally up to 255. Via supporting port aggregation, the Managed Switch allows the operation of a high-speed trunk
combining multiple ports, up to eight groups of maximum to 8-ports for trunking, and it supports fail-over as well.
Excellent Traffic Control
The Managed Switch is loaded with powerful traffic management and QoS features to enhance services offered by telecoms.
The functionality includes QoS features such as wire-speed Layer 4 traffic classifiers and bandwidth limiting that are particular
useful for multi-tenant unit, multi business unit, Telco, or Network Service Provide applications. It also empowers the
enterprises to take full advantages of the limited network resources and guarantees the best performance at VoIP and Video
conferencing transmission.
Efficient Management
For efficient management, the series of Managed Switch is equipped with console, WEB and SNMP management interfaces.
With its built-in Web-based management, it offers an easy-to-use, platform-independent management and configuration
facility. The Managed Switch supports standard Simple Network Management Protocol (SNMP) and can be managed via any
standard-based management software. For text-based management, it can also be accessed via Telnet and the console port.
