Planet IAP-2000PS User manual

Copyright
Copyright 2012 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any
software described in this manual is sold or licensed "as is". Should the programs prove defective following their
purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost of all necessary
servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Further,
this company reserves the right to revise this publication and to make changes from time to time in the contents
hereof without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of their
respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution:
To assure continued compliance, (example-use only shielded interface cables when connecting to computer or
peripheral devices) any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two conditions:
(1) This device may not cause harmful interference
(2) This Device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
I

Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to
avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna
shall not be less than 20 cm (8 inches) during normal operation.
CE mark Warning
This is a class B device, in a domestic environment; this product may cause radio interference, in which case
the user may be required to take adequate measures.
Energy Saving Note of the Device
This power required device does not support Stand by mode operation.
For energy saving, please remove the DC-plug or push the hardware Power Switch to OFF position to
disconnect
the device from the power circuit.
Without remove the DC-plug or switch off the device, the device will still consuming power from the power circuit.
In the view of Saving the Energy and reduce the unnecessary power consuming, it is strongly suggested to
switch off or remove the DC-plug for the device if this device is not intended to be active.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication terminal
Equipment and the mutual recognition of their conformity (R&TTE).
The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal
Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However, special
attention must be paid to the dangers of electric shock and static electricity when working with electrical
equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to
ensure the safe use of the equipment.
National Restrictions
This device is intended for home and office use in all EU countries (and other countries following the EU directive
1999/5/EC) without any limitation except for the countries mentioned below:
Country Restriction Reason/remark
Bulgaria None General authorization required for outdoor use and
public service
France
Outdoor use limited to 10
mW e.i.r.p. within the band
2454-2483.5 MHz
Military Radiolocation use. Refarming of the 2.4 GHz
band has been ongoing in recent years to allow current
relaxed regulation. Full implementation planned 2012
Italy None If used outside of own premises, general authorization is
required
Luxembourg None General authorization required for network and service
supply(not for spectrum)
II

Norway Implemented This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund
Russian Federation None Only for indoor applications
WEEE Regulation
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
Revision
User’s Manual for PLANET Industrial 802.11n PoE Wireless Access Point
Model: IAP-2000PE / IAP-2000PS / IAP-2001PE
Rev: 1.2 (February, 2012)
Part No. EM-IAP200x_v1.2 (2081-E50230-001)
III

CONTENTS
Chapter 1. INTRODUCTION ..................................................................................... 6
1.1. Package Contents .......................................................................................................6
1.2. Product Features.........................................................................................................6
1.3. Product Specification .................................................................................................7
Chapter 2. INSTALLATION....................................................................................... 9
2.1. Hardware Description .................................................................................................9
2.1.1. Physical Dimension...........................................................................................................9
2.1.2. Front Panel ..................................................................................................................... 10
2.1.3. LED Indicators ................................................................................................................ 11
2.1.4. Upper Panel .................................................................................................................... 12
2.2. Hardware Installation ................................................................................................12
2.2.1. Installation Steps............................................................................................................. 12
2.2.2. DIN-Rail Mounting........................................................................................................... 13
2.2.3. Wall Mount Plate Mounting ............................................................................................. 16
2.3. Wiring the Power Input .............................................................................................16
2.4. Cabling .......................................................................................................................18
2.4.1. Installing the SFP Transceiver (IAP-2001PE Only) ......................................................... 18
2.4.2. Removing the Module ..................................................................................................... 19
Chapter 3. USER MANAGEMENT INTERFACE .................................................... 21
3.1. Overview ....................................................................................................................21
3.2. Requirements............................................................................................................. 21
3.3. Management Method.................................................................................................21
3.3.1. Web Management........................................................................................................... 21
3.3.2. PLANET Smart Discovery Utility ..................................................................................... 23
Chapter 4. WEB CONFIGURATION ....................................................................... 26
4.1. Main Menu.................................................................................................................. 26
4.2. Web Panel ..................................................................................................................27
4.3. System........................................................................................................................ 28
4.3.1. Operation Mode .............................................................................................................. 28
4.3.2. Management ................................................................................................................... 29
4.3.3. SNMP Configuration ....................................................................................................... 30
4.3.4. Status.............................................................................................................................. 32
4.4. Network Settings .......................................................................................................34
4.4.1. LAN................................................................................................................................. 34
4.4.2. DHCP Clients.................................................................................................................. 37
4.4.3. IPv6................................................................................................................................. 37
4.5. Wireless Settings ......................................................................................................38
4.5.1. Basic ...............................................................................................................................38
4.5.2. Advanced ........................................................................................................................ 41
4.5.3. Security ........................................................................................................................... 44
4.5.4. WPS................................................................................................................................54
4.5.5. WDS................................................................................................................................58
4.5.6. Station List ...................................................................................................................... 63
4.6. Layer 2 Functions...................................................................................................... 64
4.6.1. Port Status ...................................................................................................................... 64
IV

V
4.6.2. Port Setting ..................................................................................................................... 65
4.6.3. VLAN Setting .................................................................................................................. 65
4.6.4. MAC Address Table......................................................................................................... 67
4.7. System Tools .............................................................................................................67
4.7.1. PoE Configuration........................................................................................................... 68
4.7.2. IPv6 Ping......................................................................................................................... 70
4.7.3. Upload Firmware............................................................................................................. 71
4.7.4. Settings Management ..................................................................................................... 71
4.7.5. Reboot ............................................................................................................................ 72
4.7.6. Statistics.......................................................................................................................... 73
4.8. System Log ................................................................................................................ 74
Chapter 5. PoE (Power over Ethernet) Overview................................................. 75
5.1. What is PoE? .............................................................................................................75
5.2. PoE Provision Process .............................................................................................77
Appendix A. Networking Connection ................................................................... 79
A.1. DATA OUT PoE Switch RJ-45 Port Pin Assignments (Port-1 to Port-4) .............. 79
A.2. 10/100Mbps, 10/100Base-TX .................................................................................... 79

User’s Manual of IAP-200x Series
-6-
Chapter 1. INTRODUCTION
The PLANET 802.11n Industrial Access Point Series – IAP-2000PS / IAP-2000PE / IAP-2001PE are industrial
grade multiple 10/100Mbps ports wireless Access Point. The descriptions of these models are listed as below:
Model Description
IAP-2000PS 802.11n 4 x 10/100Base-TX Ports with 4-port POE (PSE, Power Sourcing Equipment)
IAP-2000PE 802.11n 4 x 10/100Base-TX Ports with 1-port POE (PD, Powered Device)
IAP-2001PE 802.11n 4 x 10/100Base-TX Ports with 1-port POE (PD, Powered Device) + 1 x
100FX (SFP Slot)
1.1. Package Contents
Thank you for choosing the PLANET IAP-200x Industrial AP. Please check if the following items are contained in
the package:
PLANET IAP-200x Industrial AP x 1
5 dBi Antenna x 2
Quick Installation Guide x 1
CD-ROM (User’s Manual included) x 1
DIN Rail Kit x 1
Wall Mount Kit x 1
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton
including the original packing material, and use them against to repack the product in case there is a need to
return it to us for repair.
1.2. Product Features
IAP-2000PS
4 x 10/100Base-TX Ports with 4-Port PoE (PSE, Power Sourcing Equipment)
IAP-2000PE
4 x 10/100Base-TX Ports with 1-Port PoE (PD, Powered Device)
IAP-2001PE
4 x 10/100Base-TX Ports with 1-Port PoE (PD, Powered Device) + 1 x 100FX (SFP Slot)
IPv4 / IPv6 Web Management
Complies with IEEE 802.11n Wireless LAN Speed Up to 300Mbps
2 x 5dBi Detachable Omni-directional Antenna
Supports 64/128-bit WEP, WPA/WPA2, and WPA-PSK/WPA2-PSK, 802.1x
Supports WISP Mode, IEEE 802.1Q VLAN

User’s Manual of IAP-200x Series
-7-
-10 to 60 Degree C Operating Temperature
Redundant Power Design
IP-30 Aluminum case protection / DIN Rail and Wall-mount Design
1.3. Product Specification
Model IAP-2000PS IAP-2000PE IAP-2001PE
Hardware Specification
10/100Base-TX Ports 4 x 10/100Base-TX Auto-Negotiation
Auto MDI / MDI-X
IEEE 802.3af PoE Ports 4 x PSE 1 x PD 1 x PD
PoE Power Supply Type End-Span N/A
100Base-FX Interface N/A 1 x SFP slot
Antenna 2 x Detachable RP-SMA Connector
2 x 5dBi SMA Omni-directional antenna included in the package
Enclosure IP-30 Metal Case
LED Indicators
P1, P2, PWR, FAL,
WPS, WLAN, SEC,
LAN1~4, PoE
P1, P2, PWR, FAL,
WPS, WLAN, SEC,
LAN1~4, PoE-In-Use
P1, P2, PWR, FAL,
FX, WPS, WLAN, SEC,
LAN1~4, PoE
Button WPS Button
Reset Button
Dimensions (D x W x H) 135mm x 87.8mm x 56mm
Weight 871g
Power Requirement DC 24V / 48V AC 24V DC 12~48V / AC 24V
Installation DIN Rail Kit and Wall Mount Ear
Wireless Interface Specification
Standard Compliance with IEEE 802.11b/g/n
Frequency Band 2.4 to 2.4835GHz (Industrial Scientific Medical Band)
Modulation Type
DSS with DBPSK, DQPSK, QPSK and CCK
OFDM with BPSK, QPSK, 16-QAM and 64-QAM
Wireless Data Rate
IEEE 802.11b: 1/2/5.5/11Mbps
IEEE 802.11g: 6/9/12/18/24/36/48/54Mbps
IEEE 802.11n: 14/29/43/58/87/116/130/144Mps in 20MHz
30/60/90/120/180/240/270/300Mbps in 40MHz
Opt. Channel
America / FCC: 2.414~2.462GHz (11 Channels)
Europe / ETSI: 2.412~2.472GHz (13 Channels)
Japan / TELEC: 2.412~2.484GHz (14 Channels)
RF Output Power
802.11b: 18 dBm
802.11g: 15 dBm
802.11n: 15dBm
Receiver Sensitivity
802.11b CCK 1.0Mbps: -94dbm
11b CCK 11.0Mbps: -91dbm
802.11g OFDM 6Mbps: -92dbm
11g OFDM 54Mbps: -76dbm
802.11n 20MHz MCS7: -72dbm

User’s Manual of IAP-200x Series
-8-
11n 40MHz MCS7: -70dbm
Wireless Management Features
Wireless Mode Access Point
Channel Width 20MHz / 40MHz
Data Encryption Security
64 bit / 128 bit WEP
WPA / WPA2
WPA-PSK / WPA2 / WPA2-PSK
802.1x Network Access Control
Management Web-based Configuration
Wireless Isolation Yes
Protocol
Protocol / Feature
Bridge and WISP mode
WDS and WPS
Static Routing and RIPv1/2
DMZ and Virtual Server
802.1D
802.1Q VLAN
QoS
SNTP
WMM
DHCP Server / Client
IGMP Proxy and DNS Proxy
UPnP and DDNS
SNMP
Management Web-based configuration
Standards Conformance
Standards Compliance
IEEE 802.11b/g and 802.11n Wireless LAN
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.1Q VLAN
Environment Specification
Temperature / Humidity Operating: -10~60 Degree C, 5%~ 90% (non-condensing),
Storage: -20~70 Degree C, 0~95% (non-condensing)
Emission FCC, CE
Stability Testing
IEC60068-2-32 (Free Fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)

User’s Manual of IAP-200x Series
-9-
Chapter 2. INSTALLATION
2.1. Hardware Description
2.1.1. Physical Dimension
IAP-200x series Industrial Access Point dimension (D x W x H) : 135mm x 87.8mm x 56mm
Figure 2-1 IAP-200xPx diagram

User’s Manual of IAP-200x Series
-10-
2.1.2. Front Panel
Figure 2-2 & 2-3 & 2-4 show the front panels of Industrial Access Points
Figure 2-2 IAP-2000PS Figure 2-3 IAP-2000PE Figure 2-4 IAP-2001PE
■ Reset Button
In the bottom of the front panel, the reset button is designed for reset the Industrial Access Point to the factory
default settings.
Figure 2-5 Reset button of IAP-200x series

User’s Manual of IAP-200x Series
-11-
The following is the summary table of Reset button functions:
Reset Button Pressed and Released Description
About 1~3 second Reboot the Industrial AP
Over 5 seconds
Reset the Industrial AP to the Factory Default
configuration. The Industrial AP will then reboot and
load the default settings as below:
。 Default Username/Password: admin / admin
。 Default IP address: 192.168.1.1
Subnet mask: 255.255.255.0
2.1.3. LED Indicators
System
LED Color Function
P1 Green It indicates the power 1 has power.
P2 Green It indicates the power 2 has power.
PWR Green It indicates the machine is power on.
FAL Green It indicates either the power 1 or power 2 has no
power.
Wireless LAN
LED Color Function
WPS Orange It indicates WPS is enabled.
WLAN Green It indicates the wireless LAN is enabled.
SEC Orange It indicates the wireless security encryption is
enabled.
10/100Base-TX Ports / 100Base-FX Port
LED Color Function
1 ~ 4 Green It indicates which RJ-45 port is link up.
FX Green It indicates the Fiber port is link up. (IAP-2001PE)
PoE Orange It indicates the device is power supplied by PoE.
PoE
In-Use
Orange It indicates which RJ-45 port is providing 48V DC
in-line power.

User’s Manual of IAP-200x Series
-12-
2.1.4. Upper Panel
Figure 2-6 IAP-2000PS Upper Panel
Figure 2-7 IAP-2000PE / IAP-2001PE Upper Panel
2.2. Hardware Installation
This section describes how to install your Industrial access point and make connection to it. Please read the
following topics and perform the procedures in the order being presented. To install your wireless access point on
a desktop or shelf, simply complete the following steps.
2.2.1. Installation Steps
1. Unpack the package of Industrial Access Point
2. Check if the DIN-Rail is screwed on the Industrial Access Point or not. If the DIN-Rail is not screwed on

User’s Manual of IAP-200x Series
-13-
the Industrial access point, please refer to DIN-Rail Mounting section for DIN-Rail installation. If users want
to wall mount the Industrial access point, please refer to Wall Mount Plate Mounting section for wall mount
plate installation.
3. To hang the Industrial access point on the DIN-Rail track or wall.
4. Power on the Industrial access point. Please refer to the Wiring the Power Inputs section for knowing the
information about how to wire the power. The power LED on the Industrial access point will light up. Please
refer to the LED Indicators section for indication of LED lights.
5. Prepare the twisted-pair, straight through Category 5 cable for Ethernet connection.
6. Insert one side of RJ-45 cable (category 5) into the Industrial access point Ethernet port (RJ-45 port)
and another side of RJ-45 cable (category 5) to the network device’s Ethernet port (RJ-45 port), ex: Switch
PC or Server. The UTP port (RJ-45) LED on the Industrial access point will light up when the cable is
connected with the network device. Please refer to the LED Indicators section for LED light indication.
Make sure that the connected network devices support Auto MDI/MDI-X. If it does
not support, use the crossover category-5 cable.
7. When all connections are set and LED lights all show in normal, the installation is complete.
2.2.2. DIN-Rail Mounting
This section describes how to install the Industrial Access Point. There are two methods to install the Industrial
PoE Switch. DIN-Rail Mounting and Wall Mount Plate Mounting. Please read the following topics and perform the
procedures in the order being presented.
In the installation steps below, we use PLANET IGS-801(8 Port Industrial
Gigabit Switch) as the example. However, the steps for PLANET Industrial
Access Point are similar.

User’s Manual of IAP-200x Series
-14-
Step 1: Screw the DIN-Rail on the Industrial Access Point.
Figure 2-8
Step 2: Lightly press the button of DIN-Rail into the track.
Figure 2-9

User’s Manual of IAP-200x Series
-15-
Step 3: Check the DIN-Rail is tightly on the track.
Figure 2-10
Please refer to the following procedures to remove the Industrial Access Point from the track.
Step 5: Lightly press the button of DIN-Rail for remove it from the track.
Figure 2-11

User’s Manual of IAP-200x Series
-16-
2.2.3. Wall Mount Plate Mounting
To install the Industrial Access Point on the wall, please follow the instructions below.
Step 1: Remove the DIN-Rail from the Industrial Access Point. Use the screwdriver to loose the screws and
remove the DIN-Rail.
Step 2: Place the wall mount plate on the rear panel of the Industrial Access Point.
Figure 2-12
Step 3: Use the screwdriver to screw the wall mount plate on the Industrial Access Point.
Step 4: Use the hook holes at the corners of the wall mount plate to hang the Industrial Access Point.
Step 5: To remove the wall mount plate, reverse the steps above.
2.3. Wiring the Power Input
The 6-contact terminal block connector on the top panel of the Industrial access point is used for two DC
redundant powers input. Please follow the steps below to insert the power wire.
1. Insert positive / negative DC power wires into the contacts 1 and 2 for POWER 1, or 5 and 6 for
POWER 2.

User’s Manual of IAP-200x Series
-17-
V1- V1 + V2 - V2 +
Figure 2-13 The Top Panel of IAP-2000PE / IAP-2001PE
V1- V1 + V2 - V2 +
Figure 2-14 The Top Panel of IAP-2000PS
2. Tighten the wire-clamp screws for preventing the wires from loosing.
1 2 3 4 5 6
Power 1 Fault Power 2
- + - +
Figure 2-15 The Terminal Block

User’s Manual of IAP-200x Series
-18-
The wire gauge for the terminal block should be in the range between 12 ~ 24 AWG.
The Power input voltage of IAP-2000PE and IAP-2001PE is DC 12~48V / AC 24V.
The Power input voltage of IAP-2000PS is 24V or 48V DC only.
For PD devices, like IAP-2000PE / IAP-2001PE, the power 1, power 2, and PoE
power supplied can exist at the same time.
2.4. Cabling
100Base-TX and 100Base-FX
The 10/100Mbps RJ-45 ports come with Auto-Negotiation capability. Users only need to plug in working
network device into one of the 10/100Mbps RJ-45 ports. The IAP-2000PS / IAP-2000PE series will
automatically run in 10Mbps or 100Mbps after the negotiation with the connected device. The IAP-2001PE
has one 100Base-FX SFP interface (Optional Multi-mode / Single-mode 100Base-FX SFP module)
Cabling
Each 10/100Base-TX ports use RJ-45 sockets - for connection of unshielded twisted-pair cable (UTP).
Port Type Cable Type Connector
10Base-T Cat 3, 4, 5, 2-pair RJ-45
100Base-TX Cat.5, 5e, 6 UTP, 2-pair RJ-45
Any Ethernet devices like Hubs / PCs can connect to the Industrial Access Point by using straight-through wires.
The 10/100Mbps RJ-45 ports which support Auto MDI / MDI-X can be used on straight-through or crossover cable.
2.4.1. Installing the SFP Transceiver (IAP-2001PE Only)
This section describes how to insert a SFP transceiver into an SFP slot. The SFP transceiver is hot-pluggable and
hot-swappable. You can plug-in and out the transceiver to/from any SFP port without having to power down the
Industrial Access Point as the Figure 2-12 appears.

User’s Manual of IAP-200x Series
-19-
Figure 2-16 Plug in the SFP transceiver
Before connect the other switches, workstation or Media Converter,
1. Make sure both side of the SFP transceiver are with the same media type or WDM pair, for example:
100Base-FX to 100Base-FX, 100Base-BX20-U to 100Base-BX20-D.
2. Check the fiber-optic cable type match the SFP transceiver model.
To connect to MFB-FX SFP transceiver, use the multi-mode fiber cable- with one side must be male
duplex LC connector type.
To connect to MFB-F20/F40/F60/FA20/FB20 SFP transceiver, use the single-mode fiber cable-with
one side must be male duplex LC connector type.
Connect the fiber cable
1. Attach the duplex LC connector on the network cable into the SFP transceiver.
2. Connect the other end of the cable to a device – switches with SFP installed, fiber NIC on a workstation or a
Media Converter.
3. Check the LNK/ACT LED of the SFP slot of the switch / converter. Ensure that the SFP transceiver is
operating correctly.
4. Check the Link mode of the SFP port if the link failed. Co works with some fiber-NICs or Media Converters,
set the Link mode to “100 Force” is needed.
2.4.2. Removing the Module
1. Please make sure there is no network activity by console or check with the network administrator. You can
access the management interface of the Industrial Access Point to disable the port in advance.
2. Remove the Fiber Optic Cable gently.
3. Turn the handle of the MFB module to horizontal.
4. Pull out the module gently through the handle.
