1 INTRODUCTION
The Planmeca ProOne X-ray unit produces digital X-ray
images for the diagnosis of dentomaxillofacial anatomy.
The unit is allowed to be used only under supervision of a
dental/health care professional.
This manual describes how to operate the Planmeca
ProOne X-ray unit. Please read these instructions
thoroughly before using the unit.
You need a PC with the Planmeca Dimaxis/Romexis
imaging software to save, view and modify the
radiographs. The Dimaxis/Romexis software has a
separate manual which should be used in conjunction
with this manual.
Planmeca ProOne X-ray fulfills the requirements of
Directive 93/42/EEC.
CAUTION FOR US USERS:
Federal law restricts this device to sale by or
on the order of a dentist.
NOTE The X-ray unit’s software revision is shown briefly on
the control panel when the X-ray unit is switched on.
This manual is valid for software revision 1.0.0.r or
later. This software revision is compatible with
Dimaxis software revision 4.3.0.0.r or later and
Romexis software revision 1.4.0.0.r or later.
The display values shown in this guide are only examples
and should not be interpreted as recommended values
unless otherwise stated.
The Planmeca ProOne X-ray unit features preset
exposure values for all imaging programs. The exposure
values have been preset at the factory to automatically
correspond with the selected exposure program and
patient size. However, the exposure values required to
produce good X-ray images will vary considerably
according to the build and age of the patient. The preset
exposure values are average values and they are only
meant to guide the user. Users are encouraged to
develop their own radiographic techniques based on
these values.
Make sure that you are fully acquainted with the
appropriate radiation protection measures and these
instructions before using the X-ray unit.
0537

SYMBOLS ON PRODUCT LABELS
2 Planmeca ProOne
User’s Manual
2 SYMBOLS ON PRODUCT LABELS
Type B applied part (Standard IEC 60601-1)
Alternating current (Standard IEC 60417)
Attention, consult accompanying documents
(Standard IEC 60601-1)
Warning: dangerous voltage
(Standard IEC 60417)
Electrostatic sensitive device (Standard IEC 60417)
Separate collection for electrical and electronic equipment
according to Directive 2002/96/EC (WEEE).
3 ASSOCIATED DOCUMENTATION
The Planmeca ProOne X-ray unit is supplied with the
following manuals:
- User’s Manual
- Installation Manual
- Technical Manual
These manuals are intended to be used in conjunction
with the documentation for the Planmeca Dimaxis/
Romexis imaging software. The imaging software
package contains the following manuals:
- User’s Manual
- Installation Manual

Planmeca ProOne 3
WARNINGS AND PRECAUTIONS
User’s Manual
4 WARNINGS AND PRECAUTIONS
CAUTION This X-ray unit may be dangerous to both
patient and operator unless safe exposure
values are used and correct operating
procedures are observed.
CAUTION If the X-ray unit shows any signs of oil
leakage, disconnect the unit from mains and
contact your service technician for help.
CAUTION The X-ray unit is not suitable for use in the
presence of a flammable anaesthetic mixture
with air or with oxygen or nitrous oxide.
CAUTION Do not connect items which are not
specified as part of the system.
CAUTION Do not connect a multiple portable socket
outlet (MPSO) or extension cord to the
system.
NOTE It is very important that the place where the X-ray unit
is to be used and the position from which the user is
to operate the unit are correctly shielded. Since
radiation safety requirements vary from country to
country and state to state it is the responsibility of the
user to ensure that all local safety requirements are
met.
NOTE If the X-ray unit has been stored at temperatures below
+10°C for more than a few hours, time must be allowed
for the unit to reach room temperature before turning
it on.
NOTE Ensure efficient air conditioning in the X-ray room. It is
recommended to keep the room temperature between
+20°C and +25°C at all times.
NOTE If the X-ray unit is not connected to an Uninterruptible
Power Supply (UPS), disconnect the unit from mains
during lightning storms.
NOTE FOR US USERS:
The patient positioning lights are class II laser
products (21 CFR § 1040.10).
NOTE FOR EUROPEAN USERS:
Class 1 laser product (Standard EN 60825-1: 1994).
The patient positioning lights are class 1, inherently
safe laser lights.
NOTE EMC requirements have to be considered, and the
equipment must be installed and put into service
according to the specific EMC information provided in
the accompanying documents.
NOTE Portable and mobile RF communications equipment
can affect the Planmeca ProOne X-ray unit.
CAUTION
LASER RADIATION -
DO NOT STARE
INTO BEAM
1mW
635nm
CLASS II
LASER
PRODUCT
LBL-X-099
LBL-X-100
AVOID
EXPOSURE-
Laser radiation
is emitted from
this aperture.
CLASS 1 LASER PRODUCT
APPAREIL À LASER DE CLASSE 1
EN 60825-1/A2-2001

WARNINGS AND PRECAUTIONS
4 Planmeca ProOne
User’s Manual
NOTE External equipment intended for connection to signal
input, signal output or other connectors, shall comply
with relevant IEC standard (e.g. IEC 60950 for IT
equipment and the IEC 60601 series for medical
electrical equipment). In addition, all such
combinations - systems - shall comply with the
standard IEC 60601-1-1, Safety requirements for
medical electrical systems. Equipment not complying
to IEC 60601 shall be kept outside the patient area
(more than 2m (79 in.) from the X-ray unit).
Any person who connects external equipment to
signal input, signal output or other connectors has
formed a system and is therefore responsible for the
system to comply with the requirements of IEC 60601-
1-1. If in doubt, contact your service technician or local
representative for help.
NOTE Never place or hang any objects on any part of the X-
ray unit.
NOTE Make sure that neither you nor your patient can get
caught or hooked up on any part of the X-ray unit.
Keep loose items of clothing, hair and jewellery tucked
away safely.
NOTE Do not attempt to remove any covers from the X-ray
unit. X-ray unit covers may be removed by service
personnel only.
NOTE Do not touch the arm structures (C-arm, upper arm)
when the X-ray unit is moving.

Planmeca ProOne 5
MAIN PARTS
User’s Manual
5 MAIN PARTS
5.1 General view of the system
ProOne_013
2m
79 in.
X-ray unit
Exposure switch
Dimaxis/Romexis
Ethernet
Patient area
NOTE:
PC MUST BE PLACED
imaging software
OUTSIDE PATIENT AREA

MAIN PARTS
6 Planmeca ProOne
User’s Manual
5.2 General view of the X-ray unit
ProOne_015
C-arm
On/off switch
(on the back of the column)
Upper arm
Patient support
Patient support table
Patient handles
Control panel
Temple supports
Emergency stop button
Stationary column
Moving column

Planmeca ProOne 7
MAIN PARTS
User’s Manual
5.3 Exposure switch
The exposure switch can be mounted on the wall, or it can
be hung from the hook located on the back of the moving
column if a protected area is within reach.
When the X-ray unit is ready to take an exposure a green
indicator light will come on on the exposure button.
Additionally, the status bar at the bottom of the control
panel display will turn green.
When you take an exposure an amber indicator light will
come on on the exposure switch. It indicates that the X-
ray unit is generating radiation. Additionally, a radiation
warning symbol will be shown on the control panel display
and you will hear a radiation warning signal. The status
bar at the bottom of the control panel display will now turn
amber.
When you take an exposure you must press and hold
down the exposure button for the whole duration of the
exposure. If you remove your finger from the exposure
button before the exposure cycle is completed radiation is
interrupted, the C-arm will stop moving and an error
message will appear on the control panel. The error
message must be cleared before the X-ray unit can be
used again.
Exp_sw_wall6.eps
Exposure button with
indicator light
GREEN = READY
AMBER = EXPOSURE
Exposure
indicator light
Green = Ready for exposure
Grey = Not ready for exposure
Status
bar
Amber = Exposure

MAIN PARTS
8 Planmeca ProOne
User’s Manual
5.4 Patient supports
5.5 Emergency stop button
The emergency stop button is located on the underside of
the patient support table arm. Press the button to stop the
X-ray unit operating in an emergency. When the
emergency stop button is pressed down, all movements
of the X-ray unit are blocked and the unit will not generate
radiation.
A help message will appear on the control panel display.
Pull the stop button out to start the X-ray unit again.
TEMPLE?SUPPORTAI
Chin support
Chin rest
Chin cup
Bite piece
Bite2.eps
Chin1.eps
Chin2.eps
Lip1.eps
Temple supports
ProOne_016
Emergency stop button

Planmeca ProOne 9
SWITCHING THE X-RAY UNIT ON
User’s Manual
6 SWITCHING THE X-RAY UNIT ON
The on/off switch is located on the back of the moving
column. When you switch the X-ray unit on the main
display will be shown on the control panel and a blue light
will come on on the left side of the display. Additionally,
the X-ray unit will carry out a self-test which will last a few
seconds.
The X-ray unit is then ready for use.
NOTE The X-ray unit incorporates a self-checking feature
that monitors the operation of the unit. If the system
detects a malfunction or an operating error an error
message will appear on the control panel. The X-ray
unit will not accept any commands from the user until
the malfunction is corrected and the error message
cleared.
NOTE To prolong the lifetime of the Planmeca ProOne X-ray
unit, always switch the X-ray unit off when it is not in
active use.
ProOne_014
On/off switch

PROGRAM PACKAGES
10 Planmeca ProOne
User’s Manual
7 PROGRAM PACKAGES
The Planmeca ProOne X-ray unit offers a wide selection
of exposure programs for various diagnostic purposes.
The basic program package is included as standard and
the other program packages are available as options.
The basic program package includes basic panoramic,
double TMJ and sinus programs for general maxillofacial
diagnostics. The advanced program package consists of
special panoramic, TMJ, sinus and cross-sectional
programs for specific diagnostic needs.
In the table the programs are divided according to the
sales packages. In the following chapters the programs
will be presented according to the program type.
Program package Contents
Basic programs (standard) • Standard panoramic program
• Double lateral TMJ program
• Double PA TMJ program
• PA sinus program
Advanced programs (optional) • Improved interproximality panoramic program
• Improved orthogonality panoramic program
• Bitewing panoramic program
• Double lateral-PA TMJ program
• 3 angles lateral TMJ program (left or right)
• Lateral sinus program (left or right)
• Midsagittal sinus program (left or right)
• Cross-sections manual
• Cross-sections automatic
Segmenting (optional) • Horizontal segmenting for panoramic programs
• Vertical segmenting for panoramic programs

Planmeca ProOne 11
CONTROL PANEL
User’s Manual
8 CONTROL PANEL
To make a selection on the control panel, simply touch the
display with your finger on a text field or on an icon. For
example, to select the program type touch the program
field with your finger. You will hear a signal tone when a
field is activated.
Only the text fields and icons on the display are touch-
sensitive, and touching areas outside them will not
activate an action.
To accept a selection, touch the green check button in the
bottom right corner of the display. To cancel a selection,
touch the red cross button in the bottom left corner of the
display.
The display will automatically switch to stand-by mode if
you do not touch it for more than 30 minutes. A blue
power light on the left side of the display indicates that the
unit is switched on even though the display is dark. The
display will switch on as soon as you touch it again.
NOTE The patient positioning lights will be automatically
switched on when the display is touched.
NOTE The contents of the displays depend on the unit
configuration. The displays shown here are from a unit
that features all currently available imaging programs.
NOTE Never allow patients to touch the display when they
are positioned in the unit.
8.1 Selecting panoramic exposure program
To select a panoramic exposure program touch the
program field on the main display. The main display is the
display that is shown when the X-ray unit is switched on.
Cross = Cancel Check mark = Accept
Program
field

CONTROL PANEL
12 Planmeca ProOne
User’s Manual
The Select program display appears. Select the required
panoramic exposure program by touching the appropriate
field on the display. The selected program will be
highlighted.
There are four panoramic exposure programs: Standard,
Improved orthogonality, Improved interproximality and
Bitewing.
NOTE The panoramic program “Standard” is included in the
basic program package. Other panoramic programs
are optional.
The Standard panoramic program has a traditional path
and angles of the beam.
In the Improved orthogonality program the basic
imaging geometry is the same as in the standard
panoramic program but the angle of the X-ray beam is
more perpendicular to the jaw.
The program is useful for periodontal studies.
NOTE This program is optimized for orthogonal imaging and
a shadow of the opposite side teeth may therefore be
visible in the radiograph.
Direction of beam
Standard panoramic program
layer laser beam
1 cm
Direction of beam
Improved orthogonality
layer laser beam
1 cm

Planmeca ProOne 13
CONTROL PANEL
User’s Manual
In the Improved interproximality program the basic
imaging geometry is the same as in the standard
panoramic program but the angle of the X-ray beam is
more parallel to the interproximal contacts of the teeth.
This program is used for caries detection.
NOTE This program is optimized for interproximal imaging
and a shadow of the opposite side teeth may therefore
be visible in the radiograph.
The Bitewing program produces bitewing-like images
from premolar and molar areas including parts of maxilla,
mandible and rami.
The bottom of the maxillary sinus as well as the
mandibular canal and the mental foramen are also visible.
The bitewing program uses improved interproximal
angulation projection geometry.
NOTE This program is optimized for interproximal imaging
and a shadow of the opposite side teeth may therefore
be visible in the radiograph.
Accept the selection and return to the main display by
touching the green check button in the bottom right corner
of the display.
layer laser beam
1 cm
Direction of beam
Improved interproximality
layer laser beam
Direction of beam
Bitewing
Cancel Accept

CONTROL PANEL
14 Planmeca ProOne
User’s Manual
8.1.1 Selecting exposure area for panoramic exposures (optional)
This optional segmenting function allows you to take
panoramic exposures of different jaw segments. It will
reduce the radiation dose as only diagnostically
interesting areas need to be X-rayed.
Touch the exposure area field on the main display.
The
Select exposure area display appears. The display
shows an image which is divided into two horizontal and
five vertical segments.
Touch the corresponding arrow field(s) to deselect the
segment(s) that should not be exposed. The segments
which will not be exposed are shown faded. The
segments which will be exposed are shown in full colour.
Touching the arrow of a deselected segment again will
change the colour of the segment back to normal.
NOTE The image shown on the display is only an example.
The exposed image will not equal the example image.
Accept the selection and return to the main display by
touching the green check button in the bottom right corner
of the display.
Exposure
area
field
Deselected segments -
no exposure
Segments to be exposed
Accept
Cancel

Planmeca ProOne 15
CONTROL PANEL
User’s Manual
8.2 Selecting temporomandibular joint (TMJ) exposure program
To select a temporomandibular joint (TMJ) exposure
program touch the program field on the main display. The
main display is the display that is shown when the X-ray
unit is switched on.
The
Select program display appears. Select the required
TMJ exposure program by touching the appropriate field
on the display. The selected program will be highlighted.
There are four TMJ exposure programs: Double lateral,
Double PA, Double lateral-PA and 3 angles lateral.
NOTE The temporomandibular programs “Double lateral”
and “Double PA” are included in the basic program
package. Other temporomandibular programs are
optional.
Double lateral:
Lateral TMJ exposures of open and closed
temporomandibular joints (default imaging angle: 17°).
Program
field
1 cm
Double lateral
1.
2. 3.4.

CONTROL PANEL
16 Planmeca ProOne
User’s Manual
Double PA:
Posteroanterior TMJ exposures of open and closed
temporomandibular joints (default imaging angle: 65°).
Double lateral-PA:
Lateral and posteroanterior TMJ exposures of open or
closed temporomandibular joints (default imaging angles:
17°/65°).
3 angles lateral:
Three lateral multi-angle left-hand or right-hand side TMJ
exposures (three imaging angles: 17° ±7° by default).
Accept the selection and return to the main display by
touching the green check button in the bottom right corner
of the display.
1 cm
Double PA
1.
2. 3.4.
1 cm
Double lateral-PA
1.
2. 3.4.
1 cm
1 2 3
3 angles lateral, left
1.
2.
3.
