Plantronics CS50 Setup guide

QUICK START USER GUIDE
WIRELESS OFFICE
HEADSET SYSTEM
CS50
© 2003 Plantronics, Inc. All rights reserved. Plantronics, the logo design,
Plantronics and the logo design combined, and IntelliStand are trademarks
or registered trademarks of Plantronics, Inc. All other trademarks are the
property of the respective owners.
Patent U.S. 5,210,791 and Patents Pending
345 Encinal Street
Santa Cruz, California 95060
[phone]
www.plantronics.com
Printed in China 63913-01 (12-03)
Thank you for selecting the CS50 Wireless Office
Headset System from Plantronics. You have made the right
choice for comfort and versatility.
This system allows your telephone to use a cordless Plantronics
headset through an adapting base. It offers hands-free
convenience and long-range workspace mobility.
With the use of an optional handset lifter, the user can
remotely receive the telephone’s ring alert and can answer
the call by simply pushing the talk button on the headset.
This side of the guide has the Important Safety Instructions
that should be read prior to set up and use of your system.
The quick start part on the other side identifies the
components, has five steps to get you started, and test the
system.
Most telephones will work with little or no adjustments. This
system is not designed to work with phones which have the
dial pad built into the handset.
The Product Information Booklet in all languages is online
at: http:www.plantronics.com/documentation/
Choose your preferred language and the Plantronics model number “CS50”
to access complete user documentation including this Quick Start Guide and
the Product Information Booklet which has more on the system’s operation,
adjustments, and troubleshooting.
IMPORTANT SAFETY
INSTRUCTION
8. Do not overload outlets and extension cords as this can
result in risk of fire or electric shock.
9. Never disassemble or push objects of any kind into the
product as this may short out parts which could result in
a fire or electric shock. Never spill liquid of any kind on
the product.
10. Use caution when installing or modifying telephone lines.
11. This product is intended to be powered by a Listed Class 2
Direct Plug-In Power Unit rated 9VDC 800mA. Plantronics
Part No. 45561-02, rated at an input voltage of 120 VAC,
60Hz and an output voltage of 9 VDC at 800mA.
12. This product requires AC power in order to operate.
In order to have phone service during a power outage,
have another telephone available that is powered only
by the telephone line.
13. Keep all product cords and cables away from operating
machinery.
14. Avoid using telephone equipment during an electrical
storm.
15. Do not use this equipment to report a gas leak in the
vicinity of a gas leak.
When using your telephone equipment these
basic safety precautions should be followed to reduce
the risk of fire, electric shock, and injury to persons.
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the
product. The symbol identifies and alerts the user to
the presence of important operating, safety, and service
instructions.
3. This product contains gold-plated nickel, phosphor bronze
and copper. If you experience a skin irritation, discontinue
use and contact Plantronics.
4. Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
5. Do not locate this product near water, for example,
near a bathtub, or sink, in a wet basement or near a
swimming pool.
6. This product should never be placed near or over a
radiator or heat register. It should not be placed in a
built-in installation unless proper ventilation is provided.
7. Do not allow anything to rest on the power cord. Do
not locate this product where persons walking on it will
damage the cord.
BATTERY PRECAUTIONS
To reduce the risk of fire or
injury to persons, read and follow these instructions.
1. Use only the battery pack supplied with this product.
Plantronics part number 64399-01.
2. Do not dispose of battery pack in a fire. The cells may
explode. Check with local codes for possible disposal
instructions.
3. Do not open or mutilate battery pack. Released electrolyte is
corrosive and may cause damage to eyes or skin and may be
toxic if swallowed.
4. Exercise care in handling the battery pack in order not to short
the battery contacts with conducting materials such as rings,
bracelets, and keys. The battery or conductor may overheat
and cause burns.
5. Charge the battery pack in accordance with instructions
supplied with this unit.
6. Observe proper orientation between battery pack and charger
contacts.
7. Never allow children to play with the headset/adapter–small
parts may be a choking hazard.
Batteries can be swallowed by children and are dangerous if
swallowed. Always store and dispose of batteries where
children can’t reach them.
The Plantronics Technical Assistance Center (TAC) is ready to
assist you! Dial [phone] x5538 Sunday 5P.M. through
Friday, 5P.M.Pacific Time or visit the Support section of our
website at www.plantronics.com. For accessibility information
also call the Technical Assistance Center.
SAVE THESE INSTRUCTIONS
SAFETY INSTRUCTIONS CONTINUED
FCC REGISTRATION INFORMATION
FCC Requirements—Part 15
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1.This device may not cause harmful interference, and
2.This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception which can be determined by turning the radio or television
off and on, the user is encouraged to try to correct interference by one or
more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on another circuit.
4. Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Information
This device and it’s antenna must not be co-located or operated in conjunction
with any other antenna or transmitter. To comply with FCC RF exposure
requirements, only use supplied antenna. Any unauthorized modification to the
antenna or device could void the user's authority to operate this device.
FCC Requirements—Part 68
This equipment complies with Part 68 of the FCC Rules and the requirements
adopted by ACTA. On the bottom of the base unit of this equipment is a label
that contains, a product identifier in the format US:AAAEQ##TXXXX.
If requested, this information must be provided to your telephone company.
If this equipment causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of service
may be required. But if advance notice isn't practical, the telephone company
will notify the customer as soon as possible. Also, you will be advised of your
right to file a complaint with the FCC if you believe it is necessary.
WARRANTY AND SERVICE
What does this warranty cover?
This warranty covers any defects in workmanship or materials in this product
purchased in the U.S. or Canada. For warranty information in other countries,
contact your local distributor.
How long does the coverage last?
This warranty runs for one year from the date of purchase.
What will Plantronics do?
If the product is found defective, we will replace it at no charge.
What does this warranty NOT cover?
Damage caused by accident, abuse, misuse, or an act of God (such as a
flood) are not covered. Implied warranties, including those of merchantability,
fitness for a particular purpose and non-infringement shall (a) have no
duration greater than one year from the date of purchase, (b) terminate
automatically at the end of that period, and (c) to the extent permitted by law,
be excluded. Consequential and incidental damages, including without
limitation, loss of property and those arising from breach of any express or
implied warranty, are not the responsibility of Plantronics, and to the extent
permitted by law, are excluded. Some states do not allow exclusion or
limitation of incidental or consequential damages, so the above exclusion may
not apply to you.
How do you get service?
To obtain service in the U.S. contact Plantronics at [phone] and in
Canada call [phone].
How does state law apply?
This warranty gives you specific legal rights, and you may also have other
rights, which vary from state to state.
The telephone company may make changes in it's facilities, equipment,
operations or procedures that could affect the proper functioning of your
equipment. If they do, you will be notified in advance in order for you to
make necessary modifications to maintain uninterrupted service.
If trouble is experienced with this unit, for repair or warranty information, please
contact customer service at the address and phone listed in the Warranty
section of this User’s Guide.
INDUSTRY CANADA NOTICE
Notice: This equipment meets the applicable Industry Canada Terminal
Equipment Technical Specifications. This is confirmed by the registration
number. The abbreviation, IC, before the registration number signifies that
registration was performed based on a Declaration of Conformity indicating
that Industry Canada technical specifications were met. It does not imply that
Industry Canada approved the equipment. The Industry Canada registration
number is located in the bottom of the unit. Before installing this equipment,
users should ensure that it is permissible to be connected to the facilities of the
local telecommunications company. The equipment must also be installed using
an acceptable method of connection. The customer should be aware that
compliance with the above conditions may not prevent degradation of service
in some situations. Repairs to certified equipment should be coordinated by
a representative designated by the supplier. Any repairs or alterations made
by user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user disconnect the
equipment. Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and internal metallic
water pipe system, if present, are connected together. This precaution may
be particularly important in rural areas.
Caution: Users should not attempt to make such connection themselves,
but should contact the appropriate electric inspection authority, or electrician,
as appropriate.
RSS 210
This digital apparatus does not exceed the Class B limit for radio noise
emissions from digital apparatus set out in the Radio Interference Regulations
of Industry Canada. Operation is subject to the following two conditions:
1) this device may not cause interference, and 2) this device must accept
any interference, including interference that may cause undesired operation
of the device.
WELCOME

2
1CS50 WIRELESS OFFICE HEADSET SYSTEM
3
EXAMINE THE COMPONENTS OF THE CS50 SYSTEM
BASE & CHARGING UNIT
Front View
Outside View
Inside View
CORDLESS HEADSET WEARING OPTIONS
Set Up the Base
1.1 Connect your telephone’s
handset cord to the handset
jack
.
1.2 Connect your telephone
with the supplied short cord
to the telephone base jack
.
1.3 Connect the supplied AC power
adapter to the AC power adapter jack
and the plug into your power source.
The red power indicator light
should go on.
1.4 *Optional: Install the
optional handset lifter after
you have completed Step 5.
Use the handset lifter instructions
to install it. More information on
using the handset lifter with your CS50
system is located in the online Product
Information Booklet.
Charge the Headset
2.1 Dock the headset into
the charge cradle . The
amber charge indicator
will flash during charge.
If charge indicator does not
go on, reposition headset
in the cradle.
2.2 The charge indicator
will go steady after headset
is fully charged and ready for
use (approximately 3 hours).
Make Volume and Final
Adjustments
5.1 Adjust your
listening volume
with the listen
volume control
dial located towards
the back of the headset capsule.
Rock the dial up or down for
volume changes.
5.2 For “larger step” adjustments
to your listening volume, change
the position setting on the listen
volume master switch located on
the back of the base.
5.3 Push in the mute control
to activate mute, push in again to
de-activate mute. (You will hear a
slight beep in the speaker when
mute is activated.)
5.4 Adjust your speak volume
(how others hear you) with the
speak volume fine tune buttons
on the back side of the base.
5.5 For “larger step” adjustments
to your speak volume, change the position
setting on the talk volume master switch
located on the bottom of the base.
5.6 You can now activate your IntelliStand feature if you
have installed the optional handset lifter. When enabled,
this feature provides automatic Lifter activation by simply
removing and replacing your headset
in the base unit (no need to press
the talk button on the headset).
To enable, slide the IntelliStand
switch located on the side
of the base to the on position
(down) or disable by sliding
to the off position (up).
Set Up the Headset
For over-the-head use
3.1 Determine right or left
ear wearing position and
snap the headset speaker
capsule
into the t-pad headset
retainer ring.
3.2 While wearing the headset, adjust
the microphone
tip toward the corner
of your mouth by rotating the speaker
capsule within the t-pad retainer ring.
You may need to support the headband
in position while doing this, or just take
off headset and adjust, as the fit is snug.
OR
For over-the-ear use
3.3 Choose the earloop
size (small,
medium, or large) that should best fit
your ear. (You may need to experiment
to find the best comfort).
3.4 Determine right or left ear wearing
position and snap the headset
speaker capsule
into the
earloop
ring accordingly.
3.5 While wearing the headset, adjust
the microphone
tip toward the corner of
your mouth by rotating the speaker
capsule within the earloop retainer ring.
You may need to support the earloop in
position while doing this, or just take off
headset and adjust, as the fit is snug.
Setup and Test
Your System
4.1 Begin with your
“charged” headset
mounted in the
configuration of your choice.
4.2 Remove the telephone
handset from its base, taking it
“off-hook”.
4.3 Press the talk button on the headset.
The talk indicator lights on both the base and
headset should go on, indicating a successful link.
You should now be able to hear a dial tone through
the headset.
4.4 If not, you need to
adjust your telephone
configuration dial on
the base to another one
of its 4 positions until you
hear the tone.
4.5 Continue
configuration setup by
making a test call to a
friend or associate using
the key pad on your
telephone.
4.6 If they cannot hear you at all try changing
your telephone configuration dial on the base to
another one of its 4 positions until you hear them
and they hear you. Volume adjustments can be
made separately as described in the next step.
Listen Volume/
Mute Control
Microphone
Talk Indicator Light
Microphone Boom
Talk Button
Small Medium Large
This Quick Start Guide and the Product Information Booklet are located on our website at
www.plantronics.com/documentation/. Choose your language preference and Plantronics model number
Maintenance and Troubleshooting sections are in the Product Information Booklet at www.plantronics.com/documentation/
3.2
2.1
4.1
5.1
5.3
4.3
3.1
3.3
3.4
3.5
4.4
1.1
1.2
1.3
1.4
P
L
A
N
T
R
O
N
I
C
S
Back View
Speak Volume
Fine Tune
13
Listen
Volume
Master
11
Telephone
Configuration
Dial
Power
Indicator
(Red)
Talk
Indicator
(Green)
Charge
Indicator
(Amber)
Charge Cradle
IntelliStand
Switch
10
1
3
2
4
9
Underside View
Speak
Volume
Master
Handset
Jack
8
Accessory
Jack
6
AC Power
Adapter
Jack
7
Telephone
Base Jack
5
12
14 16
15
18
Headset
Speaker
Capsule
20
17
AC Power Adapter
24 Short Cord
25
Earloops
21
Headband
22
T-Pad
Headset Retainer
23
19
Underside of Base *Optional Telephone
Handset Lifter
11
9
9
3
15
15
20
25
21
13
17
2
4
12
Battery Contacts
5.2
5.6
4
5.5
