M100™Bluetooth®Headset

TAKE A GOOD LOOK
CALL BUTTON
• Takeacallorendit (1 tap)
• Redial(2 taps)
• Initiatephone’svoice-dialing
(2-seccond press until tone heard)
• Reconnectlostconnection (1 tap)
• Activatepairingafterinitialsetup
(press until LED flashes red/blue)
• Activatemultipoint (press while
powering on)
• Transferacallto/fromheadset
(1-second press while on a call)
POWER SWITCH
• On (slide to reveal black)
• Off (slide to reveal red)
MICRO USB CHARGING PORT
• WithACcharger:
30 minutes (2 hours talk time)
90 minutes (full charge)
• Bestperformancewhenfullycharged
VOLUME/MUTE BUTTON
• Min-Lo-Med-Hi-Max
(1 tap per level change)
• Mute:on/off (1-second press)
LED
• Charging (solid red)
• Fullycharged (solid blue)
• Lowbattery (2 red flashes, 2 tones)
• Criticallylow (3 red flashes, 3 tones)
• Multipoint (on=2 blue flashes,
and off=1 blue flash)
Besafe!Pleasereadthesafetyguide
beforeusingyournewheadset.

CONNECT TO YOUR PHONE
“Pairing” connects your
headset to your phone.
“Multipoint” lets you use this
headset with two phones.
(Activate this feature before
pairing your second phone.)
1. READY
Activate the Bluetooth feature on
your phone, then use the phone’s
settings to add/search/discover
new Bluetooth devices.
iPhone: Settings > General >
Bluetooth>On
(starts the search for devices)
BlackBerrysmartphone®: Settings/
options > Bluetooth: On >
Search for devices
VIDEO TUTORIAL IN USA:
www.plantronics.com/pairing
2. SET
FirstTime:
With headset turned off, activate
Bluetooth pairing mode by sliding
Power switch on. The LED flashes
red/blue to indicate pairing mode.
ActivateMultipoint:
While pressing the Call button, turn
on the headset and keep pressing
the Call button until LED flashes
blue twice. (Repeat to deactivate.)
PairingNewPhone/
ReconnectingOriginal:
Turn on the headset then press
and hold the Call button until the
LED flashes red/blue.
3. CONNECT
Select “1xxPlantronics” from the
list of Bluetooth devices shown on
your phone.
If phone asks for a passcode, enter
four zeros (0000). You may see
**** on screen.
Some phones also ask to confirm
headset connection after pairing.
Headset LED will stop flashing red/
blue once your phone and headset
are successfully paired/connected.

FIND YOUR GROOVE
The loop of the gel eartip tucks into the back curve of your
ear for a stable fit.
Try on the headset. The eartip is positioned to suit most
people, but you may want to rotate it to best fit your left or
right ear.
The gel eartip and speaker click into matching grooves so
the eartip doesn’t move out of place during use.
The loop on the gel eartip should point away from the
headset. (Do not rotate the eartip too far.)
ForLeftEar
ForRightEar

MIX AND MATCH FOR BEST FIT
If the gel eartip feels loose or tight in your
ear, then change it. To replace the medium gel
eartip for small or large, pull the loop of the gel
eartip to remove it. (Don’t pull on the speaker
base and stem.)
Using your thumb, tuck the bottom of the
eartip over the speaker and pull the loop of
the eartip over the speaker. (Don’t push the
speaker through the gel eartip.)
If you aren’t familiar with this style of gel
eartip, clip on the earloop to the stem for
extra stability.
VIDEO TUTORIAL:
www.plantronics.com/M100t

MORE ABOUT MULTIPOINT
Plantronics M100 supports multipoint
technology, which allows you to use one
headset with two different Bluetooth
mobile phones.
To pair your headset to a second phone,
see “Connect to Your Phone.”
How to Initiate a Call
When multipoint is on, the headset
controls initiates or redials a call from
the phone that last made an outgoing
call.
To use the second paired phone in-
stead, make the call using the controls
on that phone. The second phone acti-
vates its link with the headset.
NOTE: The headset cannot place a cur-
rent call on hold while answering a call
from the second phone.
How to Answer a Call While Talking on
the Other Paired Phone
To answer a second call on the other
phone, the current call must be termi-
nated or transferred back to the first
phone. To transfer the call, see “Take a
Good Look.”
If you choose not to answer, the sec-
ond call will go to voice mail.
Answeringanincomingcallfrom
thesecondphone,whilealreadyon
anothercall:
1. Before answering the second call,
end the first call by tapping the Call
button.
2. Answer the second call by tapping
the Call button again.
TIP To avoid issues with Multipoint,
use the Call button on the headset
rather than your phone controls.

LISTEN TO THE VOICE
WHAT YOU’LL HEAR WHEN YOU’LL HEAR IT
PowerOn After sliding the Power switch to “on” position
PowerOff After sliding the Power switch to “off” position
TalkTime:(5hrs,4hrs,
3hrs,2hrs,1hr)
After sliding the Power switch to “on” position
BatteryLow When you have approximately 30 minutes left before
the battery must be recharged
RechargeHeadset When you have approximately 15 minutes left before
the battery must be recharged
Phone1Connected After sliding the Power switch to “on” position or recon-
necting a dropped Bluetooth connection
Phone2Connected After pairing a second phone using multipoint feature
Pairing While the headset and phone are trying to pair/connect
PairingSuccessful After the headset and phone are successfully paired/
connected
PairingIncomplete,
RestartHeadset
After the headset and phone tried to pair but failed
VolumeMaximum When the highest volume level is reached after tapping
Volume button
MuteOn After pressing Volume button for 1 second during a call
MuteOff When on mute, after pressing Volume button
for 1 second
LostConnection When the phone loses the Bluetooth connection with
the headset
MultipointOn After activating the feature by pressing Call button
while sliding the Power switch to “on” position
MultipointOff After deactivating the feature by pressing Call button
while sliding the Power switch to “off” position
This headset whispers various status
alerts when you power on/off, run low
on talk time, or lose/reconnect the
Bluetooth connection to your phone.

TIPS
Pair/Connect Just Once
Pairing is a one-time process unless
your phone loses the connection or
you want to pair a new phone.
Watch for Flashing Red LED
This headset will visually warn you
when your battery is low and needs to
be recharged.
Continue a Call Without the Headset
If you need to continue a call without
using your headset, just press the Call
button for 1 second and the call trans-
fers back to your phone. You will hear
a tone to confirm the transfer.
Stay Near Your Phone:
Bluetooth has a working “range” of
up to 33 feet between the phone and
headset before audio degrades and
the connection is lost.
Know How to Reconnect:
Your headset tries to reconnect a lost
connection. If it can’t, then tap the Call
button once or manually reconnect via
the phone’s Bluetooth device menu.
Reset if You Cannot Reconnect
If your headset was working but now
won’t connect, remember that newer
phones are like small computers, so
they may become corrupt over time
and you may need to reset them every
so often.
Simply turn your phone off and re-
move the battery for a few seconds,
then replace the battery and turn it
back on again. If this does not resolve
the issue, delete the pairing informa-
tion for your M100 headset and pair it
with your phone again.
Sound Your Best:
For best voice pickup, always check
that the headset points towards the
corner of your mouth.

SPECIFICATIONS
TalkTime Up to 6 hours
StandbyTime Up to 10 Days
OperatingDistance(Range) Up to 33 feet (10 meters), Class II
HeadsetWeight 9 grams
HeadsetDimensions 55 x 18.5 x 8.1 mm
ChargeConnector Micro USB charging
BatteryType Rechargeable non-replaceable lithium ion polymer
ChargeTime(Maximum) 90 minutes for full
PowerRequirements 5V DC – 180mA
BluetoothVersion 2.1 specifications with EDR
BluetoothProles Hands-Free (HFP) Profile 1.5 and Headset (HSP) Profile 1.1
OperatingTemperature 32°F - 104°F (0 - 40°C)
StorageTemperature 32°F - 104°F (0 - 40°C)
ChargingTemperature 32°F - 104°F (0 - 40°C)

NEED MORE HELP?
24-hour support in USA:
1-866-363-BLUE (2583)
FAQs:
www.plantronics.com/M100faq
1-year limited warranty details:
www.plantronics.com/warranty
