Plantronics CS70 Series User manual

5 Easy Steps
The fastest way to setup your
CS70 Headset System
CS70 Series Setup Guide
Base Power
Adaptor
CS70
Headset Base
CS70 Headset
with Ear Tip
HL10
Automatic
Handset Lifter*
*Not included in all congurations

2Plantronics CS70 Setup Guide
Headset
Headset Base with Pre-
installed Phone Cable
Ear Tips
Base Power Adapter
Setup Guide
HL10 Automatic
Handset Lifter
HL10
User Guide
CS70 PaCkage ContentS
CS70 With Handset Lifter* Adds:
HL10 Additional Parts Kit (if needed)
Extender
Arm
Ringer
Microphone
Adapter for
Nortel i2004
Phones
Please refer to the separate Safety Instructions sheet for important product safety
information prior to installation or use of the product.
*Automatic Handset Lifter is bundled with certain CS70 congurations and also available separately.

3
Questions? For fast, efficient Technical Support call: 800-544-4660 Ext. 5538
InStall ear tIP & adjuSt fIt
S T E P
Fit the Headset
Slide the headset over and behind your ear, then press gently toward your ear. Rotate the
microphone boom until it is pointed toward your mouth. If the ear tip is uncomfortable,
install a dierent ear tip. See below.
To Convert for Wearing on Left Ear
A. Rotate microphone
boom up
B. Turn microphone
boom around
C. Rotate microphone
boom down
1
For your safety and comfort, the ear tip should never be inserted into the ear canal.
Choose the style and size of Ear
Tip that ts most comfortably.
Align Ear Tip tabs with notches
in headset.
Push in rmly and
twist counter
clockwise.
To Install a Dierent Ear Tip
Remove the pre-installed ear tip by
pushing in and turning the ear tip
clockwise, then pull rmly.
To view an interactive set-up guide online, visit www.plantronics.com/cs70setup and click on Adjusting Fit.

4Plantronics CS70 Setup Guide
S T E P
2ConneCt BaSe to deSk Phone
Use Conguration A if:
You will use the Automatic Handset Lifter
or…
Your phone has NO built-in headset functionality (no Headset button).
Conguration A
2. Plug the short black Phone Cable that
is pre-installed on the Headset Base into
the now-open handset port [A] on the
desk phone.
1. Unplug the handset coil
cord from the desk phone
handset port [A], then plug it
into the green labeled handset
port [B] on the Headset Base.
A
A
Handset
Coil Cord Handset
Headset Base
(bottom view)
B

5
Questions? For fast, efficient Technical Support call: 800-544-4660 Ext. 5538
Use Conguration B if:
You will NOT use the Automatic Handset Lifter
and…
Your phone has built-in headset functionality (a Headset button).
1. Plug the short BLACK Phone
Cable that is pre-installed on
the Headset Base into the Heaset
port [C] on the desk phone.
Conrm there is
a “HEADSET” button
on your phone
Conguration B
HANDSET port or HEADSET port?
You should only use the headset port if you will not be using the Automatic Handset
Lifter and you have a pre-programmed Headset button on your phone.
In this conguration you must press both the Headset button on your phone
and the Call Control Button on the headset to answer/end calls.
C
Headset Base
(bottom view)

6Plantronics CS70 Setup Guide
ConneCt Power and Charge headSet
3
S T E P
1. Plug the Base Power Adapter into a wall outlet, then plug the power cord into the yellow
labeled connector on the bottom of the Headset Base. The red Power light on the left
front of the Headset Base will turn on. (See illustration at bottom of page.)
Power
(red)
Charge
Status
(amber)
IMPORTANT! Make sure the headset
is facing correctly (as shown at left)
when inserted into the charging cradle.
Insert into yellow labeled power
connection on Headset Base as
shown to charge.
Headset Base
(bottom view)
Base
Power
Adapter
A. Connect Headset Base to power outlet
1. Gently push the headset into the charging cradle as shown below. The amber Charge
Status light on the base will ash to indicate the headset battery is charging. A solid
light indicates full charge. A full charge will take approximately 3 hours.
B. Charge the Headset for at least 20 Minutes before using

7
Questions? For fast, efficient Technical Support call: 800-544-4660 Ext. 5538
InStall automatIC handSet lIfter
Why use a handset lifter? The lifter greatly simplies using
a headset with your desk phone. It lets you answer and
end calls without being near your phone.
4
S T E P
firmly press Lifter power
cord into red labeled port
on Headset Base.
Automatic Handset Lifter
Headset Base
(bottom view)
The HL10 Automatic Handset lifter is included with certain CS70 congurations and is
also available separately.
If you do not have the Lifter, skip to step 5.
1. Verify that the base-to-desk Phone Cable is connected to the handset port of the desk
phone, and not the headset port (Refer to Step 2, Conguration A).
2. firmly press the Handset Lifter power cord into the red labeled port to ensure a
complete connection.
A. Connect Handset Lifter power cord to Headset Base

8Plantronics CS70 Setup Guide
Press Call
Control Button
4. Press the Call Control Button on the headset.
This will activate the Handset Lifter and lift the
handset from the phone.
If you hear a dial tone, the lifter height is set
correctly and needs no adjustment.
Please continue with the next section “Mount the
Lifter in Permanent Position”.
5. If you do not hear a dial tone, the Lifter may not
be raising the handset high enough OR the
Conguration Dial may need adjusting. Continue to
step 6.
Handset Lifter Arm
Lifter viewed
from back
2. While wearing your headset, slide the Handset Lifter Arm under the handset until the
lifter base touches the side of the phone.
3. Slide the Lifter up to where it nearly touches the handset earpiece.
Start with Lifter
Height Switch in
lowest position
Slide Lifter under
handset, then up
toward the ear piece
1. Set the Lifter Height Switch to the lowest setting.
B. Determine Lifter position and height setting

9
Questions? For fast, efficient Technical Support call: 800-544-4660 Ext. 5538
Peel back
mounting tape
protective strips
(3 places)
6. Check the Lifter height adjustment by moving the Lifter Height Switch to a higher position.
Repeat steps 2. through 4. as necessary.
If you hear a dial tone, the lifter height is now set correctly. Please continue with the next
section “Mount the Lifter in Permanent Position”.
7. If you still cannot hear a dial tone,
you will need to change the setting
on the Conguration Dial.
Using a coin or paperclip,
turn the Conguration Dial to
a dierent setting until you hear a
dial tone. Multiple settings might work
with your phone; however, only one is the
optimal position. If you still cannot hear a dial
tone, please call Technical Support
at 800-544-4660 Extension 5538.
To view an interactive set-up guide online, visit www.plantronics.com/cs70setup
and click on Compatibility.
1. Remove the protective strips from the three mounting tapes on the underside of the Lifter.
2. gently place the Lifter on the desk phone in the optimum position as determined above.
Test the Lifter to verify positioning by pressing the Call Control Button on your headset to
activate the Lifter and listen for a dial tone.
3. Press firmly to adhere the Lifter to the desk phone.
C. Mount the Lifter in permanent position
Conguration
Dial
Position Indicator
If your handset falls o the phone base or
does not return to its cradle when lowered,
you will need to attach the Extender Arm to
the Lifter as described in the HL10 Additional
Parts Kit.
Use the Extender Arm to Stabilize
Handset (if needed)

10 Plantronics CS70 Setup Guide
make ateSt Call to ConfIgure
and oPtImIze your SyStem.
5
S T E P
To get the best sound quality for both you and your
listeners You MUST congure and optimize your
system!
Automated Sound Test
866-210-2157
For your safety, do not use headset at high volumes for extended periods of time. Doing so can cause
hearing loss. Always listen at moderate levels. For more information on headsets and hearing
visit: www.plantronics.com/healthandsafety
1. If your desk phone has a volume control, set it to mid-range.
2. If you have installed the Automatic Handset Lifter, press the Call Control Button on
your headset.
If you have not installed the Automatic Handset Lifter, press the Call Control Button
then lift the handset from its cradle (or press the HEADSET button on your telephone,
if it has one).
3. Verify that you hear a dial tone. If so, continue with step 4.
if you do not Hear a dial tone: Use a coin or paperclip to turn the Conguration Dial
to a dierent setting until you hear a dial tone.
If you still do not hear a dial tone at any of the four positions, review Setup Guide
Steps 1–4 to verify completion.
4. Make the test call (TOLL FREE). It’s the quickest way to test and optimize
your system.
A. Make the test call
Press Call
Control Button
