Plantronics Discovery®925
User Guide

ii
Welcome
Thank you for purchasing the Plantronics Discovery®925 earpiece.
This guide contains instructions for setting up and using
your new earpiece.
Please refer to the separate “For Your Safety” booklet for important
product safety information prior to use of the product.
Getting Assistance
The Plantronics Technical Assistance Centre is ready to assist you.
You can find answers to frequently asked questions, ask a question
using e-mail, receive service over the Internet, or speak directly
with a representative. Visit www.plantronics.com/support or call
your country support line mentioned at the back of this user guide.
NOTE If you are considering returning this earpiece, please contact
the Technical Assistance Centre first.
Registering Your Product
Visit www.plantronics.com/productregistration to register your product
online so we can provide you with the best service and technical support.
NOTE For pairing your earpiece, your PIN code, or “Passkey,” is 0000.

iii
Contents
Package Contents, Features and Accessories......................................iv
Charging Your Earpiece........................................................................1
Using the AC or USB charger......................................................1
Using the Charging Case.............................................................2
Checking the Battery Level..........................................................2
Recharging the Charging Case....................................................3
Pairing Your Earpiece............................................................................4
Plantronics QuickPair™ Technology............................................4
How to Pair Your Phone With Your Earpiece for the First Time.....5
Adjusting the Fit....................................................................................6
How to Install a Different Gel Eartip..............................................6
Earpiece Controls.................................................................................7
Hands-Free Features............................................................................8
Range ..................................................................................................9
Indicator Lights and Tones....................................................................9
Troubleshooting..................................................................................11
Using More Than One Bluetooth Phone..............................................13
How to Turn the Multipoint Feature On and Off..........................13
How to Initiate a Call..................................................................13
How to Answer a Call While Talking on the Other Phone ...........13
Product Specifications........................................................................14

Package Contents and Features
Optional Accessories*
Vehicle Power Charger
#78583-01
Earpiece
Charging Case
* Not included. To order, please contact your Plantronics supplier or go
to www.plantronics.com
AC Charger
100–240V USB Charging Cable
Volume Control Button
Charging Jack
Eartip
Stabilizing Eartips
(small, medium, and large)
Call Control Button
USB Lanyard
#79393-01
iv

1
Option A: Using the AC Charger
1 Plug the AC charger into a power outlet.
2 Connect the AC charger to the charging jack on the earpiece.
Charging Your Earpiece
Your new earpiece performs best when fully charged. While your
earpiece is charging, the indicator light slowly flashes red. When your
earpiece is fully charged, the indicator light turns off. This applies to
all charging options.
1
2
Option B: Using the USB Charger
1 Connect USB charger to the USB
port on a computer or laptop.
2 Connect the USB charger to the
charging jack on the earpiece.
3 Turn the computer or laptop on.
1
2
3
WARNING Do not use your earpiece while it is
connected to the charger.
CHARGING TIME
3 hours.....Full charge using
AC or USB
1 hour.......Minimum charge
before first use

2
Option C: Using the Charging Case
Open the cover of the case. Align the charging jack on the earpiece with
the micro USB connection in the case. Gently push the earpiece onto
the micro USB connection until you feel it click into place.
IMPORTANT Incorrect removal of the earpiece from the case will
damage the micro USB port in the case. To properly remove the
earpiece, use your thumb to gently push the earpiece in a diagonal,
not vertical, direction away from the micro USB connector.
Checking the Battery Level of Your Earpiece
With the earpiece on, simultaneously press and hold the call control
button and the volume button for about 2 seconds. The indicator light
flashes red to show the charge level.
Charging Your Earpiece
press and hold the call control
CHARGE INDICATOR LIGHTS
Red Flashes Battery Level
1 Full battery
2 1/3 to 2/3 full
3 Less than 1/3 full
Volume Button
Call Control Button
CHARGING TIME
3 hours.....Full charge using
charging case
1 hour.......Minimum charge
before first use

3
2
The charging case provides one full charge to your earpiece before the
battery within the case requires charging. While the case is charging,
the indicator light on the bottom of the case flashes red. When fully
charged, the indicator turns off.
Recharging the Charging Case
1 To check the battery status of the charging case, you must
connect the earpiece to the case.
If the earpiece does not begin charging mode (indicator light slowly
flashes red) then both the earpiece and case need recharging.
2 Plug either the AC charger or the USB charger to power
source before connecting to the charging jack on the bottom
of the case.
If you disconnect the power source from the case after 10 minutes of
charging you must then wait at least 60 minutes before reconnecting
a power source to resume the charging cycle.
NOTE If recharging with the AC charger, the charging case will feel
warm to the touch during the charging cycle. Once fully charged, the
case will cool down. See the separate “For Your Safety” booklet for
more information.
1
Charging Your Earpiece
Indicator Light
Charging Jack
CHARGING TIME
9 hours....Full charge
using USB
3 hours....Full charge
using AC

4
Pairing Your Earpiece
Pairing is the process of introducing your earpiece to your phone.
Before using your earpiece for the first time, you must pair it with
your Bluetooth®wireless technology enabled phone. Normally you
need to pair your earpiece with your phone only once.
To see a demo of the pairing process, visit www.plantronics.com/
EasyToPair (only available in English).
Plantronics QuickPair™Technology
Your new earpiece includes Plantronics QuickPair technology to simplify
the Bluetooth setup process. The fi
rst time you turn your earpiece on,
your earpiece automatically enters pairing mode for 10 minutes. Once
paired successfully, your earpiece stays on for instant use.
If not successfully paired after 10 minutes, your earpiece automatically
powers off. When you turn the earpiece on again, it automatically goes
into pairing mode until successfully paired with a Bluetooth phone.

5
3
2
How to Pair Your Phone with Your Earpiece for the First Time
1 Turn on the Bluetooth feature on your phone.
For most phones, select Settings/Tools > Connections >
Bluetooth > On. See your phone’s user guide for more information.
2 Turn the earpiece on.
Press and hold the call control button until the indicator flashes
red/blue. The earpiece is now in pairing mode.
If you don’t see the red/blue flash, press and hold the call control
button to turn your earpiece off, and then press and hold the call
control button again until you see the red/blue flash.
3 Use the commands on your phone to locate your earpiece.
For most phones, select Settings/Tools > Connections > Bluetooth
> Search > 9XXPlantronics. See your phone’s user guide for more
information.
4 When prompted for the PIN code or Passkey, enter 0000.
Pairing is successful when the indicator on your earpiece flashes
blue. Your earpiece is now connected and ready to use.
Pairing Your Earpiece
SETTINGS
Time and Date
Phone Settings
Bluetooth
Sound Settings
Network Serv ces
Security
Reset Settings
1BLUETOOTH
BLUETOOTH
9XXPlantronics
PASSKE Y
0000
4
B O
BLUETOOTH
9XXPlantronics
PASSKEY
0000

6
How to Install a Different Gel Eartip
If the earpiece does not feel stable, the eartip needs adjusting or it may
be the wrong size for your ear. The earpiece comes with the medium
eartip installed, but you can replace it with the optional small or large
eartip provided.
Adjusting the Fit
For optimal voice clarity,
point the boom towards
the corner of your mouth.
Correct Fit Incorrect Fit
23
1 Remove the earpiece from your ear.
Rotate the eartip on the earpiece to position the stabilizer to rest
comfortably in your ear. If the earpiece still feels unstable, then remove
the earpiece from your ear and change the eartip to a different size.
2 To remove the eartip, hold the stabilizer and gently pull the
eartip off the speaker housing.
3 To fit a new eartip, position the eartip over the speaker
housing with the stabilizer pointed away from the microphone
boom and gently press the eartip onto speaker housing.
Eartip
Speaker housing
1

7
Earpiece Controls
Turn on the earpiece Press and hold the call control button for 2
seconds until the indicator glows blue. If earpiece
flashes red 3 times when you turn on the earpiece
then the battery is very low and should be
recharged.
NOTE When your earpiece is in standby mode, the indicator
is off. To confirm that your earpiece is on, press any button.
You should see a blue light flash.
Turn off the earpiece Press and hold the call control button for 4
seconds until the indicator glows red. When
power is off, indicator stays off.
NOTE If you’re wearing the earpiece, you hear ascending
tones when the power turns on and descending tones when
the power turns off.
Answer or reject
a call When your earpiece rings, tap the power button once; you should hear 1 low tone.
To reject a call and send the caller to voice mail,
press the call control button for 2 seconds.
NOTE Your phone may ring before your earpiece rings.
Wait until you hear the ring in your earpiece to press the call
control button and answer the call.
End a call During active call, tap the call control button.
Make a call When the earpiece is paired to your phone and in
range, enter phone number on your phone and
press send. The call automatically transfers to
your earpiece.
Transfer a call
between earpiece
and phone
During an active call, press and hold the call
control button for 2 seconds. You will hear a
single low tone followed by a double low tone.

8
Earpiece Controls
Turning the
multipoint feature on To prolong battery life, the multipoint feature
is turned off by default. To turn on feature, see
“How to Turn the Multipoint Feature On and Off”
on page 13.
Turn off the online
indicator Press and hold the volume button for 4 seconds
while the earpiece is on. Blue light will dim over
2 seconds. Repeat action to activate online
indicators. Blue light will brighten over 2 seconds.
You will hear a single low tone, silence, and then
a double low tone.
Adjust the volume During an active call, tap the volume button.
There are 3 volume settings. Each tap will
increase the volume until maximum is reached
and you hear two low tones. Tapping again will
drop volume to minimum setting and subsequent
taps will increase volume until maximum is
again reached.
Hands-Free Features
If your phone and your wireless service provider both support hands-free
operation, you can use the following features:
Redial the last number
you called Tap the call control button twice. You will hear two low tones.
Voice activated dialling When the earpiece is on, press and hold
the call control button for 2 seconds until
you hear 1 low tone.
WARNING Do not use headphones/earpieces at high volumes for an extended
period of time. Doing so can cause hearing loss. Always listen at moderate levels. See
www.plantronics.com/healthandsafety for more information on earpieces and hearing.

9
Range
To maintain a connection, keep your earpiece within 33 feet (10 metres)
of the Bluetooth phone. If there are obstacles between your earpiece and
the phone you may experience interference. For optimal performance,
place your earpiece and phone on the same side of your body.
Audio quality degrades as you move out of range. When you are
far enough away to lose the connection, you hear a high tone in the
earpiece.
The earpiece attempts to reconnect for 60 seconds. If you move back in
range, you can manually reconnect by pressing the call control button.
NOTE Audio quality is also dependent upon the device with which the
earpiece is paired.
Indicator Lights and Tones
Light Tone
Status check 1 blue flash 1 tone
Charging 1 red flash every 10 seconds None
Fully charged None None
Low battery 2 red flashes for 2/3 full battery None
Very low battery 3 red flashes every 10 seconds 3 high tones every
10 seconds
Pairing Red and blue flashes 1 low tone
Paired Blue flashes 1 low tone
Turning on Solid blue for 2 seconds Ascending tones
Turning off Solid red for 4 seconds Descending tones

10
Indicator Lights and Tones
Light Tone
Incoming call 3 blue flashes every 2 seconds 3 rapid low tones
every 2 seconds
Answer call 1 blue flash 1 low tone
Call in progress 1 blue flash every 2 seconds None
Volume up or
down 1 blue flash for each volume adjustment 1 tone with volume corresponding to
volume level
2 low tones to
indicate maximum
volume level
reached
End call 1 blue flash 1 low tone
Missed call 3 purple flashes every 10
seconds for 5 minutes None
Out of range None 1 high tone
Back in range Flashes to match current
earpiece state 1 low tone
Turning on
multipoint 2 blue flashes None
Turning off
multipoint 1 blue flash None
NOTE By default, the online indicator is turned on. To turn off the online
indicator, see “Earpiece Controls” on page 8.

11
Troubleshooting
My earpiece
does not work
with my phone.
Make sure the earpiece is fully charged.
Make sure earpiece is paired with the Bluetooth
phone you are trying to use.
See “Pairing Your Earpiece” on page 4.
My phone did not
locate the earpiece. Turn both your phone and earpiece off and on, and then repeat the pairing process on page 4.
I could not enter
my PIN code. Turn both your phone and earpiece off and on, and then repeat the pairing process on page 4.
Your PIN code, or Passkey, is 0000.
I cannot hear
caller/dial tone. The earpiece is not turned on. Press the call control button for approximately 2 seconds until
you hear a tone or see the indicator glow blue.
Your earpiece is out of range. Move the earpiece
closer to the Bluetooth phone.
Your earpiece battery is drained. Charge your
battery. See “Charging Your Earpiece” on page 1.
The listening volume is too low. Incremental
tapping of the volume button will adjust volume.
See instructions for adjusting the volume in
“Earpiece Controls” on page 8.
Make sure that the eartip fits properly. See
“Adjusting the Fit” on page 6.

12
Troubleshooting
Audio quality
is poor. Make sure that earpiece is sitting correctly in ear with boom pointing towards corner of mouth.
See “Adjusting the Fit” on page 6.
Callers cannot
hear me. Your earpiece is out of range. Move the earpiece closer to the Bluetooth phone. See “Range” on
page 9.
The eartips do not
fi
t my ear. Try a different size eartip. See “Adjusting the Fit”
on page 6.
My earpiece falls
out of my ear. Make sure that earpiece is sitting correctly in ear
with boom pointing towards corner of mouth.
See “Adjusting the Fit” on page 6.
My eartip needs to
be cleaned. Remove the eartip from the earpiece and wash it in warm soapy water and dry thoroughly. When
the eartip is completely dry, put it back on your
earpiece.

13
Using More Than One Bluetooth Phone
Plantronics Discovery 925 supports multipoint technology, which allows
you to use one earpiece with two different Bluetooth mobile phones.
How to Turn the Multipoint Feature On and Off
To use more than one phone, you must turn the multipoint feature on.
When this feature is off, your earpiece can connect to only one Bluetooth
phone.
1 With your earpiece turned off, press and hold the volume and
call control buttons simultaneously until earpiece turns on and
indicator flashes blue 2 times.
2 To pair earpiece to a second phone, see “Pairing Your
Earpiece” on page 5.
NOTE To turn the multipoint feature off, repeat step 1. The indicator
flashes blue 1 time to indicate multipoint is off.
How to Initiate a Call
The earpiece initiates a call on the phone you most recently used. To
use the second phone, initiate the call using the controls on the second
phone. The second phone forms an active link with the earpiece.
How to Answer a Call While Talking on the Other Phone
To answer the second call, the first call must be terminated. There is no
function for placing one call on hold while answering another call from the
earpiece.
1 Press the call control button once to hang up the existing call.
2 Press the call control button again to answer the new call from
the other phone.
NOTE If you choose not to answer the second call, and you have voice
mail on the second phone, the call will go to voice mail.

14
Product Specifications
Talk Time* Battery enables up to 5 hours
Standby Time* Battery enables up to 175 hours with
multipoint feature OFF
Battery enables up to 100 hours with
multipoint feature ON
Charge Time Charging earpiece using AC = 3 hours
Charging earpiece using USB = 3 hours
Charging earpiece using the case = 3 hours
Charging the case using AC = 3 hours
Charging the case using USB = 9 hours
Range Up to 33 feet (10 metres)
Earpiece Weight 8 grams
Battery Type Earpiece: Lithium ion polymer
Charging Case: Nickel-metal hydride
Storage/Usage
Temperature50 °F – 104 °F (10 °C – 40 °C)
Version Bluetooth 2.0 + EDR (Enhanced Data Rate)
Bluetooth Profiles Headset Profile (HSP) for talking on the phone
Hands-free Profile (HFP) for talking on the
phone and operating the phone
* Performance may vary by device.

For safety information, see the separate “For Your Safety” booklet.
For warranty information, see the separate “2 Year Warranty” leaflet or visit
www.plantronics.com
15
Plantronics Ltd
Wootton Bassett, UK
Tel: [phone]
Middle East Region
:لمزيد من المعلومات
www.plantronics.com
Czech Republic
www.plantronics.com
Danmark
Tel: [phone]
Plantronics GmbH
Hürth, Deutschland
Kundenservice:
Deutschland 0800 9323 400
Österreich 0800 242 500
Schweiz 0800 932 340
Για περισσότερες
πληροφορίες:
www.plantronics.com
Plantronics Iberia, S.L.
Madrid, España
Tel: [phone]
Finland
Tel: [phone]
Plantronics Sarl
Noisy-le-Grand
France
Plantronics BV
Regus House
Harcourt Centre
Harcourt Road
Dublin 2
Ireland
Office: [phone]
Service ROI: 1800 551 896
:למידע נוסף, בקר באתר
www.plantronics.com
További információk:
www.plantronics.com
Plantronics Acoustics
Italia Srl
Milano, Italia
Numero Verde: 800 950934
Plantronics B.V.
Hoofddorp, Nederland
Tel: (0)0800 Plantronics
0800 7526876 (NL)
00800 75268766 (BE/LUX)
Norge
Tel: [phone]
Aby uzyskać więcej
informacji:
www.plantronics.com
Portugal
Tel: [phone]
Pentru informaţii
www.plantronics.com
Дополнительная
информация:
www.plantronics.com
Sverige
Tel: [phone]
Daha fazla bilgi için:
www.plantronics.com
en
cs
da
de
el
es
fi
fr
ga
he
hu
it
nl
ar
no
pl
pt
ro
sv
tr
ru

©2008 Plantronics, Inc. All rights reserved. Plantronics, the logo design, Plantronics
Discovery, and Sound Innovation are trademarks or registered trademarks of Plantronics,
Inc. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and
any use of such marks by Plantronics, Inc. is under license. All other trademarks are the
property of their respective owners.
US patent 5,210,791 and Patents Pending
78647-03 Rev A
МЛ05
Plantronics, Inc.
345 Encinal
Santa Cruz, CA 95060
United States
Tel: [phone]
www.plantronics.com
