PLANTRONICS EXPLORER™300 Series
BLUETOOTH®HEADSET
USER GUIDE_
72357-01 (04-06)

REGISTER YOUR PRODUCT ONLINE
Visit www.plantronics.com/productregistration to register your product online so
we can provide you with the best possible service and technical support.
WELCOME
Thank you for purchasing a Plantronics headset.
Let us provide you with the best possible service and technical support. After you
reviewthis user guide, if you need additional assistance or have any product
questions, please contact:
•Plantronics Technical Assistance Center at 866-363-BLUE (2583)
•www.plantronics.com/support
Before getting started, please review the safety booklet included in the package.
TABLE OF CONTENTS
Package Contents & Features 3
Charging & Powering 5
Pairing 6
Adjusting Fit 7
Using Your Headset 8
Indicator Lights 9
Accessories 10
Troubleshooting 12
Product Specifications 12
Technical Assistance 13
Warranty 13
Regulatory Notices 14

3
PACKAGE CONTENTS & FEATURES
PLANTRONICS EXPLORER 330
Indicator light
Call control button
Microphone
Adjustable ear loop
Ear tip
Charging jack
Indicator light
Call control button
Microphone
Adjustable ear loop
Ear tip
Charging jack
PLANTRONICS EXPLORER 340 AND 350

4
PACKAGE CONTENTS & FEATURES
In-car charging
cradle (shown
with vent clip)
AC power adapter
Vent clip
Vehicle
charging
adapter
USB headset
charger
Dash mount
Cradle Mount Options
PLANTRONICS EXPLORER 350
PLANTRONICS EXPLORER 330 & 340

5
CHARGING & POWERING
1
2
1
2
Before using, you must first charge your headset.
20 minutes = minimum charge
2hours = full charge
Light is solid red when battery is charging.
NOTE For the best user experience, keep your headset fully charged.
CAUTION Do not use headset while charging and do not connect the charger while
the headset is in use.
CHARGING
POWERING
Press the control button for 2 seconds to power on. Press the control button for
3seconds to power off.
Explorer 330 & 340 Explorer 350

6
PAIRING
Begin with headset turned off.
1. Press call control button for
6seconds. Release button when
indicator light flashes blue and
red. Headset is ready to pair with
Bluetooth device.
NOTE The headset can pair to
multipleBluetooth devices, but
will only connect to one device
at a time. The headset will auto-
maticallyconnect to the last
device to which it was connected.
2. Whilethe headset is flashing red
and blue, use the phone menu
to search for Bluetooth devices
and select “3XXPlantronics”.
3. When prompted for passkey enter
0000. Headset will flash blue when
paired successfully.
1. 2.
3.
Before using your headset for the first time, you must pair it with your Bluetooth®
phone or device. Be sure the headset is fully charged. For set up and pairing
instructions with Bluetooth devices other than mobile phones, please consult your
Bluetooth device user guide.

7
ADJUSTING FIT
Place ear loop
behind ear.
Position speaker and
align microphone with
mouth.
Right Ear Left Ear
Lift ear loop. Swivel ear loop to the right or left for
right or left ear wearing.
Pivot headset to
place speaker
intoear.
1. 2.
3. 4. 5.

8
USING YOUR HEADSET
ADJUSTING THE VOLUME
ANSWERING/ENDING/MAKING CALLS
Briefly push up or down on the call control button for incremental volume steps.
You will hear two tones (high tone followed by low tone) at the volume limit.
WARNING For your comfort, health, and safety, do not exceed moderate
listening levels.
For best performance, position your mobile phone on the same side of your body
as the headset.
To answer or end a call, briefly press the call control button.
Tomake a call, enter number on your phone, press send, and the call is
automatically transferred to headset; no need to press call control button.

9
USING YOUR HEADSET
ADDITIONAL FEATURES
INDICATOR LIGHTS
Headset Status Headset Indicator Light
Powering on Blue flashes. Repeat.
Powering off Red appears and goes off.
Charging battery Red solid light.
Low battery Red flashes.
Pairing mode Blue/red flashes for 120 seconds.
Missed call Purple flashes. Double press the call control
button to cancel.
Ringing Purple flashes. Briefly press call control button
toanswer the call. Press call control button for
2seconds to reject the call.
Redialing Last Number
To activate last number redial, double
press the call control button. You will
hear a high tone after each double
key press.
Using Voice Dialing
With the headset on, press the call
control button for 2 seconds to
activate the voice dialing.
NOTE To use voice activated dialing,
the voice dialing feature must be
enabled on your phone. See your
Bluetooth phone manual for
instructions.
Rejecting a Call
When receiving an incoming call,
press the call control button for
2seconds to reject the call.
Switching a Call From Phone to Headset
To switch an active call from your
phone to your headset, press the
call control button for 3 seconds.
Switching a Call From Headset to Phone
To switch an active call from your
headset toyour phone, press the
call control button for 2 seconds.

ACCESSORIES
INCLUDED ACCESSORIES
10
In-car charging cradle and in-vehicle charging adapter – for Explorer 350 only
1. Select vent clip or dash mount option. Attach to rear of in-car charging cradle.
NOTE Select the mounting option that allows the charging cradle to not interfere
with car controls.
2. Insert charging plug into slot on bottom of charging cradle. Be sure to slide to
top of slot.
3. Attach charging cradle to dash mount or vent.
IMPORTANT Clip onto lowest vent slot. Be sure the headset is not directly in the
vent air flow. If headset cannot be positioned out of air flow, use dash mount
instead.
4. Place ear tip as shown in the top of the cradle. Gently press the bottom of the
headset to plug the charging adapter into the charging jack. Then plug in-vehicle
charging adapter into vehicle power.
1.
3.
2.
4.

AVAILABLE FOR PURCHASE
69520-01 Vehicle charging adapter
72321-01 Desktop charging cradle 72323-01 In-car charging cradle
(can be used with
Explorer 340)
69519-01 USB headset charger
11
Toorder, please contact your Plantronics supplier or go to www.plantronics.com.
ACCESSORIES

12
TROUBLESHOOTING
PRODUCT SPECIFICATIONS
Headset was not in pairing mode when mobile phone menu
selections were made. See page 6 “Bluetooth Pairing”.
Incorrect menu selections were made on your mobile phone.
See page 6 “Bluetooth Pairing”.
Your phone did not locate the headset.
Repeat the pairing process on page 6.
Incorrect menu selections were made on your mobile phone.
Repeat the pairing process on page 6.
The headset is not turned on. Press the call control button
for 2 seconds until you hear a beep or see the indicator light
glow blue to turn headset on.
Your headset is out of range. Move the headset closer to the
phone or Bluetooth device.
Your headset battery is drained. Charge your battery using
the ACpower adapter supplied.
The listening volume is too low. Press the volume key up
(toward the ear loop) to increase the sound heard in the
headset.
My headset
does not work
with my phone.
Idid not enter
my passkey.
Callers cannot
hear me, or
Icannot hear
caller/dialing
tone.
PROBLEM SOLUTION
Talk Time* Up to 8 hours
Standby Time* Approximately 240 hours
Charge Time 2hours
Range Bluetooth standard 33 feet (10 meters)
Power Requirements 5V DC – 300 mA
Battery Type Lithium Ion Polymer
Version Works with Bluetooth 1.1 or higher
Storage and Usage Temperature 50F–104F (10C – 40C)
Supports Bluetooth hands-free and headset profiles.
*Performance may vary by device. Headset can last up to four days without charging,
based on average talk time of 1.5 hours per day.

13
TECHNICAL ASSISTANCE
Visit our Web site at www.plantronics.com/support for technical support including
frequently asked questions, compatibility and accessibility information. The
Plantronics Technical Assistance Center (TAC) is also ready to assist you on
866-363-BLUE (2583).
WARRANTY
LIMITED WARRANTY
•This warranty covers defects in materials and workmanship of products
manufactured, sold or certified by Plantronics which were purchased and used
in the United States.
•The warranty lasts for one year from the date of purchase of the products.
•This warranty extends to you only if you are the end user with the original
purchase receipt.
•Wewill at our option, repair or replacethe products that do not conform to the
warranty. We may use functionally equivalent
reconditioned/refurbished/remanufactured/pre-owned or new products or parts.
•To obtain service in the U.S., contact Plantronics at (866) 363-BLUE (2583).
•THIS IS PLANTRONICS’ COMPLETE WARRANTY FOR THE PRODUCTS.
•This warranty gives you specific legal rights, and you may also have other rights
that vary from state to state. Please contact your dealer or our service center
for the full details of our limited warranty, including items not covered by this
limited warranty.

REGULATORY NOTICES
14
US FCC REQUIREMENTS PART 15
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception which can be determined by turning the radio or television off and on, the
user is encouraged to try to correct interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment intoan outlet on another circuit.
4. Consult the dealer or an experienced radio/TV technician for help.
EXPOSURE TO RADIO FREQUENCY
RADIATION
This deviceand its antenna must not be co-located or operated in conjunction with
any other antenna or transmitter. To comply with FCC RF exposure requirements,
onlyuse supplied antenna. Any unauthorized modification tothe antenna or device
could void the user’s authority to operate this device.

15

©2006 Plantronics, Inc. All rights reserved. Plantronics, the logo design, Plantronics Explorer and Sound
Innovation are trademarks or registered trademarks of Plantronics, Inc. The Bluetooth word mark and logo
are owned by Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc. is under license. All other
trademarks arethe property of their respective owners. Patents U.S. 5,210,791; EM 000392600-0003 and
Patents Pending
Printed in USA
Plantronics, Inc.
345 Encinal Street
Santa Cruz, CA 95060 USA
Tel: [phone]
www.plantronics.com

©2006 Plantronics, Inc. Todos los derechos reservados. Plantronics, el diseño del logotipo, Plantronics
Explorer y Sound Innovation, son marcas comerciales o marcas registradas de Plantronics, Inc. El nombre
Bluetooth y las marcas comerciales Bluetooth son propiedad de Bluetooth SIG, Inc., y Plantronics, Inc. las utiliza
en virtud de una licencia. Todas las demás marcas registradas son propiedad de sus respectivos propietarios.
Patente de EE.UU. 5.210.791; EM 000392600-0003 y pendiente de otras patentes.
Impreso en EE.UU.
Plantronics, Inc.
345 Encinal Street
Santa Cruz, California, EE.UU.
Teléfono: [phone]
www.plantronics.com

AVISOS SOBRE NORMATIVA
14
REQUISITOS DE LA FCC (SECCIÓN 15)
Este dispositivo cumple lo establecido en la sección 15 de las normas de la FCC.
El funcionamiento está sujeto a las siguientes dos condiciones:
1. Este dispositivo no debe causar interferencias peligrosas.
2. Este dispositivo debe aceptar cualquier interferencia recibida, incluidas las
interferencias que puedan causar un funcionamiento no deseado.
Este equipo se ha probado y se ha demostrado que cumple los límites para
dispositivos digitales de Clase B, de conformidad con la sección 15 de las normas
de la FCC. Dichos límites se han establecido para garantizar una protección
razonable contra interferencias peligrosas en instalaciones residenciales. Este
equipo genera, utiliza y puede radiar energía de radiofrecuencia y, si no se instala
yutiliza según las instrucciones, puede causar interferencias peligrosas en las
comunicaciones por radio.
Sin embargo, no se garantiza que no se puedan producir interferencias en una
instalación concreta. En el caso de que este equipo produjera interferencias
peligrosas en la recepción de radio o televisión, que se puede determinar apagando
yencendiendo la radio o el televisor, se recomienda que el usuario corrija dichas
interferencias mediante alguno de los siguientes procedimientos:
1. Vuelva a orientar o colocar la antena receptora.
2. Aumente la distancia de separación entre el equipo y el receptor.
3. Conecte el equipo a una toma de corriente de un circuito distinto.
4. Póngase en contacto con el distribuidor o con un técnico de radio o televisión
con experiencia para obtener ayuda.
EXPOSICIÓN A LA RADIACIÓN DE LA
RADIOFRECUENCIA
Ni el dispositivo ni la antena deben colocarse o utilizarse en combinación con
ninguna otraantena o transmisor. Para cumplir con los requisitos de la FCC
sobre exposición a la radiación de radiofrecuencia, utilice únicamente la antena
proporcionada. Toda modificación no autorizada en la antena o dispositivo podría
anular el derecho del usuario a utilizar este dispositivo.

13
ASISTENCIA TÉCNICA
Si desea obtener asistencia técnica y consultar el archivo de las preguntas más
frecuentes e información sobre compatibilidad y accesibilidad, visite nuestro sitio
web en la dirección www.plantronics.com/support. También puede ponerse en
contacto con el centro de asistencia técnica de Plantronics (TAC) en el 866-363-2583.
GARANTÍA
GARANTÍA LIMITADA
•Esta garantía cubre los defectos de materiales y mano de obra de los productos
fabricados, vendidos o certificados por Plantronics que se adquieran y utilicen
en Estados Unidos.
•La garantía tiene un periodo de validez de un año a partir de la fecha de compra
del producto.
•Estagarantía sólo es válida para el usuario final en posesión de la factura de
compra original.
•Los productos que no cumplan esta garantía podrán, según nuestro propio
criterio, repararse o sustituirse. Para ello, podrán utilizarse piezas o productos
que funcionen de forma equivalente. Estas piezas o productos podrán ser
nuevos, de segunda mano, refabricados, renovados o reacondicionados.
•Para obtener asistencia técnica en Estados Unidos, póngase en contacto con
Plantronics llamando al 866 363-2583.
•ESTAES LA GARANTÍA COMPLETA PARA LOS PRODUCTOS DE PLANTRONICS.
•Esta garantía le garantiza derechos legales concretos, a los que se pueden
añadir otros derechos que varían de un estado a otro. Para obtener información
completa sobre esta garantía limitada, incluidos los elementos no cubiertos,
póngase en contacto con el distribuidor o con el centro de mantenimiento de
Plantronics.
