Plantronics ML Series User manual

GET STARTED
ML Series Bluetooth® Headset

TAKE A GOOD LOOK
Be safe! Please read the
safety guide before
using your new headset.
MICRO USB CHARGING PORT
• Use with the AC wall charger:
1 hour before first use
2 hours (100% charge)
• Do not use headset while charging
VOLUME BUTTONS
• Volume: up/down (tap + or – buttons per
level change)
LED
• Charging (solid red)
• Low battery (3 red flashes at powering on)
• On a call (blue flash every 2 seconds)
• Missed call (purple flashes. Repeats
for 5 minutes or until cancelled).
• Pairing mode (repeating red/blue flashes)
CALL BUTTON
• Take a call or end it (1 tap)
• Redial (2 taps)
• Initiate phone’s voice-dialing
(2 second press until tone is heard)
• Reconnect lost Bluetooth connection
(1 tap if the headset doesn’t automatically
reconnect)
• Activate pairing mode after initial set up
(press until red/blue LED flashes)
• Cancel missed call LED (1 tap)
POWER SWITCH
• On (slide to reveal black)
• Off (slide to reveal red)

CONNECT TO YOUR PHONE
“Pairing” is the set-up process of
introducing your headset to your
phone.
Before using your headset for the
first time, you must pair it with
your Bluetooth-enabled phone.
Pairing is a one-time process
unless your phone loses the
connection or you want to pair a
new phone.
P LT_ M L X X
1. READY
Activate the Bluetooth feature on
your phone, then get phone to add
/ search / discover new Bluetooth
devices.
Phones Have Different Menus to
Select From:
iPhone: Settings > General >
Bluetooth > On (starts the search
for devices)
BlackBerry® smartphone:
Settings/options > Bluetooth: On >
Search for devices
VIDEO TUTORIAL FOR USA:
www.plantronics.com/pairing
2. SET
First Time, Right out of the Box:
With headset turned off, activate
Bluetooth pairing mode by sliding
Power switch on. The LED flashes
red/blue to indicate pairing mode.
Pairing New
Phone/Reconnecting Original:
With headset turned off, slide
Power switch on. Press and hold
the Call button until the LED
flashes red/blue.
3. CONNECT
Select “PLT_MLXX” from the list
of Bluetooth devices shown on
your phone.
If phone asks for a passcode,
enter four zeros (0000). You may
see **** on screen. Some phones
also ask to confirm headset
connection after pairing.
Headset LED will stop flashing
red/blue once successfully
paired/connected.
You can now make a call using
your phone’s keypad or
voice-dialing feature.

FIT EITHER EAR
2
1
Left ear Right ear

TIPS
Understand the Tones You Hear:
This headset beeps different tones to advise you on what it is
doing.
Usually, a high tone requires you to act (e.g. you lost the
Bluetooth connection or need to recharge battery) but a low
tone is just a reaction to you pressing a button (e.g. volume
changes, call start/end).
Stay Near Your Phone:
Bluetooth has a working “range” of up to 30 feet between the
phone and headset before audio degrades and the connec-
tion is lost.
Know How to Reconnect:
Your headset tries to reconnect a lost connection. If it can’t,
then tap the Call button once or manually reconnect via the
phone’s Bluetooth device menu.

SPECIFICATIONS
Talk Time Up to 7 hours
Standby Time Up to 8 days
Operating Distance (Range) Up to 33 feet (10 meters), Class II
Headset Weight 11.5 grams
Charge Connector Micro USB charging
Battery Type Rechargeable non-replaceable lithium ion polymer
Charge Time (Maximum) 90 minutes for full
Power Requirements 5V DC – 180mA
Bluetooth Version Bluetooth v2.0
Bluetooth Profiles Hands-Free (HFP) Profile 1.5 and Headset (HSP) Profile 1.1
Operating Temperature 32°F - 104°F (0 - 40°C)
Storage Temperature 32°F - 104°F (0 - 40°C)
Charging Temperature 32°F - 104°F (0 - 40°C)

NEED MORE HELP?
Don’t return to the store - call our friendly customer support
team at 1-866-363-2583 (USA) or visit plantronics.com/support
for local numbers outside the US.
© 2011 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark of
Bluetooth SIG, Inc. and any use by Plantronics is under license. All other trademarks
are the property of their respective owners.
U.S. Patents Pending. 85663-01 EN-US
