The TriStar delivers: ultralight weight, discreet style,
and a comfortable, custom t. Its unique three-point
design provides support behind, on top of, and in
the ear for extra stablity. Advanced materials make
TriStar incredibly light but still very durable.
TriStar Key Features
• Plantronicscompatibility. TriStar works with all
Plantronics audio processors and USB-to-headset
adapters. Direct-connect solutions are also available
for headset-ready phones and agent consoles,
providing connection exibility for your diverse
working environment.
• Exceptionallylightweight,over-the-earstyle.
Three-point design provides unsurpassed stability
and all-day comfort.
• Fouruser-selectableearbuds for a custom t.
• SupportsClearline™audiotechnology. Ensures
precise listening levels, sophisticated hearing
protection, and superior audio performance when
used with Plantronics audio processors.
• QuickDisconnect™lets you walk away from your
phone while still wearing your headset.
• 10-footcoilcord and adjustable clothing clip
for freedom of movement.
• AvailablewithVoiceTubeornoise-canceling
microphone:
Voice Tube—Plantronics’ trademark design; light
weight and unobtrusive, delivers great sound
quality in all but the noisiest environments.
Noise-canceling—Filters out background sounds
for heightened speech clarity.
• Canbewornoneitherear.
• Warranty:Twoyears for unsurpassed durability.
BackedbyPlantronicsglobal
service and support
TriStar®
OperatingFrequency: Standard Band
Headset Microphone: Noise-canceling or Voice Tube
Models/Weight: H81N Noise-canceling: 28 g
 H81 Voice Tube: 12 g
Compatibility: Plantronics Audio Processor
WearingStyles: Over-the-Ear
Limited Warranty: 2 years
Vista®M22AudioProcessor
The Vista M22 audio processor delivers
precise levels of listening comfort,
sophisticated hearing protection, and
superior audio performance. The Vista M22
includes Clearline™audio to improve call
quality in any environment, especially
wideband VoIP.
DA45™USBAudioProcessor
Compatible with all Plantronics H-series
headsets, this headset-to-USB adapter/
audio processor brings superior call clarity
to PC-based communications. The DA45
USB provides advanced audio technolo-
gies, plug-and-play connectivity, and Quick
Disconnect.
TriStar headsets require a Plantronics audio processor, USB audio
processor, or direct connect cable to connect to phone or PC.
Choice of ear buds
for customized t
Voice Tube
H81TriStar with Voice Tube
Three-way support for
a secure t
H81N TriStar with Noise-canceling
