Plantronics CS520 Series Instruction manual

Telephone
Network
Outlet
Plantronics Telephone
Interface Cable
Interquartz
IQ750 9 Adaptor
Savi Office (WO100, WO200, W700 etc) & OLI Connection Diagram for IQ750
IQ750
Savi Office
(WO100, WO200 etc) Mains
Power
Outlet
Interquartz
Line Cord
Interquartz Cable
Plantronics Cable
Set Configuration Switch to "A"
Plantronics
Base Power Supply
Mains
Power
Outlet
Set Desk Phone Speaking olume
to "1" and Desk Phone Listening
olume to "3"
5 August 2011
Plantronics
Lifter Power Cord
Step 4Step 5
Set olume Slider to
Recommended Setting Position
as shown
- OLUME +
Step 3
Set Headset Polarity Switch to "P"
Reversed headset
polarity
Normal headset
polarity
Step 1
HEADSET
MIC ADJUST
Step 2
Set Headset Mic Adjust Control
fully clockwise to Recommended
Setting Position as shown
HL10
Lifter
OLI
Interquartz
Handset Cord

Telephone
Network
Outlet
Plantronics Telephone
Interface Cable
Interquartz
IQ750 9 Adaptor
CS510, CS520, CS530, CS540 Series & OLI Connection Diagram for IQ750
IQ750
Mains
Power
Outlet
Interquartz
Line Cord
Interquartz Cable
Plantronics Cable
Plantronics
Base Power Supply
Mains
Power
Outlet
07 March 2012
Plantronics
Lifter Power Cord
CS510, CS520,
CS530, CS540 Series
Set olume Slider to
Recommended Setting Position
as shown
- OLUME +
Step 3
Set Headset Polarity Switch to "P"
Reversed headset
polarity
Normal headset
polarity
Step 1
HEADSET
MIC ADJUST
Step 2
Set Headset Mic Adjust Control
fully clockwise to Recommended
Setting Position as shown
HL10
Lifter
OLI
Interquartz
Handset Cord
Set Configuration Switch to "A"
Step 4
Set Desk Phone Speaking olume
to "3" and Desk Phone Listening
olume to "3"
Step 5
A
B
C
D
E
F
G
1 4
2 3
1
4
5
6
2
3

CS60 Connection Diagram for IQ750
CS60
Plantronics
Lifter Power Cord
IQ750
5 August 2011
Interquartz
Line Cord
Telephone
Network
Outlet
Interquartz
IQ750 9 Adaptor
Mains
Power
Outlet
Plantronics
Base Power Supply
Interquartz Cable
Plantronics Cable
Set Headset Polarity Switch to "P"
Reversed headset
polarity
Normal headset
polarity
Step 1
HEADSET
MIC ADJUST
Step 2
Set Headset Mic Adjust Control
fully clockwise to Recommended
Setting Position as shown
Speaking olume Minor Adjust
Press the lower button 7 times and then
the upper button 4 times
1
2
3
4
1
2
3
4
Step 5
Set Listening olume Major Adjust
Control to "3"
Step 6
OLI
HL10
Lifter
Plantronics
Telephone Cord
Interquartz
Handset Cord
Set Speaking olume Major Adjust
to "B"
Step 4
Set olume Slider to
Recommended Setting Position
as shown
- OLUME +
Step 3
Step 7
Rotary switch on headset
base to be set to
Position 1

CS351N/A, CS361N/A and OLI Connection Diagram for IQ750
CS351N/A and
CS361N/A
Plantronics
Lifter Power Cord
IQ750
5 August 2011
Interquartz
Line Cord
Telephone
Network
Outlet
Interquartz
IQ750 9 Adaptor
Mains
Power
Outlet
Plantronics
Base Power Supply
Interquartz Cable
Plantronics Cable
Set Headset Polarity Switch to "P"
Reversed headset
polarity
Normal headset
polarity
Step 1
Set olume Slider to
Recommended Setting Position
as shown
- OLUME +
Step 3
HEADSET
MIC ADJUST
Step 2
Set Headset Mic Adjust Control
fully clockwise to Recommended
Setting Position as shown
Speaking olume Minor Adjust
Press the lower button 7 times and then
the upper button 4 times
1
2
3
4
1
2
3
4
Step 5
Set Listening olume Major Adjust
Control to "3"
Step 6
OLI
HL10
Lifter
Plantronics
Telephone Cord
Interquartz
Handset Cord
Set Speaking olume Major Adjust
to "B"
Step 4
