pleasant hearth MARTIN OFW165S User manual

1
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m., CST, Monday – Friday.
ATTACH YOUR RECEIPT HERE
Serial Number ________________________________ Purchase Date _________________________________
30-10-016 Rev. 9/12
MARTIN FIRE PIT
MODEL #OFW165S
Español p. 7

2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
AMesh Wire Cover Assembly
Cooking Grid
Firebox
Base
Poker
1
1
1
1
1
B
C
D
E
F
C
D
E
B
A
A

3
HARDWARE CONTENTS
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
WARNINGS:
 •FOR OUTDOOR USE ONLY! Burning charcoal indoors can kill you. It gives off carbon
monoxide, which has no odor.
•NEVER LEAVE FIRE UNATTENDED!
•DO NOTallowchildrenorpetsneartherepitwithoutsupervision.
•DO NOTtouchsurfaceofironregrateorrebowlwhileinuse.
•NEVER burn in vehicles, tents or indoors. CARBON MONOXIDE HAZARD.
•Whentherepitisinuse,thehandleonthemeshscreencanreachextremetemperaturesthat
can cause serious injury to an unprotected hand. Use a poker or an appropriate heat resistant
glove or pad when handling.
•Toavoidmarringthenish,handlethesurfaceusingasoftclothinsteadofyourbarehands.
CAUTIONS:
 •Burnonlywood,charcoalorrelogsintherepit.
•DO NOTusegasolineorkerosenetostartthereinyourrepit.
•DO NOT use this unit on a wood deck, long or dry grass and/or leaves, or on combustible
surfaces.
•DO NOTattempttomovetherepitwhileitishotorinuse.
•Placetherepitnocloserthan8feetfromwallsorcombustiblesduringuse.
•Adequatereextinguishingmaterialshouldbereadilyavailable.
•Alwaysensurethatthemeshwirecoverissecuredoverrebowlwhileinuse.
•Pokerhandlemaybecomehotduringandafteruse.
•Useheat-resistantglovestohandlehottools.
CALIFORNIA PROPOSITION 65 WARNING: Fuels used in wood and charcoal burning appliances
and the products of combustion of such fuels, contain chemicals known to cause cancer, birth
defects or other reproductive harm.
Consumers should check State, Provincial, in addition to local codes and regulations regarding the
use of the product.
AA
M6 x 10 mm
Bolt
Qty. 8

4
PREPARATION
ASSEMBLY INSTRUCTIONS
Yourrepitisnowreadyforuse.
Keeppoker(E)nearrepitforuseanytime.
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents above. If any part is missing or damaged, do
not attempt to assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 15 minutes
Tools Required for Assembly: Phillips Screwdriver (not included).
Hardware Used
1
2
AA x 8
M6 x 10 mm
Bolt
C
AA
D
B
A
1. Attach rebox (C) to base (D) using
M6 x 10 mm (AA) bolt. Tighten with screwdriver.
2. Put cooking grid (B) into rebox, put mesh wire
cover assembly (A) into rebox.

5
ONE YEAR LIMITED FRAME WARRANTY
If within one year from the date of original purchase, this item fails due to a defect in material or
workmanship, we will replace or repair at our option, free of charge. To order parts or to obtain
warranty service, call 1-877-447-4768, 8:30 a.m. –4:30 p.m., CST, Monday – Friday. This warranty
does not cover defects resulting from improper or abnormal use, misuse, accident, or alteration.
Failure to follow all instructions in the owner’s manual will also void this warranty. The manufacturer
will not be liable for incidental or consequential damages, or common erosion of outdoor products.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation may not apply to you. This warranty gives you specic legal rights, and you may also
have other rights which vary from state to state.
GHPGroup,Inc.•8280AustinAvenue•MortonGrove,IL•60053
CARE AND MAINTENANCE
I
• To extend the life of your re pit, clean it after each use.
• To protect re pit nish, use a soft cloth to wipe re pit and poker.
• Do not attempt to clean while hot.
• Store in a cool, clean, dry place.

6
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:30 a.m. –4:30 p.m.,
CST, Monday – Friday.
30-10-016 Printed in China
F
C
B
D
E
A
A1
A2
A3
A4
PART DESCRIPTION PART #
A1
Handle 30-06-082
A2 Handle Base 30-06-083
A3
Mesh Wire Cover 30-06-084
A4 Nut 30-09-013
B Cooking Grid 30-06-085
C
Firebox 30-06-086
D Base 30-06-087
E
Poker 30-09-088
PART DESCRIPTION PART #
F
Hardware Kit 30-09-018

7
