Sunderland 12" Deep Bowl Fire Pit
MODEL #OFW110R/#OFW110R-1
Serial Number Purchase Date
ATTACH YOUR RECEIPT HERE
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m. CST, Monday – Friday, or
log on to [email protected]
Rev 2/14/14
30-10-033
™
Espanol p.9
Francais p.17

2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Handle 1
B Mesh Cover 1
C Cooking Grid 1
D Air Vents 3
E Outer Handle 4
F Fire Bowl 1
G Legs 4
H Poker 1
E
F
C
B
A
G
D
H

3
HARDWARE LIST
Please read and understand this entire manual before attempting to assemble, operate or install the
product. If you have any questions regarding the product, please call customer service at 1-877-447-
4768, 8:30 a.m. – 4:30 p.m. CST, Monday – Friday.
WARNINGS:
• FOR OUTDOOR USE ONLY! Burning wood or charcoal indoors can kill you. It gives off carbon
monoxide, which has no odor.
• NEVER LEAVE FIRE UNATTENDED!
• DO NOT allow children or pets near the re pit without supervision.
• DO NOT touch surface of re pit while in use.
• NEVER burn in vehicles, tents or indoors. CARBON MONOXIDE HAZARD.
•NEVER place a cover on the re pit when in use. Ensure the re pit and mesh cover have
cooled before placing a cover over the re pit.
• When the re pit is in use, the handle on the mesh cover can reach extreme temperatures that
can cause serious injury to an unprotected hand. Use a poker when handling.
CAUTIONS:
 •Burnonlywood,charcoalorrelogsintherepit.
 •DO NOTusegasolineorkerosnetostartthereinyourrepit.
•DO NOT use this unit on a wood deck, long or dry grass and/or leaves,
or on combustible surfaces.
 •DO NOTattempttomovetherepitwhileitishotorinuse.
 •Placetherepitnocloserthan8ft/2.4metersfromwallsorcombustiblesduringuse.
 •Adequatereextinguishingmaterialshouldbereadilyavailable.
 •Alwaysensurethatthemeshcoverissecuredoverrebowlwhileinuse.
 •Pokerhandlemaybecomehotduringandafteruse.
 •Useheat-resistantglovestohandlehottools.
 •DO NOTplaceoruserepitunderacanopyoftrees.
CALIFORNIA PROPOSITION 65 WARNING: Fuels used in wood and charcoal burning appliances and
the products of combustion of such fuels, contain chemicals known to cause cancer, birth defects or other
reproductive harm.
Consumers should check State and Provincial, in addition to local codes and regulations regarding the
use of the product.
SAFETY INFORMATION
M6x15mm
Bolt
Qty. 12
M6 Nut
Qty. 1
AA BB CC DD EE
M6x12mm
Bolt
Qty. 6 Threaded
Peg
Qty. 4
M6 Wrench
Qty. 1

4
PREPARATION
ASSEMBLY INSTRUCTIONS
1. Insert Handle (A) into hole in mesh cover (B)
and secure with M6 nut (BB).
Tighten nut with wrench (EE)
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents above. If any part is missing or damaged, do not attempt to
assemble the product. Contact customer service for replacement parts.
Estimated Assembly Time: 25 minutes
Tools Required for Assembly: Phillips Screwdriver (Not Included) and Wrench (Included)
EE
Hardware Used
BB M6 Nut x1
1
B
A
BB
EE M6 Wrench x1

5
ASSEMBLY INSTRUCTIONS
2. Assemble outer handle (E) by inserting the
male end of each outer handle (E) section into
the corresponding female end in order to make a
complete ring.
3.Placerebowl(F)onitssideonasmooth,
clean surface. Attach one air vent (D) by
insertingtwoM6x12mmbolts(CC)through
pre-drilledholesinrebowl(F)andairvents(D)
as illustrated. Repeat with remaining air vents (D)
Tighten all bolts with a screwdriver.
4.AttachLeg(G)totherebowl(F)byinserting
M6x15mmbolts(AA)throughpre-drilledholesin
rebowl(F)andleg(G)asillustrated.Tightenall
bolts with wrench (EE).
2
F
D
E
G
CC
AA
3
F
4
Hardware Used
CC M6x12mmBolt x6
Hardware Used
AA M6x15mmBolt x8
EE M6 Wrench x1

6
ASSEMBLY INSTRUCTIONS
5. Attach outer handle (E) to the top of the
legs(G)byinsertingfourM6x15mmbolts(AA)
through pre-drilled holes in handle (E) and legs
(G). Tighten securely with wrench (EE).
5
G
E
AA
Hardware Used
7. Forrepituse,topwithcookinggrid(C)and
meshcover(B).Placepoker(H)besiderepit
for use as needed.
7
B
H
AA M6x15mmBolt x4
6. Insertthreadedpegs(DD)intoedgeofre
bowl (F) as illustrated and hand tighten. 6DD
Hardware Used
DD Threaded Peg x4
EE M6 Wrench x1
F
C

7
CARE AND MAINTENANCE
•Toprotectrepitnish,useasoftclothinlieuofbarehandswhilehandling.
•Useasoftclothtowiperepitandpoker.
•Donotattempttocleanwhilehot.
•Storeinacool,clean,dryplace.
1-YEAR LIMITED FRAME WARRANTY
If within one year from the date of original purchase, this item fails due to a defect in material or
workmanship, we will replace or repair at our option, free of charge. To order parts or to obtain
warrantyservice,call1-877-447-4786,Monday-Friday,8:30a.m.-4:30p.m.CST.Thiswarranty
does not cover defects resulting from improper or abnormal use, misuse, accident, or alteration.
Failure to follow all instructions in the owner's manual will also void this warrranty. The
manufacturer will not be liable for incidental or consequential damages, or common erosion of
outdoorproducts.Somestatesdonotallowtheexclusionorlimitationofincidentalor
consequential damages, so the above limitation may not apply to you. This warranty gives you
speciclegalrights,andyoumayalsohaveotherrightswhichvaryfromstatetostate.
GHP Group, Inc.
6440 W. Howard St.
Niles, IL 60714-3302
877-447-4768

8
E
F
C
B
A
G
D
H
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m.,
CST, Monday – Friday.
PART DESCRIPTION PART #
A Handle 30-06-173
B Mesh Cover 30-06-174
C Cooking Grid 30-06-223
D Air Vents 30-06-177
E Outer Handle 30-06-176
 F FireBowl 30-06-175
 G Legs 30-06-178
H Poker 30-06-179
DESCRIPTION PART #
Hardware Pack 30-09-094
Printed in China
