Podab ProLine FC 20 Guide

Drying cabinet ProLine FC 20
Service manual and spare parts list

2
©PODAB 2015
Thank you for choosing drying cabinet FC 20. We hope that it will
be of great use for you.

3®PODAB 2015
Contents
Specification 4
Dimensions 4
Technical information 4
Main control board 5
Setup menu 5
Parameter list 6
Explanation of parameters 6
Error codes 8
Spare parts list 9
Cabinet 9
Top 10
Electrical drawing 11

4
©PODAB 2015
Dimensions
Specification
900
250
790
R768
1955
1800 800
200
Technical information
Loading capacity, number of suits 6
Evacuated air, max, m³/h 600
Heating effect, kW 12,0
Total effect, kW 12,45
Membrane Cotton wool
Drying capacity, g/min * 55 45
Drying time, min * 175 65
Energy consumption, kWh/kg 0,98 0,34
Part No 131035
*Drying of 20 kg fire suits (dry weight) washed and high-spinned to 50 %
residual moisture for membrane suits and 15 % for cotton wool suits. Dried to
4 % residual moisture.
(mm)

5®PODAB 2015
The drying cabinet can be customized by adjusting the main
control board´s parameters. The following pages describe how
to adjust the parameters.
Setup menu
Activate the setup menu
To enter the setup menu; press both the ”P” button and the
”+” button for about 5 seconds until the screen shows ”SETUP
MENU FC20”. Push the START button, 5 times continuously, to
enter the parameter list.
Navigate the setup menu
The parameter names are shown on row 1 and 2 on the screen.
The value is shown on the bottom row. Use the ”P” button to
browse in the parameter list.
Change parameter values
The ”+” button increases a numeric value and is used for togg-
ling ON/OFF functions. The hidden button between the ”P” but-
ton and the ”+” button can be used to decrease numeric values.
Leave the setup menu
To leave the menu, push the ”START” button.
5 times
5 seconds
Main control board

6
©PODAB 2015
Parameter Alternative Factory position
SOFTWARE VERSION - [version name]
RESET YES -
TEMPERATURE PR1 50-90 80
TEMPERATURE PR2 50-90 80
TEMPERATURE PR3 50-90 60
TEMPERATURE PR4 50-90 80
TEMPERATURE
REACTIVATION 50-90 80
HYSTERESIS 1-10 10
HYSTERES
REACTIVATION 1-10 3
COOL DOWN 5-15 15
∆F STOP
AUTOMATIC DRYING -50 % -> +50 % 0
MEMBRANE PR1 ON/OFF ON
WITHOUT MEMBRANE
PR2 ON/OFF ON
STATIONWEAR PR3 ON/OFF ON
TIMED DRYING PR4 ON/OFF ON
REACTIVATION TIME PR1 0:00h-1:00h 0:30h
REACTIVATION TIME PR2 0:00h-1:00h 0:30h
REACTIVATION TIME PR3 0:00h-1:00h 0:00h
MAXIMUM TIME 0:30h-10:00h 5:00h
DELAY START ON/OFF OFF
CHILD LOCK ON/OFF OFF
SOUND ON/OFF ON
LOGOTYPE ON/OFF ON
LANGUAGE SVENSKA/NORSK/DANSK/
ENGLISH/FRANCAIS/
DEUTSCH/ESPAÑOL
ENGLISH
COIN ON/OFF OFF
COIN SIGNAL TYPE NORMALLY OPENED/NOR-
MALLY CLOSED/PULSE NORMALLY OPENED
OPERATING HOURS - 00000h
ERROR LOG - EMPTY
Parameter list
SOFTWARE VERSION
The name of the installed software file is shown.
RESET
Only shown if any parameter’s default value has been changed.
If option ”YES” is pushed, all the parameters are reset to their
factory position.
TEMPERATURE PR1
Setting of the drying temperature for program MEMBRANE.
TEMPERATURE PR2
Setting of the drying temperature for program WITHOUT MEM-
BRANE.
TEMPERATURE PR3
Setting of the drying temperature for program STATIONWEAR.
TEMPERATURE PR4
Setting of the drying temperature for program TIMED DRYING.
TEMPERATURE REACTIVATION
Setting of the drying temperature for the reactivation phase.
During this phase the evacuation fan is swithed off. The tem-
perature inside the cabinet increases in order to improve the
hardening of impregnation solvents.
HYSTERESIS
Controls the hysteresis. FC 20 is preset to 10 ºC. When the
working temperature is attained the heating elements are
turned off. When the temperature has dropped 10 ºC the heat-
ing starts again.
HYSTERESIS REACTIVATION
Controls the hysteresis during the reactivation phase.
COOL DOWN
After the heating phase and the reactivation phase (if activated)
the cabinet has a period of cool down to recondition the laun-
dry and lower the temperature within the cabinet.
∆F STOP AUTOMATIC DRYING
Adjusts the automatic drying function. Can be changed if
needed. If the value is decreased (negative %-value), the drying
time is prolonged for all automatic programs.
MEMBRANE PR1
Turns the MEMBRANE program ON/OFF in user mode.
WITHOUT MEMBRANE PR2
Turns the WITHOUT MEMBRANE program ON/OFF in user
mode.
STATIONWEAR PR3
Turns the STATIONWEAR program ON/OFF in user mode.
Explanation of parameters

7®PODAB 2015
TIMED DRYING PR4
Turns the TIMED DRYING program ON/OFF in user mode.
REACTIVATION TIME PR1
Decides the duration of the reactivation phase for program
MEMBRANE. If the time is set to 0:00h the program skips to
cool down immediately after the drying phase is finished.
REACTIVATION TIME PR2
Decides the duration of the reactivation phase for program
WITHOUT MEMBRANE. If the time is set to 0:00h the program
skips to cool down immediately after the drying phase is finis-
hed.
REACTIVATION TIME PR3
Decides the duration of the reactivation phase for program STA-
TIONWEAR. If the time is set to 0:00h the program skips to cool
down immediately after the drying phase is finished.
MAXIMUM TIME
Controls the maximum time that can be set at timed drying.
The parameter also controls the maximum drying time for the
automatic programs.
DELAY START
This parameter activates delayed start. If the parameter is set
to ”ON” the user is given the choice to delay the program start
with up to 24:00h.
CHILD LOCK
It is possible to activate a child lock function. When set to ”ON”
the user has to press and hold the ”P” button while pushing
start.
SOUND
In mode “ON” there is a beep sound every time an active button
is pushed or when a drying program is finished.
LOGOTYPE
Turns the PODAB-logo, shown on the welcome screen, ON/
OFF.
LANGUAGE
The cabinet has seven languages.
COIN
The cabinet can be connected to a booking system. To activate
the function, set the parameter in position “ON”. To start a pro-
gram a signal to the COIN plinth is needed.
COIN SIGNAL TYPE
This parameter is only visible if COIN is activated. COIN is used
when the cabinet is connected to a booking system. Choose
position depending on which type of signal the booking system
is sending.
NORMALLY OPENED should be chosen when there is a signal
to the COIN plinth when the cabinet has been booked. A run-
ning program will finish even if the signal is interrupted.
NORMALLY CLOSED should be chosen when there is a signal
to the COIN plinth when the cabinet has not been booked.
PULSE means that the cabinet is booked per drying period.
One pulse gives one drying period.
OPERATING HOURS
The parameter shows the total amount of hours the cabinet has
been running. Saved on the memory unit even if the power to
the control board is cut.
ERROR LOG
Error messages are memorized in a log. If the log is empty the
screen shows the text ”EMPTY”. If there are messages that
have been logged it is possible to toggle with the P button.
When all errors have been displayed the log can be cleared.

8
©PODAB 2015
Error messages
TEMP SENSOR FAILURE
The control board gets no signal from the temperature sensor.
The cabinet is out of function until the error is solved. Check if
the sensor is connected correctly on the main control board,
and that the cable from the sensor to the board is intact.
MAX TEMP REACHED
If the temperature registered by the temperature sensor rises
above 100°C a cool down period starts. The heat is reactivated
when the temperature has dropped to 50°C.
OVERHEATING
The control board’s electronically overheat protection has been
activated. The error code is generated if the temperature reg-
istered by the temperature sensor rises above 100ºC, twice
within 30 minutes.
Control that the fan motors are working as they should. Also
control the temperature sensor and that the cable from the
board is intact.
MAX TIME REACHED
This code is generated if the maximum drying time of 5h (de-
fault) is reached. The drying time can exceed the limit if the
cabinet is over loaded or if the textiles has a very high residual
moisture level when the program starts. If desired the maximum
time can be adjusted.
HUMIDITY SENSOR
Control board gets no signal from the temperature sensor. Con-
trol that the sensor is connected correctly on the main control
board and that the cable from the sensor to the board is intact

9®PODAB 2015
Cabinet
No Part No Description
1TS61053 Door left
2TS61054 Door right
3TS 61086 Handle
4TS61055 Hanger frame left
5TS61056 Hanger frame right
6TS61057 Hanger
7TS61058 Service door (middle fan)
8TS 61081 Lamp
970107001 Door switch
10 011071 Sticker user instructions
11 0110166 Keypad
12 0110161 Display control board
13 TS61094 Foot
Spare parts list
Detailed view A

5

11 ®PODAB 2015
Electrical drawing
