Podab ProLine TS 93 E User manual

Drying cabinet ProLine TS 93 E
Installation and operation manual

2
©PODAB 2017
Thank you for choosing the drying cabinet TS 93 E from PODAB.
We hope that it will be of great use for you and ask you kindly to
read the instructions carefully.
FOR YOUR SAFETY, the information in this manual must be followed to prevent property damage and personal injury.
NOTE: The paragraphs marked “WARNING” and “CAUTION” appearing in this manual are not meant to cover all possible
conditions and situations that may occur. It is very important that water and electricity are handled with great care and
respect, by both installation technicians and end users.

3©PODAB 2017
Contents
Safety regulations 4
Important safety instructions 5
Specification 6
Dimensions 6
Technical information 6
Assembly instructions 7
Installation of the cabinet 22
Step 1: Put the cabinet in place 22
Step 2: Fasten the cabinet to the wall 22
Step 3: Connect the cabinet to the ventilation channel 22
Step 4: Connect the drying cabinet to the main switch 22
Step 5: Control that the heating relay is working 22
Requirements for ventilation 23
Ventilation channel – choice of material 23
Requirements for incoming air 23
Ventilation channel – design 23
Evacuated amount of air and pressure fall 24
User manual 25
Automatic programs 25
Select drying time manually 25
Gentle drying 25
Maintenance 26
Take good care of the cabinet 26
Ventilation system 26
Keep your cabinet efficient and economical 26

4
©PODAB 2017
Safety regulations
WARNING
Indicates hazardous situation that, if not avoided, could cause
severe personal injury.
CAUTION
Indicates hazardous situation that, if not avoided, could cause
minor personal injury or property damage.
You will also find precautions marked: IMPORTANT and NOTE.
These are followed by information of what should be consid-
ered.
IMPORTANT: to inform the reader of special steps that must
be taken in order to prevent injuries on the cabinet.
NOTE: to inform what is important to know, but it cannot
cause personal injuries or injury on the cabinet.
Throughout this manual you will find text warnings in text box-
es: “WARNING” and “CAUTION”. In these boxes you’ll find the
safety measurements you’ll have to take; end user, service staff
or installation staff.

5©PODAB 2017
1. Read the instruction before using the drying cabinet.
2. Follow the installation instructions for proper electrical
connection.
3. Never dry textiles that have been washed, dipped or ex-
posed to fire dangerous substances or fluids.
4. Never add fire dangerous or explosives substances to the
cabinet.
5. The cabinet is not a toy. Look after children who are around
the cabinet.
6. Never connect the cabinet with an extension cable.
7. Only use the cabinet for what it is designed for: drying
clothes.
8. Always turn off the main switch before performing any ser-
vice on the cabinet. Only authorized service technicians
should perform service.
9. Always follow the installation manual. The electrical con-
nections must be installed by authorized personnel.
10. Keep after the cabinet. If it is exposed to violence there is a
risk that certain security functions will stop working. Please
contact your nearest service partner if you are unsure of
the cabinet’s status.
11. If the electrical cable is damaged, it must immediately be
changed by a person with electrical authorization.
12. The doors shall always be shut when the cabinet is in use.
Do not try to manipulate the lock of the doors. It can lead
to personal injuries. If the cabinet does not stop when the
doors are opened during the drying phase, call for service.
The cabinet shall not be used if the drying programme is
active when the doors are open!
13. Look after the area around the evacuating pipe so it is
clean from dust and dirt.
14. To get the best drying result, follow the garments washing
and drying advice.
15. Never use the cabinet if any panel is broken or removed.
16. Never use the cabinet if any parts are broken or if the inside
is broken.
17. Never try to manipulate or connect past any safety func-
tions.
18. If the cabinet is not assembled after the manufacturer’s
instructions, there is a risk that the cabinet can cause per-
sonal injuries or injuries on property.
WARNING
To minimize the risk of fire, electrical shock, personal injuries
or death when the cabinet is in use the following precautions
must be followed:
Important safety instructions

6
©PODAB 2017
Dimensions
Specifications
250
900
1392
788
1955
1800 800
200
Technical information
Loading capacity, kg/lbs up to 16/35,2
Drying capacity, g/min * 81
Hanging length, m 32
Drying time, min * 64
Evacuated air, max, m³/h 550
Heating effect, kW 9
Total effect, kW 9,4
Fuse, A 16
Energy consumption, kWh * 6,4
Part No 131034
*Drying of 12 kg cotton (dry weight), washed and high-spinned to 43% residual
moisture. 15 minutes cool down excluded. Dried to 0% residual moisture.

7©PODAB 2017
Tools
You need the following tools to easily install the drying cabinet,
TS 93 E:
• Cordless screwdriver
• Wrench
• Hex key 3 and 5 mm
• Level
• Torx screwdriver bit no. 25
Assembly instructions

8
©PODAB 2017
2
6x
3
1
4x

9©PODAB 2017
4
5
5x
4x
5x
6 (repeat step 3-5)

10
©PODAB 2017
9
1x
6x
8
7
3x
1x
1x

11 ©PODAB 2017
11
10
12
6x
1x
1x

12
©PODAB 2017
15
14
1x
3x
1x
3x
13
1x

13 ©PODAB 2017
16
13x
13x
18
17
1x
1x
1x

14
©PODAB 2017
19
20
2x
21
6x
4x

15
©PODAB 2017
22
6x
24
23

16
©PODAB 2017
27
25
26
3x

17
©PODAB 2017
30
28
29
3x
4x
6x

18
©PODAB 2017
31 Connect the cables
32
Reläkort
2x
Light (LIGHT)
Relay board
Humidity sensor
(HUMIDITY) Control board
Temp sensor
(NTC1)
Relay board
(X11)
Door switch
(DOOR)

19
©PODAB 2017
34
4x
4x
35
33
7x
35 Nm

20
©PODAB 2017
37
36
4x
8x
AB
D
C
38
