Podab ProLine FC 20 Guide

Drying cabinet ProLine FC 20
Service manual and spare parts list

2
© PODAB Group 2023
Thank you for choosing drying cabinet FC 20. We hope that it will
be of great use for you.

3© PODAB Group 2023
Contents
Specification 4
Dimensions 4
Technical information 4
Main control board 5
Setup menu 5
Parameter list 6
Explanation of parameters 6
Error codes 8
Spare parts list 9
Cabinet 9
Top 10
Electrical drawing 11

4
© PODAB Group 2023
Specification
Dimensions
(mm)
900
250
790
R768
1955
1800 800
200
Technical information FC 20
Main data
Capacity, complete re suits 6
Maximum air ow (at 0 pressure), cfm / m³/h 383 / 650
Drying program Membrane Cotton wool
Drying capacity, oz/min / g/min 2 / 55 1.6 / 46
Drying time, min * 215 87
Energy consumption, kWh 19.6 6.8
*Drying of 20 kg / 44 lbs re suits (dry weight) washed and high-
spinned to 5o % residual moisture for membrane suits and 15 %
for cotton wool suits. Dried to 4 % residual moisture.
Electrical connection - standard 208-240 V, 3P, 60Hz
Breaker, A, 3P 40
Heating effect, kW 12
Total effect, kW 12.5
Electrical connection - optional 208-240 V, 1P, 60Hz
Breaker, A, 1P 70
Heating effect, kW 12
Total effect, kW 12.5
Measurements shown in millimeter (mm).

5© PODAB Group 2023
Main control board
The drying cabinet can be customized by adjusting the main
control board´s parameters. The following pages describe how
to adjust the parameters.
Setup menu
Activate the setup menu
To enter the setup menu; press both the ”P” button and the
”+” button for about 5 seconds until the screen shows ”SETUP
MENU FC20”. Push the START button, 5 times continuously, to
enter the parameter list.
Navigate the setup menu
The parameter names are shown on row 1 and 2 on the screen.
The value is shown on the bottom row. Use the ”P” button to
browse in the parameter list.
Change parameter values
The ”+” button increases a numeric value and is used for tog-
gling ON/OFF functions. The hidden button between the ”P”
button and the ”+” button can be used to decrease numeric
values.
Leave the setup menu
To leave the menu, push the ”START” button.
5 x
5 sec

6
© PODAB Group 2023
Parameter list
SOFTWARE VERSION
The name of the installed software le is shown.
RESET
Only shown if any parameter’s default value has been changed.
If option ”YES” is pushed, all the parameters are reset to their
factory position.
TEMPERATURE PR1
Setting of the drying temperature for program MEMBRANE.
TEMPERATURE PR2
Setting of the drying temperature for program WITHOUT MEM-
BRANE.
TEMPERATURE PR3
Setting of the drying temperature for program STATIONWEAR.
TEMPERATURE PR4
Setting of the drying temperature for program TIMED DRYING.
TEMPERATURE REACTIVATION
Setting of the drying temperature for the reactivation phase.
During this phase the evacuation fan is swithed off. The tempe-
rature inside the cabinet increases in order to improve the
hardening of impregnation solvents.
HYSTERESIS
Controls the hysteresis. FC 20 is preset to 50 °F /10 ºC. When
the working temperature is attained the heating elements are
turned off. When the temperature has dropped 50 °F /10 ºC the
heating starts again.
HYSTERESIS REACTIVATION
Controls the hysteresis during the reactivation phase.
COOL DOWN
After the heating phase and the reactivation phase (if activated)
the cabinet has a period of cool down to recondition the laundry
and lower the temperature within the cabinet.
ΔF STOP AUTOMATIC DRYING
Adjusts the automatic drying function. Can be changed if
needed. If the value is decreased (negative %-value), the drying
time is prolonged for all automatic programs.
MEMBRANE PR1
Turns the MEMBRANE program ON/OFF in user mode.
WITHOUT MEMBRANE PR2
Turns the WITHOUT MEMBRANE program ON/OFF in user
mode.
STATIONWEAR PR3
Turns the STATIONWEAR program ON/OFF in user mode.
Explanation of parameters
Parameter Alternative Factory position
SOFTWARE VERSION - [version name]
RESET YES -
STANDBY ON/OFF ON
TEMPERATURE PR1 86-176°F / 30-80°C 176°F / 80°C
TEMPERATURE PR2 86-176°F / 30-80°C 176°F / 80°C
TEMPERATURE PR3 86-176°F / 30-80°C 140°F / 60°C
TEMPERATURE PR4 86-176°F / 30-80°C 176°F / 80°C
TEMPERATURE
REACTIVATION 86-176°F / 30-80°C 176°F / 80°C
HYSTERESIS 34-50°F / 1-10°C 50°F / 10°C
HYSTERESIS
REACTIVATION 34-50°F / 1-10°C 37°F / 3°C
COOL DOWN 41-59°F / 5-15°C °F / 15°C
ΔF STOP
AUTOMATIC DRYING -50 % -> +50 % 0
MEMBRANE PR1 ON/OFF ON
WITHOUT MEMBRANE
PR2 ON/OFF ON
STATIONWEAR PR3 ON/OFF ON
TIMED DRYING PR4 ON/OFF ON
REACTIVATION TIME
PR 1 0:00h-1:00h 0:30h
REACTIVATION TIME
PR2 0:00h-1:00h 0:30h
REACTIVATION TIME
PR3 0:00h-1:00h 0:00h
MAXIMUM TIME 0:30h-10:00h 5:00h
DELAY START ON/OFF OFF
CHILD LOCK ON/OFF OFF
SOUND ON/OFF ON
LOGOTYPE ON/OFF ON
LANGUAGE SVENSKA/NORSK/DANSK/
ENGLISH/FRANCAIS/
DEUTSCH/ESPAÑOL/SUOMI
ENGLISH
COIN ON/OFF OFF
COIN SIGNAL TYPE NORMALLY OPENED/
NORMALLY CLOSED/PULSE NORMALLY OPENED
OPERATING HOURS - 00000h
ERROR LOG - EMPTY

7© PODAB Group 2023
TIMED DRYING PR4
Turns the TIMED DRYING program ON/OFF in user mode.
REACTIVATION TIME PR1
Decides the duration of the reactivation phase for program
MEMBRANE. If the time is set to 0:00h the program skips to
cool down immediately after the drying phase is nished.
REACTIVATION TIME PR2
Decides the duration of the reactivation phase for program
WITHOUT MEMBRANE. If the time is set to 0:00h the program
skips to cool down immediately after the drying phase is nis-
hed.
REACTIVATION TIME PR3
Decides the duration of the reactivation phase for program STA-
TIONWEAR. If the time is set to 0:00h the program skips to cool
down immediately after the drying phase is nished.
MAXIMUM TIME
Controls the maximum time that can be set at timed drying.
The parameter also controls the maximum drying time for the
automatic programs.
DELAY START
This parameter activates delayed start. If the parameter is set
to ”ON” the user is given the choice to delay the program start
with up to 24:00h.
CHILD LOCK
It is possible to activate a child lock function. When set to ”ON”
the user has to press and hold the ”P” button while pushing
start.
SOUND
In mode “ON” there is a beep sound every time an active button
is pushed or when a drying program is nished.
LOGOTYPE
Turns the PODAB-logo, shown on the welcome screen, ON/
OFF.
LANGUAGE
The cabinet has seven languages.
COIN
The cabinet can be connected to a booking system. To activate
the function, set the parameter in position “ON”. To start a pro-
gram a signal to the COIN plinth is needed.
COIN SIGNAL TYPE
This parameter is only visible if COIN is activated. COIN is used
when the cabinet is connected to a booking system. Choose
position depending on which type of signal the booking system
is sending.
NORMALLY OPENED should be chosen when there is a signal
to the COIN plinth when the cabinet has been booked. A run-
ning program will nish even if the signal is interrupted.
NORMALLY CLOSED should be chosen when there is a signal
to the COIN plinth when the cabinet has not been booked.
PULSE means that the cabinet is booked per drying period.
One pulse gives one drying period.
OPERATING HOURS
The parameter shows the total amount of hours the cabinet has
been running. Saved on the memory unit even if the power to
the control board is cut.
ERROR LOG
Error messages are memorized in a log. If the log is empty the
screen shows the text ”EMPTY”. If there are messages that
have been logged it is possible to toggle with the P button.
When all errors have been displayed the log can be cleared.

8
© PODAB Group 2023
Error messages
TEMP SENSOR FAILURE
The control board gets no signal from the temperature sensor. The
cabinet is out of function until the error is solved. Check if the sen-
sor is connected correctly on the main control board, and that the
cable from the sensor to the board is intact.
MAX TEMP REACHED
If the temperature registered by the temperature sensor rises
above 212 °F / 100°C a cool down period starts. The heat is re-
activated when the temperature has dropped to 122 °F / 50°C.
OVERHEATING
The control board’s electronically overheat protection has been
activated. The error code is generated if the temperature reg-
istered by the temperature sensor rises above 212 °F / 100ºC,
twice within 30 minutes.
Control that the fan motors are working as they should. Also
control the temperature sensor and that the cable from the
board is intact.
MAX TIME REACHED
This code is generated if the maximum drying time of 5h (de-
fault) is reached. The drying time can exceed the limit if the
cabinet is over loaded or if the textiles has a very high residual
moisture level when the program starts. If desired the maximum
time can be adjusted.
HUMIDITY SENSOR
Control board gets no signal from the temperature sensor. Con-
trol that the sensor is connected correctly on the main control
board and that the cable from the sensor to the board is intact.

9© PODAB Group 2023
Spare parts list
Cabinet
No Part No Description
1TS61053 Door left
2TS61054 Dor right
3TS 61086 Handle
4TS61055 Hanger frame left
5TS61056 Hanger frame right
6TS61057 Hanger
7TS61058 Service door (middle fan)
8TS 61081 Lamp
970107001 Door switch
10 011070 Sticker user instructions
11 0110166 Keypad
12 0110161 Display control board
13 TS61094 Foot
9®PODAB 2015
Liste des pièces détachées
Armoire
No Pièce no Description
1TS61053 Porte gauche
2TS61054 Porte droite
3TS 61086 Poignée
4TS61055 Support pour cintres gauche
5TS61056 Support pour cintres droit
6TS61057 Cintre
7TS61058 Porte de service (ventilateur du
milieu)
8TS 61081 Lampe
970107001 Commutateur de porte
10 011070 Autocollant: instructions
utilisateur
11 0110166 Clavier
12 0110161 Tableau de commande
13 TS61094 Pied
Vue détaillée A
Detailed view A

10
© PODAB Group 2023
No Part No Description
1TS 61080 Heater 2000 W
2E 150020 Fan motor
3TS61028 Overheat protection 320°F/160°C
4TS61052 Front panel
5TS61062 Contactor LC1-K0610M72
60110160 Relay board
70110174 Humidity sensor
8TS 61083 Condensator
90110165 Temperature sensor
Top

11 © PODAB Group 2023
Electric drawing
KF2
K4 B1
KF3
K3 K2
K1
M1 M3 KF1 M2
Capacitor 2
Fan contactor 2 Fan contactor 1
Heat contactor 2 Heat contactor 1 Door switch 1
Capacitor 3 Fan motor 1 Capacitor 1 Fan motor 3
Fan motor 2
R1-3
K1
1 2
3 4
5 6
13
14
15
R4-6
L1
M1
K2
5 6
1 2
3 4
16
17
18
N
KF1
12
K3 1
2
R1-R3 R4-R6 KK T2 T1 NTC1 B2 X2 H1 X1
Circuit board Over heat protection 2 Over heat protection 1 Heat element 4-6 Heat element 1-3 Thermostat Humidity sensor Lamp 2 Lamp 1 Door switch 2
HEATER 2
160 C
2
1
HEATER 1
L1
M3
L1
M2
KF3
N
KF2
N
X1
X2
26
LAMP
25
27
24
MAIN
1 2
3
K4
K1 A2
A1
2
1
7
KK
8
9
160 C
T1
DOOR
FAN2FAN1
NTC1
+ -
H1 1
2
NTC1 CN2
B1 B2
K4 A2
A1
K3 A2
A1
K2 A2
A1
6
T2
10
23
2
28
29
13 14 13 14
30
I0531200-3
3~ 400V N 50/60Hz
20
L3 L2 L1 N
1 19
22
21
5

PODAB Group, 1330 Main Street , Floor 2
Sarasota, FL 34236, USA
[email protected]
www.podab.us
[phone]
Copyright © 2023 PODAB Group, All rights reserved.
Subject to change without notice.
Product Number: 131035
SERVICE/SUPPORT
Email: [email protected]
www.podab.us
