POLLOGEN Intelligent Biology STOP X User manual

1
USER MANUAL
A HOME-USE DEVICE FOR TREATMENT
OF MILD TO MODERATE FACIAL WRINKLES
STOP X
MODEL: STOP U

2
TABLE OF CONTENTS
1. WHAT IS THE STOP X? 6
2. WHO CAN BENEFIT FROM STOP X TREATMENTS? 6
3. CONTRAINDICATIONS AND SAFETY INFORMATION 7
• CONTRAINDICATIONS 7
• WARNINGS 8
• PRECAUTIONS AND SAFETY INSTRUCTIONS 9
• FIRE HAZARDS 9
4. WHAT’S INSIDE THE STOP X BOX 10
5. GETTING TO KNOW YOUR STOP X DEVICE 11
• TREATMENT HEAD 11
• CONTROL PANEL 11
• POWER SUPPLY 12
• STOP PREPARATION GEL 12

3
6. STOP X TREATMENT PROCEDURE 13
• HOW OFTEN TO USE YOUR STOP X 13
• TREATMENT SAFETY GUIDELINES 13
• FIRST TIME USE 13
• BEFORE STARTING 14
• HOW TO APPLY STOP PREPARATION GEL 14
• HOW TO CONNECT THE POWER SUPPLY AND START THE DEVICE 15
• TREATMENT PROCEDURE 16
7. CLEANING AND STORAGE 18
8. TROUBLESHOOTING 18
9. TECHNICAL SPECIFICATIONS 19
10. SYMBOLS AND LABELS GLOSSARY 20
11. CUSTOMER SUPPORT 21
12. WARRANTY TERMS 21
13. APPENDIX I – WRINKLE FORMATION 22
14. APPENDIX II – CLINICAL TRIAL 22
15. APPENDIX III – OUTPUT POWER VS. LOAD RESISTANCE 23
16. APPENDIX IV – ELECTROMAGNETIC COMPATIBILITY 24
1. WHAT IS THE STOP X? 6
2. WHO CAN BENEFIT FROM STOP X TREATMENTS? 6
3. CONTRAINDICATIONS AND SAFETY INFORMATION 7
• CONTRAINDICATIONS 7
• WARNINGS 8
• PRECAUTIONS AND SAFETY INSTRUCTIONS 9
• FIRE HAZARDS 9
4. WHAT’S INSIDE THE STOP X BOX 10
5. GETTING TO KNOW YOUR STOP X DEVICE 11
• TREATMENT HEAD 11
• CONTROL PANEL 11
• POWER SUPPLY 12
• STOP PREPARATION GEL 12

4
1. WHAT IS THE STOP X?
Use the STOP X at home to help reduce the appearance of mild to moderate
facial wrinkles.
STOP X uses a mild energy source that heats the skin and treats the wrinkles.
Indications for Use:
The STOP X device is intended for use in the non-invasive treatment of
mild to moderate facial wrinkles for adult users who have Fitzpatrick
Skin Types II-IV*.
* See section 3 for contraindications and safety information.
The STOP X device is a radio frequency (RF) device, based on the well-
established TriPollar
®
technology. The technology is based on four electrodes
designed to transmit thermal (heat) energy into the deep layers of the skin,
in order to trigger collagen remodeling that will reduce the appearance of
wrinkles and improve your skin tone and texture. TriPollar®Radio Frequency
technology combines the delivery of controlled heat deep into the skin, while
preserving the external layer - the epidermis.

5
3. CONTRAINDICATIONS AND SAFETY INFORMATION
2. WHO CAN BENEFIT FROM STOP X TREATMENTS?
CONTRAINDICATIONS
Do not use the STOP X if you have any of the following:
• An implanted pacemaker, arrhythmias, or any other severe known heart
disorder. Flow of electrical energy through the body may damage the
pacemaker and cause dangerous heart arrhythmias.
• An implantable metal device or body piercing in the treatment area. Flow
of electrical energy through the implanted metal may heat the object and
cause burns.
• You currently have or have had a history of cancer or pre-cancerous moles.
• You currently have diseases such as heart problems, autoimmune disorders,
Adults who have mild to moderate facial wrinkles and want to decrease
them using a home device.
FIG.1 Who can benefit from STOP X treatments
Mild
Wrinkles
Moderate
Wrinkles
Severe
Wrinkles

6
cancer and use of immunosuppressive medications.
• You have skin problems or irritations on your face.
• You are under 21 years of age.
• You are allergic to glycerin.
• Suffer from autoimmune disorders or diabetes.
• Currently using or used isotretinoin (Accutane) within the past six months.
Using this device after using isotretinoin can cause severe scarring or more
serious injury to your skin.
• Have Fitzpatrick skin type I (light, pale white skin) or V (brown, dark brown)
or VI (very dark brown, black). The safety and effectiveness of the device
when used in individuals with pale skin (type I) or darker skin (types V or
VI) or may be prone to skin discoloration has not been established (See
Fitzpatrick Scale - FIG.2).
The Device should be used only for skin types 2,3,4.
Type 1
Light, pale
white
Always burns,
never tans
Type 2
White, fair
Usually burns,
tans with
difficulty
Type 3
Medium
white to olive
Burns mildly,
tans gradually
Type 4
Olive, mid
brown
Rarely burns,
tans with
ease
Type 5
Brown, dark
brown
Very rarely
burns, tans
very easily
Type 6
Very dark
brown, black
Never burns,
tans very
easily
FIG.2 Fitzpatrick Scale
NO NO NO YES YES YES

7
Precaution is required before using the device if any of the following
relate to you:
• You use medications or cosmetic products that may cause fragile or dry
skin.
• You currently have or have had in the past cold sores (Herpes) or other
conditions sensitive to heat.
• You recently had any facial aesthetic procedure, such as fillers, Botox,
skin peeling or other wrinkle treatments.
Skin healing in these cases may be impaired:
• Lesions on the treatment area.
• Blood clotting disorders.
• Use of blood thinning medications.
Safety and effectiveness of the device was not tested in the following
conditions or anatomical locations; therefore, DO NOT use STOP X
under the following circumstances:
• If you have severe, deep wrinkles.
• If you are pregnant or breastfeeding.
• If you have moderate or severe wrinkles underneath the chin.
• Over the eyelids due to the potential damage to the eye structures.
• Over the eyebrows, eyeballs, lips, ears, thyroid, breasts or genital area.
• Use in subjects without total removal of facial hair may result in follicular
burn in these areas.
• Do not use the STOP X device over any areas other than the recommended
areas in this user manual (FIG.10).
• Do not use the STOP X device without the supplied treatment gel. The

8
PRECAUTIONS AND SAFETY INSTRUCTIONS
Remember, this is an electric device using radio frequency waves.
Please adhere to the following precautions:
• Use this device only for its intended use as described in the user manual.
device may not operate properly if used without the STOP preparation
gel or if used with another lotion or gel.
Eye damage, damage to glands, sensitive and delicate skin and other
tissue may occur. Follow instructions for use exactly as directed for
your safety:
• The device is intended only for a single user to prevent contamination
between users.
• During treatment, in case of excessive redness or swelling, stop treatment
and cool the area using a wash cloth and cold water for at least 15 minutes.
• If redness persists for more than 24 hours after the treatment, please
consult your physician.
• Patients with visual difficulties should use the device only while wearing
corrective vision aid.
Skin injury can occur under this condition:
• Using blood thinning medications may induce skin hematomas due to
the mechanical massage by the device.
If in doubt about any other medical condition or medication that might
affect the treatment, please consult with your physician or contact us at
inf[email protected]om.

9
• Do not use the device if it is damaged or an item is missing.
• Turn the device on only during treatment.
• Do not use the device if it is disassembled, cracked or if the electric cord
is damaged.
• Do not use the device in the vicinity of inflammable liquids (alcohol,
acetone).
• Always thoroughly dry your hands and face before treatment.
• Keep out of reach of children.
• Do not place, store or use the device near sources of water such as the
sink or bathtub.
• Do not touch the device if it is wet or falls in to water. Unplug the power
supply from the electrical outlet immediately and then take the device
out of the water. This situation could damage the device or power supply,
or cause an electric shock that may lead to serious injury or death.
• Immediately after use, or before cleaning the device, turn the device off
and unplug it from the electrical outlet.
• Only use the power supply supplied with the STOP X device. Using a
different power supply can damage the device.
FIRE HAZARDS
• Do not use the device close to explosive or highly flammable materials
(alcohol, methanol, acetone, etc.).
• If alcohol is used for cleaning the device, it must be allowed to dry
thoroughly before the device is used and then move the alcohol away
from the device.

10
4. WHAT’S INSIDE THE STOP X BOX
STOP X kit includes:
• STOP X DEVICE
• POWER SUPPLY
• STOP PREPARATION GEL
FIG.3 In the box.
Check that the box includes all items.
Stop Preparation GelSTOP X Device Power Supply
Stop
Preparation
Gel

11
Important
Do not use the device if it is damaged or an item is missing.
Check that there is a sticker on the protective cover.
If your device does not have this sticker, DO NOT USE and contact STOP X
customer service at [e-mail]

12
5. GETTING TO KNOW YOUR STOP X DEVICE
The STOP X device consists of a body and a protective cover.
The device's body has a treatment head on one side and a control panel
on the other side.
TREATMENT HEAD
The treatment head has four energy tips (electrodes) and a temperature
sensor. When not in use, the treatment head should be covered with its
protective cover (FIG.4).
CONTROL PANEL
The control panel includes the ON/OFF power button, power supply connection,
heating level indicator light (green) and temperature range indicator light
(orange) (FIG.4).

13
FIG.4 STOP X Device Overview. Check that the box includes all items.
6.
7.
9.
8.
5.
4.
2.
1. 3.
10.
1. DEVICE BODY
2. TREATMENT HEAD
3. CONTROL PANEL
4. ENERGY TIP
5. TEMPERATURE SENSOR
6. POWER SUPPLY CONNECTION
7. ON/OFF BUTTON
8. GREEN INDICATOR LIGHT
9. ORANGE INDICATOR LIGHT
10. PROTECTIVE COVER

14
POWER SUPPLY
STOP PREPARATION GEL
STOP preparation gel is required for use with the STOP X. After opening the
container, the STOP preparation gel can be used for 12 months.
Power supply cord
Power supply
FIG.5 Power Supply
The power supply is equipped with a built-in electric plug adapter and power
supply cord (FIG.5)

15
6. STOP X TREATMENT PROCEDURE
HOW OFTEN TO USE YOUR STOP X
For best results, use the STOP X device 2-3 times (not consecutive days) a
week for a period of 8-12 weeks. For maintenance: additional treatments
are recommended once a week.
TREATMENT SAFETY GUIDELINES
• Be sure that all four energy tips firmly touch the skin at all times during
treatment.
• It is important to keep the device moving at all times during treatment.
Leaving the device on the same spot without movement may
result in skin overheating and possible excessive skin redness.
• For most effective treatment, use slow, circular movements.
FIRST TIME USE
Before your first treatment, perform a test on a small area of skin (forearm,
2"x2"). This will ensure that your skin does not have a negative reaction
(excessive redness and/or swelling) to the gel or treatment and that the
device is operating correctly.
• Apply a small amount of STOP preparation gel on the test area
• Treat the area with the STOP X. Follow the steps below:
1. Remove the protective cover.

16
2. Press the On/Off button.
3. Make sure the heating level green indicator light is on.
4. Place the device on the skin, and using slight pressure ensure that all
4 energy tips touch the skin.
5. Move the device slowly in circular motions until the orange indicator
light comes on.
6. After the orange light comes on, continue treating the same area for
a few more seconds.
7. Check if your skin has a negative reaction (excessive redness and/or
swelling).

17
Orange
Indicator
light
FIG.6 Orange indicator light
BEFORE STARTING
• Remove all jewelry, piercing and eye glasses (if you wear them).
• Sit in front of a mirror during treatment so you can see the orange
temperature indicator light.
• Clean your face with soap and water and dry thoroughly.
• Make sure your hands are clean and dry.

18
FIG.7 Applying STOP preparation gel
HOW TO APPLY STOP PREPARATION GEL
1. Dab a small amount of gel on your fingertip from the surface of the
STOP preparation gel.
2. Dab small spots of gel around the face.
Important
Be careful not to apply gel into your eyes.
3. Evenly spread a thin layer of the gel onto the face.
4. Clean your hands.
1. 2. 3.

19
HOW TO CONNECT THE POWER SUPPLY AND START THE DEVICE
FIG.8 How to connect the power supply and start the device
FIG.9 Control panel
1. Connect the power supply cord to the device. You should hear a "click"
indicating that the connector is in place.
2. Plug the power supply into an electrical outlet.
3. Press the On/Off button to turn the device on.
4. Make sure the heating level green indicator light is on.
1. 2. 3.
Orange
Indicator
light
Green
Indicator
light
On/Off
button

20
TREATMENT PROCEDURE
TREATMENT PROCEDURE
FIG.10 Recommended and prohibited treatment areas
Identify the parts of your face that you wish to treat. Divide your face
into several treatment areas.
Treatment time is up to 2-3 minutes for each treatment area. Total
treatment session should not exceed 20 minutes.
Eyelids
Ears Chin / Submental
Thyroid
Nose
Mouth
Thyroid
Recommended treatment areas
Areas prohibited for treatment
Important
Never treat directly on eyes / eyelids, lips, nose, ears or thyroid.
1. Remove the protective cover.
2. Press the On/Off button.
3. Start on the lower cheek and jawline (FIG.11).
4. Place the device on the skin, and using slight pressure ensure that the
4 energy tips touch the skin at all times.
Do not use if you have moderate or severe
wrinkles underneath the chin
