Pontec PondoStar LED Set 3 User manual

EN
Operating instructions
PondoStar LED Rocklight Set 3
Downloaded from www.watergardeningdirect.com

--
2
A
PSR0031
B
PSR0029
Downloaded from www.watergardeningdirect.com

-EN -
7
-EN -
Original operating manual. This operating manual belongs with the unit and must always be handed over together with
the unit.
EN
WARNING
WARNING
Disconnect all electrical units in the water from the power supply
before reaching into the water. Otherwise there is a risk of injuries
or death by electrocution.
Disconnect the power plug before carrying out any work on the unit.
This unit can be used by children aged 8 and above and by per-
sons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they are supervised or have been
instructed on how to use the unit in a safe way and they under-
stand the hazards involved. Do not allow children to play with the
unit. Only allow children to carry out cleaning and user mainte-
nance under supervision.
Safety information
Correct electrical installation
•Special regulations apply to electrical installation in outdoor areas. Only allow a qualified electrician to perform the
electrical installation.
– The qualified electrician has the required professional training, knowledge and skills to perform electrical installa-
tions in outdoor areas. The qualified electrician can detect potential risks and adheres to regional and national
standards, regulations and directives.
– For your own safety, please consult a qualified electrician.
•Only connect the unit if the electrical data of the unit and the power supply match.
•Only plug the unit into a correctly installed outlet. Ensure that the unit is fused for a rated fault current of max. 30 mA
by means of a fault current protection device.
•Install the transformer at a minimum safety distance of 2 m from the water.
•Extension cables and power distributors (e.g. outlet strips) must be suitable for outdoor use (splash-proof).
•Protect open plugs and sockets from moisture.
Safe operation
•The power pack or transformer and plug connections are only protected from rain and splash water, they are not
waterproof. Ensure that they are never placed in water.
•Do not use the unit, if electrical lines or the housing are damaged.
•A damaged connection cable cannot be replaced. Dispose of the unit.
•Do not carry or pull the unit by its power cable.
•Route lines so that they are protected from damage and nobody can trip over them.
•Never make technical modifications to the unit.
•Only carry out work on the unit that is described in this manual.
•Only use original spare parts and accessories.
Downloaded from www.watergardeningdirect.com

-EN -
8
Intended use
Only use the product described in this manual as follows:
•For use in water fountain systems and ponds.
•For use above and under water.
•Operate the product in compliance with the technical data. (→ Technical data)
The following restrictions apply to the unit:
•Do not use for commercial or industrial purposes.
•Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
Installation and connection
Installation
A, B
WARNING
The transformer is subject to dangerous voltage and must not be installed directly adjacent to the water. Otherwise
there is a risk of severe injuries or death by electrocution.
Install the transformer at a distance of at least 2 m from the water to ensure that it is protected against flooding.
•Position the LED spotlights and the transformer so that they do not pose a danger to anyone.
•Install the transformer so that it is protected from flooding.
– Ensure that the transformer is not placed in water.
•The LED spotlights may be installed under water.
– Max. immersion depth: 1 m
•Connect the connection cable of the LED spotlights to the transformer socket by means of the plug.
– Hand-tighten the cap nut of the plug.
Commissioning/start-up
•Switching on:Plug the power plug into the outlet.
– The unit switches on immediately.
•Switching off: Pull the power plug from the outlet.
Maintenance and cleaning
NOTE
Do not use aggressive cleaning agents or chemical solutions. These agents can damage the housing, impair the func-
tion of the device and harm animals, plants and the environment.
Only clean the glass of the spotlight and the transformer with a damp cloth.
Only use clear water and a soft brush or sponge to clean the spotlight housing.
Downloaded from www.watergardeningdirect.com

-EN -
9
Storage/overwintering
If the ambient temperature falls outside the permissible ambient temperature range, it is necessary to remove the unit.
(→ Technical data)
•Store the unit in a dry and frost-free place.
Troubleshooting
Malfunction
Possible cause
Remedy
Lamp does not light up.
Power supply interrupted
•Establish power connection
•
Establish the transformer/spotlight connec-
tion
•
Clean the contacts of the transformer/spot-
lights plug connection
Transformer defective
Replace transformer
Light intensity decreases
Lamp glass soiled
Clean lamp glass
Technical data
PondoStar LED Rocklight Set 3
Transformer
Connection voltage
V AC
230-240
Mains frequency
HZ
50
Max. power consumption
W
5
Output voltage
V AC
12
Max. power output
VA
12
Protection type
IP44
Permissible ambient temperature
°C
-10 … +40
Length of power cable
m
2
Weight
kg
?
Spotlights
Connection voltage
V AC
12
Power consumption
W
3
Protection type
IP68
Max. immersion depth
m
1
Colour temperature
k
3000
warm white
Permissible water temperature
°C
+4 … +35
Permissible ambient temperature
°C
-10 … +40
Transformer connection cable length
m
3
Length of connection cable between spotlights
m
2
Spotlight dimensions
mm
110 × 105 × 71
Total weight
kg
2.3
Downloaded from www.watergardeningdirect.com

-EN -
10
Symbols on the unit
The unit is dust-tight and water-tight down to 1 m.
The unit is protected against foreign objects (Ø ≥1 mm) and splash water.
The unit has protection rating II and is protected by double or reinforced insulation.
The unit has protection rating III. Only operate the unit with safety-low voltage.
The transformer is a safety transformer supplying safety-low voltage on the secondary side.
Do not dispose of the unit with normal household waste.
Read the operating instructions.
Disposal
NOTE
Do not dispose of this
unit with domestic waste.

Dispose of the unit by using the return system provided for this purpose.
Disable the unit by cutting off the cables.
Warranty conditions
PfG grants a 2 year warranty from the date of sale on verifiable material and manufacturing defects. Wear parts such
as bulbs etc. are exempt from the warranty. The prerequisite for our warranty is the presentation of the purchase re-
ceipt. Our warranty will become null and void if the unit is misused, electrically or mechanically damaged by inappropri-
ate use or improperly repaired by non-authorised workshops. Repairs may only be performed by PfG or workshops
authorised by PfG. In the case of warranty claims, please return the defective unit or part freight paid to PfG together
with a description of the fault and the purchase receipt. PfG reserves the right to invoice repair costs. PfG is not liable
for transport damage. Any damage must be claimed against the carrier. Further claims of whatever type, especially
consequential damage, are excluded. This warranty does not affect the final customer’s claims against the dealer.
