Portalp SW10 User manual

INSTALLATION GUIDE
SW10/19
AUTOMATED PEDESTRIAN
SWINGING DOOR
OPERATOR
SW10 (Full Power) & SW19 (Low Energy)
IG-SW10-19-JUN 23, 2022 - USA - A © COPYRIGHT 2022 PORTALP USA, INC
Automatic Doors & Building Access Control
PORTALP USA, Inc
www.portalp.com

INSTALLATION GUIDE
WWW.PORTALP.COM |2
© COPYRIGHT
© Copyright PORTALP USA, Inc. from 2020.All rights reserved.
No part of this manual may be reproduced, archived, distributed
to third parties nor copied in any other way, in any format and
with any means, be it electronic, mechanical or by
photocopying, without prior written authorization by PORTALP
USA, Inc. All names and trademarks mentioned are the property
of their respective manufacturers. Customers may make copies
exclusively for their own use. This manual was published in
2020.
© Copyright PORTALP USA, Inc. depuis 2020. Tous droits
réservés. Aucune partie de ce manuel ne peut être reproduite,
archivée ou distribuée à des tiers ni copiée, sous tout format et
avec tout moyen, qu’il soit électronique, mécanique ou par
photocopie, sans le consentement écrit préalable de PORTALP
USA, Inc. Tous les noms et les marques cités sont la propriété de
leurs fabricants respectifs. Les clients peuvent faire des copies
pour leur usage exclusif. Ce manuel a été publié en 2020.
PORTALP, USA, Inc
11075 Parker Drive
Irwin, PA 15642
Tel: [phone]
Email: [e-mail]
www.portalp.com
The data contained in this document are the property of
PORTALP INTERNATIONAL and should not be changed without
prior agreement of the manufacturer.
Les données contenues dans ce document sont la propriété de
PORTALP INTERNATIONAL et ne doivent pas être modifiées
sans l'accord préalable du fabricant.
Automatic Doors & Building Access Control
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
WWW.PORTALP.COM |3
SW10 (Full Power) & SW19 (Low Energy)
TABLE OF CONTENTS:
IMPORTANT NOTES
NOTES IMPORTANTES
PRODUCT DESCRIPTION & SPECIFICATIONS
HEADER INSTALLATION
MOUNT THE OPERATOR(S)
PUSH ARM INSTALLATION
PULL ARM INSTALLATION
120 VOLT AC ELECTRICAL CONNECTION
POWER ON & INDICATIONS
SET-UP PROCEDURES
SET THE DIP SWITCHES ON THE I/O BOARD
SET THE DIP SWITCHES ON THE ADJUSTMENT BOARD
WIRING CONNECTIONS
ADJUSTING THE MECHANICAL DOORSTOP
TROUBLESHOOTING
JOB DOCUMENTATION &CLOSEOUT
ACCESSORIES
CUSTOMER SERVICE
Automatic Doors & Building Access Control
04
05
06
07 -13
14 -17
18 -20
21
22
23
24
25
26 -27
28
29
30
31
31
31
APPENDIX -BOX CONTENT
APPENDIX -WIRING DIAGRAMS
APPENDIX -ELECTRIC LOCK APPLICATION
APPENDIX -SW10 PAIR WITH THE BAT + TORPEDO + BEA BODUGUARD
APPENDIX -SW10 SINGLE/PAIR WITH THE BAT + BEA LZR MICROSCAN
APPENDIX -SW10 SINGLE WITH THE BAT + BEA BODUGUARD
APPENDIX -FIRE RATED DOOR APPLICATION
APPENDIX -TAP PROGRAMMING DEVICE -KP evo
32 -45
46 -47
48
49
50
51
52
53

INSTALLATION GUIDE
IMPORTANT NOTES
READ THIS SECTION BEFORE PROCEEDING WITH INSTALLATION
PORTALP USA, Inc. recommends that all of its automated
pedestrian door products be installed by a trained automatic
door technician and that the resulting performance of the
product be in full compliance with the most current version of
the American National Standards Institute document A156.10 or
A156.19 (whichever is applicable) as well as any applicable
building codes and/or fire codes. PORTALP further recommends
that a full inspection of the operating system be performed in
accordance with the guidelines of the American Association of
Automatic Door manufacturers (AAADM). This inspection must
be performed by a certified AAADM trained inspector. PORTALP
recommends this documented inspection be performed upon
completion of the installation as well as, following the
completion of every service call thereafter. If service is not
performed within one year of the previous service action, a
routine AAADM inspection should be performed and
documented. Under no circumstance should the product
operate for more than one year without an AAADM inspection.
PORTALP does NOT recommend installation or service, on any of
their automated pedestrian door products, by any individual
who is not certified as an AAADM inspector.
Following the installation or service of any PORTALP automated
pedestrian door product, if it is deemed unsafe, or is operating
in an unsatisfactory manner according to national performance
standards or recommended performance guidelines as defined
by PORTALP, repairs should be made immediately. If an
immediate repair cannot be made, the product should be
disabled, and appropriate measures should be taken to secure
the door in asafe position or to enable the door to safely be
used manually. During this situation, every effort should be
made to notify the owner (or person responsible) of the
condition and to advise on corrective actions that must be taken
to return the product to safe operation.
LOW ENERGY APPLICATION NOTE
When using the SW10/19 for alow energy application, PORTALP
recommends the use of a door-mounted presence sensor on the
approach side of the door to be used as a secondary activation
device. This type of sensor can be installed at time of installation
or can also be retrofitted. This device serves to re-activate the
door to the open position should a person enter the closing path
at the approach side of the door, as it is closing. Once the door is
fully closed, a "knowing act" device must then be used for initial
activation.PORTALP considers this device to be essential in
reducing the possibility of doors "timing out" and closing before
all pedestrians have passed though the doorway.
PORTALP USA, Inc reserves the right to change the presented
products and materials without prior notice. Their description
cannot on no account take on a contractual aspect.
The data contained in this document are the property of
PORTALP INTERNATIONAL and should not be changed without
prior agreement of the manufacturer.
WWW.PORTALP.COM |4
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

NOTES IMPORTANTES
READ THIS SECTION BEFORE PROCEEDING WITH INSTALLATION
PORTALP USA, Inc (ci-après dénommée “PORTALP”) préconise
que tous ses produits relatifs aux portes piétonnes automatiques
soient installés par un technicien de portes automatiques
experimenté et que la performance du produit qui en résultera
soit tout à fait conforme à la version la plus actualisée du
document A 156.10 ou 156.19 de l’Institut des Normes
Nationales Américaines (en fonction de l’application), ainsi
qu’aux codes du bâtiment et/ou codes de prévention des
incendies applicables. PORTALP recommande qu’une inspection
générale du système de fonctionnement soit effectuée
conformément aux directives de l’Association Américaine des
fabricants de Portes Automatiques (AAADM) et par un
inspecteur qualifié agréé AAADM.
PORTALP préconise que cette inspection documentée soit
realisée dès l’achèvement de l’installation initiale, mais aussi à la
fin de chaque appel de service ultérieur. Si aucune prestation de
service n’a eu lieu durant une période d’un ans depuis la date
des derniers travaux de service, une inspection préventive
AAADM devra être effectuée et documentée. Sous aucune
condition, le produit peut-il être en fonctionnement pour plus
d’un an sans inspection. AAADM.PORTALP ne recommande NI
l’installation NI le service d’entretien sur aucun de leurs produits
de portes piétonnes automatisées par une personne autre qu’un
inspecteur AAADM agréé. Apres l’installation ou la prestation de
service des portes piétonnes automatisées, si celles-ci sont
jugées non sécurisées ou ne fonctionnent pas de manière
satisfaisante conformément aux normes d’opération nationales
ou aux directives d’opération définies par PORTALP, il faudra
procéder aux réparations nécessaires dans les plus brefs délais.
Si une réparation immédiate ne peut se faire, le produit doit être
désactivé et des mesures appropriées doivent être prises afin de
sécuriser la porte ou de permettre à celle-ci de pouvoir être
utilisée manuellement en toute securité. Dans tel cas, tous les
efforts devront être entrepris afin de signaler le problème au
propriétaire (ou àla personne responsable) et de lui fournir les
renseignements nécessaires afin de corriger la situation et
rétablir le bon fonctionnement du produit.
REMARQUE SUR L’APPLICATION ÀÉNERGIE FAIBLE
Lors de l’utilisation du SW10 /19 en présence d’application à
énergie faible, PORTALP préconise l’utilisation d’un avertisseur
de présence monté sur porte côté non battant en guise de
dispositif d’activation secondaire. Ce type d’avertisseur peut
être installé ou faire l’objet d’une actualisation. Ce dispositif sert
àréactiver la porte dans sa position ouverte au cas où une
personne entrerait dans le parcours de fermeture du côté non
battant pendant que la porte se ferme.Lors de la fermeture
complète de la porte, un dispositif d’action délibérée doit être
utilisé pour l’activation initiale. Tucker considère ce dernier
comme essentiel afin de minimiser les éventualités de
temporisation et les risques que les portes ne se ferment avant
de permettre l’achèvement de la circulation piétonne dans la
voie de passage.
PORTALP USA, Inc. se réserve le droit de modifier les produits et
matériaux présentés sans préavis. Leur description ne peut en
aucun cas prendre un aspect contractuel.
Les données contenues dans ce document sont la propriété de
PORTALP INTERNATIONAL et ne doivent pas être modifiées sans
l'accord préalable du fabricant.
GUIDE D'INSTALLATION
WWW.PORTALP.COM |5
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
PRODUCT DESCRIPTION & SPECIFICATIONS
Po
wer Supply*
115
VAC (+6%, -10%) 60Hz with ground
Po
wer Consumption
100
W
C
urrent Consumption
1
A
M
otor
24
VDC Permanent Magnet with Belt Driven Encoder
H
eader Dimensions
4
1/2” Height x 47/8” Depth
F
used Protection
3
.5A Fuse(F1 located on I/O Board)
W
eight
32
lbs – 65 lbs Per Operator Assembly
Am
bient Operating Temperature**
-
4 to 131º F
I
ngress Protection
I
P23 (protection from spray water up to 60º from the vertical - ie. Rainstorm)
M
aximum Door Weight
P
USH ARM PULL ARM
36
” Door:438 lbs 342 lbs
42
” Door:328 lbs 256 lbs
44
” Door:299 lbs 234 lbs
48
” Door:254 lbs 198 lbs
24
VDC Accessories Power Supply
24
VDC /I A. Max
24
VDC Electric Lock Power Supply
24
VDC /I A. Max
A
djustable Speeds & Timers
O
pening Speed, Closing Speed, Hold Open Time,
Closing
Speed with power off
S
tandard Selector Switch Functions
A
utomatic, Hold Open, Manual(Off)
S
tandard Control Outputs•Malfunction Alarm Signal
•Electric Lock Relay
•24 VDC Accessories Power Supply
•Door Status
S
tandard Control Inputs
I
nterior Activation, Exterior Activation, Emergency Shutdown,
Al
arm Output, “Stop” Safety Device (door-mounted),
S
afety Device Input, Secondary Activation
Qu
ick Disconnects
T
AP-Controller (optional)
*This product should only be connected to an electrical installation that complies with the regulations.
** The installer must ensure that the temperature range marked on the nameplate is well suited to the site.
Before any work is carried out, please comply with the size (width,
weight) specified in the Technical Characteristics.If instructions
are not followed, this may seriously affect the function of the
operator.The manufacturer is not responsible if the operator is
used outside of the scope of its application or contrary to the
assembly instructions.
Avant tout travail, veuillez respecter les dimensions (largeur,poids)
spécifiées dans les caractéristiques techniques.Si les instructions ne
sont pas respectées,cela peut affecter gravement le fonctionnement
de l'opérateur.Le fabricant n'est pas responsable si l'opérateur est
utilisé en dehors du domaine d'application de son application ou
contrairement aux instructions de montage.
WWW.PORTALP.COM |6
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
HEADER INSTALLATION
Mount the pre-drilled back-plate to the top door frame using appropriate fasteners for the type of frame.
(Refer to Door Prep drawings on pgs. 8-13.)
§Push side mounting: Pre-drilled back-plate is flush with bottom of door frame.
§Pull side mounting: Pre-drilled back-plate is mounted 1.5” up from bottom door frame.
§Back-plate should overlap each jamb tube by 1.5”.
§Refer to the APPENDIX for fire rated door applications.
PUSH ARM APPLICATIONS:
Bottom of swing unit is flush with bottom of top
door frame.
NOTE:
PORTALP is now using a 35mm spindle adaptor
for all standard push arm applications – this
requires that the header assembly be mounted
as shown at left, flush with bottom of top door
frame.
PULL ARM APPLICATION: STANDARD PULL ARM
& DOUBLE EGRESS APPLICATIONS
Double egress applications require the use of an
80mm spindle adaptor for the side using the
push arm.
WWW.PORTALP.COM |7
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
HEADER INSTALLATION
§PUSH SIDE INSTALLATION SINGLE |DOOR PREP DRAWINGS
Opening Width Operator Width X Dim
36" 39" 6.25"
42" 45" 12.25"
44" 47" 14.25"
48" 51" 18.25"
WWW.PORTALP.COM |8
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
HEADER INSTALLATION
Opening Width Operator Width A Dim C Dim
72" 75"
12
-
7/16"
N/A
84" 87" N/A
10
-
7/8"
88" 91" N/A
14
-
7/8"
96" 99"
24
-
7/16"
22
-
7/8"
§PUSH SIDE INSTALLATION DOUBLE |DOOR PREP DRAWINGS
WWW.PORTALP.COM |9
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
HEADER INSTALLATION
§PULL SIDE INSTALLATION SINGLE |DOOR PREP DRAWINGS
Opening Width Operator Width Y Dim
36" 39" 6.25"
42" 45" 12.25"
44" 47" 14.25"
48" 51" 18.25"
WWW.PORTALP.COM |10
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
HEADER INSTALLATION
§PULL SIDE INSTALLATION DOUBLE |DOOR PREP DRAWINGS
Opening Width Operator Width A Dim C Dim
72" 75"
12
-
7/16"
N/A
84" 87" N/A
10
-
7/8"
88" 91" N/A
14
-
7/8"
96" 99"
24
-
7/16"
22
-
7/8"
WWW.PORTALP.COM |11
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
HEADER INSTALLATION
§DOUBLE EGRESS INSTALLATION | DOOR PREP DRAWINGS
Opening Width Operator Width A Dim C Dim
72" 75"
12
-
7/16"
N/A
84" 87" N/A
10
-
7/8"
88" 91" N/A
14
-
7/8"
96" 99"
24
-
7/16"
22
-
7/8"
WWW.PORTALP.COM |12
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
HEADER INSTALLATION
DOUBLE EGRESS PULL ARM DOUBLE EGRESS PUSH ARM
WWW.PORTALP.COM |13
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)
4.875” 4.875”

INSTALLATION GUIDE
MOUNT THE OPERATOR(S)
§Operator is non-handed – same operator for all hands of doors
§Handing is determined by how the operator is mounted inside the header
§The operator is mounted to a short aluminum “drive” plate that is held into the header by 5 mounting screws. Four (4) of the
screws secure the drive plate. One (1) screw is used to locate the drive plate using a ‘keyhole’ configuration. The keyhole allows
for easy removal of the drive plate without the need to loosen the screw. Removing the four (4) screws allows the drive plate &
operator to be removed from the header and rotated 180 degrees to change from a push to a pull or vice versa.
Drive Plate mounted in standard position using four (4) screws to secure.
Loosen the screws using a 5 mm allen wrench and slide each one off the drive plate.
1
Drive plate removed by shifting to the left and lifting the drive plate off the locating screw.
2
WWW.PORTALP.COM |14
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
MOUNT THE OPERATOR(S)
3
4Key slot configuration & location screw mounted in backplate.
WWW.PORTALP.COM |15
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)
For pull application the motor should be located near the hinge side of the door.
For push application the I/O board should be located near the hinge side of the door.
Re-align locating screw to key slot, insert drive plate and shift to the right into position.
Re-position the four (4) screws to secure the drive plate.

INSTALLATION GUIDE
MOUNT THE OPERATOR(S)
PUSH = I/O BOARD IS TOWARDS THE HINGE JAMB
OPERATOR OPERATOR
RH PUSH LH PUSH
I/O BOARD MOTOR
WWW.PORTALP.COM |16
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
MOUNT THE OPERATOR(S)
RH PUSH LH PUSH
OPERATOR OPERATOR
PULL = ROUND MOTOR IS TOWARDS THE HINGE
§Mount the header to the doorframe with the screws provided.
§The header will overlap the doorframe by 1-1/2" at each side.
WWW.PORTALP.COM |17
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
PUSH ARM INSTALLATION
All push arms come standard with 35mm spindle. 50mm and 80mm available as an accessory.
Attach the primary door arm approx. 20 degrees past perpendicular and towards the closing direction as shown.
If more spring tension is desired, simply increase the mounting angle to greater than 20 degrees so it results in
increased preload.
(BOX CONTENT -Page 33 -35)
(BOX CONTENT -Page 33 -35)
WWW.PORTALP.COM |18
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)
(INCLUDED WITH DOUBLE EGRESS ARM)
(INCLUDED WITH PUSH ARM)
(INCLUDED WITH DOUBLE EGRESS ARM)

INSTALLATION GUIDE
PUSH ARM INSTALLATION
Adjust the secondary telescopic arm to the prescribed length according to chart:
Before installing any portion of the door arm assembly, it is easiest to lay the arm out on a flat surface and insert
the secondary and primary arm into the sleeve as it will be when installed on the door:
§Slide the short arms within the sleeve to obtain the prescribed "X" dimension.
§Tighten the screws on the short arm that is connected to the door shoe.
§Double-check the "X" dimension of the arm - this is the distance between the center of the hole at the door
shoe and the center of the hole at the pivot point of the primary arm (as shown).
§Mark a pencil line at the edge of the sleeve where it overlaps the short arm that is connected to the primary
arm. This will make it easier when positioning the primary arm for final installation.
Reveal Hinge Hung X Dim. Center Pivot X Dim.
0" 13" 16"
1" 14" 17"
2" 15" 18"
3" 16" 19"
4" 17" 20"
5" 18" 21"
6" 19"
7" 20"
8" 21"
DEEPER REVEAL REQUIRES ARM EXTENSION
Attach the secondary arm mounting bracket to the door. The centerline of the bracket should be at 13-1/2” in from the inside
face of the hinge jamb when using butt hinges on the door, and 16” when using a center pivoted door.
WWW.PORTALP.COM |19
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)

INSTALLATION GUIDE
PUSH ARM INSTALLATION
Rotate the primary arm in the opening direction as to reach the pivot point of the secondary.
Attach the arms together with the hardware provided.
WWW.PORTALP.COM |20
Automatic Doors & Building Access Control
SW10 (Full Power) & SW19 (Low Energy)
