Assa Abloy CMD User manual

Original instructions
User Manual
Curved Sliding Door System
ASSA ABLOY CMD
ASSA ABLOY Entrance Systems
ILL-00224
assaabloyentrance.com
assaabloyentrance.com

CONTENTS - Original instructions
4Instructions for safe operation .......................................................................................................
5Congratulations on your new automatic door! ........................................................................
5Electronic equipment reception interference ...........................................................................
5Environmental requirements ..........................................................................................................
5Product liability ...................................................................................................................................
6Warranty ................................................................................................................................................
6Service .....................................................................................................................................................
7Intended use .........................................................................................................................................
7.........................................................................................................................................
7Technical specification ......................................................................................................................
7How the ASSA ABLOY CMD works .................................................................................................
7Programme selectors .........................................................................................................................
8Programme selector functions .............................................................................
8Locking ....................................................................................................................................................
8Unlocking ...............................................................................................................................................
9Standard safety ....................................................................................................................................
9Microprocessor for precise control ....................................................................
9Safety system with presence sensors ..........................................................................................
10Optional safety .....................................................................................................................................
10Emergency escape ..............................................................................................................................
10Electrical emergency unit .......................................................................................
11Regular safety checks .........................................................................................................................
14Safety accessories ................................................................................................................................
14General accessories ............................................................................................................................
14Cover .............................................................................................................................
14Motion sensor and presence sensors .................................................................
14Programme selectors ...............................................................................................
14Electrical locks ............................................................................................................
14Micro switch kit, LSK/LIS .........................................................................................
14Electrical emergency unit with batteries ..........................................................
14Emergency closing with repeated closing ........................................................
14Mechanical emergency unit with elastic cord ................................................
15Interlocking .................................................................................................................
15Synchronization ........................................................................................................
1006492-en-3.0Issue 2018-03-092

15Convenience battery UPS .......................................................................................
15External error indication .........................................................................................
15Key switches (flush and/or surface mounted) .................................................
15Push button ................................................................................................................
15Emergency open impulse .......................................................................................
15Open / Close function ..............................................................................................
16Troubleshooting ..................................................................................................................................
16Service/Maintenance .........................................................................................................................
17Other products from ASSA ABLOY Entrance Systems ............................................................
ASSA ABLOY as word and logo are trademarks owned by the ASSA ABLOY Group
©ASSA ABLOY Entrance Systems, 2018
Technical data subject to change without notice.
Backtrack information: folder:Workspace Main, version:a448, Date:2018-03-09 time:13:53:09, state: Frozen
3Issue 2018-03-091006492-en-3.0

Instructions for safe operation
•Failure to observe the information in this manual may
result in personal injury or damage to equipment.
•To reduce the risk of injury of persons - use this oper-
ator only with pedestrian doors.
•Do not use the equipment if repair or adjustment is
necessary.
•Disconnect supply when cleaning or other mainten-
ance is to be carried out.
•The operator can be used by children over 8 years of
age if they have been instructed by a person in charge
of their safety.
•The operator can be used by children 8 years of age
or younger if they are supervised by a person respons-
ible for their safety.
•The operator can be used by persons with impaired
physical, sensory or mental capacity if they have been
instructed by a person in charge of their safety.
•Cleaning and user maintenance shall not be made by
children.
•Do not let anyone climb on or play with the door or
the fixed/remote controls.
•The doorset can be operated automatically by sensors
or manually by activators.
1006492-en-3.0Issue 2018-03-094

Congratulations on your new automatic door!
ASSA ABLOY Entrance Systems has developed automatic doors for more than 50 years. State-of-the-
art technology and carefully tested materials and components provide you with a superior product.
As with all other technical products, your automatic door requires periodic maintenance and service.
It is essential that you know your automatic door (system) and that you recognize the importance
of maintaining it in compliance with applicable standards for safety.
Your local ASSA ABLOY Entrance Systems-authorized representative is familiar with these standards,
as well as all applicable local codes and ASSA ABLOY Entrance Systems recommendations for power-
operated pedestrian doors. Service and adjustments performed by your
ASSA ABLOY Entrance Systems-authorized representative, will ensure safe and proper operation of
your automatic door unit.
Electronic equipment reception interference
The equipment may generate and use radio frequency energy and if not installed and used properly,
it may cause interference to radio, television reception or other radio frequency type systems.
If other equipment does not fully comply with immunity requirements interference may occur.
There is no guarantee that interference will not occur in a particular installation. If this equipment
does cause interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Re-orient the receiving antenna.
•Relocate the receiver with respect to the equipment.
•Move the receiver away from the equipment.
•Plug the receiver into a different outlet so that equipment and receiver are on different branch
circuits.
•Check that protective earth (PE) is connected.
If necessary, the user should consult the dealer or an experienced electronics technician for additional
suggestions.
Environmental requirements
ASSA ABLOY Entrance Systems products are equipped with electronics and may also be equipped
with batteries containing materials which are hazardous to the environment. Disconnect power
before removing electronics and battery and make sure it is disposed of properly according to local
regulations (how and where) as was done with the packaging material.
Product liability
According to regulations, the following are the responsibility of the owner or caretaker of the
equipment
•that the equipment operates correctly, so that it gives sufficient protection in regard to safety
and health
•that the equipment is operated and regularly maintained, inspected and serviced by someone
with documented competence in the equipment and in applicable regulations
•that the provided “Service Log Book”and “Site Acceptance Test and Risk Assessment”documents
(PRA-0005) are kept available for maintenance and service records
•that inspection covers the emergency opening function (when applicable)
•that the closing force is appropriate for the door size on fire-approved door systems (when ap-
plicable)
5Issue 2018-03-091006492-en-3.0

Warranty
ASSA ABLOY Entrance Systems warrants its products to be free from defects in material and work-
manship under intended use and service for a warranty time of 12 months, beginning at time of
delivery. This warranty extends only to the original buyer of the equipment.
ASSA ABLOY Entrance Systems warrants that the software will operate substantially in accordance
with its functional descriptions and that it has been recorded on non-defective media.
The ASSA ABLOY Entrance Systems warranty does not apply to
•That the software will be error-free or operate without interruption
•General wear and tear on the system
•Fuse, disposable batteries and glass damage
•System deviations caused by installer other than ASSA ABLOY Entrance Systems
•System that has been altered or damaged by vandalism or misuse
•System that has been additionally equipped with non-ASSA ABLOY Entrance Systems original
branded parts and/or spare parts
•Unrequired visits due to poor client communication (door working when our technician arrives,
reset, power discontinuation)
•Adjustments (closing and opening speed and also detection field radars) due to customer re-
quests (excludes operational adjustments thought to create a hazard)
•Water damage
•Adverse weather conditions
•Any damage caused, directly or indirectly, by a circumstance beyond the control of the applicable
company within ASSA ABLOY Entrance Systems, such as industrial dispute, fire, natural disaster,
war, extensive military mobilization, insurrection, requisition, seizure, embargo, restrictions in
the use of power and defects or delays in deliveries by sub-contractors caused by any such cir-
cumstances
Please note:
•Non-compliance with manufacturers care and maintenance recommendations may void the
warranty.
•ASSA ABLOY Entrance Systems-authorized resellers shall extend this warranty to end-users only,
but have no authority to extend a greater or different warranty on behalf of
ASSA ABLOY Entrance Systems.
•A service agreement with ASSA ABLOY Entrance Systems will help secure the availability of a
fully operational system and will give priority at call-out, thus minimizing the time that the
equipment is unusable.
Service
Inspections should be done regularly by a trained and qualified person. The frequency of these
inspections should be according to national regulations (or according to industry standard if
there are no national regulations). This is especially important when the installation concerns
a fire-approved door or a door with an emergency-opening function. To extend the life of your
investment and ensure safe and reliable operation of the door, we recommend a minimum
of 2 visits per year or more, depending on usage and operating conditions. Environmental as-
pects shall also be considered.
1006492-en-3.0Issue 2018-03-096

As your entrances are part of your business flow, there’s every reason to keep
them working well. ASSA ABLOY Entrance Systems offers you a maintenance and
modernization expertise to rely on. Our Maintenance Programs and Modernization
Services for entrance automation is backed by a extensive expertise for all types
of pedestrian- and industrial door and docking systems, independent of brand.
At your disposal is a team of dedicated expert technicians, proven through decades
of maintenance, service and satisfied customers.
Intended use
The ASSA ABLOY CMD is an automatic sliding door operator developed to facilitate entrances to
buildings and within buildings.
The door is designed to offer continuous use, a high degree of safety and maximum lifetime. The
system is self-adjusting to the effects caused by normal variations in the weather conditions and to
minor friction changes caused by e.g. dust and dirt.
The ASSA ABLOY CMD sliding door makes it possible to design the entrance in three dimensions,
width, depth and height in addition to the normal width and height. This gives the entrance an elegant
and decorative appearance while it remains extremely functional. A curved sliding door gives a wider
opening than a flat sliding door.
Ensure that the lock is only activated when there are no persons in the room.
For installation and maintenance see Installation and Service manual 1006491.
Save these instructions for future reference.
Technical specification
ASSA ABLOY Entrance Systems ABManufacturer:
Lodjursgatan 10, SE-261 44 Landskrona, SwedenAddress:
ASSA ABLOY CMDType:
120 - 240 V AC 50/60 Hz, mains fuse max 10AMains power supply:
Max. 250 WPower consumption:
IP20Degree of protection:
Third party approvals from established certification organizations valid
for safety in use, see Declaration of Conformity.
Approvals:
How the ASSA ABLOY CMD works
The ASSA ABLOY CMD sliding door system works electromechanically. The drive unit, control unit,
transmission, optional emergency unit and electromechanical locking device are all assembled in a
support beam with an integrated cover. The motor and gear box transmit movement to the door
leaves by means of a tooth belt. The door leaf is fitted to a door adapter/carriage and hangs on a
sliding track. The active leaf travel is directed by a floor guide.
When an opening impulse (e.g. from a motion sensor) is received by the control unit, the drive unit
starts and transmits movement to the door leaves to open.
The closing starts when no OPENING IMPULSE is received, the HOLD OPEN TIME has ended and no
PRESENCE IMPULSE is activated.
Programme selectors
The ASSA ABLOY CMD user can select different modes of operation if a programme selector is installed.
See the table below.
•PSMB-5, for control of one operator only.
7Issue 2018-03-091006492-en-3.0

•PS-5M, for central control of an optional number of operators. In setting AUTO every connected
operator are individually controlled by its own programme selector. Reset is not available on
PS-5M.
•PSK-6U, surface mounted on the side screen or on the wall close to the door.
Programme selector functions
This function is only used on emergency escape doors after it is certain
that all people have left the building.
The door cannot be opened with inner and outer activation units. The
door is locked if an electromechanical locking device has been fitted. The
door can be opened partially with a key switch (if fitted). With an emer-
gency push-button (if fitted) the door opens fully.
OFF
Passage from inside only. The door is normally locked if an electromech-
anical locking device has been fitted. The door can only be opened with
the inner activation unit or with a key switch/emergency push-button (if
fitted).
EXIT
Two-way traffic, normal operation of the door. The door can be opened
with the inner and outer activation units and with a key switch/emergency
push-button (if fitted).
AUTO
Two-way traffic, AUTO PARTIAL is obtained. The door can be opened
partially with the inner and outer activation units and with a key switch
(if fitted). With an emergency push-button the door opens fully.
AUTO
PARTIAL
The door is permanently open. The door can be moved by hand e.g. for
window cleaning. All activation units except for the emergency push
button (if fitted) are disconnected.
OPEN
Set the programme selector to AUTO. Insert a narrow object in the small
hole on the programme selector and push briefly. The operator makes a
system test of the emergency unit (if selected), electromechanical lock,
watchdog relay and closed door position. The operator is after closing
reset and ready for normal operation.
RESET
PSO-5R
PSO-5T
PSMB-5
Note! The RESET is not available on programme selector PS-5M.
Turn the key clockwise to the position “R”(six o’clock) and insert a narrow
object in the small hole on the programme selector and push briefly. Then
turn the key counter-clockwise back to the requested setting. The oper-
ator makes a system test of the emergency unit (if selected), electromech-
anical lock, watchdog relay and closed door position. The operator is after
closing reset and ready for normal operation.
RESET
PSK-6U
R
Note! The key cannot be removed in the "R" position.
Note! If monitored emergency unit is a demand, a test of the emergency unit is performed when
the programme selector is turned from OFF or OPEN to any other position.
Locking
Doors used for emergency escape in buildings such as hospitals and homes for elderly people may
not be locked or put in programme selection OFF mode. In other buildings emergency escape doors
may be locked or put in programme selection OFF mode after it has been secured and all people
have left the building.
Unlocking
Unlock all the mechanical locks before activating the operator.
1006492-en-3.0Issue 2018-03-098

Note that more than one lock may be fitted.
ILL-00116
12
assaabloyentrance.com
assaabloyentrance.com
Standard safety
To permit a safe passage between closing doors, the doors reverse immediately if an obstruction is
detected. They then resume their interrupted movement at low speed to check whether the obstruc-
tion has disappeared or not.
ILL-00209
If an obstruction is detected while the door is opening, the doors stop immediately, and then close
after a time delay.
ILL-00210
Microprocessor for precise control
The microprocessor has a routine for self-monitoring, which detects any interference or faulty signals
in door operation. If an input signal does not correspond to the preprogramming, the microprocessor
automatically takes necessary actions to ensure a safe operation.
Safety system with presence sensors
Usually the safety system incorporates presence sensors installed above the door opening. A presence
sensor detects an object in the doorway, while the doors are closing, the doors reverse immediately.
The doors will start to close when the object is removed.
9Issue 2018-03-091006492-en-3.0

Optional safety
Two or four extra safety presence sensors can be included. The number of extra sensors are depending
on the opening width. The distance between the photocells is 400 mm.
ILL-00247
Emergency escape
The ASSA ABLOY CMD can be combined with an emergency unit that automatically opens or closes¹
the doors in the event of a power failure and can also be interfaced with the fire alarm or smoke
detector. For further information, see General accessories on page 14.
Doors used for emergency escape in buildings such as hospitals and homes for elderly people may
not be locked or put in programme selection OFF.
¹ Electrical emergency unit only
Electrical emergency unit
The door is opened by means of a rechargeable battery unit in the event of a power failure. The door
remains in this position until the power is restored. The operator will then resume the function set
by the programme selector. The emergency unit is monitored by the operator control unit. A mon-
itoring error means that the door opens and remains open until the error is cleared.
For further information, see General accessories on page 14.
The electrical emergency function can also be used to close the door in the event of power failure.
The fire authorities make this a requirement to stop fire or smoke from spreading throughout the
building.
1006492-en-3.0Issue 2018-03-0910

Regular safety checks
To help you fulfil the national/international requirements and to avoid malfunction and risk for in-
juries, we have provided the following checklist.
Do not use the operator if repair or adjustment is necessary.
Disconnect supply
12
when cleaning or other maintenance is to be carried out.
If problem
occurs
Daily Action
Activate your operator and visually check, fastening and any damage of
•operator and cover
1
•cables
2
•operator mode selector(s)
3
•door and glass (stability)
4
Also inspect your operator and check visually for
•condition of door seals and weather stripping
5
•condition of glazing rubbers
6
•finger protection
7
•proper operation; closes slowly and smoothly
•any ventilation being obstructed
Set the mode selector to OFF and check that the operator and electromechanical lock (if fitted)
work together. Also check that the lock
8
really secures the door.
Activate the manual activation units
9
, if any, and walk towards the door. Check that the door has
opened appropriately while you pass the entrance/exit.
Then proceed with the automatic activation units
10
in the same way.
Check the safety sensors
11
if any.
See page 10.
If you are unsure of which type of sensor you have, please contact your ASSA ABLOY Entrance Systems
representative.
If the operator is equipped with automatic opening system, shut off the
power and the door should open and remain open. Restore power and the
door should close.
By law, these tests must be performed regularly by trained personnel.
Escape
doors
Let the door close after an impulse ensuring nothing prevents the door from
closing and locking (if regulations require it).
Fire
doors
Take appropriate measures.=
Contact your ASSA ABLOY Entrance Systems representative. For contact information, see last page.=
11Issue 2018-03-091006492-en-3.0

FUNCTION AND VISUAL INSPECTION
ILL-00226
5
6
1
4
7
5
8
12
Click!
9
2
25
3
1011
CLEANING
The best way to remove dust and dirt from the ASSA ABLOY CMD is to use water and a soft cloth or a sponge.
A gentle detergent may be used. To maintain the quality of the surface treatment, the surfaces should be cleaned
once/four months period. The cleaning should be documented. To avoid damages to the profiles the
brushes/weather stripping must be vacuum-cleaned weekly.
•Do not expose windows, doors or profiles to alkalis. Both aluminium and glass are sensitive to alkalis.
•Do not clean with high pressure water. Operator, programme selector and sensor may be damaged and
water may enter the profiles.
•Do not use polishing detergent.
•Do not scrub with materials like Scotch-brite, as this will cause mechanical damage.
1006492-en-3.0Issue 2018-03-0912

SIGNAGE
800 mm
1100 mm
40 mm
Click!
E
B
F
D
C
A
No entry
No entr y
Click!
ID No. Year
XXXXXXXXXX XX
XXXXXXXXX XXXXXXX
Service XXX XXX XXX
assaabloyentrance.com
assaabloyentrance.com
H
Keep clear
Keep clear
G
DESIGNATIONART. NO.
YEAR+WEEK
1004083
XXXXXXX XXXXXXXXXXXXX
TYPE
XXXXXXXXXX
TEMPERATURE
XXXXXXXXXXXXXXX
LOAD
XXXXX
PROD. ORDER
XXXXXXX
XXXXXX
XX/XX
Hz
PROJECT/SERIAL NO.
XXXXXXXXXX
W
XXXX
AVAC
ASSA ABLOY Entrance Systems AB LODJURSGATAN 10 LANDSKRONA SWEDEN FACTORY NO. X
xxxxxxx
xxxxxxx 1002
SÜD
1 2 3 4 5 6 7 8
CLASSIFICATION DIN 18650
J
Automatic
door
Automatic
door
If problem oc-
curs
Action
Check that all required signage is applied and intact. Mandatory indicates that the signage is
required by European directives and equivalent national legislation outside the European Union.
Product label: Mandatory
A
ASSA ABLOY Entrance Systems door sticker: Mandatory, if applicable to highlight the
presence of the glass (applied to all glass sections that are moving).
B
Supervision of child (applied to both sides of the door): Mandatory according to national
regulations. Recommended, if the risk analysis shows use by children.
C
Operator designed for disabled people:
Recommended, if applicable (applied to both sides of the door).
D
Activation by disabled people: Recommended, if applicable.
E
No entry, identifying one-way traffic: Mandatory in GB and US, if applicable, not included
in the product.
F
Local product label
G
Keep clear
H
Automatic door
J
Contact your ASSA ABLOY Entrance Systems service representative. For contact information, see last
page.
=
13Issue 2018-03-091006492-en-3.0

Safety accessories
Even though the ASSA ABLOY CMD is installed to comply with all applicable safety regulations, it is
possible to enhance safety/comfort with the following add-ons (please contact your local
ASSA ABLOY Entrance Systems company for detailed description).
•Combined motion and presence sensors
•Separate presence sensors (presence in the door opening or side presence for the trailing edge
of the door)
General accessories
Your ASSA ABLOY CMD can be further improved with the following add-ons (please contact your
local ASSA ABLOY Entrance Systems dealer for detailed description).
Cover
Made in clear anodized aluminium as standard. Paint finished in RAL colours or anodizing optional.
Motion sensor and presence sensors
Add motion and presence sensors to improve comfort and safety.
Programme selectors
See page 7.
Electrical locks
The following locks are available to the operator:
•Locked with power (LDP), fail safe
•Locked without power (LD), fail secure
•Bistable lock (LDB)
Micro switch kit, LSK/LIS
For indication of door and lock position.
Electrical emergency unit with batteries
Used if a door is required to be opened or closed by means of a rechargeable battery unit and remain
in this position in the event of power failure. Authorities can demand that the emergency units are
monitored on a regular time basis. Half an hour before this time has elapsed the following opening
impulse generates an emergency opening test. If there is no opening impulse within the next half
hour, the operator control unit generates the opening impulse itself.
If the battery opens the door within the limited time the test is successful and the door resumes the
function set by the programme selector.
Note! The test is never performed in programme selector setting OPEN. In setting OFF it can be se-
lected. The test is always performed after a RESET and after changing program selection, from a pos-
ition where a test is not done to a position where the test is a demand.
Emergency closing with repeated closing
If the door is opened by hand after an electrical emergency closing, it will close again.
Mechanical emergency unit with elastic cord
Used if a door is required to be opened and remain opened by means of an elastic cord in the event
of power failure. Authorities can demand that the emergency unit is monitored on a regular time
basis. Half an hour before this time has elapsed the following opening impulse generates an emergency
opening test. If there is no opening impulse within half an hour, the operator control unit generates
the opening impulse itself.
1006492-en-3.0Issue 2018-03-0914

If the elastic cord opens the door within the limited time the test is successful and the door resumes
the function set by the programme selector.
Note! The test is never performed in programme selector setting OPEN. In setting OFF it can be se-
lected. The test is always performed after a Reset and after changing program selection, from a pos-
ition where a test is not done to a position where the test is a demand.
Interlocking
Used between two operators when the first operator must close before the other one can open
(typical to reduce energy losses and not for security reasons).
Synchronization
Used between the operators of two single sliding doors, working together in very large openings.
Convenience battery UPS
Stand-by supply which gives continued operation during short power failure.
External error indication
Obtained if a lamp or a buzzer is connected.
Key switches (flush and/or surface mounted)
Used to give opening impulse to the door in any programme selector setting.
The key switch can also open the door when power is switched off, if a battery is fitted.
Push button
Used to give opening impulse to the door.
Emergency open impulse
Used to give opening (fireman's opening) impulse to the door in any operation mode selector setting.
With electrical emergency unit also during power failure.
Open / Close function
One button impulse, will alternate between Open and Close. The door will stand open until next
impulse or can after an adjustable time delay automatically start to close even if a new impulse is
not received.
15Issue 2018-03-091006492-en-3.0

Troubleshooting
RemediesWhat´s wrong?
The door does not open
Change the setting of the program selector.The motor does not start
Check the mains switch and fuse in the building.
Unlock the mechanical locks.The motor starts but stops during
opening Clean the floor guide.
Check for objects jammed under the door.
The door does not close
Change the setting of the program selector.The motor does not start
If a presence sensor is installed, check for and remove objects placed in the
presence zone.
Clean the floor guide.The motor starts but stops during
opening Check for objects jammed under the door.
The door moves slowly
Prevent traffic from using the door and allow it to close completely.
Allow the operator to control the closed position without interruption.
If the problem continues, please contact your ASSA ABLOY Entrance Systems representative.
Service/Maintenance
Service and adjustments performed by your ASSA ABLOY Entrance Systems-authorized representative
will ensure safe and proper operation of your automatic door unit.
Remember to keep “Service Log Book”and “Site Acceptance Test and Risk Assessment”documents
(PRA-0005) available. These are used together.
The table below shows the recommended interval in months, when to replace parts during preventive
maintenance. Talk to your ASSA ABLOY Entrance Systems representative to learn more about our
service offering.
Abusive
Environment
Cycles/hour in operation
Part NumberPart >100<100<10
High
Traffic
Medium
Traffic
Low
Traffic
24242424
33550475
Electrical emergency unit bat-
tery
12121212
331700121
Mechanical emergency unit
elastic cord
661224b
33831622
Floor guide shoe
Felt padded
12122436
830060
246313
Carriage wheel
Single
Anti-derailing
2436486033735251Tooth belt
Check that all required signage is applied and intact, see page 13. Also check other consumable
parts, such as brushes, door stops and glazing rubbers.
1006492-en-3.0Issue 2018-03-0916

Other products from ASSA ABLOY Entrance Systems
•Vertical lifting fabric doors•Door Systems
•Dock levelers•Balance doors
•Dock shelters•Air curtains
•Folding doors•Revolving doors
•High speed doors•Swing doors
•Loadhouses•Automatic and manual activation units
•Overhead sectional doors
•Service such as preventive maintenance and upgrade programs, emergency repairs, service
advice and door management
17Issue 2018-03-091006492-en-3.0

ASSA ABLOY Entrance Systems is a leading supplier of entrance
automation solutions for efficient flow of goods and people. Building
on the long-term success of the Besam, Crawford, Albany and Megadoor
brands, we offer our solutions under the ASSA ABLOY brand. Our
products and services are dedicated to satisfying end-user needs for
safe, secure, convenient and sustainable operations.
ASSA ABLOY Entrance Systems is a division within ASSA ABLOY.
assaabloyentrance.com
ASSA ABLOY Entrance Systems
Tel: [phone]
[e-mail]
assaabloyentrance.com

Originální pokyny
Uživatelská příručka
Systém obloukových posuvných dveří
ASSA ABLOYCMD
ASSA ABLOY Entrance Systems
ILL-00224
assaabloyentrance.com
assaabloyentrance.com

OBSAH
4Pokyny k bezpečnému provozu .....................................................................................................
5Blahopřejeme vám k nákupu nových automatických dveří! ................................................
5Rušení příjmu elektronického zařízení ........................................................................................
5Požadavky související se životním prostředím ..........................................................................
5Odpovědnost za výrobek ..................................................................................................................
6Záruka .....................................................................................................................................................
6Servis .......................................................................................................................................................
7Účel použití ...........................................................................................................................................
7.........................................................................................................................................
7Technické specifikace .........................................................................................................................
7Jak systém ASSA ABLOY CMD funguje ..........................................................................................
7Programové voliče ..............................................................................................................................
8Funkce programového voliče ...............................................................................
8Zamykání ...............................................................................................................................................
9Odemykání ............................................................................................................................................
9Standardní bezpečnostní funkce ...................................................................................................
9Přesné mikroprocesorové řízení ..........................................................................
10Bezpečnostní systém se snímači přítomnosti ..........................................................................
10Volitelné bezpečnostní funkce .......................................................................................................
10Nouzový únikový východ ..................................................................................................................
10Elektrická nouzová jednotka .................................................................................
11Pravidelné bezpečnostní kontroly .................................................................................................
14Bezpečnostní příslušenství ..............................................................................................................
14Univerzální příslušenství ...................................................................................................................
14Kryt .................................................................................................................................
14Snímačpohybu a snímače přítomnosti ............................................................
14Programové voliče ....................................................................................................
14Elektrické zámky ........................................................................................................
14Sada mikrospínačů, LSK/LIS ...................................................................................
14Elektrická nouzová jednotka s bateriemi ..........................................................
14Nouzové opakované zavření .................................................................................
14Pružné lanko mechanické nouzové jednotky ..................................................
15Vázané zamykání .......................................................................................................
15Synchronizace ............................................................................................................
1006492-cs-CZ-3.0Vydání 2018-03-282
