Power Max TAC-585 User manual

TAC-585
Semi-Commercial Treadmill User Manual
OWNER’S MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this
owner’s manual for future reference. The specifications of this product may vary from
this photo, subject to change without notice.

2
www.powermaxfitness.net
TABLE OF CONTENTS
WARRANTY 2
PRODUCT BRIEF 3
SECURITY PRECAUTIONS AND WARNING 5
INSTALLATION INSTRUCTIONS 7
USING INSTRUCTIONS 9
ROUTINE MAINTENANCE AND INSTRUCTIONS 14
1 YEAR LIMITED WARRANTY
PowerMax Fitness warrants to the original purchaser that this product is free from defects in material
and workmanship when used for the purpose intended, under the conditions that it has been
installed and operated in accordance with PowerMax Fitness's Owner's Manual. PowerMax Fitness's
obligation under this warranty is limited to replacing or repairing, free of charge, any parts which
may prove to be defective under normal home use. This warranty does not include any damage
caused by improper operation, misuse or commercial application. From the date of purchase, the
frame is warranted to be free from defects for 1(one) year*.
Customer Care
Phone: [phone]
Email: [e-mail]
Support / Complaint Generation: support.powermaxfitness.net
This warranty is extended only to the original owner and is not transferable. When ordering
replacement parts please have the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase
* Terms and Conditions Apply. For T&C visit www.powermaxfitness.net

3
www.powermaxfitness.net
1. PRODUCT BRIEF
Single function Motorized Treadmill
Main Parameters and Parts List
Main Technical Parameters
No. Parameters Names Description
1 Rated voltage 220-240V
2 Rated frequency 50-60Hz
3 Speed 1.0-20 km/h
4 Running surface 1450 * 580mm
5 Max user weight 150kg
6 Expand dimensions 2040*930*1400mm

4
www.powermaxfitness.net
Accessory Bag List
No. Name Qty.
1 Screw M10*50 4
2 Screw M8*25 4
3 Inner hexagon spanner 5mm 1
4 Inner hexagon spanner 6mm 1
5 Silicon oil 1
6 User manual 1
7 MP3 Cable 1
8 Power line 1
9 Safety key 1
Packing List
No. Name Unit Qty
1 Complete machine Set 1
2 Side Cover Set 1
3 Protective cover Set 1
4 Accessory bag Set 1

5
www.powermaxfitness.net
2. SECURITY PRECAUTIONS AND WARNING
Note: Please read the instructions carefully before use.
♦Indoor using and storing the treadmill, avoid dampness, and cannot be spilled by water.
♦Please wear suitable clothes and sneakers before exercise. Prohibited to exercise on the
treadmill barefoot.
♦High power plug must be grounded, electric outlet should have a dedicated circuit, do not
share with other electrical equipment.
♦Keep children away from the machine to avoid accidents.
♦Avoid too long time and overload operation, otherwise will cause motor and controller
damaged, and will accelerate the deterioration of bearing, running belt and running board.
Should maintain machine on a regular basis.
♦Keep machine away from dust to avoid strong static.
♦Please cut the electric power off after using.
♦Please maintain good ventilation when running.
♦Please clamp security lock cable on your clothing to make sure the machine stops at
emergency condition.
♦If you feel not very well when using this machine, please stop and consult a doctor.
♦Silicone oil must be kept away from children after use.
♦If power cord is damaged, please contact our qualified maintenance personnel
for service rather than disassemble it at your own discretion.
Forbidden
♦Don't use the machine in the status of the shell break in or break off （the internal structure
exposed）or under the condition of welding-parts may fall off.
---- Otherwise an accident or injury may happen.
♦Don't jump up and down in the process of movement.
---- May be injuries caused by the fall.
♦Don't keep machine in or near moist space such as the bathroom.
♦Don’t place machine in direct sunlight, or high temperature places such as near a stove or a
heating appliance.
----Otherwise may cause the leakage and burst into flames.
♦Don't use when the power cord is damaged or power plug pin is loose.
----Otherwise will lead to an electric shock, short circuit or fire.
♦Don't damage or bent by force or reverse the power cord. Don’t place heavy objects on
machine, don't clamp the power line.
----Otherwise will cause fire or get an electric shock.
Tips: Before folding the treadmill, make sure that the gradient is "zero".

6
www.powermaxfitness.net
♦Don't use machine for more than 2 people at the same time, and don't get close to the
machine when it is in use.
---- Or it may be an accident or injury due to falls.
♦People who can’t express their consciousness or can’t operate the machine by themselves
cannot use the treadmill.
----May occur accident or injury.
♦Avoid drinking water or pouring water when operation.
---- May cause electric shock and fire. Forbidden!
♦People who seldom do exercise shouldn't suddenly do intense exercise.
♦After eating or when feel tired, do not use machine.
---- May lead damage to your health.
♦This product is suitable for family use, does not apply to schools, gymnasium and so on. ----
There is the danger of injury.
♦Don’t use when hard objects are in pants pockets.
----May cause accident or injury.
♦Don’t use when the power plug is on the needle, garbage, or water.
----May cause electric shock, short circuit, or fire. Do not use with wet hands!
♦when not in use, pull out the power plug from the socket.
----The dust and moisture can age the insulation, and result in leakage fire.
♦This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
♦Children should be supervised to ensure that they do not play with the appliance.
Ground Protection System!
♦This product must be grounded. If the machine is dysfunctional, grounding will provide a
good channel for electric current, in order to reduce the electric shock risk.
♦This product is equipped with power plug with grounding conductor and plug. Completely
insert the plug to standard socket.
♦If the equipment grounding conductor’s connection is improper, it will cause electric shock.
If you have doubts about whether your product is grounded correct or not, please entrust
professional to check.
♦Please use the socket which has the same shape with the grounding plug. Don’t use plug
adapter.

7
www.powermaxfitness.net
3. INSTALLATION INSTRUCTIONS
When installing, simple fix all screws first, then tighten screws when the installation of frame is done.
1. Put the machine flat on the ground. Cut the nylon cable ties on the base. Then stand the columns
and console with the direction shown in the picture below (The machine is heavy, please ensure there
are two people to install it).
2. Use 6# inner hexagon spanner, screw M10*50, screw M8*25 to lock the columns on the base, as
shown in the picture bellow (do not tighten it).
3. Use 6# inner hexagon spanner and screw M8*25 to lock the console on the columns (do not
tighten it).
4. (Before step 5, please tighten all screws first. If it’s multifunction model, please do this step at last)
Use screwdriver to remove the preinstalled screw M5*14 and use these screws to fix the base corner
protective covers on the columns.
M10*50
M8*25

8
www.powermaxfitness.net
5. Silicon oil needs to be added before using the treadmill, method is as follow:
A. Open the cover of the silicon oil tube
on the front motor cover.
B. Cut the upper part of the silicon oil
bottle.
90ml Scale
C. Squeeze the silicon oil from the
hole site (not more than 90ml,
otherwise it will overflow), and
then press the cover back.
M5*14

9
www.powermaxfitness.net
7. Put the safety key on the picture showing place and press the start button to start the treadmill.
NOTE: please confirm that all screws are locked uniformly according to the requirements after
installation, and check no part is left out before plugging electricity.
4. USING INSTRUCTIONS
Using treadmill
1. Insert the power plug properly and turn on the switch (in red color) (1). When the light is on,
there will be beep sound, and then the screen will be light up (Systems of TFT screen takes more
time to enter the start interface).
6. Plug the power line as showing
Safety key is in red
color. Please find it in
the accessory bag.

10
www.powermaxfitness.net
2. Please keep the safety key away from children when the treadmill is not in use. Please put the
silicon oil bottle in places children cannot reach. If it is eaten or split into eyes by mistake, please use
water to wash and consult doctor immediately.
3. Safety key Introduction
The treadmill can only start when the safety key is put on the yellow area of the
console. Clip the safety key on clothes when using the treadmill to prevent
accidents. Put the safety key back when continue using the treadmill.
4. Folding Instructions
Fold the treadmill: It will save space when the treadmill is folded. Please turn off the switch and pull
out the power plug before folding. Lift the running deck until it is held. Unfold the treadmill: Kick the
pressure rod, hold the running deck and then let the running deck to fall gradually.
We advise to add silicon oil according to the following schedule:
A. Light user (Use the machine less than 3 hours per week): Open the motor cover once in a
month to check and make sure the oil in the oil tank is no less than 30ml.
1
Kick this
part to
lower the
running
deck

11
www.powermaxfitness.net
B. Heavy user (Use the machine more than 7 hours per week): Open the motor cover once in half
month to check and make sure the oil in the oil tank is no less than 30ml. If it’s lower than
30ml, please add silicon oil. For better maintain the treadmill and expand the lifespan of the
machine, we advise you turn the machine off and let it rest for 10 minutes after continuous
use of every 1 hour.
5.1 Display Instructions
5.2 Amount of programs
3 modes and several automatic programs.
5.3 Safety lock function
Disconnect the security lock, "E7" shows on the screen and the treadmill stops immediately. Put the
safety key back, all the data will be cleared in 2 seconds.
5.4 Key function
5.4.1 Start button, Stop button：
When the power is on, press the start button, the treadmill starts. Stop key: when the treadmill is in
running state, press the stop button, all data will be cleared, and the treadmill gradually comes into
a complete stop and returns to the manual mode.
5.4.2 Program key
In standby mode, pressing this key can cycle the options from manual mode to automatic programs.
Manual mode is the system defaulting running mode.
5.4.3 Mode key
In standby mode, press this key can cycle the options of 3 different countdown running mode: time
countdown running mode, distance countdown running mode and calorie countdown running
mode. Use speed button to set the parameters.
5.4.4 Speed ± key
Use these keys to adjust the speed of the treadmill. Press speed+ to increase the speed and press
speed- to decrease the speed.
Note: When machine at the running state, turn the knob to the right, speed increase; Turn the knob
to the left, speed decrease.
5.4.5 Speed cycle key
When the treadmill is running, press the "speed 3/3/6/12" button, and the speed switches between
3/6/9/12;

12
www.powermaxfitness.net
5.4.6 Incline ± key
When the treadmill is in running state, use these keys to adjust the incline of the treadmill. Press
incline+ to increase the incline and press incline- to decrease the incline.
5.4.7 Incline quick keys
When the treadmill is on running state, press these keys to change the incline directly to 3/6/9/12%.
5.4.8 Volume ± key
Press volume+ to turn the volume up and press volume- to turn the volume down. If there’s no
sound, please press volume+ for a while and the volume will be turned on.
Note: If you cannot connect the treadmill Bluetooth speaker or APP, please check whether there is a
plug the MP3 cable in the AUX hole or the U disk at the USB port; If it is plugged in, please unplug
it and then connect to Bluetooth.
6. Display function
6.1 Time Display
Display the current value of speed
6.2 Incline Display
Display the current value of incline
6.3 Time Display
Display the time under manual mode and the countdown mode.
6.4 Distance Display
Display the distance under manual mode and program and the countdown distance under
countdown mode.
6.5 Calorie Display
Display the calorie under manual mode and program and the countdown calorie under countdown
mode.
6.6 Heart Rate Display
In running mode and standby mode, display the heart rate value and the heart icon flashes while
testing. (This number is for reference only. It cannot be considered as medical data.)

13
www.powermaxfitness.net
Automatic programs
Time
Program
Set time / 10 = Running time of each period
1 2 3 4 5 6 7 8 9 10
P1 SPEED 3 3 6 5 5 4 4 4 4 3
INCLINE 0 3 3 3 4 4 4 1 1 0
P2 SPEED 3 3 4 4 5 5 5 6 6 4
INCLINE 2 2 2 3 3 3 3 4 4 2
P3 SPEED 2 4 6 8 7 8 6 2 3 2
INCLINE 3 5 4 4 3 4 4 3 4 2
P4 SPEED 3 3 5 6 7 6 5 4 3 3
INCLINE 0 3 3 2 2 5 5 3 3 2
P5 SPEED 3 6 6 6 8 7 7 5 5 4
INCLINE 3 5 3 4 2 3 4 2 3 2
P6 SPEED 2 6 5 4 8 7 5 3 3 2
INCLINE 3 4 5 6 3 5 5 6 4 3
P7 SPEED 2 9 9 7 7 6 5 3 2 2
INCLINE 0 3 3 3 4 4 4 1 1 0
P8 SPEED 2 4 4 4 5 6 8 8 6 2
INCLINE 1 1 4 4 4 5 5 4 3 2
P9 SPEED 2 4 5 5 6 5 6 3 3 2
INCLINE 3 5 3 4 2 3 4 2 3 2
P10 SPEED 2 5 7 5 8 6 5 2 4 3
INCLINE 1 5 6 8 12 9 10 9 5 3
P11 SPEED 2 5 6 7 8 9 10 5 3 2
INCLINE 3 5 6 8 6 5 8 7 5 2
P12 SPEED 2 3 5 6 8 6 9 6 5 3
INCLINE 5 7 5 8 6 5 9 10 6 2
Meaning of Error Codes
Fault code Failure Description Fault handling
E1
Communication Abnormal:
when the power is on, the
connection between lower
controller and the console is
abnormal.
Possible Cause: the communication between the lower
controller and console is blocked, check each joint between the
controller and console, ensure that each core is fully plugged in.
Check the connection line, replace it if it’s damaged.

14
www.powermaxfitness.net
E2 No signal from motor.
Possible Cause:
Check the motor cable to see whether it is connected well or
not, if not, connect the motor wire again. Check the motor
cable to see whether it is damaged or has a burnt smell, if yes,
replace the motor. Check the speed sensor to see whether it is
correctly installed or damaged
E5
Over current protection:
In working, the lower
controller detects the
current to be over 6A for
more than 3 seconds.
Possible Cause:
Overloading leads to excessive current, and the system stop out
of self-protection, or some part is stuck, causing the motor to
stop. Adjust the treadmill and restart it. Check if there is liquid
or burnt smell while the motor is running, if yes, replace the
motor; check if the controller has a burned smell, if yes, replace
the controller;
check the power supply voltage, if it does not
match the specifications, change into correct voltage and test
the machine again.
E6
Explosion-
proof impact
protection: the abnormal
voltage or motor cause the
faulty of circuit
that drive
the motor.
Possible Cause:
Check if the power supply voltage is 50% lower than normal
voltage ，use the correct voltage and test the machine again；
check if the controller has a burnt smell and replace the
controller; Check if the motor cable is connected and connect
the motor wire again.
E7
Without putting the safety
Key Put the safety Key on the right place.
5. ROUTINE MAINTENANCE
Warning: Before cleaning or maintaining products, please be sure the power plug of the
treadmill is pulled out.
Cleaning: Comprehensive cleaning will extend the using life of the electric treadmill.
Remove dust periodically in order to keep the parts clean. Be sure to clean running belt with both
sides of the exposed portion, which will reduce the accumulation of impurities. Make sure to wear
clean athletic shoes to avoid carrying the dirty matters into running board and belt. Treadmill belts
shall be cleaned by a damp cloth with soap. And please pay attention to avoid too wet the electrical
components and running belt.
Warning: Make sure power plug disconnect before moving motor cover away, clean the motor at
least once a year.
Running belt specialized lubricant
This electric treadmill’s running board and running belt has been lubricated in factory. Friction
between the running belt and running board has a great influence to the using life and the

15
www.powermaxfitness.net
performance of the electric treadmill, therefore regular applying of lubricant is needed. We advise
you to check the board regularly. If the board’s surface is damaged, please contact our customer
service centre.
We advise using lubricant between running belt and running board with following schedule:
Lightweight user (use less than 3 hours a week) once per month;
Heavyweight use (use more than 7 hours a week) once every half month.
1. In order to maintain your treadmill better and extend the life of the machine, it is suggested that
after your continued use of one hour, turn off the machine and let it rest for 10 minutes before using
again.
2. If the treadmill belt is too loose, there will be skid phenomenon’s while running; if it’s too tight, it
may reduce motor performance and harden the abrasion of roller and the running belt. You can lift
two sides of the running belt for 50-75mm when the tightness is appropriate.
Running with adjusted alignment and tightness
In order to better use the treadmill and make the treadmill functions work better, it is necessary for
you to adjust the running belt into the best condition.
Running Belt alignment
•Put electric treadmill flat on the ground.
•Make the electric treadmill run at a speed of about 6-8km/hour.
•If the running belt is closer to the left, rotate the left adjusting bolt with 1/2 turn clockwise,
then rotate the right adjusting bolt with 1/2 turn counter-clockwise. (Picture A)
•If the running belt is closer to the right, rotate the right adjusting bolt with 1/2 turn clockwise,
then rotate the left adjusting bolt with 1/2 turn counter-clockwise. (Picture B)
Picture A Picture B
Multi-wedge Belt Tension Adjusting
When you use the treadmill for a long time, the multi-wedge belt becomes loose because of the
abrasion, then you have to do some appropriate adjustment to facilitate the safe use.
Judgment: the feeling of running with the occasional pause phenomenon, which indicating that the
treadmill belt or multi-wedge belt are a little loose and further affirmation need to be made.
Method of judging which part is loose: Remove the four screws on protective cover, make the
treadmill run at a speed of 1 km/h, and then stand on the running belt, grip the armrests, and tread
the treadmill belt slightly. (we advise treading the treadmill belts with the user's own weight)

16
www.powermaxfitness.net
A. The instantaneous step cannot stop the belt, the tightness is appropriate.
B. If your instantaneous step stops the running belt, but the multi-wedge belt and former roller
is still running, it indicates that the running belt is loose and appropriate adjustments must
be made to facilitate the safe use
C. If you observe that the instantaneous step makes the treadmill belt and multi-wedge belt
stop, but the motor is still running, it indicates that the multi-wedge belt is loose and
appropriate adjustments must be made to facilitate the safe use
Step 2: Use a wrench to adjust the screws on the motor base according the condition. Meanwhile,
gently flip the multi-wedge belt between the motor shaft and the front roller, if it is too loose, you
can flip the multi-wedge belt by 100%; if it is too tight, the degree for you to flip the belt is very
limited. It is appropriate to flip the multi-wedge belt by 80% after adjustment. Please adjust the
tightness of the multi-wedge belt into the state that it could be flipped by 80%.
Step 3: Finally lock the motor base, and install the front cover.
Lubrication Method
The running belt is pre-lubricated in factory. The abrasion between running belt and running board
will influence the lifespan of the product, therefore, the product needs to be lubricated regularly.
Light user (use the machine less than 3 hours every week): Once per month.
Heavy user (use the machine for more than 7 hours every week): Once per half month.
1. Add silicon oil: Before using the machine for the first time, it has been to be lubricated. The
method is as below:
1.1. The oil tank tube is at the front side of the motor cover. Open the oil tank cover and cut the
head of the silicon oil bottles.
1.2. Squeeze the 4 bottles of silicon oil into the oil tank.
2. Automatic Lubrication: After adding oil into the oil tank, the treadmill will lubricate automatically
according to the use of machine. (default setting is to lubricate every 30km and lubricate for 3
seconds with 2.5ml.)

17
www.powermaxfitness.net
3. Manual Lubrication Method: If the machine is not in use for more than 3 months, the silicon oil
will volatilize with the influence of whether or temperature. Users can add oil manually to let it
lubricated quickly and the running belt will work more smoothly. Manual lubrication method is as
below:
3.1: Machine with LCD Screen: Turn the machine on and let it run. Press Start button for 3 seconds
and then it will lubricate automatically. (If you want to lubricate more, please switch the machine off
and turn it on to repeat the method again.)
3.2: Machine with Touch Screen: When the machine is on, press Setting- Lubricate- Manual
Lubricate.
Note: Please use manual lubrication carefully. If the machine is over lubricated, the belt will be
too slippery to use.
