Power Max TDA-125 User manual

TDA-125
Treadmill User Manual
OWNER’S MANUAL
Read all instructions carefully before using this product. Retain this owner's manual
for the future's reference. Product may be slightly different with photos, it is subject
to actual product. Thank you for purchasing the product.

www.powermaxfitness.net
2
TABLE OF CONTENTS
WARRANTY
02
PRODUCT BRIEF INTRODUCTION
03
PARTS LIST
04
SECURITY CONSIDERATIONS AND WARNINGS
05
INSTALLATION
09
SPORT SUGGESTIONS AND GUIDING PRINCIPLE
11
BRIEF USAGES INSTRUCTIONS
13
PRODUCT MAINTENANCE
17
TROUBLESHOOTING GUIDE
19
1 YEAR LIMITED WARRANTY
PowerMax Fitness warrants to the original purchaser that this product is free from defects in
material and workmanship when used for the purpose intended, under the conditions that it has
been installed and operated in accordance with PowerMax Fitness's Owner's Manual. PowerMax
Fitness's obligation under this warranty is limited to replacing or repairing, free of charge, any
parts which may prove to be defective under normal home use. This warranty does not include
any damage caused by improper operation, misuse or commercial application. From the date of
purchase, the frame is warranted to be free from defects for 1(one) year*.
Customer Care
Phone: [phone]
Email: [e-mail]
Support / Complaint Generation: support.powermaxfitness.net
This warranty is extended only to the original owner and is not transferable.
When ordering replacement parts please have the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase
* Terms and Conditions Apply. For T&C visit www.powermaxfitness.net

www.powermaxfitness.net
3
1. PRODUCT BRIEF INTRODUCTION
Product Name: Motorized Treadmill
Model Number: TDA-125
Electronic
Safety
Upright
Run platform

www.powermaxfitness.net
4
Technical Parameters
No.
Parameters Name
Description
1
Running Area
1260*420(MM)
2
Max Allowable weight
115KG
3
Expand Size
1550*710*1260
4
Voltage/Frequency
AC220V 50/60HZ
5
Speed
0.8-14KM/H
6
Function
Run /Audio/ /HR
Parts Number List
No.
Item
Qty
Use
1
6 mm Internal Hexagonal Screw M8×20
6
Upright fixed, computer fixed
2
6 mm Internal Hexagonal Screw M8*45
4
Upright fixed
3
6 mm Internal Hexagonal Screw M8*40
4
U tube fixed
4
6 mm Internal Hexagonal Screw M8*65
2
5
M8
8
6
ST4*16
4
Upright cover fixed
7
Multi-functional Screw Driver
1
8
5 mm/6mm Internal Hexagonal Wrench
2
9
Si-oil
1
10
Safety key
1
11
MP3 wire
1

www.powermaxfitness.net
5
2. SECURITY CONSIDERATIONS AND WARNINGS
Attentions:
Please read manual carefully before use, and pay attention to security considerations followings,
Treadmill should be placed suitable position in interior, avoiding damp, could not be splashed by
water-drop, could not be put on any other objects.
Before exercise, please put on suitable sport suits, sport shoes. It is forbidden running on the
treadmill and spreading oneself under bear feet.
Power plug must be earthed, and there must have appropriative loop in plug seat. refraining from
others electrical equipment to share.
The kids must keep away from treadmills, averting accident.
It should avoid exceed time load working, or else it will result in the damage of motor and
controller, accelerating the wearing and maturing of the bearings, running belt, and running
deck.it should be maintenance termly.
Reduce the dust inside, keep interior a certain amount of damp to avoiding coming out strong
electrostatic, or else it could affect proper functioning of meter and controller.
Please shut down the power of the treadmill after over use.
Please keep airiness in interior when using the treadmill.
Please nip the safety key into the clothes to stop in case of coming across critical situation.
If you feel uncomfortable or abnormal condition, please stop running, and consult your doctor.
Si-oil used up must be put where the kids can’t find, in case to eat and result in far more serious
consequences.
Warnings!
In order to reduce the accident happens or hurt others, please observe the following rules:
•Please check whether the clothes are buttoned or zipped or not.
•Don’t put on the clothes which is easy to be hooked by the treadmill
•Don’t let the kids be near to the treadmill
•Don’t use the treadmill outside
•It must be cut down the power before moving the treadmill
•Don’t dismantle the treadmill unless professional persons, or else it could come out serious
consequences
•The treadmill is used only in 20 Ampere circuitries

www.powermaxfitness.net
6
•The treadmill is only for one person to use when it was started
•If you feel dizziness, pectoralgia, stomach-turning or tachypnoea, please stop right now and
respectively consult your gymnasium coach or doctor.
WARNINGS! FORCING!
◆One on treating or following patient makes sure to talk over with professional doctor, and then
can use Backache or leg, waist, neck hurt before, leg, waist, neck and hand numbness
(Protrusion of intervertebral disc, Spinal Slide Disease, Protrusion of Cervical vertebra Disease,
and so on)
◆Deformability arthrophlogosis, Rheumatic, Gout. etc.
◆Osteoporosis etc. unusual patients
◆Circulation System Obstacle (Cardiopathy, Vascellum Obstacle, Hypertension Disease) etc.
◆Respiratory Organ
◆Under use artificial heart rate regulator, which is put into body.
◆Cancer
◆Thrombosis or Dynamic Fang tumour, Acute Static Fang tumour etc, Vascellum Obstacle or
Skin Infection disease.
◆Enthesis Obstacle caused by Higher Tip Circulation Obstacle caused by Glycuresis
◆Skin hurt
◆As sick in a high fever (38 degree or up)
◆Spine unusual or inflected
◆On Pregnancy or could be Pregnancy or on Menstrual Phase
◆Sense body unusual, need to convalesce
◆Obvious in a bad condition on body
◆As aim to recover
◆Sense body unusual except for above
----Probable to result in accident or worse physical condition
Sense backache, legs and feet numbness, Dizziness, heartbeat, etc. unsuitable in body, stop use
right now and then look for doctor to consult
•Don’t allow the kid to use the treadmill, keep them away around of treadmill to play
----If don’t observe, it probably will have been hurt in danger
When use or take out or in the product, or move it, please make sure to confirm the round the
treadmill whether have persons or pets

www.powermaxfitness.net
7
FORBIDDEN!!
•Don’t use it in state of outer shell rupture, cracking, fallen off, or the welding fallen off
----Or else it will probably come out accident or hurt
•Don’t jump out or in the treadmill when running
----Or else it will probably hurt as falling down
•Don’t use and look after the treadmill where outside and near bathroom etc. high damp and
more water-drop venue.
•Don’t use or look after the treadmill where direct sunlight, around of furnace etc. high heat
and above the electric blanket etc., heater.
----Or else it will probably result in leakage of electricity, fire
•Don’t use when power wire or power plug damage or socket faucet loose.
----Or else it will probably result in electric shock, short circuit, fire
•Don’t damage or bend or twist the power wire. At the meanwhile, don’t set high weight
above it, don’t make it be infibulated
----Or else it will probably result in electric shock, fire
•Don’t use it over 2 persons, at the meanwhile, don’t let others around persons near to the
treadmill when running,
----Or else it will probably come out accident or hurt as falling down
•Don’t use who could not express feelings or operate by his/herself.
----Or else it will probably come out accident or hurt
•Absolutely prohibit disassembling, fixing, remould.
•it will probably come out mechanical failure on danger of hurt
•avoid touching water!
•Body or operation part should be far away from water and drink
•Don’t do intense sport who often don’t sport
•Don’t use after meals or feeling tired, just did sports or unusual performance status
•it will probably harm health
•The product is for home use, could not use for school, Gym, etc. others places
•It will probably be harmful with danger
•Don’t use when have diet and do other sports at the meanwhile

www.powermaxfitness.net
8
•Don’t use when feel thick-skulled after being drunk
----it will probably come out accident or hurt
•Don’t use when the pockets of pants put in tough objects
----it will probably come out accident or hurt
•Don’t make the power plug attach needle, water, or rubbish
----Or else it will probably result in electric shock, short circuit, fire
•Don’t use on wet hands!
Don’t take out or plug in power plug on wet hands!
----Or else it will probably result in electric shock and hurt
•Take out the power plug!
Take out the power plug when no use
----If not that, it can result in lack of electricity and fire as for insulation wire under dust and damp
Earthed Instruction
◆The product must be earthed. If the machine happen malfunction, the earthed will provide
electric current of passageway of minimum resistance to reduce the danger of electric shock.
◆The product is equipped with equipment ground conductor and earthed power plug wire, the
power plug must be plugged in replying on local law and rules under proper assembling and
earthed, applicable socket.
DANGER!!
•If equipment ground conductor is connected undeservedly, then, will result in danger of
electric shock. If you have questions whether is right ground for the product. please entrust
professional wireman to check. Even product power plug doesn’t match the socket, you still
could not remake it.
•Please ensure professional wireman to equip proper socket
•There is ground plug in the product, please confirm the product whether connected with
same sharp as socket, the product could not be used multi-tap

www.powermaxfitness.net
9
3. INSTALLATION
When installing, first simply fix all the screws, and then tighten up after the shelf has been installed.
Step1
Upright:
1.Uplift part of the upright and electronic watch dial,
use one M8*45 screw respectively on both sides of the
treadmill to pass through the below connection hole,
add the shims and tighten up the screws.
2. Tighten up the two uprights with two M8*20 Screws
Step 2
Electronic watch and hand grip Tighten up the hand
grips on both sides with M8*20 screw separately by
making them pass through handgrip hole and
connected with the uprights.
Step 3 (only for multifunction)
up and down U-shaped tube
First place the rubber protection sleeve at each side of
U-shaped tube, assembly 2 ends of U-shaped tube to
iron plate of left and right stand column with M8*40
screws, lock with nuts (special attention, the middle
screw hole of U-shaped tube point to the bevelled-up
direction-tube should not trap the L iron. Put on the
above it's approved. Down U-tube with foam, and
upper without it) see on the right picture

www.powermaxfitness.net
10
Step 4 (only for multifunction)
Functional frame
Use two M8*65 screws to fix the functional frame on
the top and bottom U tube.
Step 6 (only for six level shock Absorption system)
remove safety fixed button, use Allen wrench remove
two bolts
Step7 (only for six level shock Absorption system)
Install rubber decoration cover put the rubber
decoration cover to the Threaded hole based on step
6.
Step 5 (only for multifunction)
Massage
First, screw off the three M8*16 screws below the
massage machine head, (include flat washers and
spring washers), and then place the massage machine
head on the functional frame, and tighten up with the
above unloaded screws.

www.powermaxfitness.net
11
4. SPORT SUGGESTIONS AND GUIDING PRINCIPLE
Warm-up
Every time you need to do warming-up in 5 to 10 minutes before use this treadmill
Breath
You could not hold the breath when running, usually you prepare to do/undo action breathing by
nose, exhale emphatically by mouth, breath should be harmonious with actions
If you are in tachypnoea, you should stop sporting promptly
Frequency
It needs 48 hours rest after same part muscle got trained, next day the same part muscle can be
trained again
Burthen
Personal performance status makes up training component，and then to be trained as the
principle of ordinal approximate burthen, it is normal for muscular soreness of training at the first,
only go on training, the soreness will be out Relax
Do/undo action in 5 minutes after per training, especially the spread and relaxation, so as to avoid
the muscle congealed, keeping the muscle whippy
Diet
In order to protect digestive system, you can train in 1 hour after a meal, you can have meal in at
least half an hour after training, and drink little water in training, never drink more water, in order
to avoid adding burden to heart and kidney.
Stretching exercise
No matter what speed you run, you’d better do stretch exercise at the beginning, it is much
easier to do stretching exercise on warm muscle, so you need to cost 5-10 minutes to be warm-
up. Then, stop to do stretching exercise 5 times as following ways, every leg needs to be done
every 10 second or more, after training over, you need to do stretching exercise again.

www.powermaxfitness.net
12
1. Downward Stretch
The body bends forward slowly so that the back and
Shoulders relaxed, hands to touch the toes as far as
possible. Maintain 10 to 15 seconds, and then relax.
Repeated 3 times (see Figure 1).
2. Crus Sinew Stretch
Put one leg straight, the other leg inward to keep
Straight the inside. A hand to touch the toes as far
as possible. Maintain 10 to 15 seconds, and then
relax. To do a leg each repeat times (see Figure2)
3. Crus and Heal Sinew Stretch
Two hands extending wall or table stand, one foot
In the post. Hind legs to keep upright and lean to the
walls or trees direction. Maintain 10 to 15 seconds, and
then relax. To do a leg each repeat 3 times (see Figure 3).
4. Muscles Stretch
Right hand extending the wall or cable, keep balance,
Then the left hand back stretches to seize the left ankle
to the hips slowly pulls, until you feel the front thigh
muscles tense. Pull about 10 ~ 15 seconds, then relax.
To do a leg each repeat 3 times (see Figure 4).
5. Sartorius Muscle (Inner Thigh Muscles) Stretch
The sole of the feet relative, seated knee outward.
Hands grasp the feet to the groin direction pull slowly.
Maintain10 to 15 seconds, then relax. Repeated 3 times
(see Figure 5).

www.powermaxfitness.net
13
5. BRIEF USAGE INSTRUCTION
1. CONSOLE
2. SPEED: Rang 0.8-14.0KM/H. The LCD will show numbers 3,2,1, then, Starting treadmill. The
setting and data shows in LCD display during fat measurement.
3. TIME:
A. Manual Model: Setting time 0-100 minutes or ‘end’ shows in LCD display, the speed of
treadmill will be slow stably and standby time after 5 minutes.
B. Distance & Calories model: Setting 0-100 minutes or ‘end’ shows in LCD display and finished
it OK. Keep Moving. If setting 100-0 minutes, or ‘end’, show in LCD display, the speed of
machine will slow stably and stop. Standby time after 5 minutes.
C.DIS
Sports distance: Setting 0-100 minutes or ‘end’ show in LCD display, speed down and stop
stably. Standby time after 5 minutes.
D.CAL/PULSE
Expend Calories:0-999 or ‘end’ show in LCD display, speed down and stop stably. If setting 999-
0 or ‘end’, The treadmill will stop and standby time after 5 minutes.
Pulse value: When you running and catch the handrail, the system will be auto-checking your
pulse value. The reference pulse value:50-200 time/min.
E.INC
Incline way range: It is adjustment 0-18% auto incline.

www.powermaxfitness.net
14
2. KEY FUNCTION.
‘SELECT’ KEY:
Manual Model: 0:00
Count down Time model: 15:00 MIN: SECONCDS.
Count down distance model: 1.00 KM
Calories: 50.0
Inner Procedure: P01-P12.
‘START’ KEY: Starting the treadmill as long as power on and safe key grip compete.
‘STOP’ KEY: Pressing it later. STOP treadmill running.
SPEED: ‘+’ this sign to be increase the speed. ‘-’ this sign to be decrease the speed. If you
press it over 0.5 continues + or - sign, the speed will be automatic increasing or decreasing.
SPEED 6,8,12 No. Show in console.it means fast speed shortcut key. E.G., It can adjust the speed
6KM smoothly.
SMART: Start the SMART mode, the treadmill memorizes this motion track automatically, such as
the speed and slope values of different time periods. If the motion time exceeds 10 minutes, the
motion track data will be saved or it will be discarded. The next time the SMART mode is started,
it will run according to the current motion track automatically. If the user modifies the speed or
slope, the treadmill will abandon the track repeat function. The user must adjust the speed and
slope automatically (full manual mode), but the motion time exceeds 10 minutes, the current
motion track will be saved, covering the previous motion track data.
3. FAST STARTING (MANUAL MODEL)
Pls following operation step by step.
POWER ON/OFF--------POST SAFE KEY GRSIP-----------START KEY------SPEED ‘+’ OR ‘-’
AND INCLINE ‘+’ OR ‘-’
4, MANUAL MODEL
•1.STARTING:0.8KM/H---------SPEED ‘+’ OR ‘-’ AND INCLINE ‘+’ OR ‘-’
•2.MODE KEY----------TIME window:15:00 twinkle.
The INCLINE+ or - and SPEED + or - can adjust the time. The range of time: 5:00-99:00.
4. FUNCTIONS OF THE SAFETY LOCK:
In any state, if pulling off the safety lock, you may immediately stop the motor running, and then
the time window will display the marks “------“, and the buzzer will emit “B1-B1-B1” alarm
sound. At this point, except for the shutdown, the any other operations cannot be implemented

www.powermaxfitness.net
15
to the treadmill, while the safety lock is correctly reinstalled, the treadmill will enter into the
standby mode again, and wait for inputting the command.
Before making the exercise, you should firstly inspect that whether the treadmill has been loaded
the power supply, and then check whether the safety lock is effective.
If taking place, the abnormal situations during the motion, you may pull off the safety lock, and
then the treadmill will quickly decrease the speed until the stop; while the safety lock is put into
again, this device will be reset to wait for inputting the command.
5. MP3, USB MUSIC PLAY FUNCTION
•MP3 music play function
The 3.5 audio interfaces with the audio signals should be plugged into MP3 Play Jack, and then
the power amplifier circuit will automatically enlarge the audio signal, so as to output signal to
loudspeaker.
•USB Music Play Function
U Disk with MP3 files should be plugged into USB Jack, and then the machine will automatically
identify the audio files and play music.
The song should be selected by pressing “Last Song” and “Next Song”, and playing the music
should be started or paused by pressing “Play/Pause” Key. In addition, the volume should be
adjusted by pressing “Volume Increase” and “Volume Decrease” Key.
6. Bluetooth connection
Bluetooth App: Download Bluetooth app HK-Treadmill, from Google Play for Android OS system,
from App Store from Apple IOS system, then customers can control treadmill speed by mobile
phone.
7. Safety
In any circumstances, remove the safety switch, the system is down and sends alarm sound (all
the windows show “-”).

www.powermaxfitness.net
16
8. Attachment：P1-P12Program Sports Diagram

www.powermaxfitness.net
17
6. PRODUCT MAINTENANCE
Lubricating
The running belt must be lubricated with specially configured methyl silicone oil after used for a
period of time.
1. Advice:
When use time a week is less than 3 hours, it should be lubricated once in five months.
When use time a week is between 4-7 hours, it should be lubricated once in two months.
When use time a week is more than 7 hours, it should be lubricated once in one month.
It can’t be over-lubricated. It is not the more lubricant, the better. Remember: proper lubricating
is the important factor to increase the treadmill’s service time.
2. Lubricating methods
First: For the methods to examine whether it is needed lubricant, you only need catch up the
running belt and touch the central part of the back of the belt with hand as nearly as possibly. If
the belt is with silicon resin (a bit sense of dampness) inside, this means no lubricant is needed; if
the running board is dry and you feel no silicon resin inside, this means lubricant is needed.
A. Steps for coating the running board with lubricant: (see the picture)
B. Stop the rotation of the running belt and fold the machine.
C. Pick up the belt of the back of the body frame: stretch the oil holder as nearly as possible
into the moving place of the belt, coat the inner side of the belt with silicone oil and coat
both sides of the belt with silicone resin, and then operate the treadmill at the speed of 1K
M/H so as to evenly coat the silicone resin; and step on the belt from left to right for a few
minutes, then the silicone resin will be completely absorbed by the belt.
Second: Automatic refuelling: In order to ensure adequate lubrication between the treadmill and
running belt and to extend the service life of the treadmill, we equip the treadmill with an
automatic refuelling system that does not require manual refuelling to prevent forgetting to refuel
and damaging the treadmills. Treadmill cumulative operating mileage reaches the specified value,
the system will automatically add appropriate amount of oil to the treadmill and clear the
kilometre counter, restart the cumulative mileage. 5-inch blue screen run after running 300 km oil
bottle logo blinking, this time to remind users to refuel, you must press the Confirm button to
confirm the oil tank has been filled with oil, oil flashes logo back to normal.

www.powermaxfitness.net
18
3. Running belt tension adjustment
All treadmills’ belts should be adjusted before leaving the factory and after the installation,
however, after it is used for a period, looseness may occur. For example: when users are running,
it may occur pause and slip, if which happens, adjust the belt and bolts synchronously from both
the left and right side in a clockwise direction and with semicircle as the unit; if the running belt is
too loose, it may occur slip between the belt and the roller when treading on the belt; but if too
tight, it will be easy to increase the motor load and damage motor, running belt, roller, etc.
4. Running belt deviation adjustment
All treadmills’ belts should be adjusted before leaving the factory and after the installation,
however, after it is used for a period, it may occur belt deviation, which is caused by the following
reasons:
•The main engine is not placed evenly.
•The user’s feet are not on the centre of running belt.
If the deviation phenomenon is caused by the uneven force of the user’s feet, no-load rotation
for a few minutes can make it normal. For deviation phenomenon that can’t return to normal
automatically, adjust step by step by using 6MM inner hexagon spanner with the machine and
with quarter-circle as the unit. Running belt deviation is not covered in the warranty scope and is
mainly maintained by users according to the instruction book. Deviation phenomenon will
severely damage the running belt, so it should be found and corrected in time.
5. Driving belt adjustment
如果跑带左偏,则顺时针调节左
边螺丝或逆时针调节右边螺丝
如果跑带右偏,则顺时针调节右
边螺丝或逆时针调节左边螺丝
If deviate to the right, then
adjust the screw on the right side
clockwise or the screw on the left
side anticlockwise.
If deviate to the left, then adjust
the screw on the left side clockwise
or the screw on the right side
anticlockwise.

www.powermaxfitness.net
19
All the treadmills’ driving belts are adjusted before leaving the
factory, but after using for a period, it may still occur slip, which
is mainly adjusted by users. Adjustment steps (see the picture):
•Clockwise rotate adjustment screw with spanner.
•Adjustment scope is subject to no slip when loading.
Notice: Periodically clean the impurities in the belt groove and the belt wheel groove.
6. Treatment method of running belt slip or pause
First open the front motor cover, then open the treadmill, hold the hand grip with both hands,
step on the belt hard with your feet, watch it is the conveyor belt of the motor that pauses or the
running belt that pauses. If running belt pauses, adjust the running belt, while if conveyor belt of
the motor pauses, adjust the motor.
TROUBLESHOOTING GUIDE
Fault Code
Main reason
Solution
E01
The wire from computer to
bottom control board
didn’t connected well
1. Check the connection wire between
computer
and control board was well connected.
2. Make sure the IC on the control board was
well inserted. If not re-insert.
3. Abnormal power supply in control board.
Please change a new control board.
E02
Protect the exploding
1. Bad contact with motor open circuit. Please
change a new motor or check the connector.
2. Power tube was puncture. Please change a
new Power tube or control board.
E05
Over current Protection
1. Overloaded。
2. Running board with heavy resistance. Need
to be oiled
3. Damage in Motor. Change a new motor.
E06
Control board self-checking
E08
EEPROM damage
Change the control board
