Power Products LOGIC 8 User manual

INSTRUCTIONS
MODEL:LOGIC 8 ™P/N:BR8A
8 AMP BATTERY CHARGER FOR 24V
LEAD ACID AND NICKEL CADMIUM BATTERIES
Manufactured By: Power Products, Inc.
27Pamaron Way Ste E
Novato, CA 94949
Cage Code: 3C8X4
Tel: [phone] Fax: [phone]
www.power-products.com
www.power-products.com

TABLE OF CONTENTS
PAGE 2 …………………………………….DESCRIPTION
PAGE 3 ………………………………… SPECIFICATION
PAGE 4……………………………………..ACCESSORIES
PAGE 5…………………….….….……….INSTRUCTIONS
PAGE 6……..………….CALIBRATION VERIFICATION
PAGE 7 ………………….CALIBRATION CERTIFICATE
PAGE 8………………………………………...WARRANTY

DESCRIPTION
A) The Logic 8 is a fully automatic 8 Amp battery charger for 24V
Lead Acid or Nickel Cadmium batteries. Method of charge is
constant potential with initial constant current. It is lightweight,
compact and will operate on any worldwide AC input from 100 to
240 volts.
B) The Logic 8 will pulse charge a highly discharged battery. When
voltage climbs to approximately 17 volts pulsing stops and smooth
ripple-free charge occurs.
C) The battery can be left ON even when loading the battery.
D) The Logic 8 monitors charge progression. If abnormal progression
occurs the CHARGE CUT-OFF led will illuminate and charging
will cease. This may be due to an internal battery problem, i.e.:
shorted cell. This prevents the battery from over heating.
E) When a battery is charged, a timed topping mode will begin. The
topping voltage is adjustable by setting the Lead Acid or NiCad
adjust. At the end of the topping mode, a green READY led will
illuminate and charge stops completely. This avoids battery
deterioration that is a result of lengthy trickle or float charge. The
charge cycle automatically repeats as the battery requires.
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE
COVER OR BACK.NO USER-SERVICEABLE PARTS INSIDE.REFER
SERVICING TO FACTORY.

LOGIC 8 INSTRUCTIONS
1) Set ON/OFF switch to OFF.
2) Set w/ small screwdriver for NiCad or Lead Acid.
3) Plug unit into 115 or 230VAC outlet.
4) Connect battery – observe polarity.
Note: If reversed, breaker will trip and alarm will sound.
5) View battery Open Circuit Voltage. (OCV)
6) Set ON/OFF switch to ON, Yellow CHARGING illuminates.
7) When fully charged, Green READY illuminates.
8) If battery fault is detected, Red CHARGE CUTOFF blinks.

Included with Unit:
• Instruction Manual
• IEC Line cord (6 ft)
• DC output Cable Assembly with alligator clips
• DC output Cable Assembly with ring terminals
Optional Accessories:
• Aircraft Battery Connector
• Custom DC output cable assembly
• Mounting Bracket
• Plastic Carrying Case

SPECIFICATIONS
Dimensions: Max. unit width: 4.6”
Max. unit height: 4.5”
Max. unit depth: 12.5”
Weight: 5.5 lbs
AC Input: 90 – 260 VAC 47-410 Hz 3Amps Max.
(3 A @ 115 VAC 1.5 A @ 220 VAC)
AC Inlet: Standard IEC receptacle. 3 wire grounded.
Mates with USA and int’l IEC line cords.
AC Protection: 5 Amp 250V fuse – internal
Reverse Polarity
Protection: DC circuit breaker w/indicator – manual reset.
Short Circuit
Protection: Voltage inhibit –automatically restores when
short is removed.
Cooling: Fan cooled.
DC Output: Constant Potential
28.8Vnominal
29.4V lead acid balancing
31.0V NiCad topping
8.5A max charge
16A pulses for low batteries

CALIBRATION VERIFICATION PROCEDURE
1) Voltmeter -Compare the voltage reading of the Logic 8 with a
voltmeter whose calibration is traceable to N.I.S.T. Reading must
coincide to 0.2 volts.
The reading can be taken at any voltage level during charge or
without battery connected.
2) End Voltage –Without the battery connected, note the voltmeter
reading. Adjust the NiCad-Lead Acid pot completely CW and
CCW. Lead Acid should read 29.0 – 29.4V, NiCad should read
30.8 – 31.2V.

CERTIFICATION OF CALIBRATION
8 AMP CHARGER FOR 24 VOLT AIRCRAFT BATTERIES
MODEL: LOGIC 8 P/N: BR8A
APPLICATION: Charging 24 volt lead-acid or nickel-cadmium aircraft batteries.
SPECIFICATIONS: ●AC Input 90 – 260 VAC 47-410 Hz 3Amps Max.
3 A @ 115 VAC 1.5 A @ 220 VAC
•Meter reading accuracy:0.2 decimals
•AC Inlet: Standard IEC receptacle. 3 wire grounded.
•Mates with USA and international IEC line cords.
•AC Protection: 5 Amp 250V fuse – internal.
•Reverse Polarity Protection: DC circuit breaker with trip indicator
and audible alarm
•Short Circuit Protection: Voltage inhibit – automatic restore
•Cooling: Fan cooled.
•DC Output: Constant Potential 8.5A / 16A pulses for low batteries
28.8V nominal / 29.4V lead acid balancing / 31.0V NiCad topping
NOTES: A. Unit manufactured and calibrated under MIL I45208A
B. Calibrating instruments used:
Meter: FLUKE Model 8010A & 73III DC volts / DC MV (Amperes)
Shunt: EMPRO Standard 0.25% 50 Amp 50 MV
V/MV standard, EPPLY LABS Standard Cell
Power Products Load Bank
UNIT: BATTERY CHARGER
MODEL: LOGIC 8 P/N: BR8A
SERIAL NO: _______________
DATE FACTORY CALIBRATED: _____________
SHIPPED CONDITION: _____ CALIBRATED / IN TOLERANCE -PASSED
ENVIRONMENTAL CONDITIONS: 74°F 38% R.H.
DATE OF FIRST USE: _____________________
Power Products Inc. certifies that the above listed instrument meets or exceeds all published specifications. It has
been calibrated using Standard MIL-STD I45208 whose accuracies are traceable to the National Institute of
Standards and Technology.
DATE MANUFACTURED: ___________ S/N: ________________ SIGNATURE: ____________________
POWER PRODUCTSINC. • 27PAMARON WAY STE E • NOVATO • CA 94949
Tel: [phone] • Fax: [phone] www.power-products.com

WARRANTY
1 YEAR WARRANTY
POWER PRODUCTS warrants its products to be free from
defects in workmanship and material for a one year period
from the date of shipment to the distributor, original
equipment manufacturer (OEM), or original end user. If any
product shall prove to be defective during the warranty
period, POWER PRODUCTS will repair or replace such part.
There are no warranties which extend beyond the description
on the face hereof. This warranty is in lieu of all other
warranties, express or implied. POWER PRODUCTS
excludes liability for incidental and consequential damages.
An action for breach of this warranty must be commenced
within one year after the breach is or should have been
discovered.
POWER PRODUCTS specifically disclaims all other
representations to the first user/ purchaser, and all other
obligations or liabilities. No person is authorized to give any
other warranties or to assume any liabilities on POWER
PRODUCTS’ behalf.
