- 1 -
CONTENT PAGE
Intended Usage 2
Safety instructions 2
Items supplied 2
Description of the appliance 2
Technical Data 3
Utilisation 3
Cleaning and care 4
Disposal 5
Service 5
Importer 5
Read the operating instructions carefully before using the device for the first time and preserve this booklet
for later reference. Pass this manual on to whoever might acquire the device at a future date.
IB_64586_KH710_LB7.qxd 02.05.2011 9:09 Uhr Seite 1

- 2 -
DRAIN CLEANER
KH 710
Intended Usage
This Drain cleaner is intended for the environ-
mentally friendly and chemical-free cleaning of
drainpipes, pipes and other difficult to reach
places, using air pressure.
This appliance is intended for domestic use only, do
not use it for commercial or industrial applications.
Safety instructions
Risk of personal injury!
• Never direct the appliance at people or other
living creatures.
• This appliance is not intended for use by individuals
(including children) with restricted physical,
physiological or intellectual abilities or deficiences
in experience and/or knowledge unless they are
supervised by a person responsible for their
safety or receive from this person instruction in
how the appliance is to be used.
• Children should be supervised to ensure that
they do not play with the appliance.
• To avoid potentionally noxious fumes, do not use
solvents, alcohols, carbon-based detergents or
similar agents. This appliance works exclusively
with compressed air and without the addition of
chemicals.
Warning in regard to property
damage!
• Remove all loose parts, for example particle sieves,
from the bowl and seal all openings on the same
pipe, for example overflows, with a wet cloth or
something similar. This will avoid soiling from the
sprays which may be generated by the compressive
splice.
• Use this appliance only on drains able to withstand
pressure. Screwed pipes are able to bear more
pressure than inserted pipes. Support poorly
seated pipes against the floor! If you do not, the
compressive splice could damage the pipe.
Items supplied
Drain Cleaner
WC attachment
Shower attachment
Attachments Ø 6 cm and Ø 5 cm
Overflow seal
Operating instructions
Description of the appliance
1Air release valve
2Sealing cap
3Pump
4Compressive splice actuator
5Air exit opening
6WC attachment
7Shower attachment
8Attachment Ø 6 cm
9Attachment Ø 5 cm
0Overflow seal
IB_64586_KH710_LB7.qxd 02.05.2011 9:09 Uhr Seite 2

- 3 -
Technical Data
Max. operating pressure: 4 bar
Attachments: Attachment Ø 6 cm
Attachment Ø 5 cm
WC Attachment
Shower attachment
Utilisation
1. Select the most suitable attachment 6/7/8/
9for the blocked pipe and place it on the air
exit opening 5. Ensure that it is firmly secured.
2. Remove the sieve or any other inserts from the
pipe.
3. Close and seal all openings, for example over-
flows, on the pipe to be cleared. Use the over-
flow seal for the overflows 0:
• With round overflows, press and hold the roll pin
so that the locking lever can be flapped in such
a way that it stands in extension with the roll pin
(Fig 1).
Fig. 1
• Guide it into the overflow. As soon as the locking
lever hits against the rear wall, it opens itself out
(Fig. 2).
Fig. 2
• Slowly release the roll pin and check to ensure
that the overflow is completely closed. The ed-
ges of the overflow seal 0must close as uni-
formly as possible around the overflow, otherwi-
se residual soiling could be pressed out.
Fig. 3: Correctly inserted overflow seal 0
• For elongated overflows, press the roll pin and tip
the locking lever so that it stands at right angles
to the roll pin (Fig. 4).
Abb. 4
• Guide it into the overflow.
• Turn the roll pin through 90° and slowly release
it (Fig. 5).
Fig. 5
• Check to ensure that the overflow is completely
closed. The edges of the overflow seal 0must
close as uniformly as possible around the over-
flow, otherwise residual soiling could be pressed
out.
