TORQUE WRENCH SET PDS 45 A1
TORQUE WRENCH SET
Operating instructions
SET CHEI TUBULARE
Instrucţiuni de utilizare
MOMENT KLJUČ
Upute za upotrebu
IAN 74190
DREHMOMENTSCHLÜSSEL-SET
Bedienungsanleitung

GB/CY Operating instructions Page 1
HR Upute za upotrebu Stranica 11
RO Instrucţiuni de utilizare Pagina 21
DE/AT/CH Bedienungsanleitung Seite 31
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na
osnovu toga sa svim funkcijama uređaja.
Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate funcţiile
aparatului.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

TORQUES
NEWTON-METER
182
210
154
126
196
168
140
TORQUES
NEWTON-METER
182
210
154
126
196
168
140
BA

1
PDS 45 A1
GB
CY
Index
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Items supplied and transport inspection . . . . . . . . . . . . . . . . . . . . . 2
Component description. . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Commissioning and adjustment of the torque . . . . . . 6
Conversion Table (Nm to kgm ) . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Buch_74190_LB7.indb 1Buch_74190_LB7.indb 1 08.05.12 16:3108.05.12 16:31

GB
CY
2PDS 45 A1
Introduction
Congratulations!
With your purchase you have decided in favour of a quality product.
Familiarise yourself with the product before taking it into use. To do
this, read the following operating instructions attentively. Use the product
only as described and only for the specified areas of application.
Retain these instructions for future reference. In addition, pass these
documents on, together with the product, to any future owner.
Intended use
This torque wrench is intended exclusively for the controlled tightening
of screws and nuts on cars, motorcycles, caravans, etc.. This torque
wrench is not intended for commercial or industrial applications.
This tool is not intended for any other use or for uses beyond those
mentioned. Claims of any kind for damage resulting from unintended
use will not be accepted. The user alone bears liability.
Items supplied and transport inspection
This torque wrench is supplied with the following components as
standard:
▯ ½ ” Torgue wrench with ratchet and quick release
(manufactured as per DIN ISO 6789)
▯ ½“ Extension piece125 mm
▯ ½“ Sockets 17 mm, 19 mm and 21 mm
▯ Storage box
▯ This operating manual
Buch_74190_LB7.indb 2Buch_74190_LB7.indb 2 08.05.12 16:3108.05.12 16:31

3
PDS 45 A1
GB
CY
NOTICE
► Check the contents to ensure everything is available and for
signs of visible damage.
► If the delivery is not complete or is damaged due to defective
packaging or through transportation, contact the Service Hotline
(see chapter Service).
Component description
Release button
Switching lever
Main scale
Ring scale
Rotatable hand-grip
Locking screw
Socket 21 mm
Socket 19 mm
Socket 17 mm
Extension piece 125 mm
Technical data
Drive ½“
Adjustable torque range 28-210 Nm
Actuation accuracy ± 4% of Scale value
Length approx. 45 cm
Weight approx. 1360 g
Buch_74190_LB7.indb 3Buch_74190_LB7.indb 3 08.05.12 16:3108.05.12 16:31

GB
CY
4PDS 45 A1
Safety instructions
In this chapter you will receive important safety information regard-
ing the handling of the torque wrench. Incorrect usage can lead
to personal injury and property damage. For safe handling of the
torque wrench pay heed to the following safety information:
■ This tool is not intended for use by individuals (including children)
with restricted physical, physiological or intellectual abilities or
deficiencies in experience and/or knowledge unless they are
supervised by a person responsible for their safety or receive
from this person instruction in how the torque wrench is to be used.
■ Children should be supervised to ensure that they do not play
with the torque wrench.
■ Do not use brute force on the torque wrench to tighten a nut/screw.
During tightening apply a steady and consistent pressure.
■ To prevent damage to the tool, stop applying pressure to the torque
wrench when the ”click” sound is heard. Bear in mind that the ”click”
sound is acoustically weaker with lower torque settings!
■ In the event of an overload, or improper handling of the torque
wrench, it must be recalibrated by a specialist firm, which will
incur costs.
■ The supplied accessories are matched to this torque wrench.
When using accessories that were not supplied with it, please
pay heed to the standardised design and to the correct shapes
and sizes. The use of non-standard accessories will void the
warranty itself and all warranty claims.
Buch_74190_LB7.indb 4Buch_74190_LB7.indb 4 08.05.12 16:3108.05.12 16:31

5
PDS 45 A1
GB
CY
■ Do not use worn or damaged accessories (sockets or extension
pieces), as these may negatively influence the actuation accuracy.
■ Do not use hinged or ball joints, as these can lead to incorrect
settings of the torque.
■ When you use the tool for the first time, and after a long storage
period, it is important to operate the torque wrench a few times,
for the purpose of uniform lubrication of the mechanism, before
the actual torque is set.
■ Ensure that the torque is set at the lowest level (28 Nm) if you are
not using the torque wrench.
■ Do not turn the setting below the lowest torque marking (less than
28 Nm).
■ This tool is robust and suitable for domestic use, but it is also a
precision tool and should therefore be treated as such.
■ Before each use check the correct setting of the actuation value
and the correct seating of the accessory being used.
■ Store the torque wrench exclusively at room temperatures (15° -
25°C) so as not to falsify the actuation levels.
■ A calibration of the torque wrench should be performed only by
qualifi
ed personnel.
Buch_74190_LB7.indb 5Buch_74190_LB7.indb 5 08.05.12 16:3108.05.12 16:31

GB
CY
6PDS 45 A1
Commissioning and adjustment of the
torque
1. Loosen the locking screw (do not remove it) at the lower end
of the torque wrench by turning it anti-clockwise.
2. The precise setting of the torque value is made by using the ring
scale and the main scale . In the following example, this
process is explained for a torque of 120 Nm.
3. Turn the hand-grip until its upper edge reaches the kinked down-
wards marking of 112 Nm and the ”0” of the ring scale meets
the centre line of the main scale (see Figure A). With this step,
you have made the rough adjustment.
4. Turn the hand-grip further to the right, until the ”8” on the ring
scale meets the centre line of the main scale (see Figure B).
With this you have made the fine adjustment and the torque wrench
is now set to 120 Nm.
5. Turn the locking screw clockwise to lock the set torque value.
6. Use the switching lever to change the direction of rotation
(tighten or loosen) of the ratchet.
7. To attach and detach the extension piece/socket wrenches, press
the release button on the top of the torque wrench.
Buch_74190_LB7.indb 6Buch_74190_LB7.indb 6 08.05.12 16:3108.05.12 16:31

7
PDS 45 A1
GB
CY
Conversion Table (Nm to kgm )
Newton meters
(Nm)
Kilogramme meters
(kgm)
28 2,856
42 4,283
56 5,710
70 7,138
84 8,566
98 9,993
112 11,421
126 12,848
140 14,276
154 15,704
168 17,131
182 18,558
196 19,986
210 21,414
Buch_74190_LB7.indb 7Buch_74190_LB7.indb 7 08.05.12 16:3108.05.12 16:31

GB
CY
8PDS 45 A1
Cleaning and care
TAKE NOTE
► Do not use aggressive or abrasive cleaning agents, as these
can damage the upper surfaces.
► Clean the torque wrench with a dry cloth.
► Store the torque wrench only in a dry place and in the supplied
storage box.
► Ensure that the torque is set at the lowest level if you are not
using or are storing the torque wrench.
► If it is new, or has been stored a long time, first activate the
torque wrench several times, at a low torque, so that the
internal lubrication of the mechanical parts can be restored.
► In the event of an overload, or improper handling of the
torque wrench, it must be recalibrated by a specialist firm.
Disposal
Do not dispose of the tool in your normal domestic waste. Arrange
for the tool, or parts of it, to be disposed of by a professional disposal
company or by your community disposal facility. Pay heed to the
currently applicable regulations. In case of doubt, please contact
your waste disposal centre. Dispose of packaging materials in an
environmentally responsible manner.
Buch_74190_LB7.indb 8Buch_74190_LB7.indb 8 08.05.12 16:3108.05.12 16:31

9
PDS 45 A1
GB
CY
Appendix
Warranty
The warranty for this appliance is for 3 years from the date of purchase.
The appliance has been manufactured with care and meticulously
examined before delivery.
Please retain your receipt as proof of purchase. In the case of a war-
ranty claim, please make contact by telephone with our Customer
Service Department. Only in this way can a post-free despatch for
your goods be assured.
NOTICE
► The warranty covers only claims for material and manufacturing
defects, but not for transport damage, wearing parts or for dam-
age to fragile components, e.g. buttons or batteries.
This product is for domestic use only and is not intended for commer-
cial use. The warranty is void in the case of abusive and improper
handling, use of force and internal tampering not carried out by our
authorised service branch.
Your statutory rights are not restricted in any way by this warranty.
The warranty period is not extended by repairs made under the
warranty. This applies also to replaced and repaired parts.
Damages and defects extant at the time of purchase must be reported
immediately after unpacking, resp. no later than two days after the
date of purchase.
Repairs made after the lapse of the warranty period are subject
to charge.
Buch_74190_LB7.indb 9Buch_74190_LB7.indb 9 08.05.12 16:3108.05.12 16:31

GB
CY
10 PDS 45 A1
Service
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
IAN 74190
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: k[email protected]
IAN 74190
CY Service Cyprus
Tel.: [phone]
E-Mail: k[email protected]
IAN 74190
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
Buch_74190_LB7.indb 10Buch_74190_LB7.indb 10 08.05.12 16:3108.05.12 16:31

11
PDS 45 A1
HR
Sadržaj
Uvod. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Uporaba u skladu sa namjenom . . . . . . . . . . . . . . . . . . . . . . . . . 12
Obim isporuke i transportna inspekcija . . . . . . . . . . . . . . . . . . . . 12
Opis dijelova . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Tehnički podaci . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sigurnosne upute . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Puštanje u pogon i podešavanje momentnog ključa 16
Tablica za preračunavanje (Nm u kgm). . . . . . . . . . . . . . . . . . . . 17
Čišćenje i održavanje . . . . . . . . . . . . . . . . . . . . . . . . . 18
Zbrinjavanje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Prilog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Jamstvo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Servis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Uvoznik . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Buch_74190_LB7.indb 11Buch_74190_LB7.indb 11 08.05.12 16:3108.05.12 16:31

HR
12 PDS 45 A1
Uvod
Srdačno čestitamo!
Vašom kupnjom ste se odlučili za visokovrijedan proizvod. Prije prvog
puštanja u pogon se upoznajte sa proizvodom. U tu svrhu pažljivo
pročitajte slijedeće upute za rukovanje. Proizvod koristite isključivo
na opisani način i u navedenim područjima primjene. Ove upute
dobro sačuvajte. Svu dokumentaciju u slučaju predaje proizvoda
trećim osobama priložite i takođe predajte.
Uporaba u skladu sa namjenom
Ovaj momentni ključ je namijenjen za kontrolirano zatezanje vijaka
i matica na osobnim vozilima, motociklima, kamp-kućama i sl. Ovaj
momentni ključ nije namijenjen za gospodarsku ili industrijsku upo-
rabu. Svaki drugi način uporabe i uporaba koja prelazi navedene
okvire smatra se nenamjenskom. Potraživanja svake vrste na temelju
štete nastale uslijed nenamjenske uporabe su isključena. Rizik nosi
isključivo sam korisnik.
Obim isporuke i transportna inspekcija
Momentni ključ se standardno isporučuje sa slijedećim komponentama:
▯ ½“ Momentni ključ sa usmjerivačem i brzim izbacivanjem
(izrađen prema normi DIN ISO 6789)
▯ ½“ Produžetak 125 mm
▯ ½“ Nastavci ključa 17 mm, 19 mm i 21 mm
▯ Kutija za čuvanje
▯ Ove upute za uporabu
Buch_74190_LB7.indb 12Buch_74190_LB7.indb 12 08.05.12 16:3108.05.12 16:31

13
PDS 45 A1
HR
NAPOMENA
► Prekontrolirajte cjelovitost obima isporuka i ustanovite, da li
postoje vidljiva oštećenja.
► U slučaju nepotpune isporuke ili štete uslijed oskudnog pakiranja
ili transportne štete obratite se dežurnoj servisnoj telefonskoj
liniji (vidi poglavlje Servis).
Opis dijelova
Gumb za otpuštanje
Poluga za prebacivanje
Glavna skala
Kružna skala
Okretna ručka
Vijak za zatvaranje
Nastavak ključa 21 mm
Nastavak ključa 19 mm
Nastavak ključa 17 mm
Produžetak 125 mm
Tehnički podaci
Pogon ½“
Podesivo područje okretnog
momenta 28-210 Nm
Preciznost aktiviranja ± 4% od vrijednosti skale
Dužina ca. 45 cm
Težina ca. 1360 g
Buch_74190_LB7.indb 13Buch_74190_LB7.indb 13 08.05.12 16:3108.05.12 16:31

HR
14 PDS 45 A1
Sigurnosne upute
U ovom poglavlju možete pronaći važne sigurnosne napomene za
rukovanje momentnim ključem. Nestručna uporaba može dovesti
do ozljeda osoba i do nastanka predmetne štete. U svrhu sigurnog
rukovanja momentnim ključem obratite pažnju na slijedeće sigurnosne
napomene:
■ Ovaj alat nije namijenjen za to da bude korišten od strane osoba
(uključujući djecu) sa ograničenim fizičkim, senzoričkim ili duševnim
sposobnostima ili pomanjkanjem iskustva i/ili znanja, osim ako
ove osobe stoje pod nadzorom druge osobe zadužene za njihovu
sigurnost ili od dotične osobe primaju naputke za korištenje
momentnog ključa.
■ Djeca trebaju biti nadzirana, kako bi bilo osigurano da se ne
igraju s momentnim ključem.
■ Ne povlačite momentni ključ u svrhu zatezanja matice/vijka.
Prilikom zatezanja primijenite ravnomjeran pritisak.
■ Ne opterećujte momentni ključ, nakon što se oglasi zvuk klika,
kako biste izbjegli nastanak oštećenja alata. Obratite pažnju na
to, da zvuk klika kod nižih podešenja okretnog momenta postaje
akustično tiši!
■ Kod preopterećenja ili nakon nestručnog rukovanja momentnim
ključem isti mora biti kalibriran od strane stručnog poduzeća uz
naplatu troškova.
■ Priloženi dijelovi opreme su usklađeni sa ovoi momentnim ključem.
Ako koristite dijelove opreme koji nisu sadržani u obimu isporuke,
molimo Vas da obratite pažnju na izvedbu shodno normi i na
ispravne oblike i veličine. Uporaba dijelova opreme koji nisu
shodni normi dovodi do prestanka važenja prava na jamstvo i
na odštetu.
Buch_74190_LB7.indb 14Buch_74190_LB7.indb 14 08.05.12 16:3108.05.12 16:31

15
PDS 45 A1
HR
■ Ne koristite istrošene i defektne dijelove opreme (produžetke
ili umetke ključa), jer ovi dijelovi mogu promijeniti preciznost
aktiviranja.
■ Ne koristite šarnirske ili kuglične zglobove, jer oni mogu dovesti
do pogrešnog podešenja okretnog momenta.
■ Kod prve uporabe i nakon dužeg vremena skladištenja obavezno
morate obratiti pažnju na to, da momentni ključ zbog ravno-
mjernog podmazivanja mehanike nekoliko puta aktivirate prije
podešavanja okretnog momenta.
■ Osigurajte, da okretni moment bude podešen na najnižem stupnju
(28 Nm), kada momentni ključ ne koristite.
■ Podešenje ne postavite ispod najniže oznake okretnog momenta
(ispod 28 Nm).
■ Ovaj alat je robustan i prikladan za privatnu uporabu, ali pred-
stavlja i precizan alat i kao takav treba biti tretiran.
■ Prije svake uporabe prekontrolirajte ispravno podešenje vrijednosti
aktiviranja i ispravan položaj korištenog umetka.
■ Momentni ključ čuvajte isključivo na sobnoj temperaturi (15°- 25°C),
kako ne biste promijenili vrijednosti aktiviranja.
■ Kalibriranje momentnog ključa treba izvršiti isključivo stručno
osoblje.
Buch_74190_LB7.indb 15Buch_74190_LB7.indb 15 08.05.12 16:3108.05.12 16:31

HR
16 PDS 45 A1
Puštanje u pogon i podešavanje
momentnog ključa
1. Otpustite vijak za zatvaranje (ne odvrnuti) na donjem kraju
momentnog ključa tako, što ćete je okretati u smjeru protivnom
kazaljci sata.
2. Precizno podešenje vrijednosti okretnog momenta se vrši na teme-
lju kružne skale i glavne skale . U slijedećem primjeru ovaj
postupak je objašnjen sa okretnim momentom od 120 Nm.
3. Okrenite ručku, sve dok njegova gornja ivica ne dostigne oznaku
od 112 Nm postavljenu prema dolje, a vrijednost „0“ kružne
skale pritom pogodi središnju liniju glavne skale (vidi sliku A).
Sa tim korakom ste izvršili grubo podešenje.
4. Okrenite ručku dalje u desnu stranu, dok vrijednost „8“ kružne
skale ne pogodi srednju liniju glavne skale (vidi sliku B).
Na taj način ste izvršili fino podešavanje i sada je momentni ključ
podešen na vrijednost od 120 Nm.
5. Okrenite vijak za zatvaranje u smjeru kazaljke sata, kako biste
blokirali podešenu vrijednost okretnog momenta.
6. Koristite polugu za prebacivanje kada želite promijeniti smjer
okretanja (zatezanje ili otpuštanje) jednosmjernog zateznika.
7. Za postavljanje i otpuštanje produžetka/umetaka ključa pritisnite
gumb za otpuštanje na glavi momentnog ključa.
Buch_74190_LB7.indb 16Buch_74190_LB7.indb 16 08.05.12 16:3108.05.12 16:31

17
PDS 45 A1
HR
Tablica za preračunavanje (Nm u kgm)
Newton-metar
(Nm)
Kilogram-metar
(kgm)
28 2,856
42 4,283
56 5,710
70 7,138
84 8,566
98 9,993
112 11,421
126 12,848
140 14,276
154 15,704
168 17,131
182 18,558
196 19,986
210 21,414
Buch_74190_LB7.indb 17Buch_74190_LB7.indb 17 08.05.12 16:3108.05.12 16:31
