PR electronics 5350 User manual

Programmable displays with a wide se-
lection of inputs and outputs for display of temperature,
volume and weight, etc. Feature linearisation, scaling,
and difference measurement functions for programming
via PReset software.
Interfaces for analogue and digital
signals as well as HART®signals between sensors / I/P
converters / frequency signals and control systems in Ex
zone 0, 1 & 2 and for some modules in zone 20, 21 & 22.
Galvanic isolators for analogue and digital
signals as well as HART®signals. A wide product range
with both loop-powered and universal isolators featuring
linearisation, inversion, and scaling of output signals.
PC or front programmable modules with
universal options for input, output and supply. This range
offers a number of advanced features such as process
calibration, linearisation and auto-diagnosis.
A wide selection of transmitters for DIN
form B mounting and DIN rail modules with analogue
and digital bus communication ranging from application-
specific to universal transmitters.
Displays
Temperature
Isolation
Ex barriers
Universal
DK
UK
FR
DE
Side 1
Page 17
Page 33
Seite 49
SIGNALS THE BEST
5350
PROFIBUS®PA / FOUNDA-
TION™ Fieldbus Transmitter
No. 5350V109-IN (0825)
From ser. no. 030640001

PROFIBUS®PA / FOUNDATION™ FIELDBUS
TRANSMITTER
PRetrans 5350
Indholdsfortegnelse
Sikkerhedsinstruktion......................................................... 2
EF-overensstemmelseserklæring....................................... 3
Anvendelse......................................................................... 4
Teknisk karakteristik ........................................................... 4
Montage / installation......................................................... 4
Applikationer ...................................................................... 5
Bestillingsskema................................................................. 6
Elektriske specifikationer ................................................... 6
Tilslutninger, indgang ......................................................... 12
Tilslutninger, udgang .......................................................... 13
Montering af følerledninger ................................................ 13
Blokdiagram ....................................................................... 14
Bus-installation................................................................... 15
Appendix:
FM, UL, CSA and FISCO
Installation Drawing No. 5350QE01 ................................... 65
1

EF-OVERENSSTEMMELSESERKLÆRING
Som producent erklærer
PR electronics A/S
Lerbakken 10
DK-8410 Rønde
hermed at følgende produkt:
Type: 5350
Navn: PROFIBUS®PA/FOUNDATION™
Fieldbus transmitter
er i overensstemmelse med følgende direktiver og standarder:
EMC-direktivet 2004/108/EF og senere tilføjelser
EN 61326-1 : 2006
For specifikation af det acceptable EMC-niveau henvises til modulets
elektriske specifikationer.
ATEX-direktivet 94/9/EF og senere tilføjelser
EN 50014 : 1997, EN 50020 : 2002,
EN 60079-15 : 2003, EN 50284 : 1999,
EN 60079-27 : 2005
ATEX-certifikat: KEMA 03ATEX1011 X (5350A)
ATEX-certifikat: KEMA 02ATEX1318 (5350B)
Bemyndiget organ:
KEMA Quality B.V. (0344)
Utrechtseweg 310, 6812 AR Arnhem
P.O. Box 5185, 6802 ED Arnhem
The Netherlands
Rønde, 13. maj 2008 Peter Rasmussen
Producentens underskrift
32
Sikkerhedsinstruktion
Ex-installation:
For sikker installation af 5350 i eksplosionsfarligt område skal følgende
overholdes. Installation må kun foretages af kvalificeret personale, der er
bekendt med de nationale og internationale love, direktiver og standarder, der
gælder for området.
Produktionsår fremgår af de to første cifre i serienummeret.
Følerkredsløbet er ikke ufejlbarligt galvanisk isoleret fra indgangskredsløbet,
men den galvaniske isolation mellem kredsene kan modstå en testspænding
på 500 VAC i 1 minut.
Transmitteren skal monteres i et hus, der giver en tæthedsgrad på mindst IP20.
I eksplosive atmosfærer forårsaget af en blanding af luft og støv:
Transmitteren må kun installeres i områder med potentiel eksplosionsfare på
grund af brændbart støv, når modulet et monteret i et form B hus i overens-
stemmelse med DIN 43729. Huset skal have en tæthedsgrad på mindst IP 6X
i overensstemmelse med EN 60529 og skal være egnet til den pågældende
applikation samt være installeret korrekt.
Der må kun anvendes kabelforskruninger og blindstik, som egner sig til den
pågældende applikation og som installeres korrekt.
Hvis omgivelsestemperaturen ≥60°C, skal der bruges varmebestandige kabler
med specifikationer på mindst 20K over omgivelsestemperaturen.
Særlige betingelser for sikker anvendelse 5350A:
5350A skal monteres i et hus med en tæthedsgrad på mindst IP54 i overens-
stemmelse med EN 60529.
Der skal træffes foranstaltninger, der forhindrer at den nominelle forsynings-
spænding overskrides af transienter på mere end 40%.
Særlige betingelser for sikker anvendelse 5350B:
Hvis huset, hvori transmitteren er monteret, er lavet af aluminium og installeret i
zone 0, 1 eller zone 20, 21 eller 22, må det i vægt højest have et totalindhold
af 6% magnesium og titanium.
Den omgivende kapsling skal konstrueres / installeres således, at der selv ved
sjældent opstående hændelser ikke er risiko for antændelse på grund af stød
og friktionsgnister.

5
+
-+
-
+
-
1
+
2
+
-
+
-
2
1
2
1
-
RTD til
bus-kommunikation
Modstand til
bus-kommunikation
mV til
bus-kommunikation
TC til
bus-kommunikation
Differens, redundans eller
middel; RTD, TC eller mV
eller
PROFIBUS®PA / FOUNDATION™ FIELDBUS
TRANSMITTER - PRetop 5350
• PROFIBUS®PA ver. 3.0
• FOUNDATION™ Fieldbus ver. ITK 4.6
• Automatisk switchfunktion
• FISCO-certificeret
• Basic funktionalitet med F.F.
Anvendelse:
• Temperaturlineariseret måling med RTD- eller termoelementføler.
• Differens-, redundans- eller gennemsnitstemperaturmåling med RTD- eller ter-
moelementføler.
• Lineær modstand, potentiometer og bipolær mV-måling.
Teknisk karakteristik:
• Bustransmitter med både PROFIBUS®PA og FOUNDATION™ Fieldbus kommu-
nikation. En unik switchfunktion sørger for automatisk skift mellem protokol-
lerne.
• Opsætning til PROFIBUS®PA kan ske via Siemens Simatic®PDM®, ABB
Melody / Harmony og Metso DNA XD software og til FOUNDATION™ Fieldbus
via Emerson DeltaV, Yokogawa CS 1000 / CS 3000, ABB Melody / Harmony
og Honeywell Experion software.
• Simulation mode-funktion kan aktiveres via magnet.
• Polaritetsuafhængig busforsyning.
• 24 bit A/D konverter sikrer høj opløsning.
• PROFIBUS®PA funktionsblokke: 2 analoge.
• FOUNDATION™ Fieldbus funktionsblokke: 2 analoge og 1 PID.
• FOUNDATION™ Fieldbus funktionalitet: Basic eller LAS.
Montage / installation:
• Kan monteres i DIN form B følerhoved. I ikke-eksplosionsfarlige områder kan
5350 monteres på en DIN-skinne med PR-beslag type 8421.
4

Vibration (DIN class B) ................................ IEC 60068-2-6 og IEC 60068-2-64
4 g / 2...100 Hz
Luftfugtighed ............................................... < 95% RH (ikke kond.)
Mål............................................................... Ø 44 x 20,2 mm
Kapslingsklasse (hus / klemme).................. IP68 / IP00
Vægt............................................................ 55 g
Elektriske specifikationer, indgang:
RTD- og lineær modstandsindgang:
Kabelmodstand pr. leder............................. 50 Ω
Følerstrøm ................................................... Nom. 0,2 mA
Virkning af følerkabelmodstand (3- / 4-leder).. < 0,002 Ω /Ω
Følerfejlsdetektering.................................... Ja
Kortslutningsdetektering ............................. < 15 Ω
7
Basisværdier
Indgangstype
Basis-
nøjagtighed
Temperatur-
koefficient
Pt100 og Pt1000 ≤±0,1°C ≤±0,002°C / °C
Ni100 ≤±0,15°C ≤±0,002°C / °C
Cu10 ≤±1,3°C ≤±0,02°C / °C
Lin. R ≤±0,05 Ω≤±0,002 Ω/ °C
Volt ≤±10 µV ≤±0,2 µV / °C
TC-type:
E, J, K, L, N, T, U ≤±0,5°C ≤±0,010°C / °C
TC-type:
B, R, S, W3, W5 ≤±1°C ≤±0,025°C / °C
EMC-immunitetspåvirkning............................ < ±0,1% af visning
Udvidet EMC-immunitet:
NAMUR NE 21, A kriterium, gniststøj ............ < ±1% af visning
RTD-
type
Min.
værdi
Max.
værdi Standard
Pt25...Pt1000
Ni25...Ni1000
Cu10...Cu1000
Lin. modstand
Potentiometer
-200°C
-60°C
-50°C
0Ω
0Ω
+850°C
+250°C
+200°C
10 kΩ
100 kΩ
IEC60751/JIS C 1604
DIN 43760
α= 0,00427
-
-
*NB! Husk at bestille PR sim pin type 8422, hvis
„simulation mode“-funktionen ønskes benyttet.
Elektriske specifikationer:
Specifikationsområde:
-40°C til +85°C
Fælles specifikationer:
Forsyningsspænding DC:
Standard ................................................. 9,0...32 V
ATEX, FM, UL og CSA ............................ 9,0...30 V
I FISCO-installationer.............................. 9...17,5 V
Egetforbrug ................................................. < 11 mA
Max. stigning i strømforbrug
i tilfælde af en fejl.................................... < 7 mA
Isolationsspænding, test ............................. 1,5 kVAC i 60 s
Isolationsspænding, drift............................. 50 VRMS / 75 VDC
Opvarmningstid........................................... 30 s
Signal- / støjforhold..................................... Min. 60 dB
Reaktionstid (programmerbar) .................... 1...60 s
Opdateringstid............................................. < 400 ms
Eksekveringstid, analog indgang ................ < 50 ms
Signaldynamik, indgang.............................. 24 bit
Kalibreringstemperatur................................ 20...28°C
Nøjagtighed, størst af generelle og basisværdier:
6
Generelle værdier
Indgangstype
Absolut
nøjagtighed
Temperatur-
koefficient
Alle ≤±0,05% af visning ≤±0,002% af visning / °C

9
Ex-godkendelse - 5350A:
KEMA 03ATEX1011 X
Ex-data:
Terminal 1, 2 (Fieldbus-kredsløb):
II 3 G EEx nA [nL] II C T4...T6
Ui.................................................................: 32 VDC
eller
II 3 G EEx nL II C T4...T6
Ui.................................................................: 32 VDC
Li.................................................................: 1 µH
Ci.................................................................: 2 nF
eller
FNICO feltmonteret udstyr
Ui.................................................................: 17,5 VDC
med følgende kabelparametre:
Rc................................................................ : 15...150 Ω/km
Lc................................................................ : 0,4...1 mH/km
Cc................................................................ : 45...200 nF/km
Længde af sidekabel max. 60 m i IIC og IIB.
Længde af hovedkabel inklusive længde af alle sidekabler max. 1 km i IIC og 5
km i IIB.
Terminal 3, 4, 5 og 6 (følerkredsløb):
Uo................................................................: 5,7 VDC
Io.................................................................: 8,4 mA
Po................................................................: 12 mW
Lo................................................................: 200 mH
Co................................................................: 40 µF
FM, UL og CSA ........................................... IS, Class I, Div. 2, Group A, B, C, D
IS, Class I, Zone 2, Group IIC
TC-indgang:
Koldt loddestedskomp. (CJC)..................... < ±0,5 °C
Følerfejlsdetektering.................................... Ja
Følerfejlsstrøm:
under detektering.................................... Nom. 4 µA
ellers........................................................ 0 µA
Kortslutningsdetektering ............................. < 3 mV
Spændingsindgang:
Måleområde ................................................ -800...+800 mV
Indgangsmodstand ..................................... 10 MΩ
Udgang:
PROFIBUS®PA tilslutning:
PROFIBUS®PA protokol .............................. Profil A&B, ver. 3.0
PROFIBUS®PA protokolstandard ................ EN 50170 vol. 2
PROFIBUS®PA adresse (ved levering) ........ 126
PROFIBUS®PA funktionsblokke .................. 2 analoge
FOUNDATIONTM Fieldbus tilslutning:
FOUNDATIONTM Fieldbus protokol................. FF protokol
FOUNDATIONTM Fieldbus protokolstandard... FF designspecifikationer
FOUNDATIONTM Fieldbus funktionalitet.......... LAS eller Basic
FOUNDATIONTM Fieldbus version................... ITK 4.6
FOUNDATIONTM Fieldbus funktionsblokke ..... 2 analoge og 1 PID
8
Type Min. værdi Max. værdi Standard
B
E
J
K
L
N
R
S
T
U
W3
W5
Ekst. CJC
+400°C
-100°C
-100°C
-180°C
-200°C
-180°C
-50°C
-50°C
-200°C
-200°C
0°C
0°C
-40°C
+1820°C
+1000°C
+1200°C
+1372°C
+900°C
+1300°C
+1760°C
+1760°C
+400°C
+600°C
+2300°C
+2300°C
+135°C
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
ASTM E988-90
ASTM E988-90
IEC60751

1110
EEx- / I.S.-godkendelse - 5350B:
KEMA 02ATEX1318..................................... II 1 GD el. II 2 (1) GD,
T65°C...T105°C
EEx ia IIC eller EEx ib [ia] IIC T4...T6
Må anvendes i zone .................................... 0, 1, 2, 20, 21 eller 22
FM, UL og CSA ........................................... IS, Class I, Div. 1, Group A, B, C, D
IS, Class I, Zone 0/1, Group IIC
IS, Class I, Div. 2, Group A, B, C, D
Ex- / I.S.-data:
Signaludgang / forsyning, terminal 1 til 2:
Max. omgivelsestemperatur er afhængig af den tilsluttede barrieres Po.
Enhed
5350B
Zone 0, EEx ia IIC, Entity / Fisco
IS, Class I, Division 1, Group A, B, C, D
Entity / Fisco
Barriere med
Po< 0,84 W
Barriere med
Po< 1,3 W
Kan anvendes i
FISCO-systemer
Kan anvendes i
FISCO-systemer
Ui
Ii
Pi
Li
Ci
T1...T4
T5
T6
30 VDC
120 mADC
0,84 W
1 µH
2,0 nF
Tomg. < 85°C
Tomg. < 70°C
Tomg. < 60°C
30 VDC
300 mADC
1,3 W
1 µH
2,0 nF
Tomg. < 75°C
Tomg. < 65°C
Tomg. < 45°C
17,5 VDC
250 mADC
2,0 W
1 µH
2,0 nF
Tomg. < 85°C
Tomg. < 60°C
Tomg. < 45°C
15 VDC
900 mA
5,32 W
1 µH
2,0 nF
Tomg. < 85°C
Tomg. < 60°C
Tomg. < 45°C
Enhed
5350B
Zone 1, EEx ib IIC, Entity / Fisco
IS, Class I, Division 2, Group A, B, C, D
Entity / Fisco
Barriere med
Po< 5,32 W FISCO seg-
mentkobler
Ui
Ii
Pi
Li
Ci
T1...T4
T5
T6
30 VDC
250 mADC
5,32 W
1 µH
2,0 nF
Tomg. < 85°C
Tomg. < 75°C
Tomg. < 60°C
17,5 VDC
alle
alle
1 µH
2,0 nF
Tomg. < 85°C
Tomg. < 75°C
Tomg. < 60°C
Følerindgang, terminal 3, 4, 5 og 6:
Uo................................................................: 5,7 VDC
Io.................................................................: 8,4 mA
Po................................................................: 12 mW
Lo................................................................: 200 mH
Co................................................................: 40 µF
GOST R godkendelse:
Standard: VNIIM.......................................... Cert. no. Ross DK.ME48.V01899
Ex: VNIIFTRI ................................................ Cert. no. Ross DK.GB06.V00100
Ex permit ..................................................... РРС00-17800
Overholdte myndighedskrav: Standard:
EMC 2004/108/EF
Emission og immunitet ....................... EN 61326-1 : 2006
ATEX 94/9/EF .............................................. EN 50014 : 1997, EN 50020 : 2002,
EN 60079-15 : 2003, EN 50284 : 1999
EN 60079-27 : 2005
FM ............................................................... 3600, 3610, 3611
UL................................................................ UL 508, UL 1604, UL 913,
UL 60079-0, UL 60079-1
CSA, CAN / CSA......................................... C22.2 No. 142, No. 157, No. 213,
CAN / CSA .................................................. E79-0, -11, -15
ANSI / UL .................................................... UL 60079-0, -11, -15

13
1 2
1 2 PA
Bus-tilslutning
Bus-tilslutning
Tilslutninger:
Udgang:
Segment-
kobler
Segment-
kobler
Bus-
terminering
Bus-
terminering
12
Ledninger monteres mellem metalpladerne
Mekaniske specifikationer: Montering af følerledninger:

15
Blokdiagram:
14
Bus-installation:

16 17
PROFIBUS®PA / FOUNDATION™ FIELDBUS
TRANSMITTER
PRetrans 5350
Contents
Safety instruction ............................................................... 18
EC Declaration of Conformity ............................................ 19
Application ......................................................................... 20
Technical characteristics.................................................... 20
Mounting / installation........................................................ 20
Applications........................................................................ 21
Order .................................................................................. 22
Electrical specifications...................................................... 22
Connections, input ............................................................. 28
Connections, output........................................................... 29
Mounting of sensor wires................................................... 29
Block diagram .................................................................... 30
Bus installation................................................................... 31
Appendix:
FM, UL, CSA and FISCO
Installation Drawing No. 5350QE01 ................................... 65
17

18 1918
Safety instructions
Ex installation:
For safe installation of 5350 in a hazardous area, the following must be obser-
ved. The module must only be installed by qualified personnel who are fami-
liar with the national and international laws, directives and standards that
apply to this area.
Year of manufacture can be taken from the first two digits in the serial number.
The sensor circuit is not infallibly galvanically isolated from the input circuit.
However, the galvanic isolation between the circuits is capable of withstan-
ding a test voltage of 500 Vac during 1 minute.
The transmitter must be mounted in an enclosure in order to provide a degree
of ingress protection of at least IP20.
In explosive atmospheres caused by air / dust mixtures:
The transmitter may only be installed in a potentially explosive atmosphere cau-
sed by the presence of combustible dust when mounted in a metal enclosu-
re form B according to DIN 43729 that is providing a degree of ingress pro-
tection of at least IP 6X in accordance with EN 60529, that is suitable for the
application and is correctly installed.
Cable entries and blanking elements shall be used that are suitable for the
application and correctly installed.
For an ambient temperature ≥60°C, heat resistant cables shall be used with a
rating of at least 20 K above the ambient temperature.
Special Conditions for Safe Use - 5350A:
The transmitter shall be mounted in an enclosure providing a degree of ingress
protection of at least IP54 in accordance with EN 60529.
Provisions must be made to prevent the rated supply voltage being exceeded
by transient disturbances of more than 40%.
Special Conditions for Safe Use - 5350B:
If the enclosure in which the transmitter is mounted is made of aluminium and
installed in Zone 0, 1 or Zone 20, 21 or 22 it shall not contain by weight more
than 6% in total of magnesium and titanium.
The additional enclosure of the apparatus shall be designed and/or installed in
such a way that, even in the event of rare incidents, ignition sources due to
impact and friction sparks are excluded.
EC DECLARATION OF CONFORMITY
As manufacturer
PR electronics A/S
Lerbakken 10
DK-8410 Rønde
hereby declares that the following product:
Type: 5350
Name: PROFIBUS®PA/FOUNDATION™
Fieldbus transmitter
is in conformity with the following directives and standards:
EMC directive 2004/108/EC and later amendments
EN 61326-1 : 2006
For specification of the acceptable EMC performance level, refer to the
electrical specifications for the module.
The ATEX directive 94/9/EC and later amendments
EN 50014 : 1997, EN 50020 : 2002,
EN 60079-15 : 2003, EN 50284 : 1999,
EN 60079-27 : 2005
ATEX certificate: KEMA 03ATEX1011 X (5350A)
ATEX certificate: KEMA 02ATEX1318 (5350B)
Notified body
KEMA Quality B.V. (0344)
Utrechtseweg 310, 6812 AR Arnhem
P.O. Box 5185, 6802 ED Arnhem
The Netherlands
Rønde, 13 May 2008 Peter Rasmussen
Manufacturer’s signature
19

20 21
PROFIBUS®PA / FOUNDATION™ FIELDBUS
TRANSMITTER - PRetop 5350
• PROFIBUS®PA ver. 3.0
• FOUNDATION™ Fieldbus ver. ITK 4.6
• Automatic switch between protocols
• FISCO-certified
• Basic capability with F.F.
Application:
• Linearised temperature measurement with RTD or TC sensor.
• Difference, average or redundancy temperature measurement with RTD or TC
sensor.
• Linear resistance, potentiometer and bipolar mV measurement.
Technical characteristics:
• Bus transmitter with both PROFIBUS®PA and FOUNDATIONTM Fieldbus
communication. A unique switch function ensures automatic shift between
the two protocols.
• Set-up for PROFIBUS®PA can be done via Siemens Simatic®PDM®, ABB
Melody / Harmony and Metso DNA software and for FOUNDATION™ Fieldbus
via Emerson DeltaV, Yokogawa CS 1000 / CS 3000, ABB Melody / Harmony
and Honeywell Experion software.
• The simulation mode function can be activated by way of a magnet.
• Polarity-independent bus connection.
• 24 bit A/D converter ensures high resolution.
• PROFIBUS®PA function blocks: 2 analogue.
• FOUNDATION™ Fieldbus function blocks: 2 analogue and 1 PID.
• FOUNDATION™ Fieldbus capability: Basic or LAS.
Mounting / installation:
• For DIN form B sensor head mounting. In non-hazardous areas the 5350 can
be mounted on a DIN rail with the PR fitting type 8421.
20 21
+
-+
-
+
-
1
+
2
+
-
+
-
2
1
2
1
-
RTD to
bus communication
Resistance to
bus communication
mV to
bus communication
TC to
bus communication
Difference, redundancy or
average; RTD, TC or mV
or

22 23
*NB! Please remember to order PR sim pin type 8422
if the simulation mode function is to be used.
Electrical specifications:
Specifications range:
-40°C to +85°C
Common specifications:
Supply voltage, DC
Standard ................................................. 9.0...32 V
ATEX, FM, UL and CSA .......................... 9.0...30 V
In FISCO installations ............................. 9.0...17.5 V
Consumption............................................... < 11 mA
Max. current increase in
the event of an error ............................... < 7 mA
Isolation voltage, test .................................. 1.5 kVAC for 60 s
Isolation voltage, operation......................... 50 VRMS / 75 VDC
Warm-up time.............................................. 30 s
Signal / noise ratio ...................................... Min. 60 dB
Response time (programmable).................. 1...60 s
Updating time.............................................. < 400 ms
Execution time, analogue input................... < 50 ms
Signal dynamics, input................................ 24 bit
Calibration temperature .............................. 20...28°C
Accuracy, the greater of general and basic values:
22
General values
Input type
Absolute
accuracy
Temperature
coefficient
All ≤±0.05% of reading ≤±0.002% of reading / °C
Vibration (DIN class B) ................................ IEC 60068-2-6 and IEC 60068-2-64
4 g / 2...100 Hz
Humidity ...................................................... < 95% RH (non cond.)
Dimensions.................................................. Ø 44 x 20.2 mm
Protection degree (enclosure / terminal)..... IP68 / IP00
Weight ......................................................... 55 g
Electrical specifications, input:
RTD and linear resistance input:
Cable resistance per wire............................ 50 Ω
Sensor current............................................. Nom. 0.2 mA
Effect of sensor cable resistance (3- / 4-wire) < 0.002 Ω /Ω
Sensor error detection ................................ Yes
Short circuit detection................................. < 15 Ω
23
Basic values
Input type
Basic
accuracy
Temperature
coefficient
Pt100 and Pt1000 ≤±0.1°C ≤±0.002°C / °C
Ni100 ≤±0.15°C ≤±0.002°C / °C
Cu10 ≤±1.3°C ≤±0.02°C / °C
Lin. R ≤±0.05 Ω≤±0.002 Ω/ °C
Volt ≤±10 µV ≤±0.2 µV / °C
TC type:
E, J, K, L, N, T, U ≤±0.5°C ≤±0.010°C / °C
TC type:
B, R, S, W3, W5 ≤±1°C ≤±0.025°C / °C
EMC immunity influence ................................ < ±0.1% of reading
Extended EMC immunity:
NAMUR NE 21, A criterion, burst .................. < ±1% of reading
RTD
type
Min.
value
Max.
value Standard
Pt25...Pt1000
Ni25...Ni1000
Cu10...Cu1000
Lin. resistance
Potentiometer
-200°C
-60°C
-50°C
0Ω
0Ω
+850°C
+250°C
+200°C
10 kΩ
100 kΩ
IEC60751/JIS C 1604
DIN 43760
α= 0.00427
-
-

24 25
TC input:
Cold junction compensation (CJC) ............. < ±0.5 °C
Sensor error detection ................................ Yes
Sensor error current:
when detecting ....................................... Nom. 4 µA
else.......................................................... 0 µA
Short circuit detection................................. < 3 mV
Voltage input:
Measurement range .................................... -800...+800 mV
Input resistance........................................... 10 MΩ
Output:
PROFIBUS®PA connection:
PROFIBUS®PA protocol .............................. Profile A&B, ver. 3.0
PROFIBUS®PA protocol standard............... EN 50170 vol. 2
PROFIBUS®PA address (at delivery) ........... 126
PROFIBUS®PA function blocks................... 2 analogue
FOUNDATIONTM Fieldbus connection:
FOUNDATIONTM Fieldbus protocol................. FF protocol
FOUNDATIONTM Fieldbus protocol standard.. FF design specifications
FOUNDATIONTM Fieldbus capability ............... Basic or LAS
FOUNDATIONTM Fieldbus version................... ITK 4.6
FOUNDATIONTM Fieldbus function blocks...... 2 analogue and 1 PID
24
Type
Min.
value
Max.
value Standard
B
E
J
K
L
N
R
S
T
U
W3
W5
Ext. CJC
+400°C
-100°C
-100°C
-180°C
-200°C
-180°C
-50°C
-50°C
-200°C
-200°C
0°C
0°C
-40°C
+1820°C
+1000°C
+1200°C
+1372°C
+900°C
+1300°C
+1760°C
+1760°C
+400°C
+600°C
+2300°C
+2300°C
+135°C
IEC584
IEC584
IEC584
IEC584
DIN 43710
IEC584
IEC584
IEC584
IEC584
DIN 43710
ASTM E988-90
ASTM E988-90
IEC6075
25
Ex approval - 5350A:
KEMA 03ATEX1011 X
Ex data:
Terminal 1, 2 (Fieldbus circuit):
II 3 G EEx nA [nL] II C T4...T6
Ui.................................................................: 32 VDC
or
II 3 G EEx nL II C T4...T6
Ui.................................................................: 32 VDC
Li.................................................................: 1 µH
Ci.................................................................: 2 nF
or
FNICO field device
Ui.................................................................: 17.5 VDC
with cable parameters:
Rc................................................................ : 15...150 Ω/km
Lc................................................................ : 0.4...1 mH/km
Cc................................................................ : 45...200 nF/km
Spur cable length max. 60 m in IIC and IIB.
Trunk cable length inclusive length of all spurs max. 1 km in IIC and 5 km in IIB.
Terminal 3, 4, 5 and 6 (sensor circuit):
Uo................................................................: 5.7 VDC
Io.................................................................: 8.4 mA
Po................................................................: 12 mW
Lo................................................................: 200 mH
Co................................................................: 40 µF
FM, UL and CSA ......................................... IS, Class I, Div. 2, Group A, B, C, D
IS, Class I, Zone 2, Group IIC

26 2726
EEx / I.S. approval - 5350B:
KEMA 02ATEX1318..................................... II 1 GD or II 2 (1) GD,
T65°C...T105°C
EEx ia IIC or EEx ib [ia] IIC T4...T6
Applicable in zone....................................... 0, 1, 2, 20, 21 or 22
FM, UL and CSA ......................................... IS, Class I, Div. 1, Group A, B, C, D
IS, Class I, Zone 0/1, Group IIC
IS, Class I, Div. 2, Group A, B, C, D
Ex / I.S. data:
Signal output / supply, terminal 1 to 2:
Max. ambient temperature depends on the Poof the connected barrier.
Sensor input, terminal 3, 4, 5 and 6:
Uo................................................................: 5.7 VDC
Io.................................................................: 8.4 mA
Po................................................................: 12 mW
Lo................................................................: 200 mH
Co................................................................: 40 µF
GOST R approval:
Standard: VNIIM.......................................... Cert. no. Ross DK.ME48.V01899
Ex: VNIIFTRI ................................................ Cert. no. Ross DK.GB06.V00100
Ex permit ..................................................... РРС00-17800
Observed authority requirements: Standard:
EMC 2004/108/EC
Emission and immunity ....................... EN 61326-1 : 2006
ATEX 94/9/EC.............................................. EN 50014 : 1997, EN 50020 : 2002,
EN 60079-15 : 2003, EN 50284 : 1999,
EN 60079-27 : 2005
FM ............................................................... 3600, 3610, 3611
UL................................................................ UL 508, UL 1604, UL 913,
UL 60079-0, UL 60079-1
CSA, CAN / CSA......................................... C22.2 No. 142, No. 157, No. 213,
CAN / CSA .................................................. E79-0, -11, -15
ANSI / UL .................................................... UL 60079-0, -11, -15
Unit
5350B
Zone 0, EEx ia IIC, Entity / Fisco
IS, Class I, Division 1, Group A, B, C, D
Entity / Fisco
Barrier where
Po< 0.84 W
Barrier where
Po< 1.3 W
Suitable for
FISCO systems
Suitable for
FISCO systems
Ui
Ii
Pi
Li
Ci
T1...T4
T5
T6
30 VDC
120 mADC
0.84 W
1 µH
2.0 nF
Tamb. < 85°C
Tamb. < 70°C
Tamb. < 60°C
30 VDC
300 mADC
1.3 W
1 µH
2.0 nF
Tamb. < 75°C
Tamb. < 65°C
Tamb. < 45°C
17.5 VDC
250 mADC
2,0 W
1 µH
2.0 nF
Tamb. < 85°C
Tamb. < 60°C
Tamb. < 45°C
15 VDC
900 mA
5.32 W
1 µH
2.0 nF
Tamb. < 85°C
Tamb. < 60°C
Tamb. < 45°C
Unit
5350B
Zone 1, EEx ib IIC, Entity / Fisco
IS, Class I, Division 2, Group A, B, C, D
Entity / Fisco
Barriere where
Po < 5.32 W FISCO segment coupler
Ui
Ii
Pi
Li
Ci
T1...T4
T5
T6
30 VDC
250 mADC
5.32 W
1 µH
2.0 nF
Tamb. < 85°C
Tamb. < 75°C
Tamb. < 60°C
17.5 VDC
All
All
1 µH
2.0 nF
Tamb. < 85°C
Tamb. < 75°C
Tamb. < 60°C

28 29
1 2
1 2 PA
Connections:
Output:
Bus connection
Bus connection
Segment
coupler
Segment
coupler
Bus
termination
Bus
termination
Wires must be mounted between the metal
plates.
Mechanical specifications: Mounting of sensor wires

30 31
Block diagram: Bus installation:

32 33
TRANSMETTEUR PROFIBUS®PA /
FIELDBUS FOUNDATION™
PRetrans 5350
Sommaire
Consigne de sécurité ......................................................... 34
Déclaration de conformité CE............................................ 35
Application ......................................................................... 36
Caractéristiques techniques .............................................. 36
Montage / installation......................................................... 36
Applications........................................................................ 37
Référence ........................................................................... 38
Spécifications électriques .................................................. 38
Connexions, entrée ............................................................ 44
Connexions, sortie ............................................................. 45
Montage des fils du capteur .............................................. 45
Schéma de principe ........................................................... 46
Installation bus ................................................................... 47
Appendix:
FM, UL, CSA and FISCO
Installation Drawing No. 5350QE01 ................................... 65

34 35
Consigne de sécurité
Installation S.I.:
Pour l’installation de 5350 dans les zones dangereuses, conformez-vous aux
consignes de sécurité suivantes : l’installation ne doit être réalisée que par du
personnel qualifié connaissant la législation nationale et internationale ainsi
que les directives et standards régissant ce domaine.
L’année de production ressort des deux premiers chiffres du numéro de série.
L’isolation galvanique entre le circuit du capteur et le circuit d’entrée n’est pas
infaillible. Cependant, l’isolation galvanique entre les circuits est capable de
résister à une tension de test de 500 Vca pendant 1 minute.
Le transmetteur doit être monté dans un boîtier assurant un degré d’étanchéité
d’au moins IP20.
Dans les atmosphères explosibles dues à des mélanges d’air avec des poussières :
Le transmetteur doit seulement être installé dans les atmosphères potentiellement
explosibles dû à la présence de poussières combustibles quand il est monté
dans un boîtier métallique DIN B conformément à DIN 43729 assurant un
degré d’étanchéité d’au moins IP 6X conformément à l’EN 60529. Ce boîtier
doit convenir à l’application et il doit être correctement installé.
Seulement des raccords de câble et des bouchons convenant à l’application et
correctement installés doivent être utilisés.
Pour une température ambiante ≥60°C, il faut utiliser des câbles résistant aux
températures élevées avec une capacité nominale d’au moins 20 K au dessus
de la température ambiante.
Conditions spécifiques à l’utilisation sûre - 5350A :
Le transmetteur doit être installé dans un boîtier de protection assurant un
degré d’étanchéité d’au moins IP54 conformément à l’EN 60529.
Il faut prendre des mesures pour éviter que la tension d’alimentation nominelle
soit dépassée par des transitoires de plus de 40%.
Conditions spécifiques à l’utilisation sûre - 5350B :
Si le boîtier dans lequel est monté le transmetteur est fait d’aluminium et installé
en zone 0, 1 ou zone 20, 21 ou 22, il ne doit contenir en poids plus que 6%
en total de magnésium et de titane.
Le boîtier supplémentaire de l’apparail doit être construit et/ou installé dans
une telle manière que, même dans le cas d’incidents rares, les sources
d’inflammation dûes aux impacts et aux étincelles de friction ne peuvent se
produire.
DECLARATION DE CONFORMITE CE
En tant que fabricant
PR electronics A/S
Lerbakken 10
DK-8410 Rønde
déclare que le produit suivant :
Type: 5350
Nom: Transmetteur PROFIBUS®PA / Fieldbus
FOUNDATION™
correspond aux directives et normes suivantes :
La directive CEM (EMC) 2004/108/CE et les modifications subséquentes
EN 61326-1 : 2006
Pour une spécification du niveau de rendement acceptable CEM (EMC),
renvoyer aux spécifications électriques du module.
La directive ATEX 94/9/CE et les modifications subséquentes
EN 50014 : 1997, EN 50020 : 2002,
EN 60079-15 : 2003, EN 50284 : 1999,
EN 60079-27 : 2005
Certificat ATEX : KEMA 03ATEX1011 X (5350A)
Certificat ATEX : KEMA 02ATEX1318 (5350B)
Organisme notifié :
KEMA Quality B.V. (0344)
Utrechtseweg 310, 6812 AR Arnhem
P.O. Box 5185, 6802 ED Arnhem
The Netherlands
Rønde, le 13 mai 2008 Peter Rasmussen
Signature du fabricant
35

36 37
TRANSMETTEUR PROFIBUS®PA / FIELDBUS
FOUNDATION™ - PRetop 5350
• PROFIBUS®PA ver. 3.0
• Fieldbus FOUNDATION™ ver. ITK 4.6
• Commutation automatique entre protocoles
• Certifié aux normes FISCO
• Basic en Fieldbus Foundation™
Application :
• Mesure linéarisée de la température avec sonde résistive ou thermocouple.
• Mesure de la température différentielle, moyenne ou redondance avec sonde
résistive ou thermocouple.
• Résistance linéaire, potentiomètre et mesure de tension bipolaire (mV).
Caractéristiques techniques :
• Transmetteur de bus avec communication PROFIBUS®PA et Fieldbus FOUN-
DATIONTM. Une fonction de commutation unique assure le passage d’un pro-
tocole à l’autre de manière automatique.
• Configuration PROFIBUS®PA avec les logiciels Siemens Simatic®PDM®, ABB
Melody / Harmony et Metso DNA et Fieldbus FOUNDATION™ avec les logiciels
Emerson DeltaV, Yokogawa CS 1000 / CS 3000, ABB Melody / Harmony et
Honeywell Experion.
• Le mode de simulation peut être activé à l’aide d’un aimant.
• La connexion du bus est indépendante de la polarité.
• Le convertisseur A/D de 24 bit assure une très haute résolution du signal.
• Blocs de fonctions PROFIBUS®PA : 2 blocs analogiques.
• Blocs de fonctions Fieldbus FOUNDATION™ : 2 blocs analogiques et 1 bloc PID.
• Fonctionnalités en Fieldbus FOUNDATION™ : Basic. ou LAS.
Montage / installation :
• Pour tête de sonde DIN B. En zone non-dangereuse le 5350 peut être monté
sur rail DIN avec le support PR type 8421.
36 37
+
-+
-
+
-
1
+
2
+
-
+
-
2
1
2
1
-
RTD en
communication de bus
Résistance en
communication de bus
mV en
communication de bus
TC en
communication de bus
Différence, redondance ou
moyenne; RTD, TC ou mV
ou
