Precor Commercial EFX EFX546 User manual

Commercial EFX Owner’s Manual
COMMERCIAL PRODUCTS DIVISION
6
®

page 2
COMMERCIAL PRODUCTS DIVISION
Thank you for purchasing the Precor EFX®546. Built to the exacting standards
of the health club environment, the EFX is intended for commercial use and can
withstand the rigors of daily club use with little maintenance.
Before using the Precor EFX546, we urge you to familiarize yourself and your
staff with the entire Owner’s Manual. Understanding this manual will help you
and your customers use the EFX546 safely and successfully.
ABOUT THIS MANUAL
Inside this manual, you will find instructions for installing and using the EFX. To
maximize the use of the EFX, please study this manual thoroughly. The manual
uses the following conventions for identifying special information:
“Note:”Contains additional information that applies to the preceding text.
“Important:”Indicates information to which you should pay special attention.
“CAUTION:” Indicates steps or information necessary to prevent harm to
yourself or damage to the equipment.
“WARNING:”Provides instructions to prevent electrical damage to the
equipment and prevent injuries to yourself.
“DANGER:”Indicates steps you must take to prevent electrical shock.
OBTAINING SERVICE
Do not attempt to service the EFX546 yourself except for the maintenance tasks
described in this manual. The EFX does not contain any user-serviceable parts. For
information about product operation or service, contact an authorized Precor Com-
mercial Products Customer Service Representative at 1-888-665-4404.
To help the customer service representative expedite your call, have your serial
number available. To locate the serial number, kneel down alongside the EFX
and look for a label inside the rear cover.
Model number: EFX546
Unit number: _____ Serial number: ____________________________
Unit number: _____ Serial number: ____________________________
Unit number: _____ Serial number: ____________________________
Unit number: _____ Serial number: ____________________________
Unit number: _____ Serial number: ____________________________
Unit number: _____ Serial number: ____________________________
Unit number: _____ Serial number: ____________________________
If you have any questions regarding the EFX546, use the model and serial
numbers whenever you call your Precor dealer or servicer.
Before You Begin

page 3
COMMERCIAL PRODUCTS DIVISION
When using an electrical appliance, basic precautions should always be
followed, including the following:
• Read all instructions before using the EFX546.These instructions were
written to ensure your safety and to protect the unit.
• To ensure the proper use and safety of the EFX546, make sure that all
users read this manual. Please make this manual a part of your training
program.
Remind the club users that before beginning any fitness program, he or she
should obtain a complete physical examination from his or her physician.
Il est conseillé de subir un examen médical complet avant d’entre-prendre
tout programme d’exercise. Si vous avez des étourdissements ou des
faiblesses, arrêtez les exercices immédiatement.
DANGER —
WARNING —
• The EFX546 should never be left unattended when plugged in. Unplug
the unit from the outlet when it is not in use, before cleaning it, and
before putting on or taking off parts.
• Do not allow children on or near the EFX.
• Use the EFX546 only for its intended use as described in this manual.
Do not use accessory attachments that are not recommended by the
manufacturer—such attachments might cause injuries.
• Never operate the unit if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped in
water. Return the unit to a service center for examination and repair.
• Keep the power cord away from heated surfaces.
• Never drop or insert any object into any opening. Keep hands away
from moving parts.
• Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
• Do not use outdoors.
• To disconnect, turn all controls to the OFF (O) position, then remove
the power plug from the outlet.
WARNING —
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of electrical shock, always unplug the unit
from its power source before cleaning or performing any
maintenance tasks.
To reduce the risk of burns, fire, electric shock, or injury to
persons, take the following precautions:
Connect the EFX to a properly grounded outlet
only. See Grounding Instructions on page 4.
SAVE THESE INSTRUCTIONS

page 4
COMMERCIAL PRODUCTS DIVISION
GROUNDING INSTRUCTIONS
The EFX546 must be grounded. If it should malfunction or break down, ground-
ing provides a path of least resistance for electric current which reduces the risk
of electrical shock. The EFX546 is equipped with a power cord having an equip-
ment-grounding conductor and a grounding plug. The plug must be inserted
into an appropriate outlet that is properly installed and grounded in accordance
with all local codes and ordinances. If you do not follow these Grounding In-
structions , you could void the Precor limited warranty.
DANGER
Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are
in doubt as to whether the EFX is properly grounded. Do not modify the plug
provided with the unit—if it doesn’t fit the outlet, get a proper outlet installed by
a qualified technician.
120V Units Designated for U.S. Markets
The EFX546 is for use on a nominal 120-volt circuit. The unit’s grounding plug
looks like the plug illustrated in Diagram A. The power outlet must have the
same configuration as the plug. No adapter should be used with this product.
240V Units Designated for U.S. Markets
The EFX546 is for use on a nominal 240-volt circuit. The unit is factory-equipped
with a specific power supply cord to permit connection to a proper electric circuit.
Make sure that the EFX is connected to an outlet having the same configurations
as the plug. See Diagram A. No adapter should be used with this product. If the
EFX must be reconnected for use on a different type of electrical circuit, the
reconnection must be made by qualified service personnel.
SAFETY APPROVAL
When identified with the ETL-c logo, the EFX has been tested and conforms to
the requirements of CAN/CSA-E-335-1/2-94, Safety of Household and Similar
Electrical Appliances.
Diagram A
Correct power
outlet for U.S.
Markets: 20 amp
120-volt and
240-volt plugs.
120-volt grounding plug 240-volt grounding plug

page 5
COMMERCIAL PRODUCTS DIVISION
RFI — RADIO FREQUENCY INTERFERENCE
Federal Communications Commission Part 15
The EFX has been tested and found to comply with,
• the IEC EMC Directive (international electromagnetic compatibility certification)
• the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a commercial installation. The EFX generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the owner’s manual instructions, may cause harmful interference to ra-
dio communications. Operation of the EFX in a residential area is likely to
cause harmful interference. If this occurs, the user will be required to correct
the interference at his or her own expense.
CAUTION —
Canadian Department of Communications
This digital apparatus does not exceed the Class A limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioéélectriques dépassant
les limites applicables aux appareils numériques de la Class A prescrites dans le
Règlement sur le brouillage radioélectrique édicté par le ministére des Communi-
cations du Canada.
EUROPEAN APPLICATIONS
This product conforms to the requirements of the European Council Directive 89/336/
EEC, Electromagnetic Compatibility and has been tested to the following standards:
EN55022, Limits & Methods of Measurement of Radio Interference, Information
Technology Equipment (Class A).
EN50082-1, Generic Immunity Standard for Residential, Commercial and Light
Industrial Products (Class A).
This product additionally conforms to the requirements of the European Council Direc-
tive 73/23/EEC, Low Voltage Directive and has been tested to the following standard:
IEC 335-1, Safety of Household and similar Electrical Appliances.
European Applications - 240 Volt Units Only
This product has been tested to the requirements of EN55022, “Limits & Methods
of Measurement of Radio Interference, Information Technology Equipment.” Per
that standard, the EFX546 is a Class A product. In a domestic environment, this
product may cause radio interference, in which case the user is responsible to take
adequate measures to alleviate the interference.
Per FCC rules, changes or modifications to the
EFX not expressly approved by Precor, could void
the user’s authority to operate the equipment.

page 6
COMMERCIAL PRODUCTS DIVISION
PERSONAL SAFETY
When using the EFX, take the following precautions:
• Do not allow children on or near the EFX. Do not leave children unsupervised
around the EFX.
• Completely assemble the EFX546 before using it. Check the unit before
each use. Do not continue to operate the EFX546 when it is not working
properly and return the unit to a service center for examination and repair.
• Keep all electrical components, such as the power cable and I/O switch, away
from liquids to prevent shock. Do not set anything on the casing, handrails, or
display console. Place liquids only in the appropriate receptacles.
• Assemble and operate the EFX on a solid, level surface. Locate the EFX a few
feet from walls or furniture. Keep the area behind the EFX clear.
• Maintain the EFX in good working condition. (See the
Maintenance section).
Run through a check list prior to each use. Verify that all fasteners are secure.
• Wear proper exercise clothing and shoes during a workout—no loose cloth-
ing. Tie long hair back. Keep towels away from moving parts.
• Use care when getting on or off the EFX. Use the stationary handrail(s)
whenever possible. Keep your body and head facing forward. Never attempt
to turn around on the EFX.
• Never place your hand(s) or feet in the path of the roller arm because injury
may occur to you or damage may occur to the equipment.
• Do not use accessory attachments that are not recommended by the manu-
facturer—such attachments might cause injury.
• Do not rock the unit. Do not stand on the display console or casing.
• Do not attempt to service the EFX yourself other than the assembly and main-
tenance instructions found in this manual. Refer to Obtaining Service .
• Do not overexert yourself or work to exhaustion. If you feel any pain or abnor-
mal symptoms, stop your workout immediately and consult your physician.
PRECOR HEART RATE OPTIONS—SAFETY GUIDELINES
The Precor Heart Rate Options are created and designed exclusively for Precor
products. The equipment is very sensitive—you should use the heart rate options
with this in mind and take time to read the guidelines found in this owner’s manual.
If you purchased the POLAR®chest strap, review the guidelines found in the Precor
Heart Rate Option Owner’s Manual that is supplied with that option.

page 7
COMMERCIAL PRODUCTS DIVISION
Before You Begin ..............................................................2
About this Manual .................................................................. 2
Obtaining Service .................................................................. 2
Important Safety Instructions ................................................. 3
Grounding Instructions .......................................................... 4
Safety Approval ..................................................................... 4
RFI — Radio Frequency Interference .................................... 5
European Applications .......................................................... 5
Personal Safety ..................................................................... 6
Precor Heart Rate Option - Safety Guidelines ....................... 6
Unpacking the EFX®................................................................................................... 9
Standard Equipment .............................................................. 9
Optional Equipment ............................................................... 9
Hardware Kit .......................................................................... 10
Acquire the Appropriate Tools ............................................... 10
Setting Up the EFX .........................................................11
Installation Requirements ...................................................... 11
Assembly Instructions ........................................................... 11
Turning the EFX546 ON and OFF ......................................... 16
Club Information .............................................................17
Changing the Club Settings ................................................... 17
Selecting the Language ......................................................... 18
Determining the Units of Measure ......................................... 18
Setting a Workout Time Limit ................................................. 19
Setting a Pause Time Limit .................................................... 19
Viewing the Odometer, Hours of Use,
Software Version, and Error Log ............................................ 19
Using CSAFE Standard Equipment ....................................... 20
The EFX546 Display .......................................................21
Features on the Display Console .......................................... 21
Top Display Windows............................................................. 22
Center Display Window ......................................................... 22
Elongated Center Display ...................................................... 22
Keys on the Display Console ................................................. 24
Keypad Tips ........................................................................... 25
Table of Contents

page 8
COMMERCIAL PRODUCTS DIVISION
Table of Contents
Exercising on the EFX....................................................28
Using the Heart Rate “Touch” Capability ............................... 28
Workout Tips ......................................................................... 28
Quick Steps to Working Out .................................................. 29
Cooling Down After a Workout .............................................. 30
Pause, Cool Down and Exit Features .................................... 30
Courses ...........................................................................32
The Heart Rate Feature ........................................................ 32
Utilizing the Smart Rate® Feature .......................................... 32
Manual Mode and the Quick Start Key .................................. 33
Cross Training and Gluteal Courses ...................................... 34
Interval Course ...................................................................... 34
Weight Loss Course .............................................................. 35
Maintenance....................................................................36
Cleaning the Equipment ........................................................ 36
Storing the POLAR®Chest Strap .......................................... 36
Servicing the EFX .................................................................. 36
Long Term Storage ................................................................ 36
Workout Statistics Log...................................................37
Warranty Card ....................................................................... 39
Specifications ............................................................back cover

page 9
COMMERCIAL PRODUCTS DIVISION
Your EFX546 is carefully inspected before shipment so it should arrive in good
operating condition. Precor ships the unit in the following pieces:
❑base frame assembly
❑upper column support with display console
❑handrails (left and right)
❑upper column support bracket covers (2 pieces)
❑hardware kit, power cord, Owner’s Manual
CAUTION:This unit weighs over 200 pounds (90 kilograms).To avoid back
strain and ensure the safety of the unit and yourself, we suggest that you
get assistance before removing the unit from the pallet. To remove the
EFX from the wood pallet, be sure to ask for assistance from more than
one adult.
If any items are missing, contact your Precor Commercial Products Service
Representative at 1-888-665-4404.
STANDARD EQUIPMENT
The EFX546 incorporates the Precor Smart Rate®and Heart Rate features into
it’s display console. Devices, such as FitLinxx®, that are CSAFE compatible, can
also be attached.
Note: An optional POLAR® chest strap must be worn to transmit a user’s heart
rate to the display console’s receiver. The Precor “touch” heart rate can be pur-
chased (at point of sale) and provides electrode strips on the handrails. When a
user places his or her hands over the strips and grasps the handrail(s), a heart
rate is transmitted to the receiver.
OTHER EQUIPMENT
Optional (and other) equipment available through your dealer includes:
• POLAR®Heart Rate Option — chest strap.
• Precor “touch” Heart Rate — This type of EFX requires special handrails
that must be purchased at the time of the sale. It is not an accessory item
that can be purchased once the unit is assembled.
• the CSAFE option (Stores personal workout statistics in a computer file.
Operation requires cable connection to a separate computer.)
If you are interested in obtaining Precor option kits for your unit, check with your
dealer. To locate the dealer nearest you, call 1-888-665-4404. For customer ser-
vice, see Obtaining Service on page 2.
Unpacking the EFX®

page 10
COMMERCIAL PRODUCTS DIVISION
HARDWARE KIT
Carefully unpack the parts from the shipping container. Open the Hardware kit
and make sure that you have the following items as shown in Diagram 1:
(A) four socket hex screws—clamp covers
(B) eight set screws—handrail assembly
(C) 1/8" hex key—set screws on handrail assembly
(E) 3/16" hex key—screws on the clamp covers
Upper and lower clamp covers (not shown in Diagram 1)
Diagram 1 EFX546
Hardware kit
C
D
If any items are missing, contact your dealer. For the Precor authorized dealer
or servicer nearest you, call 1-888-665-4404.
Note: After assembling the EFX, be sure to store the hex keys in a secure place.
The tools are used for specific maintenance procedures that are described in this
manual.
ACQUIRE THE APPROPRIATE TOOLS
Obtain the following tools before assembling the EFX.
Wire cutter
SAE Standard socket set with a ratchet or 8" crescent wrench
3/32" Hex Torque wrench
A
B
