Owner’s Manual
Addendum
This addendum accompanies your EFX
®
556i Owner’s Manual . Changes have
occurred to the hardware kit and the Assembly Instructions.
HARDWARE KIT
The following hardware kit replaces the one found in the Owner’s Manual .
❑(A) four stainless steel socket hex screws—upper column assembly
❑(B) fourteen washers—upper column assembly
❑(C) four nuts—upper column assembly
❑(D) six black socket hex screws—handlebars
❑(E) two 2-inch hex screws—link arm assembly
❑(F) six washers—link arm assembly
❑(G) two steel bushings—link arm assembly
❑(H) two low profile locknuts—link arm assembly
❑(J) four plastic caps—link arm assembly
❑(K) four buttonhead hex screws—covers for upright assembly
❑(L) ⁵⁄₁₆ - inch hex key—screws on bracket covers
❑(M) ¹⁄₄ - inch hex key— upper column assembly
P/N 47934-101
June 17, 2004
If any items are missing, refer to Obtaining Service in your Owner’s Manual .
Diagram 1
EFX
®
556i Hardware kit
(not shown to scale).
EFX556i
J

ACQUIRE THE APPROPRIATE TOOLS
An addition to this section of the owner’s manual includes:
●⁹⁄₁₆-inch open end wrench
ASSEMBLY INSTRUCTIONS
Replace steps 6 through 8 (Diagrams 7 through 9) with the following:
6. Remove the fasteners from the hardware kit and cut the tie
wraps that secure the link arms.
a. Remove two screws (E), six washers (F), two steel bushings
(G), and two locknuts (H) from the hardware kit.
b. Place a washer (F) on each screw.
Note: Perform the following steps on one handlebar at a time.
7. Attach the base of the handlebar to the foot pedal link arm.
Diagrams 2, 3, and 4.
a. Align the base of the handlebar with the foot pedal link arm.
Straighten the handlebar so that the link arm and handlebar
base fit together. Refer to Diagram 2.
b. Thread screw (E) with washer (F) through the link arm. Refer
to Diagram 3, #1 and #2.
Important: The head of the screw should be facing the EFX
®
. It
is inserted through the link arm first.
c. Place a spacer (G) and washer (F) on the end of the screw.
Insert the link arm onto the handlebar base and slide the screw
throughit.
d. Slide a washer (F) and thread a locknut (H) on to the end of
the screw. Refer to Diagram 3, #2.
e. Wrench tighten using a ⁹⁄₁₆-inch socket and open end wrench.
Refer to Diagram 4, #1.
Important: Once the fasteners are secured, use a
hex torque wrench to tighten the two linkage arm
screws to 200 in-lbs.
f. Position two plastic caps (J) over the ends of the handlebar
mounts. Press them into place. Refer to Diagram 4, #2.
8. Return to the handlebar bracket fasteners. Tighten all three
screws using a ¹⁄₄-inch hex key. Diagram 4, #3.
Note: To complete the EFX®556i assembly, return to the
assembly steps in your owner’s manual.
1
2
Handlebar alignment.
Diagram 2
EFX®upright
Handlebar
Handlebar bracket
Link arm
Handlebar base
Handlebar and link arm
assembly.
Diagram 3
Link arm
Handlebar base
Steel bushing (G)
Washer (F)
Washer (F)
2-inch screw (E)
Plastic cap (J)
Link arm
Handlebar base
Locknut (H)
1
3
Finalize link arm and
handlebar bracket
assembly.
Diagram 4
Wrench tighten
link arm assembly.
¹⁄₄-inch hex key (M)
Handlebar bracket
2
