Precor HANDBOEK EFX 556i User manual

COMMERCIAL PRODUCTS DIVISION
EFX556i
Commercial EFX®Owner’s Manual

page2
COMMERCIAL PRODUCTS DIVISION
WhenusingtheEFX®,basicprecautionsshouldalwaysbefollowed,including
thefollowing:
• To ensure your safety and to protect the unit, read all the instructions
before assembling and usingtheEFX®556i.
• To ensure the proper use and safety of the EFX®556i,make sure that all
users read this manual. Please make this manual a part of your club’s
training program. Remind the club users that before beginning any fit-
nessprogram,he or sheshouldobtain a completephysicalexamination
from his or her physician.
Il est conseillé de subir un examen médical complet avant d’entre-prendre
tout programme d’exercise. Si vous avez des étourdissements ou des
faiblesses, arrêtez les exercices immédiatement.
DANGER —
WARNING —
• TheEFX®556ishouldneverbeleft unattendedwith the battery recharger
plugged in. Unplug the unit from the outlet when it is not in use, before
cleaning it, and before putting on or taking off parts.
• Do not allow children or those unfamiliar with its operation on or near
the EFX®. Do not leave children unsupervised around the EFX®.
• Use the EFX®556i only for its intended use as described in this manual.
Do not use accessory attachments that are not recommended by the
manufacturer—such attachments might cause injuries.
• Assembleand operate the EFX on a solid level surface. LocatetheEFX®
a few feet from walls or furniture. Check the unit before each use and
verify that all fasteners are secure. Maintain the EFX®in good working
condition.(Seethe Maintenance section).
• Wear proper exercise clothing and shoes during a workout—no loose
clothing.Tie long hair back.
• Never drop or insert any object into any opening. Keep towels and
hands away from moving parts.
• Use care when getting on or off the EFX®. Use the stationary handrail
whenever possible. Keep your body and head facing forward. Never
attempt to turn around on the EFX®.
• Never operate the unit if it is damaged,if it is not working properly,if it
has been dropped, or dropped in water. Return the unit to a service
center for examination and repair.
•Keepallelectricalcomponentsawayfromliquidstopreventshock.Do not
set anything on the casing, handrails, or display console. Place liquids
onlyintheappropriatereceptacles.
• Keep the optional battery recharger cord away from heated surfaces.
• Donot operatewhere aerosol (spray) products arebeing usedor where
oxygen is being administered.
• Do not use outdoors.
IMPORTANT SAFETY INSTRUCTIONS
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONS
To reduce the risk of burns,fire, electric shock,or injury to
persons, take the following precautions:
To reduce the risk of electrical shock, always unplug the
optionalbattery rechargerfromitspowersource beforeclean-
ing or performing any maintenance tasks.
SAVE THESE INSTRUCTIONS

page3
COMMERCIAL PRODUCTS DIVISION
SAVETHESE INSTRUCTIONS
• Never place your hand(s) or feet in the path of the roller arm because
injury may occur to you or damage may occur to the equipment. Refer
to Diagram 1.
• Do not use accessory attachments that are not recommended by the
manufacturer—such attachments might cause injury.
• Do not rock the unit. Do not stand on the display console or casing.
• Do not attempt to service the EFX®yourself other than the assembly and
maintenanceinstructionsfoundinthismanual.Referto ObtainingService .
• Do not overexert yourself or work to exhaustion. If you feel any pain or
abnormal symptoms, stop your workout immediately and consult your
physician.
HAZARDOUS MATERIALS AND PROPER DISPOSAL
TheEFX®556i hasaninternal battery whichmust be removedbeforethe EFX®is
scrapped.Thebattery containsmaterials whichareconsidered hazardous tothe
environment.Proper disposal of the battery is required by federal law.
To remove the battery from the EFX®, take the following steps:
CAUTION:Unplug the battery recharger and disconnect it from
its receptacle at the rear of the EFX®.
Tools required: Phillips head screwdriver and hex wrench set.
1. Remove both the right and left rear covers from the EFX®.
2. Remove the top rear cover.
3. Unplug the black and red battery wires from the circuit board.
4. Separate the circuit board from the battery by removing four screws.
5. The battery is held in place with a metal bracket. Lift the battery away from
the bracket.
6. Disposeofthe batteryaccordingtothefederalHazardousWasteRegulations.
SAFETY APPROVAL
When identified with the ETL-c logo, the EFX has been tested and conforms to
the requirements of CAN/CSA-E-335-1/2-94, Safety of Household and Similar
Electrical Appliances.
Diagram 1
Avoid injuryfromthe roller arm
mechanism.
Front cover
Rollerarm
IMPORTANT SAFETY INSTRUCTIONS
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONS

page4
COMMERCIAL PRODUCTS DIVISION
Important Safety Information...........................................2
HazardousMaterials andProperDisposal .............................. 3
SafetyApproval ..................................................................... 3
RFI— Radio Frequency Interference ..................................... 6
EuropeanApplications ........................................................... 6
EFX®Self-powered Features.................................................. 7
ObtainingService................................................................... 7
About this Manual .................................................................. 8
Unpacking the EFX®..................................................................................................9
StandardEquipment............................................................... 9
OptionalEquipment................................................................ 9
HardwareKit .......................................................................... 10
Acquirethe AppropriateTools ................................................. 10
Setting Up the EFX®............................................................................................... 11
Installation Requirements ....................................................... 11
Assembly Instructions ........................................................... 11
Supplying Power to the EFX®556i........................................... 16
Testing the Heart Rate Display............................................... 17
Club Information.............................................................18
Changingthe ClubSettings .................................................... 18
Selectingthe Language.......................................................... 19
Determiningthe Units of Measure .......................................... 20
Setting aWorkoutTime Limit.................................................. 20
Setting a Pause Time Limit .................................................... 20
Viewingthe Odometer, Hours of Use,
SoftwareVersion,and Error Log ............................................. 20
Using CSAFEStandard Equipment ........................................ 21
The EFX®556i Display ....................................................22
Featureson the Display Console............................................ 22
SmartRate®Display ............................................................... 23
Heart Rate Display ................................................................. 23
UpperDisplay......................................................................... 23
InformationalDisplays Prior to Shutdown ............................... 23
LowerDisplay......................................................................... 24
Keys on the Display Console.................................................. 26
KeypadTips ........................................................................... 26
Table of Contents

page5
COMMERCIAL PRODUCTS DIVISION
Table of Contents, continued
Exercising on the EFX®..................................................................................... 29
Usingthe Handlebars ............................................................. 29
Usingthe Stationary Handrails ............................................... 29
Pause, Cool Down and Exit Features ..................................... 29
WorkoutTips .......................................................................... 30
Quick Steps to Working Out ................................................... 31
CoolingDown AfteraWorkout ................................................ 32
Programs ........................................................................33
TheHeart Rate Feature.......................................................... 33
Usingthe SmartRate® Feature................................................ 34
Manual Mode and the QUICKSTARTTM Key............................ 35
CrossTrainingProgram .......................................................... 35
CrossCountry and Hill ClimbPrograms ................................. 35
IntervalProgram..................................................................... 36
WeightLoss Program............................................................. 37
FitnessTest............................................................................ 37
FitnessTest Guidelines .......................................................... 37
FitnessTest Scores ............................................................... 39
Maintenance ...................................................................38
Inspection .............................................................................. 38
Cleaningthe Equipment ......................................................... 38
Storing the POLAR®Chest Strap ........................................... 39
Servicing the EFX®andLongTerm Storage............................ 39
Symptoms of a Low Battery ................................................... 39
Usingthe Battery Recharger .................................................. 39
Replacingthe Battery............................................................. 40
Battery RechargerPowerCord ............................................... 40
ExplodedViews...................................................................... 41
WarrantyRegistrationCard..................................................... 49
Warranty................................................................................. 51
Specifications ............................................................back cover

page6
COMMERCIAL PRODUCTS DIVISION
RADIO FREQUENCY INTERFERENCE (RFI)
Federal Communications Commission Part 15
The EFX®has been tested and found to comply with,
• theIECEMCDirective(internationalelectromagneticcompatibilitycertification)
• the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a commercial installation.The EFX generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
withtheowner’s manualinstructions,maycause harmfulinterferenceto radio
communications. Operation of the EFX in a residential area is likely to cause
harmful interference. If this occurs, the user will be required to correct the
interferenceat hisor herownexpense.
CAUTION:Per FCC rules,changesor modificationsto theEFX®not
expresslyapprovedbyPrecor,could voidthe user’sauthority to operate
theequipment.
Canadian Department of Communications
This digital apparatus does not exceed the Class A limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
DepartmentofCommunications.
Leprésentappareilnumériquen’émetpasdebruitsradioéélectriquesdépassantles
limites applicables aux appareils numériques de la Class A prescrites dans le
RèglementsurlebrouillageradioélectriqueédictéparleministéredesCommunica-
tionsduCanada.
EUROPEAN APPLICATIONS
This product conforms to the requirements of the European Council Directive 89/336/
EEC,ElectromagneticCompatibilityandhasbeentested tothefollowingstandards:
EN55022, Limits & Methods of Measurement of Radio Interference, Information
TechnologyEquipment(Class A).
EN50082-1, Generic Immunity Standard for Residential, Commercial and Light
Industrial Products (Class A).
ThisproductadditionallyconformstotherequirementsoftheEuropeanCouncilDirective
73/23/EEC,LowVoltageDirectiveandhasbeentestedtothefollowingstandard:
IEC 335-1, Safety of Household and similar Electrical Appliances.
European Applications
ThisproducthasbeentestedtotherequirementsofEN55022,“Limits&Methodsof
Measurement of Radio Interference, Information Technology Equipment.” Per that
standard, the EFX®556i is a Class A product. In a domestic environment, this prod-
uct may cause radio interference, in which case the user is responsible to take
adequatemeasurestoalleviatetheinterference.

page7
COMMERCIAL PRODUCTS DIVISION
EFX®SELF-POWERED FEATURES
The power source for the EFX®is the user.When a person works out on the EFX
and moves the foot pedals at a stride rate above 40 strides per minute, the power
that is generated allows the EFX to function properly.
Informationaldisplaysappearwhenthebatteryisloworwhentheuserhasstopped
pedaling during a workout.The display provides minimal instructions to let you
know what to do to retain power.If the messages are ignored, the EFX will begin
shutdown procedures to maintain the charge of the battery. Refer to page 23,
InformationalDisplaysPriortoShutdown .
An optional battery recharger can be purchased and provides sustained power to
theEFX. Ifyou planto customizeyourunit,theoptional batteryrecharger ishighly
recommended.Topurchasetheoptional batteryrecharger,checkwithyourdealer.
OBTAINING SERVICE
Donot attempt toservice the EFX®556iyourself exceptforthe maintenancetasks
describedinthis manual.TheEFXdoes notcontainanyuser-serviceableparts.For
informationaboutproductoperationorservice,contactanauthorizedPrecorCom-
mercial Products Customer Support Representative at 1-888-665-4404 or, check
outthewebsite(www.precor.com).
Diagram 2 EFX
®
556i serial number location.
Serial number label location
TohelpCustomerSupport personnel expediteyourcall, haveyourserial number
available.The serial numbercanbe foundon alabel nearthepowerreceptacle on
the rear cover. Refer to Diagram 2. If you have any questions regarding the
EFX®556i, use the model and serial numbers whenever you call your Precor
dealerorservicer.
Modelnumber: EFX®556i
Unitnumber: _____ Serialnumber: _____________________________
Unitnumber: _____ Serialnumber: _____________________________
Unitnumber: _____ Serialnumber: _____________________________

page8
COMMERCIAL PRODUCTS DIVISION
ABOUT THIS MANUAL
Insidethis manual,youwill findinstructionsfor installingandusing theEFX®556i.
To maximize the use of the EFX®, please study this manual thoroughly. The
manual uses the following conventions for identifying special information:
Note: Containsadditional information that appliestothe preceding text.
Important: Indicates information to which you should pay special attention.
CAUTION: Indicatessteps or informationnecessaryto preventharm to your-
self or damage to the equipment.
WARNING — Provides instructions to prevent electrical damage to
the equipment and prevent injuries to yourself.
DANGER — Indicates steps you must take to prevent electrical shock.

page9
COMMERCIAL PRODUCTS DIVISION
Thankyou forpurchasing theself-powered PrecorEFX®556i. Builtto theexacting
standardsof the health club environment,theEFX®556i is intended forcommer-
cial use and can withstand the rigors of daily club use with little maintenance.
Important:Before usingthePrecor EFX
®
,we urgeyoutofamiliarize yourselfand
yourstaff with theentire Owner’s Manual.Understanding thismanualwillhelpyou
and your customers use the EFX
®
556i safely and successfully.
The EFX is carefully inspected before shipment so it should arrive in good oper-
ating condition. Precor ships the unit in the following pieces:
❑base frame assembly
❑upper column support with display console
❑handlebars(left andright)
❑upper column support clamp covers (2 pieces with split rubber grommet)
❑hardwarekitand Owner’sManual
CAUTION:This unitweighsover200pounds (90 kilograms).To preventinjury
toyourselfordamageto the equipment, obtain appropriateassistancebefore
removing the unit from the pallet.
Ifany items aremissing, contact yourPrecorCommercial ProductsServiceRep-
resentative.Referto ObtainingService on page 7.
STANDARD EQUIPMENT
TheEFX®556iincorporatesthePrecorSmartRate®andHeart Ratefeaturesinto its
display console. Devices, such as FitLinxxTM, that are CSAFETM compatible, can
alsobeattached.
The Precor “touch” heart rate is standard and provides electrode strips, called
“grips,”on thecenter handrails.When auser placeshis orher handsoverthe grips
and grasps the handrails, a heart rate is transmitted to the receiver.
Note: If a user does not wish to use the touch-sensitive hand grips, an optional
POLAR® chest strap can be purchased and worn.The chest strap transmits the
user’s heart rate to the display console’s receiver.
OPTIONAL EQUIPMENT
Optionalequipment available throughyour dealer includes:
• POLAR®Heart Rate Option — chest strap.
• the CSAFE option (Stores personal workout statistics in a computer file.
Operationrequirescableconnection to a separatecomputer.)
• Batteryrecharger
If you are interested in obtaining Precor option kits for your unit, check with your
dealer.Tolocatethedealernearestyou,call1-800-786-8404.Forcustomersupport,
see ObtainingService on page7.
Unpacking the EFX®

page10
COMMERCIAL PRODUCTS DIVISION
E
F
G
D
HARDWARE KIT
Carefully unpack the parts from the shipping container. Open the Hardware kit
and make sure that you have the following items as shown in Diagram 3:
❑(A) four stainless steel socket hex screws—upper column assembly
❑(B)fourteenwashers—uppercolumnassembly
❑(C)four nuts—upper columnassembly
❑(D) six black socket hex screws—handlebars
❑(E) two hex screws—link arm assembly
❑(F)four washers—link arm assembly
❑(G) two steel bushings—link arm assembly
❑(H) two plastic caps—link arm assembly
❑(J)fourbuttonhead hex screws—covers for uprightassembly
❑(K) 5/32-inch hex key—screws on bracket covers
❑(L) 1/4-inch hex key— upper column assembly
Diagram 3 EFX
®
556i
Hardwarekit
C
Ifanyitemsaremissing, contactyourdealer.Referto ObtainingService onpage 7.
A
B
H
J
K
L

page11
COMMERCIAL PRODUCTS DIVISION
Youdo notneedanyspecialknowledgeorexperiencetosetuptheEFX®.However,
because of the size and weight of the EFX, you will need to obtain appropriate
assistanceduring assembly.
ACQUIRE THE APPROPRIATE TOOLS
Obtain the following tools before assembling the EFX.
❑Wirecutter
❑Standardhex torquewrench
❑¹⁄₂-inchopen-endor box-endwrench
❑SAE Standard socket set
Note: After assembling the EFX, be sure to store the hex keys in a secure place.
The tools are used formaintenance procedures thatare described inthis manual.
INSTALLATION REQUIREMENTS
Follow these installation requirements when installing the EFX. If you do not
install the EFX according to the following guidelines, you could void the Precor
LimitedWarranty.
•SetuptheEFXonasolid,flatsurface. UnpackandassembletheEFXcloseto
where you’ll use it. Make sure that the flat surface under the unit is smooth and
level.A level unit is required for the user’s safety and for proper operation.
•Provide ample space around the unit.Openspace aroundthe unitmakes
for a safer mount and dismount.
•Filloutandmailthe limited warranty card.Tolocatetheserialnumber,place
yourselfattherearoftheunitfacingthedisplayconsole,kneeldownandlookat
rearlabelnearthepowerreceptacle.(Referto Diagram2 on page7.)Writethe
serialnumberontothePrecorLimitedWarrantycardfoundonthebackcoverof
this manual.Return topage 7 andwrite thenumber thereas well.
ASSEMBLY INSTRUCTIONS
To assist you in the assembly, the items in the Hardware kit, shown in Diagram 3,
correspond to a particular letter in the alphabet.These letters appear throughout the
assemblyinstructions.RefertoDiagram3 on page 10.
1. Unpack the EFX®556i. Remove the packing materials and loose contents
(upper console assembly with electronic console, hardware kit, bracket
covers, and handrails) from inside the cardboard pockets and from around
the base frame assembly.
2. Pull the large cardboard piece away from the base frame assembly.Ask
for assistance to move the EFX®556i off the shipping pallet.You may need to
cut the tie wraps that hold the base frame and roller arms to the pallet.
Setting Up the EFX®

page12
COMMERCIAL PRODUCTS DIVISION
3. Attach the upper assembly. Diagram 4.Have anassistant hold the upright
support over the base frame bracket, while you take the following steps:
a. Removeanytape(orwireties) thatfastenthecablestothe baseassembly.
Ensure that the cables are out of the way while your assistant aligns the
upright support to the base frame bracket mounts.
b. Placeawasher(B)oneachoffourstainlesssteelsocketheadscrews(A)and
insertthescrewsthroughthemountingholes.Placeawasher(B)andthreada
hexnut(C)ontoeachscrew.SeeDiagram4,#2.Wrenchtightenusinga¹⁄₄-inch
hexkey and¹⁄₂-inchopen-orbox-endwrench.SeeDiagram4,#3.
CAUTION:Donotstretch,crimp,ordamagethecable.Excesscablemaybe
gently pushed into the upper support tube. Cables damaged by improper
installationwillnotbe coveredbythe Precor LimitedWarranty.
Diagram 4
1 2
4. Connect the cable. Diagram 5.Insert the cable into its receptacle.Just like a
telephone connection, a definite "click" is heard when a good connection is
made. If you do not hear a "click," try reinserting the cable again. Place the
excess cable inside the upper portion of the support tube.
Important: Recheck that the cable connection is secure after you push the
excess cable inside the support tube.
Diagram 5
Connect the cable.
Base frame support
Upper support tube
12
Screws (A) and
washers (B)
Cable
Lower bracket 3
Secure the console
assembly to the
base frame.
Cable connector
Cable
receptacle
Push excess cable
inside upper
support tube.

page13
COMMERCIAL PRODUCTS DIVISION
Diagram 7
Attaching the
handlebar linkage to
the roller arm.
Foot pedal
Handlebar linkage
Diagram 6
Attach the handlebars.
Handlebar
Black screws (D) with
washers (B)
Handlebar bracket
Steel bushing (G)
5. Attach the handlebars. Diagram6.Takethefollowingsteps:
a.Removethe six black screws (D) and sixwashers(B) from the Hardware
kit.Place a washer on each screw.
b.Pick up a handlebar and slide it onto the bracket.See Diagram 6, #1.
c.MakesurethatthehandlebarispositionedasshowninDiagram6,#1and#2.
d.Insert three black screws (D) with washers (B) and tighten the fasteners
withyour fingers.
Important:Do notwrenchtighten the fastenersuntilafter the linkagearm
is attached.
e.Perform steps b.through d.on the opposite side.
6. Attachthehandlebarlinkageto the foot pedal bytakingthefollowingsteps:
a.Remove the twoscrews (E), fourwashers(F), and twosteel bushings (G)
from the Hardware kit.Place a washer and bushing on each screw.
Note:Perform the following steps on one side at a time.
b.Thread the screw (E) with fasteners (F and G) into the roller arm mount.
SeeDiagram 7.
1 2
Washer (F)
Washer (F)
Screw (E)
Roller arm
Roller arm mount

page14
COMMERCIAL PRODUCTS DIVISION
c.Wrench tighten using a⁹⁄₁₆-inchsocketwrench.Diagram 8.
Important: Once the fasteners are secured, use a hex torque wrench to
tighten the two linkage arm screws to 200 in-lbs.
Diagram 8
Secure the rear handlebar linkage.
Handlebar linkage
Wrench tighten the screw. Once it
is secured, use a torque wrench
set at 200 in-lbs.
Diagram 9
Align and secure
the front portion of
the handlebar
linkage. Cap the
rear portion.
12
Gap around
edge of linkage
should remain
consistent
7. Align the handlebar linkage with the handlebar. Diagram 9, #1.Return to
thehandlebarbracketandstraightenthehandlebarsothatthelinkagebelowit
issetclosetoa 90degree angle.Tightenthe threescrewsoneach handlebar
using a ¹⁄₄-inch hex key.
8. Install the plastic cap onto the linkage arms. Diagram 9, #2. Position the
plastic cap over the fasteners and press on it so it snaps it into place.
Black plastic cap

page15
COMMERCIAL PRODUCTS DIVISION
Diagram 10
Installing the covers.
Rear bracket cover
Split rubber
grommet
Upright support tube
12
Front bracket cover
Buttonhead
screws (J)
9. Install the bracket covers. Diagram 10. Remove the two bracket covers,
andthesplit rubber grommet fromthepackaging. Remove four buttonhead
screws (J) from the Hardware kit.Then, take the following steps:
a.Usetwobuttonheadscrews (J)toattachtherearbracket coverto thecenter
tube.See Diagram 10, #1.Tighten the screws with the hex key provided.
b.Position thesplit rubbergrommetaround theuprightsupporttube.Slide the
grommet against the rear bracket cover to help secure it in place.
c.Usetheremainingtwobuttonheadscrews(J)toinstallthefrontbracketcover.
Alignthe mounting holesandtighten the screws.See Diagram 10,#2.
CAUTION:Do not overtightenthescrewsoryoumayinadvertentlycrack
theplastic covers. Damagedcovers due toimproper installation willnot
becoveredbythe Precor LimitedWarranty.
Note:You have completed the assembly of the EFX®556i.To level the unit,
continue with the steps on the next page.

page16
COMMERCIAL PRODUCTS DIVISION
CAUTION: A fully-assembled EFX is very heavy.To avoid possible in-
jury,obtain assistance.
10. Ifyou need tomove the EFX,ask someone for help. Lift the EFX from the
front and roll it into position on its rear wheels. See Diagram 11, #1.
11. Level the unit. Diagram 11, #2.To help keep the unit stable, the EFX has a
height adjuster at thefront ofthebase assembly.Checktomakesurethatthe
unit does not wobble from side to side or front to back.
To counteract any rocking motion, ask your assistant to grasp the upright
support and lift the front of the unit off the floor.
• To correct front to rear wobble, turn the height adjuster clockwise which
raises the height of the front end.
• To correct side to side wobble, turn the height adjuster counterclockwise
which lowers the height of the unit.
CAUTION:The height adjuster helps level the unit on uneven surfaces, but
cannotcompensateforextremelyuneven floors.Donotuse theheightadjuster
toraise orlower theunit morethan ¾-inches.
SUPPLYING POWER TO THE EFX®556I
The EFX does not require an electrical power connection. It has an internal battery
that is recharged every time a user works out for a reasonable period of time. A
pedalingspeedabove40stridesperminutemustbemaintainedforseveralseconds
beforethePrecorbannerappearsonthedisplay.Oncethebannerappears,theuser
canpressQUICKSTARTorENTER tobeginworkingout.Refertopage26, Exercis-
ingontheEFX ,formore information.
Diagram 11
Roll the unit on its
rear wheels.
Rear wheels
Height adjuster
2
1

page17
COMMERCIAL PRODUCTS DIVISION
Diagram 12
Test the heart rate feature.
Touch-sensitive grips
Important: A user must hold both touch-
sensitive grips to receive an accurate heart
rate reading.
Handrail
TESTING THE HEART RATE DISPLAY
Verify that the heart rate display is operationalbeforecustomers begin using the
machine.
1. Begin pedaling and maintain a stride rate above 40 strides per minute.The
Precorbanner will appear onthe display.
2. Grab both metalgrips on thehandrails, notjustthe onehandrailas shownin
Diagram12.
3. Wait five to ten seconds. A number indicating your heart rate (beats per
minute) should appear in the small upper right display.
4. Ifthe heart rate displayappears, thecablesare properlyconnectedand the
heart rate feature can be a viable part of a user’s workout.
5. If the heart rate display does not appear, press RESET to return to the
Precor banner and then, ask someone else to try steps 2 and 3.If no heart
rate number appears, you may need to disassemble the handrails or the
upright support to check that the heart rate cables are fully engaged.
Note: To conduct electrical impulses from a user’s heart, the electrode strips
(handrailgrips) mustbe incontactwith the user’s skin.Usually, theconcentration
of salts in a person’s perspiration provides enough conductivity to transmit a
signal to the receiver in the display console. However some people, because of
body chemistry or erratic heart beats cannot use the heart rate touch-sensitive
feature on the EFX. A POLAR®chest strap may provide better results. Refer to
ObtainingService on page 7.
Handlebar

page18
COMMERCIAL PRODUCTS DIVISION
Diagram 13 Display console keys used for Club Custom mode.
Note: The CHANGE keys are not shown in this diagram. Refer to Diagram 10
for their location.
Lightly touch the ▼ or ▲ key to
view the available selections. Accepts displayed
dataand moves to
next aspect of the
program.
Initiates Club Custom mode.To continue,
press the next key within ½ second.
Exits program
and returns to
banner.
These next few pages provide information that lets you customize the EFX®for
yourClub.Itisnotinformationthatyourcustomer needsto see.Thissectioncovers
thefollowinginformation abouthowto:
• determinewhich language appearson the display
• set maximum workout and pause times
• displaythe odometer and otherusefulinformation
• connect to CSAFE compatible devices
Note:Ifyour customersareinterestedin thelearningmoreabouttheEFX,youmay
wish to direct them to the user manual available on Precor’s web site
(www.precor.com).(The manualthat appears onthe website does not containthe
information found in this section.)
Club Information
CHANGING THE CLUB SETTINGS
The Club “custom” settings are accessed through specific codes that help elimi-
nateunauthorizedaccess. RefertoDiagram13 tolocatethekeys.Information that
you can access and features that can be customized are as follows:
•Language—Determinewhich languageisusedtodisplay theuserprompts.
•Units of Measure — Select between U.S.Standard and Metric displays.
•MaximumWorkoutTime — Set a maximum limit on workout time.
Note:Remember,an additionalfive-minutecool-downperiodis appendedto
a completed program, so adjust the maximum time limit accordingly.
•MaximumPauseTime —Setthemaximum duration forwhich a personcan
“pause”his or herworkout.
•Odometer,HoursofUse,SoftwareVersion,andErrorLog—TheEFXstores
the cumulative strides, the number of hours that the unit has been in use, the
software version and software type (which is valuable when calling Customer
Support),andanerrorlog(usefulwhentroubleshooting).

page19
COMMERCIAL PRODUCTS DIVISION
To access the Club settings, the following must occur:
❑Electrical power must be supplied.
The foot pedal speed must be maintained at 40 strides per minute. Or, the
optionalbatteryrecharger must be plugged into the EFX andconnected to an
appropriatepowersource.
Note:The optional battery recharger connection is highly recommended, if
you plan to customize the EFX.
❑Check that the Precor banner appears on the display and,if necessary,
maintain the minimum stride rate.
❑Press the appropriate key sequences within the allocated time.
Tochangethelanguage,selecttheunitsofmeasure and setthe maximumworkout
and pause times press the following:
RESET, ▼, ▲, ▼, RESET, ▼, ▲, ▼
Important:ToaccessClub Custom mode,pressRESETwhilethePrecorbanneris
displayed.Within ½ second, begin pressing the key sequences.If the system does
notdetecta keypress(within½ second afterRESET),it returnstothebanner.Once
youbeginenteringakeysequence, eachkey mustbe pressedwithin foursecondsof
theotherorthePrecorbannerreappearsandyouhavetobeginagain.
The functions of the display console keys while in Club Custom mode are de-
scribed in the box below.
▼▲ lets you scroll through the
various selections that appear.
ENTER saves the information being
displayedand moves to the
nextaspect of the program.
RESET exits Club Custom mode and
displaysthe Precor banner.
Display key functions within the Club Custom Mode
Note: The RESET key followed by the number keys, 5, 6, 5, 1, 5, 6, 5 may be
pressed instead of using the ▼▲ keys. But, in either case, RESET must be
pressed initially, for example: RESET, 5, 6, 5, 1, 5, 6, 5.
SELECTING THE LANGUAGE
You can select a language for the prompts that appear on the display by using
the ▼▲ keys to make your choice and pressing ENTER to select it. The EFX
supportsseveral languagessuchas,English, German, Spanish, French, Dutch,
andPortuguese.

page20
COMMERCIAL PRODUCTS DIVISION
DETERMINING THE UNITS OF MEASURE
Two different units of measure can be selected, Metric or U.S.Standard .Make your
selection using the ▼▲ keys. Press ENTER once the correct unit is displayed.
Note: Anytime you wish to exit the Club Custom mode, press the RESET key.
Any previous display attributes that you selected by pressing ENTER are saved
andrecorded inmemory.
SETTING A WORKOUT TIME LIMIT
You can limit how long a user works out by setting a duration between 1 and 240
minutes.The EFX also lets you choose “no limit” which allows the user to select a
programand workout indefinitely.(Note thatthe usermust enteraworkouttime of0
usingthe numeric keysattheENTERTIME promptbeforeworking out“indefinitely.”)
Important: If the club setting is “no limit” and the user enters “0” at the ENTER
TIME prompt, then the REMAININGTIME display does not appear when a user
works out.(An exception to this rule is theWeight Loss Program.)
Note:The QuickStart program is set at the Club limit (see page 20).
Use the ▼▲keys to select a workout time limit. For example, if you set the workout
timelimitto20minutes,theEFXallowsuserstospecifyaworkoutbetween1and20
minutes. Users would not be able to specify a time longer than 20 minutes.
Note:The touch-sensitive keys can be gently pressed and held to view several
selections.The longer the key is held down, the faster the numbers scroll past.
Important:Takeintoaccountthattheuser will get an additional five-minutecool-
downperiod appended to his or her workout,so adjust thetimelimitaccordingly.
SETTING A PAUSE TIME LIMIT
SettingapausetimelimitisusefulbecausetheEFXexitstheprogramandreturnsto
thePrecorbanneratapredetermined intervalafter theuserstopspedaling.
Usethe▼▲keystosetapausetimelimitbetween1and120seconds(twominutes).
VIEWING THE ODOMETER, HOURS OF USE, SOFTWARE
VERSION AND ERROR LOG
The display console keys that you need to press to view the odometer, the num-
berofhours the EFX has been in use, thesoftwareversion and any error codes,
are as follows:
RESET, ▲, ▼
Note:The number keys, 6 and 5, may be pressed instead of using the ▲ and ▼
keys, for example:RESET, 6, 5.Remember to begin at the Precor banner.After
pressingRESET, thenextkeyinthe sequence mustbe pressedwithin½ second.
