Precor P30 Console User instructions

Setting Up the Personal Viewing System
(PVS)
North American and Pro:Idiom Versions
Equation 1: Englis h

Edition Information
Setting Up the PVS (North American and Pro:Idiom Versions)
P/N 303835-112 rev B
Copyright © July 2016 Precor Incorporated. All rights reserved. Specifications subject to change without notice.
Trademark Note
Precor, AMT, EFX, and Preva are registered trademarks of Precor Incorporated. Other names in this document may be the
trademarks or registered trademarks of their respective owners.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Intellectual Property Notice
All rights, title, and interests in and to the software of the Preva Business Suite, the accompanying printed materials, any copies
of such software, and all data collected via the Preva Business Suite, are exclusively owned by Precor or its suppliers, as the case
may be.
Precor is widely recognized for its innovative, award-winning designs of exercise equipment. Precor aggressively seeks U.S. and
foreign patents for both the mechanical construction and the visual aspects of its product design. Any party contemplating the
use of Precor product designs is hereby forewarned that Precor considers the unauthorized appropriation of its proprietary rights
to be a very serious matter. Precor will vigorously pursue all unauthorized appropriation of its proprietary rights.
Precor Incorporated
20031 142nd Ave NE, P.O. Box 7202
Woodinville, WA 98072-4002
www.precor.com
2

Keypad Orientation
Important The information provided in this section is intended for system administrators and registered service technicians. Please do
not share it with equipment users or non-administrative staff.
Use the System Setting mode to configure equipment settings in ways that benefit your users and your facility. Changes made
to these settings are stored in the equipment, allowing them to persist after a loss of power.
Figure 1
The keys are labeled with their primary function for TV operation by the user, but have an alternate function during system
setup
Number
Key Name
Function during system setup
Channel (Up/Down) Scrolls up and down from one subcategory to another through sub-categories
located under the main headings
Volume (Up/Down) Scrolls right to left across the main categories at the top of the screen menu
Volume Down: Acts as a Back key.
TV Status Green: TV on / Red: TV off
Direct Channel Access (1-0) Selects specific channel numbers
— (Dash) Saves setting and exits menu
CC/Mute Enters a selection
Source Returns to previous menu
Power (On/Off) Turns PVS on or off
3

Main Menu Access
The Main Menu categories are:
•Channel
•Picture
•Audio
•Time
•Setup
Grayed out settings are not available.
To view the Main Menu:
1. Press Power On/Off
t
o turn on the PVS.
2. Press CC + Volume Up + Channel Down
.
Note If you do not press a button within 30 seconds (default), the PVS screen returns to the normal viewing mode.
3. Use Volume Up/Down to select a Main Menu category.
4. Use Channel Up/Down to navigate the sub menu.
5. Press CC/Mute to make a selection.
6. Press Source to return to previous menu.
7. Press Dash (-) to save setting and exit the menu.
4

View the Channel Menu Settings
This menu contains the following presets:
•Input
•Auto Scan
•Show/Hide
•Digital Strength
Input
Note Precor recommends using Auto Scan to ensure channel selection is complete.
Default: Cable + Air
Auto Scan
Auto Scan searches the selected ATV and/or DTV signals and saves the discovered channels to the current channel list.
For Pro:Idiom version: Auto Scan detects all encrypted channels and automatically adds them to the channel list. These
channels can be hidden during service set up if required by your facility.
Show/Hide
Use this setting to select which channels you want available for your users. Hidden channels are not deleted and can still
be accessed by pressing the channel number on the keypad.
For Pro:Idiom version: Use this setting to hide channels you do not want available in your facility.
To show or hide channels:
1. Use Channel Up/Down to navigate the channels in this setting.
2. Press CC to hide the channel.
This symbol Ø means that a channel is hidden.
3. Press CC again to show the channel to your users.
Digital Strength
When the PVS is tuned to a TV channel, this setting displays the digital signal strength for that channel.
5

View the Picture Menu Settings
This menu contains the following presets:
•Picture Mode
•Color Mode
•Aspect Ratio
Table 1: Picture Menu
Setting
Values
Default
Picture Mode Standard, Dynamic, Personal, Soft Standard
Color Mode Normal, Warm, Cool Normal
Aspect Ration 4:3, 16:9 Selected by PVS
Picture Mode
Use the Personal setting to adjust contrast, brightness, sharpness, tint, and color.
View the Audio Menu Settings
This menu contains the preset, Audio Language. Grayed out settings are not available.
Use this setting to select primary audio language for your user audience.
The three audio language choices are:
•English (default)
•French
•Spanish
View the Time Menu Settings
This menu contains the preset, Time Zone. Grayed out settings are not available.
Use this setting to select a time zone for your user audience.
The time zone choices are:
•Atlantic
•Eastern
•Central
•Mountain
•Pacific
•Alaska
•Hawaii
6

View the Setup Menu Settings
This menu contains the following presets:
•Menu Language
•OSD Time Out
•Closed Caption
•Restore Default
•Headphone Detect
•USB Update
•Software Version
Grayed out settings are not available.
Table 2. Picture Menu
Setting
Value
Default
Menu Language English, French, Spanish English
OSD Time Out 5, 15, 30, 45, 60 sec 30
Closed Caption Basic Off
-Basic CC1 Off, CC1, CC2, CC3, CC4, Text1, Text2, Text3, Text4 mode CC1
-Advanced Service1 Off, Service1, Service2, Service3, Service4, Service5, Service6 mode Service1
Restore Default Restores all settings to factory default settings N/A
Headphone Detect Enabled, Disabled Disabled
USB Update Use to update software (see procedure below) N/A
Software Version For example: 303751-xxx xxx N/A
USB Update
Use this setting to update software for your PVS.
Important Perform the following procedure in the order presented.
To perform a USB Update:
1. Turn on the PVS.
2. Insert the USB flash drive before entering the Setup Menu.
3. In the Setup Menu, select USB Update
.
4. Select F/W File, then press CC.
Note If USB is not properly inserted, the message, No Device, displays in the top left corner of the screen.
5. Select the USB drive, then press CC. After upload is completed (approximately 30 seconds), the TV turns off.
Important Do not turn off the TV power or remove USB flash drive during the USB update.
6. Remove the USB flash drive.
7
