Preen ADG+ Series User manual

ADG+Series
High Power Programmable DC Power Supply
User Manual
AC Power Corp. (Preen)
V 1.03.00EN
The information in this document is subject to change without notice.
Copyright 2022 AC Power Corp. (Preen). All rights reserved.

Legal Notices
The information in this product manual is subject to change without notice.
AC Power Corp. makes no warranty of any kind with regard to this user manual,
including, but not limited to, the implied warranties of merchantability and fitness
for a particular purpose. AC Power Corp. shall not be held liable for errors contained
herein or direct, indirect, special, incidental or consequential damages in connection
with the furnishing, performance, or use of this material.
Copyright Notices. Copyright 2022 AC Power Corp. (Preen), all rights reserved.
Reproduction, adaptation, or translation of this document without prior written
permission is prohibited, except as allowed under the copyright laws.

Warranty
Peen’s ADG+series High Power Programmable DC Power Supply is warranted against
defects in material and workmanship for a period of one (1) year after date of
shipment. Preen agrees to repair or replace any assembly or component found to be
defective, under normal use during this period. Peen’s obligation under this warranty
is limited solely to repairing any such product which in sole Peen’s opinion proves to
be defective within the scope of the warranty when returned to the factory or to an
authorized service center. Transportation to the factory or service center is to be
prepaid by the purchaser. Shipment should not be made without prior authorization
by Preen.
This warranty does not apply to any products repaired or altered by persons not
authorized by Preen, or not in accordance with instructions furnished by Preen. If the
product is defective as a result of misuse, improper repair, or abnormal conditions or
operations, repairs will be billed at cost.
Preen assumes no responsibility for its product being used in a hazardous or
dangerous manner either alone or in conjunction with other equipment. High voltage
used in some products may be dangerous if misused. Special disclaimers apply to
these products. Preen assumes no liability for secondary charges or consequential
damages and in any event, Peen’s liability for breach of warranty under any contract
or otherwise, shall not exceed the purchase price of the specific product shipped and
against which a claim is made.
Any recommendations made by Preen for use of its products are based upon tests
believed to be reliable, but Preen makes no warranty of the results to be obtained.
This warranty is in lieu of all other warranties, expressed or implied, and no
representative or person is authorized to represent or assume for Preen any liability
in connection with the sale of our products other than set forth herein.
AC Power Corp. (Preen)
USA
192 Technology Dr., Suite S, Irvine, CA 92618
TEL +1 949-988-7799
Taipei
3F No. 200 Gangqian Road, Neihu Dist., Taipei 114, Taiwan
TEL +886 2-2627-1899 FAX +886 2-2627-1879
www.preenpower.com

SAFETY SUMMARY
The following general safety precautions must be observed during all phases of
operation, service, and repair of this equipment. Failure to comply with these
precautions or specific WARNINGS given elsewhere in this manual will violate safety
standards of design, manufacture, and intended use of the equipment.
Preen assumes no liability for the customer‘s failure to comply with these
requirements.
1) BEFORE APPLYING POWER
Verify that the equipment is set to match with the power line input.
2) PROTECTIVE GROUNDING
Make sure to connect the equipment to the protective ground to prevent an electric
shock before turning on the power.
3) NECESSITY OF PROTECTIVE GROUNDING
Never cut off the internal or external protective grounding wire, or disconnect the
wiring of protective grounding terminal. Doing so will cause a potential shock hazard
that may bring injury to a person.
4) DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE
Do not operate the equipment in the presence of flammable gases or fumes.

`ADG+Series
2
5) DO NOT REMOVE THE COVER OF THE EQUIPMENT
Hazardous voltages may be present when the covers are removed. Component
replacement and internal adjustment can be done only by qualified service
personnel.
Warning
LETHAL VOLTAGES. The equipment can supply up to 40V-2000V at its output. DEATH
on contact may result if either the output terminals or the circuits connected to the
output are touched when the power is applied.

`ADG+Series
3
Table of Contents
1 General Information.................................1
1.1 Introduction 1
1.2 Specification 2
1.3 Exterior 8
2 Installation.............................................12
2.1 Unpacking and Check 12
2.2 User Preparation 12
2.3 Input & Output Connection 12
2.3.1 Input Connection 14
2.3.2 Input Wire Selection 15
2.3.3 Output Connection 16
2.3.4 Output Wire Selection 17
2.4 Parrellel Operation 19
2.5 Communication Interface 20
2.5.1 Analog Control 20
2.5.2 USB/RS-232&RS-485/Ethernet 22
2.6 USB Interface (for firmware update only) 23
2.7 Remote Sensing Function 24
3 Local Operation......................................26
3.1 Power-on Procedure 26
3.2 Touch Screen and Rotary Knob Operation 27

`ADG+Series
4
3.3 Main Page 30
3.3.1 Constant Voltage (CV) Mode 32
3.3.2 Constant Current (CC) Mode 33
3.3.3 Constant Power (CP) Mode 34
3.4 Function Page 35
3.5 Setting Page 36
3.5.1 System Setting 37
3.5.2 Protection Setting 44
3.5.3 Diagnosis 51
3.5.4 Advanced 52
3.6 Communication Setting 58
3.6.1 Control Mode 58
3.6.2 GPIB Interface Board (option) 59
3.6.3 Ethernet/RS-485/RS-232/USB Interface Board (option)59
3.7 Wave Page 61
3.8 Event Page 63
3.9 Information Page 64
3.10 Programmable Function 66
3.10.1 PGM Page 66
3.10.2 Memory Group Setting 69
3.10.3 STEP Loop 70
3.10.4 Example of STEP Loop 72
3.11 Multiple Machine (Multi Mach) Function 73
3.11.1 Multi Mach Settings 74
3.11.2 Multi Mach Page 77
4 Preen Program .......................................78
4.1 Installation and Startup 78
4.1.1 Installation 78

`ADG+Series
5
4.1.2 Startup 79
4.2 Preen Program: General Mode 82
4.3 Preen Program: Program Mode 82
5 MODBUS-RTU Protocol...........................85
5.1 Transmission Settings 85
5.2 MODBUS Protocol 86
5.2.1 Frame 86
5.2.2 ID Field 86
5.2.3 Function Code Field 86
5.2.4 Data Field 86
5.2.5 CRC Check Field 87
5.3 Message Format in Data Field 88
5.3.1 Frame Status Field 88
5.3.2 Byte Count Field 88
5.3.3 Start Address Field 89
5.3.4 Register Data Field 89
5.4 Transmission Example 91
5.4.1 Read Register (correct) 91
5.4.2 Read Register (error) 92
5.4.3 Write Register (correct) 93
5.4.4 Write Register (error) 94
5.5 MODBUS Address List 95
5.5.1 Read only Section 95
5.5.2 Read & Write Section 100
5.5.3 Advanced Section 105
6 Calibration ........................................... 107

`ADG+Series
6
6.1 Output Voltage Accuracy Calibration 109
6.2 Output Voltage Indicated Value and Set Value Calibration
111
6.3 Output Current Accuracy Calibration 112
6.4 Output Current Indicated Value and Set Value Calibration
115
7 Repair and Maintenance....................... 117
7.1 Emergency Troubleshooting 117
7.2 Dust Cleaning 117
7.3 Regular Maintenance 117
7.3.1 Daily Maintenance 118
7.3.2 Monthly Maintenance 119

`ADG+Series
1
1General Information
1.1 Introduction
Peen’s ADG+series is a high power programmable DC power supply with high power
density and high output power, offering great response time, high accuracy and a
wide range of output voltage/current combinations. Designed for the growing
demand of high power DC supplies, the ADG+series is ideal for testing EV-type
motor/compressor, server power supply, fuse, circuit breaker, contactor and PV
inverter.
With output power up to 100kW per unit, the ADG+series can offer output voltage
up to 1600V or output current up to 2500A. Series and parallel operations are
available, and power expansion of up to 300kW can be achieved through parallel
connection. For communication interface, the user can select the standard RS-485,
RS-232, Ethernet, USB and optional GPIB. With built-in STEP and GRADUAL features,
the ADG+series allows easy setup on test sequence. According to CV/CC/CP settings
and load conditions, the ADG+series can also operate as a current/voltage source.
The Remote Voltage Compensation is capable to reduce voltage drop caused by cable
length and provides greater installation flexibility.

`ADG+Series
2
1.2 Specification
Model
30kW
ADG-PLUS-40-750
ADG-PLUS-60-500
ADG-PLUS-100-300
ADG-PLUS-200-150
ADG-PLUS-240-125
ADG-PLUS-320-94
50kW
ADG-PLUS-40-1250
ADG-PLUS-60-834
ADG-PLUS-100-500
ADG-PLUS-200-250
ADG-PLUS-240-208
ADG-PLUS-320-156
AC Input
Voltage
3Φ3W + G 380VAC~ 400VAC ± 15%
(Option 200VAC/208VAC/415VAC/440VAC/480VAC)
Frequency
47-63Hz
Power Factor
≧90% at maximum power
DC Output
Voltage
40V
60V
100V
200V
240V
320V
Current(30kW)
750A
500A
300A
150A
125A
94A
Current(50kW)
1250A
834A
500A
250A
208A
156A
Line Regulation
≦0.05%
≦0.05%
Load
Regulation*1
≦0.1%
≦0.1%
Voltage Ripple
(RMS)
≦0.4% F.S.
≦0.1% F.S.
Voltage Noise
(Peak)
≦2% F.S.
≦2% F.S.
≦0.88% F.S.
Voltage Slew
Rate*2
≦50ms
≦60ms
≦85ms
Transient
Response*3
≦12ms
Setting & Measurement
Voltage Accuracy
0.5% F.S.
Voltage
Resolution
≦100V@ 0.01V
> 100V@0.1V
Current Accuracy
0.5% F.S. (≧1% Rating Current )
Current
Resolution
≦100A@ 0.01A, >100[email protected]
Power Accuracy
P=V*I Calculated
Power Resolution
0.01KW
General
MODE
CC/CV/CP

`ADG+Series
3
Efficiency
≧87% at maximum power for input 380V~ 400V
≧84% at maximum power for input
200VAC/208VAC/415VAC/440VAC/480VAC
≧90% at maximum power for input 380V~ 400V
≧87% at maximum power for input
200VAC/208VAC/415VAC/440VAC/480VAC
Interfaces
Ethernet/RS-232&RS-485/USB
Option : GPIB
Analog Input
Control (V & I )
0-5V, Accuracy: 1% F.S. (at output rated voltage & current ≧5%)
Analog Output
Monitor (V & I )
0-5V, Accuracy : 5% F.S.
Remote Sense
Limits
5% maximum voltage drop from product output to load
3% maximum voltage drop from product output to load
Protections
Input : Vin OV、Vin Unbalance
Output : OVP、OCP、OPP、OTP, LDC OV, Module OCP, Interlock open
OVP Range
0 - 110% F.S.
OCP Range
0 - 110% F.S.
OPP Range
0 - 110% F.S.
Operational
Temperature
0°C-40°C
Storage
Temperature
-20°C-70°C
Humidity
0-90%(Non condensing)
Isolation
Input to Enclosure : 1500VAC
Input to Output : 2000VDC
Output to Enclosure : 2000VDC
Dimension
(H×W×D)
1038×600×800 mm (including wheel)
200VAC/208VAC/415VAC/440VAC/480VAC Input: 1382×600×800 mm (including wheels`)
Weight*5
approx. 225kg/496.1lbs
approx. 190kg/418.8lbs
200VAC/208VAC/415VAC/440VAC/480VAC Input:
approx. 420kg/925.9lbs
200VAC/208VAC/415VAC/440VAC/480VAC Input: approx. 390kg/859.8lbs
*1. Load changes from 5% to 100% under nominal AC input
*2. Measured from 10% to 90% of the output voltage change - resistive load, typical
*3. Under nominal AC input, recovers to ±1% of full-scale output voltage for a 50% to 100% or 100% to 50% load change.
*4. The spe
cifications are tested at ambient temperature at 25°C ± 5 °C.
*5. Weight tolerance is within ± 10 kg
*Above specifications are under output voltage over 1% F.S.
** All specifications are subject to change without notice.
ications are subject to change without notice.

`ADG+Series
4
Model
30kW
ADG-PLUS-400-75
ADG-PLUS-500-60
ADG-PLUS-640-47
ADG-PLUS-800-38
ADG-PLUS-1000-30
ADG-PLUS-1600-18
50kW
ADG-PLUS-400-125
ADG-PLUS-500-100
ADG-PLUS-640-78
ADG-PLUS-800-63
ADG-PLUS-1000-50
ADG-PLUS-1600-31
AC Input
Voltage
3Φ3W + G 380VAC~ 400VAC ± 15%
(Option 200VAC/208VAC/415VAC/440VAC/480VAC)
Frequency
47-63Hz
Power Factor
≧90% at maximum power
DC Output
Voltage
400V
500V
640V
800V
1000V
1600V
Current(30kW)
75A
60A
47A
38A
30A
18A
Current(50kW)
125A
100A
78A
63A
50A
31A
Line Regulation
≦0.05%
Load
Regulation*1
≦0.1%
≦0.034%
≦0.02%
≦0.05%
Voltage Ripple
(RMS)
≦0.1% F.S.
≦0.05% F.S.
Voltage Noise
(Peak)
≦0.88% F.S.
≦1.34% F.S.
≦0.88% F.S.
≦0.2% F.S.
≦0.2% F.S.
≦0.4% F.S.
Voltage Slew
Rate*2
≦100ms
≦100ms
≦100ms
≦115ms
≦120ms
≦120ms
Transient
Response*3
≦12ms
Setting & Measurement
Voltage Accuracy
0.1% F.S
Voltage
Resolution
≦100V@ 0.01V
> 100V@0.1V
Current Accuracy
0.5% F.S. (≧1% Rating Current )
Current
Resolution
≦100A@ 0.01A, >100[email protected]
Power Accuracy
P=V*I Calculated
Power Resolution
0.01KW
General
MODE
CC/CV/CP

`ADG+Series
5
Efficiency
≧90% at maximum power for input 380V~ 400V
≧87% at maximum power for input 200VAC/208VAC/415VAC/440VAC/480VAC
Interfaces
Ethernet/RS-232&RS-485/USB
Option : GPIB
Analog Input
Control (V & I )
0-5V, Accuracy: 1% F.S. (at output rated voltage & current ≧5%)
Analog Output
Monitor (V & I )
0-5V, Accuracy : 5%F.S.
Remote Sense
Limits
3% maximum voltage drop from product output to load
2% maximum voltage drop from product output to load
Protections
Input : Vin OV、Vin Unbalance
Output : OVP、OCP、OPP、OTP, LDC OV, Module OCP, Interlock open
OVP Range
0 - 110% F.S.
OCP Range
0 - 110% F.S.
OPP Range
0 - 110% F.S.
Operational
Temperature
0°C-40°C
Storage
Temperature
-20°C-70°C
Humidity
0-90%(Non condensing)
Isolation
Input to Enclosure : 1500VAC
Input to Output : 2000VDC
Output to Enclosure : 2000VDC
Dimension
(H×W×D)
1038×600×800 mm (including wheel)
200VAC/208VAC/415VAC/440VAC/480VAC Input: 1382×600×800 mm (including wheel)
Weight *5.
approx. 190kg/418.8lbs
200VAC/208VAC/415VAC/440VAC/480VAC Input: approx. 390kg/859.8lbs
*1. Load changes from 5% to 100% under nominal AC input
*2. Measured from 10% to 90% of the output voltage change - resistive load, typical
*3. Under nominal AC input, recovers to ±1% of full-scale output voltage for a 50% to 100% or 100% to 50% load change.
*4. The specifications are tested at ambient temperature at 25°C ± 5 °C.
*5. Weight tolerance is within ± 10 kg
*Above specifications are under output voltage over 1% F.S.
** All specifications are subject to change without notice.
ications are subject to change without notice.

`ADG+Series
6
Model
75kW
ADG-PLUS-40-1875
ADG-PLUS-60-1250
ADG-PLUS-100-750
ADG-PLUS-320-234
ADG-PLUS-640-117
ADG-PLUS-1000-75
100kW
ADG-PLUS-40-2500
ADG-PLUS-60-1666
ADG-PLUS-100-1000
ADG-PLUS-320-312
ADG-PLUS-640-156
ADG-PLUS-1000-100
AC Input
Voltage
3Φ3W + G 380VAC~ 400VAC ± 15%
(Option 200VAC/208VAC/415VAC/440VAC/480VAC)
Frequency
47-63Hz
Power Factor
≧90% at maximum power
DC Output
Voltage
40V
60V
100V
320V
640V
1000V
Current(75kW)
1875A
1250A
750A
234A
117A
75A
Current(100kW)
2500A
1666A
1000A
312A
156A
100A
Line Regulation
≦0.05%
Load Regulation*1
≦0.1%
≦0.1%
≦0.1%
≦0.05%
≦0.05%
≦0.05%
Voltage Ripple
(RMS)
≦0.5% F.S.
≦0.5% F.S.
≦0.4% F.S.
≦0.1% F.S.
≦0.1% F.S.
Voltage Noise
(Peak)
≦2.5% F.S.
≦0.65% F.S.
≦0.35% F.S.
≦0.3% F.S.
Voltage Slew
Rate*2
≦50ms
≦90ms
≦120ms
≦120ms
Transient
Response*3
≦20ms
Setting & Measurement
Voltage Accuracy
0.5% F.S
0.1% F.S
Voltage
Resolution
≦100V@ 0.01V
> 100V@0.1V
Current Accuracy
0.5% F.S. (≧1% Rating Current )
Current
Resolution
≦100A@ 0.01A
> 100A@0.1A
Power Accuracy
P=V*I Calculated
Power Resolution
0.01KW
General
MODE
CC/CV/CP

`ADG+Series
7
Efficiency
≧87% at maximum power for input 380V~ 400V
≧84% at maximum power for input
200VAC/208VAC/415VAC/440VAC/480VAC
≧90% at maximum power for input 380V~ 400V
≧87% at maximum power for input
200VAC/208VAC/415VAC/440VAC/480VAC
Interfaces
Ethernet/RS-232&RS-485/USB
Option : GPIB
Analog Input
Control (V & I )
0-5V, Accuracy: 1%F.S. (at output rated voltage & current ≧5%)
Analog Output
Monitor (V & I )
0-5V, Accuracy : 5%F.S.
Remote Sense
Limits
5% maximum voltage drop from product output to load
3% maximum voltage drop
from product output to load
2% maximum voltage drop from
product output to load
Protections
Input : Vin OV、Vin Unbalance
Output : OVP、OCP、OPP、OTP, LDC OV, Module OCP, Interlock open
OVP Range
0 - 110% F.S.
OCP Range
0 - 110% F.S.
OPP Range
0 - 110% F.S.
Operational
Temperature
0°C-40°C
Storage
Temperature
-20°C-70°C
Humidity
0-90%(Non condensing)
Isolation
Input to Enclosure : 1500VAC
Input to Output : 2000VDC
Output to Enclosure : 2000VDC
Dimension
(H×W×D)
1492×600×800 mm (Including Wheel)
200VAC/208VAC/415VAC/440VAC/480VAC Input: 1837×600×800 mm (Including Wheel)
Weight*5.
approx. 345kg/760.6lbs
200VAC/208VAC/415VAC/440VAC/480VAC Input: approx.
625kg/1377.9lbs
approx. 300kg/661.3lbs
200VAC/208VAC/415VAC/440VAC/480VAC Input: approx.
574kg/1265.4lbs
Table 1.1 Technical Specifications
*1. Load changes from 5% to 100% under nominal AC input
*2. Measured from 10% to 90% of the output voltage change - resistive load, typical
*3. Under nominal AC input, recovers to ±1% of full-scale output voltage for a 50% to 100% or 100% to 50% load change.
*4. The specifications are tested at ambient temperature at 25°C ± 5 °C.
*5. Weight tolerance is within ± 10 kg
*Above specifications are under output voltage over 1% F.S.
** All specifications are subject to change without notice.
ications are subject to change without notice.

`ADG+Series
8
1.3 Exterior
Product exterior of the ADG+series —input voltage 380V with power level
30kW/50kW and 75kW/100kW are given as follows.
Front-side and back-side view, 380V, 30kW/50kW
Right-side and axis-side view, 380V, 30kW/50kW
Figure 1.1 Product exterior of input voltage 380V with power level 30kW/50kW
models

`ADG+Series
9
Front-side and back-side view, 380V, 75kW/100kW
Right-side and axis-side view, 380V, 75kW/100kW
Figure 1.2 Product exterior of input voltage 380V with power level 75kW/100kW
models

`ADG+Series
10
Product exterior of the ADG+series —input voltage 200V/208V/480V with power
level 30kW/50kW and 75kW/100kW are given as follows.
Front-side and back-side view, 200V/208V/480V, 30kW/50kW
Right-side and axis-side view, 200V/208V/480V, 30kW/50kW
Figure 1.3 Product exterior of input voltage 200V/208V/480V with power level
30kW/50kW models

`ADG+Series
11
Front-side, back-side and right-side view, 200V/208V/480V, 75kW/100kW
Figure 1.4 Product exterior of input voltage 200V/208V/480V with power level
75kW/100kW models
This manual suits for next models
12
Table of contents
Other Preen Power Supply manuals
Popular Power Supply manuals by other brands

Automationdirect.com
Automationdirect.com Productivity 2000 P2-01AC manual

EPS
EPS PSI 9040-170 3U operating guide

Amico
Amico PSF16 installation guide

Puls
Puls ML100.105 installation manual

EXAIR
EXAIR 7901 Installation & maintenance

Manson Engineering Industrial
Manson Engineering Industrial KPS-6000 Series user manual
