Premium PPA1207 User manual

Modelo/Model:PPA1207
Aire Acondicionado
Air Conditioner
HIGH
MID
LOW

Table of contents
1.Products specification
2.Operating instruction
3.Disassembly and reassembly
4.Malfunction diagnosis
5.Components and disassembly diagram
6.Brief structure diagram
7.PCB principle diagram
8.Wiring diagram

1.Products specification
1

2. Operating instruction
2

3

4

5

6

7

8

9

3.Disassenbly and reassembly
Before maintenance, switch off air conditioner and draw out the pin from power supply socket.
3-1 disassembly process
No
Components
Process
Remark
1
2
3
Front panel assembly
Back panel
1)similarly,using screwdriver loosen
bolts in front panel assembly and take
off front panel (2 bolts at upper,middle and
bottom respectively)
1loosen bolts on the back panel and take
them off.
5
Components of
top cover board
loosen two bolts around the top cover board with
"+" shape screwdriver and take it off..
10

No
Components
Process
Remark
4
5
Filter
1 pinch the protruding section of filter by thumb,forefinger
and middle finger to draw it out to take it out, and then rotate
the unit 90 .
6
Electric bracket assembly
1 loosen bolts of fixed frame for electric bracket
and take out the bolts.
2)loosen the wire binder tying connection wire
3)pull out compressor connection wire from fan
capacitor and main controller.
4 pull out the compressor connection wire from compressor
capacitor and main controller.
5)pull out zero wire and live wire from main controller.
6)pull out synchronous motor connection line from main controller
7)get the synchronous motor connection line, water level line,
ambient temperature sensor line and evaporator temperature
control prove line through the hole and take out the electrical
bracket plate, and then rotate the unit 90 .
11

No
Components
Process
Remark
6
7
8
Air out-let vent assembly
Upper hodmadod shell B
1 loosen three bolts at both ends of synchronous motor
and take out the air out-let vent assembly.
1)loosen four bolts fixing upper hodmadod shell B(2 bolts at
evaporator side, 2 at outside) and take them out
7
Upper centrifugal fan
1 find the through hole position at middle of upper
centrifugal fan and rotate it into the position arrow indicating.
2 get through the hole on the direction of arrow by
screwdriver and loosen screw, and then take out screwdriver.
3 holding upper section of fan by hands and rotate slightly the
fan with force and lift it up at thesame time, and then take out the fan.
12

No
Components
Process
Remark
9
10
Upper hodmadod shell B
1)loosen three bolts arrow indicating in diagram by screwdriver
Upper hodmadod
shellA
8
1)loosen bolts fixing upper hodmadod shell Band take them out
13

No
Components
Process
Remark
13
12
Evaporator assembly
1 cut liquid feeder process pipe with clamp force(at the position
of hollow arrow indicating) and let refrigerant went out.
2 dismantle evaporator assembly and capillary
assembly by welding(at the position of arrow indicating)
Discharge pipe assembly
air return assembly
16
1 open compressor electrical cover and draw out connection line
and heat protector, and then loosen compressor earthing line from bracket.
2 dismantle compressor discharge pipe and air return pipe
by welding (at the position of arrow indicating)
1)loosen three bolts fixing footing of compressor
and take out washer, and then draw out compressor.
Compressor assembly
14

No
Components
Process
Remark
10
18
Condenser assembly
1 loosen bolts at bottom of condenser (at position
of arrow indicating) and take them out.
15

4.Malfunction diagnosis
1.Input voltage must be in the range of ofr ating voltage ifw ork voltageo fa irc onditioneri so utsideo ft hisr ange airc onditionerw ill
possibly notr un Enough powers upply capacity mustb ep rovided
2.Make sure the good connection between power supply plug and power supply, otherwise air conditioner will not run normally.
10% , ,
normally. ( )
4-1 Items to be checked at first
3. The phenomenon listed in below table occurred, which are not caused by air conditioner failure
No
1
2
3
4
5
6
Phenomenon
Description
While the power supply pin plug into socket at first time and
sound"tick" is heard, but air conditioner does not run.
While power supply pin plug into socket ,the indicator
lamp of "water full" flickering continuously on display
panel and "tick"sounding continuously, pressing
"ON/OFF" but air conditioner does not run and fan runs only.
Timer is in timing status and air conditioner is in standby status; if cancel timing
operation, air conditioner will recover to normal status.
Under dehumidifying mode, air conditioner will control compressor work
status automatically according to indoor air temperature
under cooling or dehumidifying mode, while
air conditioner switches off and immediately switches
on, only fan runs but compressor does not run
While air conditioner switches off and switches on soon, and air conditioner provides
a three-minute delay protection function; three minutes later, compressor will
restart to run.
Which indicates air conditioner is energized, as long as press "ON/OFF"
on display panel or on remote controller, and the signal is received by
air conditioner, which means entering setting operation..
Water tank is not put into original position, or water tank is placed
improperly, which results in inner slight-moving switch in
disconnection status and air conditioner can not work
Presetting LED lamp lights on but air conditioner does not run
under dehumidifying mode, compressor does not run
continuously
Under cooling mode, while setting temperature above
room temperature, compressor does not run
Setting temperature means a temperature point of ambient temperature decreases upto by way of
operation of air conditioner under cooling. While the setting temperature decreases
below room temperature, compressor will run.
16

1.Items to be checked
1 Whether input voltage is right or not
2 Whether the connection ofAC power supply is right or not
3 Whether the output voltage of manostat isr ighto rn ot
2.Flow chart of malfunction diagnosis
7805(IC1)
4-2 Guide to malfunction diagnosis
4-2-1 No power supply (completely no work)-preliminary diagnosis
Check transformer whether is intact or not
Check DC voltage on PCB board
whether is intact or not
Check condition of power supply
line and condition end check fuse
Replace Ic2
Check PCB board
replace main PCB board
check connection status of compressor,
synchronous motor and fan motor
YES
NO
YES
NO
NO
Replace PCB
NO
YES
YES
Draw out power supply plug and about
five seconds later insert again
Whether buzzer sounds or not
Whether the indicator lamp LED and digital tube
light on or not
Whether is there signal transmittal indication
on remote controller or not
After press "ON/OFF" on remote controller,
whether air conditioner runs or not?
Normal
Refer to misfunction diagnosis
of remote controller
Whether the preliminary voltage applied
on transformer is normal or not
Whether the voltage of compressor, synchronous
motor and fan motor are normal or not
Whether Ic2 output voltage is normal or not
YES
YES
NO
YES NO
YES
YES
NO
17
